Instruction Manual
Important - Please read these instructions fully before starting assembly
These instructions contain important information that will help you get the best from
your mower, ensuring it is assembled correctly and safely.
If you need help or have damaged or missing parts, call the Customer Helpline
on 0845 077 8888.
Qualcast
18V Lithium-Ion Cordless Hedge Trimmer
Aug 2012
UK/Ireland 0845 077 8888
Republic of Ireland 0124 77708
Web www.homebasespares.co.uk
After Sales Support
Page 2
Contents
2
Customer Helpline 0845 077 8888
Safety Information .......................................................................................................................................... 3
Warnings Symbols .......................................................................................................................................3
General Safety ..............................................................................................................................................4
Personal Safety ............................................................................................................................................6
Unpacking ....................................................................................................................................................6
In the Box .........................................................................................................................................................7
Parts ..............................................................................................................................................................7
Assembly ..........................................................................................................................................................8
Front Handle Assembly ...............................................................................................................................8
Operating Instructions & Tips .........................................................................................................................9
Battery Location ...........................................................................................................................................9
Installing Battery In Charger......................................................................................................................10
Safety Features ..........................................................................................................................................11
Starting and Stopping................................................................................................................................11
Shaping .......................................................................................................................................................12
Cutting ........................................................................................................................................................13
Pruning .......................................................................................................................................................14
Lubrication..................................................................................................................................................14
General Inspection .....................................................................................................................................14
Maintenance ...................................................................................................................................................14
Troubleshooting .............................................................................................................................................15
General Troubleshooting ...........................................................................................................................15
Technical Data ................................................................................................................................................15
Technical Data Table ..................................................................................................................................15
Disposal ..........................................................................................................................................................16
Disposal and Recycling .............................................................................................................................16
Getting Help ...................................................................................................................................................16
Page 3
Important - Please read these instructions fully before starting assembly
3
Customer Helpline 0845 077 8888
The following warning symbols appear throughout this instruction manual and indicate the appropriate
safety measures you should take when assembling and operating the hedge trimmer.
Take extra care, beware of hazards.
Read instruction manual.
Warning - To reduce the risk of injury, user must read instruction manual.
Wear eye and ear protection.
Wear glove during operation.
Wear protective shoes during operation.
Do not use the machine in the rain or leave it outdoors when it is raining.
Keep hands and feet away.
Pay attention that bystanders are not injured by objects thrown out from the machine.
Keep bystanders a safe distance away from the machine.
Noise level specication Lwa in dB.
Do not dispose of electrical equipment in domestic waste.
Warnings Symbols
Safety Information
Page 4
Important - Please read these instructions fully before starting assembly
4
Customer Helpline 0845 077 8888
IMPORTANT! All operators must read these instructions before use.
WARNING! Read all safety warnings and all instructions. Failure to follow all warnings, and instructions may
result in electric shock, re or serious injury.
Save all warnings and instructions for future reference
To use this tool properly, you must observe all safety warnings, assembly, operating and maintenance
instructions in this manual. Always follow regulations regarding use in the area the tool is being used. Do
not allow children, or a person physically incapable to operate the tool.
Always be aware, and take precautions against, potential hazards during use and maintenance of the tool.
These include, but are not limited to, the following:
• Contact with the blade.
• Kickback.
• Blade fracture.
• Projection of particles.
• Damage to eyes if eective safety glasses or protective shields are not worn.
• Damage to ears if eective ear defenders are not worn.
WARNING!
When using power tools, basic safety precautions should always be taken to reduce the risk of re, electric
shock, and personal injury. Always follow the safety instructions in this manual.
• Keep the work area clear of potentially dangerous materials that might cause a hazard.
• Consider the environment in which you are working. Do not use power tools in damp or wet locations.
Keep the work area well lit. Do not expose power tools to rain and high humidity. Do not use power
tools in the presence of ammable liquids or gases.
• Keep visitors away from the work area. All visitors and onlookers, especially children and inrm
persons should be kept well away from where you are working. Do not let others in the vicinity make
contact with the tool.
• Store tools safely. When not in use, tools should be stored in a dry, high place or locked up out of
reach.
• Do not force the tool. The tool will do the job better and operate more safely at the rate for which it
was designed.
• Use the correct tool for the job. Do not force small tools or attachments to do the job best handled by
a heavier duty tool. Never use a tool for a purpose other than that for which it was intended.
• Dress correctly. Do not wear loose clothing or jewelry. They can be caught in moving parts. Rubber
gloves and non-slip footwear are recommended when working outdoors. If you have long hair, wear a
protective hair covering.
General Safety
Safety Information
Page 5
Important - Please read these instructions fully before starting assembly
5
Customer Helpline 0845 077 8888
• Use safety accessories. Safety glasses and ear mus should always be worn.
• Do not overreach. Keep your footing secure and balanced at all times.
