Quadrone Maximus Instruction Manual

Instruction Manual

Notice

• All instructions, warranties and other collateral documents are subject
to change at the sole discretion of our company.

Introduction

Table of Contents

• Thank you for choosing Quadrone! This is a four-axis aircraft that can
fly outdoors, in order to make it easier to control the aircraft. Please
carefully read this manual before operating your Quadrone. Please
keep this manual for future reference.

• Before your first flight, please take the time to carefully read this
manual containing important flight information which will help your first
flight go more smoothly.

Introduction 1
Table of Contents 1
Notice 1
Warning 2
Additional Warnings and Precautions 2
Safety Notes 2
Included 3
Quadrone Diagram 4
Remote Controller Diagram 4
Remote Controller Battery Installation 4
Charging Your Drone 5
Assembling the Drone 5
Installing the Camera 5
Syncing the Quad and Remote 6
Flight Controls 6
Practice Tips 8
Trimming the Quad 8
Flips and Rolls 9
Photo/Video 9
Speed Selection 10
Headless Mode 10
One Key Return 10
Changing the Blades 11
Troubleshooting 12
Safety Guidelines 13
Limited 90-Day Warranty 14

1

Warnings

Safety Notes

Additional Warnings and Precautions

• If this is your first time flying a quadcopter read the manual carefully.
Seek the help of an experienced pilot to help you fly. These safety
instructions are intended not only for the protection of your Quadrone
but also to protect your own safety. Improper operation can cause
injury or property damage.

• This product is suitable for indoor and outdoor use. Please make sure
you choose a flight area with no obstacles and maintain a safe
distance from people and pets. Do not operate near power lines.

• Read the ENTIRE instruction manual to become familiar with the
features of the product before operating. Failure to operate the
product correctly can result in damage to the product, personal
property or cause serious injury. This is a sophisticated hobby
product. It must be operated with caution and common sense, and
requires some basic mechanical ability. Failure to operate this product
in a safe and responsible manner could result in injury or damage to
the product or property. This product is not intended for use by
children without direct adult supervision. This manual contains
instructions for safety, operation and maintenance. It is essential to
read and follow all the instructions and warnings in this manual, prior
to assembly, set up or use, in order to operate correctly and avoid
damage or serious injury.

1. Age Recommendation: Not for children under 14 years of age. This is
not a toy.

2. Always operate in open spaces away from obstacles, people, and
hazards.

3. Always follow directions and warnings for this and any optional
equipment carefully. (chargers, rechargeable battery packs, etc)

4. Always keep small parts and electrical parts out of the reach of
children.

5. Always avoid water exposure to all equipment not specifically
designed and protected for this purpose. Moisture can cause damage
to electronics.

6. Never place any portion of the model in your mouth as it could cause
serious injury or even death.

7. Never operate your model with low batteries.

• RC models are composed of many precise electrical components. It is
important to keep the model and associated equipment away from
moisture and other contaminants. The introduction of exposure to
water or moisture in any form can cause the model to malfunction
or crash. Do not operate or expose to rain or moisture.

• To avoid a potential fire hazard from batteries, do not short, reverse
polarity, or puncture batteries. Battery charging should be done under
adult supervision at all times, at a location out of reach of children. Do
not mix Ni-Cad and Alkaline batteries.

• Make sure the batteries are installed correctly to ensure correct
polarity. If you do not plan to use your Quadrone for an extended
period of time, remove the batteries from the controller to avoid
battery leakage which may damage the controller. Please dispose
depleted batteries according to local laws and ordinances.

• Li-Polymer batteries have higher operational risks compared to other
batteries. It is imperative to follow proper operational guidelines. The
manufacturer and dealer assume no liability for accidental damages
caused by improper usage. Do not use any other charger other than
the supplied charger included in this packaging in order to avoid
potential fire or explosion. Do not crush, disassemble, burn,
or reverse polarity.

• RC models are made from various forms of plastic very susceptible to
damage or deformation due to extreme heat and cold temperatures.
Make sure not to store the model near any heat source or
adverse temperatures.

2

Crash Guards X4

Extra Blade A X2
Extra Blade B X2

USB Charger X1

Battery X1

Quadrone Maximus X1 Remote Control X1

Camera X1

Included

• RC models are composed of many precise electrical components. It is
important to keep the model and associated equipment away from
moisture and other contaminants. The introduction of exposure to
water or moisture in any form can cause the model to malfunction
or crash. Do not operate or expose to rain or moisture.

• To avoid a potential fire hazard from batteries, do not short, reverse
polarity, or puncture batteries. Battery charging should be done under
adult supervision at all times, at a location out of reach of children. Do
not mix Ni-Cad and Alkaline batteries.

• Make sure the batteries are installed correctly to ensure correct
polarity. If you do not plan to use your Quadrone for an extended
period of time, remove the batteries from the controller to avoid
battery leakage which may damage the controller. Please dispose
depleted batteries according to local laws and ordinances.

• Li-Polymer batteries have higher operational risks compared to other
batteries. It is imperative to follow proper operational guidelines. The
manufacturer and dealer assume no liability for accidental damages
caused by improper usage. Do not use any other charger other than
the supplied charger included in this packaging in order to avoid
potential fire or explosion. Do not crush, disassemble, burn,
or reverse polarity.

• RC models are made from various forms of plastic very susceptible to
damage or deformation due to extreme heat and cold temperatures.
Make sure not to store the model near any heat source or
adverse temperatures.

3

Card Reader x1

4GB SD Card x1

Quadrone Diagram

Remote Controller Diagram

Remote Controller Battery Installation

1. Use the included screw driver to open the battery cover. Rotate
counter clockwise to loosen screw.

2. Insert 6 AA batteries into the remote. Make sure the batteries are
installed in the correct polarity as indicated in the controller. Do not
mix old and new batteries or batteries with different chemistries.

3. Reattach battery cover.

Canopy

Motor

Blade

4

Antenna

Power Indicator

Directional Joystick

Throttle Joystick

Aileron Trim Buttons
Power Button

Speed Selection

Flip Button

Forward/Backward
Trim Buttons

Unlock/Emergency Stop

Auto Land/Auto Take-off

Headless Mode

One Key Return

Shoot Photo
Shoot Video