• Look after your tools. Keep tools clean and sharp for better and safer performance. Follow the
instructions regarding lubrication and accessory changes. Keep tool handles dry, clean and free from
oil and grease.
• Disable idle tools. Remove the battery from the tool before servicing and when the tool is not in use.
• Avoid unintentional starting. Make sure that the switches are in the OFF position before attaching the battery.
• Stay alert. Watch what you are doing. Use common sense. Do not operate a power tool when you are tired.
• Check for damaged parts. Before using a tool, check that there are no damaged parts. If a part is
slightly damaged, carefully determine it will operate properly and perform its intended function.
Check for alignment of moving parts, binding of moving parts, breakage of parts, proper mounting
and any other conditions that may aect the operation of the tool. A guard or other part that is
damaged should be properly repaired or replaced by an authorized service facility, unless otherwise
indicated in this manual. Defective switches must be replaced by an authorised service facility. Do not
use a tool if the switch does not turn the tool ON and OFF correctly.
• Do not charge appliance in rain, or in wet locations
• Do not use battery operated appliance in rain
• Remove or disconnect battery before servicing, cleaning or removing material from the gardening
appliance.
• Use only the battery recommended by manufacturer.
• Do not dispose of the battery(ies) in a re. The cell may explode. Check with local requirements for
possible special disposal instructions.
• Do not open or mutilate the battery(ies). Released electrolyte is corrosive and may cause damage to
the eyes or skin. It may be toxic if swallowed.
• Exercise care in handling batteries in order not to short the battery with conducting materials such as
rings, bracelets, and keys. The battery or conductor may overheat and cause burns.
• Be careful of the cords or cables hidden in the hedge or bush.
• Guard against electric shock. Prevent body contact with grounded objects such as water pipes.
• Always replace damaged parts with approved, identical parts. Use an authorised service facility to t
replacement parts.
• Do not let the tool run unattended. Always wait until the tool has come to a complete stop before
leaving it or removing the battery.
WARNING! The use of an accessory or attachment, other than those recommended in this manual, may
present a risk of personal injury.
The tool must be used only for its prescribed purpose. Any use other than those mentioned in this manual
will be considered a case of misuse. The user and not the manufacturer shall be liable for any damage or
injury resulting from such cases of misuse.
General Safety (continued)
Safety Information
Page 6
Important - Please read these instructions fully before starting assembly
6
Customer Helpline 0845 077 8888
• Do not use the trimmer in the rain.
• Keep hands and ngers well away from the blade.
• Wear work gloves, eye protection, solid shoes and trousers when using this hedge trimmer.
• Always grasp both handles when operating the unit.
• Remove the battery when you have nished work before cleaning or if you have been interrupted.
• This trimmer has been designed to cut soft, new growth and should not be used on tough branches
hard wood or other material.
• Always turn the tool OFF and remove the battery before attempting to x a jammed blade.
• If you are interrupted when operating the trimmer, complete the process and switch OFF before
looking up.
• Never allow untrained users or children to use the trimmer.
• Wear goggles. Wear hearing protection.
Due to modern mass production techniques, it is unlikely that your power tool is faulty or that a part is
missing. If you nd anything wrong, do not operate the tool until the parts have been replaced or the fault
has been rectied. Failure to do so could result in serious personal injury.
Personal Safety
Unpacking
Safety Information
Page 7
7
Customer Helpline 0845 077 8888
It is important to know the features and safety requirements of the trimmer. The trimmer should only be
used to trim soft, new growth. Do not use of the trimmer for purposes or applications it is not intended for.
1
Rear handle
2
Trigger switch
3
Front switch bar
4
Front handle
5
Safety guard
6
Cutting blade
7
Battery pack release
latch
8
Battery
9
Battery charger
10 Blade sheath
In the Box
Parts
1
789
10
234
56
1
Page 8
8
Customer Helpline 0845 077 8888
Front Handle Assembly
Assembly
2a. The front handle needs to be assembled to the main body. Position it as illustrated
2b. Insert the bolt into the right hand side and tighten.
2c. Once assembled check that this bolt is tight on a regular basis.
2a
2c
2b
Page 9
9
Customer Helpline 0845 077 8888
Battery Location
Operating Instructions & Tips
The battery pack for this tool has been shipped in a low charge condition. You should charge the battery
pack fully before use.
• Press the battery pack release latch
• Pull the battery out from its location below the handle.
• Connect the battery into the charger until fully charged (see below)
• Slide the battery into its location below the handle. Ensure it is fully inserted.
WARNING! Do not use an extension cord.
WARNING! Charge indoors only.
WARNING! Do not throw used batteries into a re or water: it could cause an explosion! Please hand in
non-working or used batteries, or tools with built-in batteries, to the environmentally safe disposal unit at a
municipal waste-disposal center, or to your dealer.
3 4
Page 10
10
Customer Helpline 0845 077 8888
Installing Battery In Charger
Operating Instructions & Tips
5
Note!
• Connect the plug of charger with battery (g 5).
• The red indicator light will come ON when the charger is connected to the mains supply.
• The red light stays on when the battery is charging.
• The green lights stays on continuously when the battery is fully charged. It can be removed and used
immediately.
Note!
• A new battery or one that is completely run down should be charged for 6 hours (for rst charge).
After normal use, a battery should be fully charged in 3-5 hours.
• It is normal for the battery charger to hum and be warm to the touch during operation.
• If the battery does not charge properly, check to make sure the electrical outlet is “live” and that the air
surrounding the battery and charger is between 10ºC (50ºF) and 40ºC (105º F).
• Unplug the charger when not in use and store it in a dry, secure place.
• Always remove the battery pack and store it in a dry, secure place when the trimmer is not in use.
• Battery charging should only be carried out indoors.
WARNING! Never leave a battery on charge if it becomes hot or the red light stays on.
Page 11
11
Customer Helpline 0845 077 8888
Operating Instructions & Tips
• The xed blade teeth have extended points with rounded ends to reduce the chance of injury in case
of accidental contact.
• The xed blade is longer than the moving blade to guard against kickback should you inadvertently
make contact with a wall or fence.
• The rear handle trigger switch and front handle bar switch must be operated together to start the
motor. This ensures that both hands are used to control the trimmer.
• If either of the two switches is released, the tool is designed to stop rapidly.
Before starting your hedge trimmer remove the blade sheath.
• To switch on, press both the trigger switch 2 and the bar switch 3 at the same time.
• To switch OFF, release either switch.
Safety Features
Starting and Stopping
6
2 3
Page 12
12
Customer Helpline 0845 077 8888
• Trim a hedge so that it is wider at the bottom than the top. This improves penetration of light and
promotes healthy growth.
• Taper the hedge approximately 4 inches (100 mm) for every 40 inches (1 metre) in height. A bush can
be round, or a column shape.
Shaping
Operating Instructions & Tips
7
Page 13
13
Customer Helpline 0845 077 8888
Cutting
Operating Instructions & Tips
• Assume a secure position, using two hands to hold the trimmer and switch on.
• Trim both sides of the hedge, starting at the bottom. This prevents cuttings falling into the area yet to
be cut.
• Pass the blade lightly through the surface of the hedge. Do not attempt to cut too deep.
• Trim the top of the hedge.
• For older hedges that require cutting back substantially, use pruning shears to cut the thicker
branches and then nish the job with the hedge trimmer.
WARNING! Do not let the blade come into contact with fencing wire or any other object that could
damage it.
8 9
Page 14
14
Customer Helpline 0845 077 8888
Pruning
Lubrication
General Inspection
Operating Instructions & Tips
Your hedge trimmer is versatile. It can also be used for frequently pruning new growth on a wide variety
of shrubs and hedges in your garden to encourage even growth and attractive shapes.
WARNING! Switch o and remove the battery before carrying out any maintenance on the tool.
After each use, clean the blades and lightly lubricate with general purpose oil or spray lubricant.
Regularly check that all the xing screws are tight. They may vibrate loose over time.
Maintenance
Maintenance
• Store the tool, instruction manual and accessories in a secure, dry place. In this way you will always
have all the information and parts ready on hand.
• Keep the tool’s air vents unclogged and clean at all times.
• Remove dust and dirt regularly. Cleaning is best done with compressed air or a rag.
• Never use caustic agents to clean plastic parts.
CAUTION! Do not use cleaning agents to clean the plastic parts of the tool. A mild detergent on a damp
cloth is recommended. Water must never come into contact with the tool.
Page 15
15
Customer Helpline 0845 077 8888
General Troubleshooting
Troubleshooting
The following table provides solutions to common problems encountered with the hedge trimmer.
Fault Possible Cause Solution
Product does not start Battery pack not properly
inserted
Insert properly
Battery pack discharged Remove and charge battery
pack
Battery pack damaged Check by a specialist electrician
Other electrical defect Check by a specialist electrician
Product does not reach full
power
Battery pack capacity too low Charge battery pack
Air vents are blocked Clean the air vents
Unsatisfactory result Cutting device worn Have it replaced by a specialist
Cutting device not suitable for
material being cut.
Use suitable cutting device
Technical Data Table
Technical Data
Specification Value
Battery Power 18V 1.5Ah
Rated no-load speed 1200min
-1
Max cutting diameter 14.4mm
Blade length 51cm/20 inches
Battery pack 1X 18V/1.5Ah Li-ion
Charger input 230V~240V a.c. 50Hz 17W
Charger output 23V d.c. 400mA
Battery full charge time 3-5 hr approx.
Page 16
16
Customer Helpline 0845 077 8888
Disposal and Recycling
Getting Help
Disposal
Do not dispose with household waste.
Recycle products and components according to local legal requirements.
After sales helpline number: 0845 077 8888
Spare parts purchases: www.homebasespares.co.uk
Loading...
