DCP 300

Digital Cinema Hardware User Manual

DCP 300 – Digital Cinema Processor

TD-000285-00 REV B

*TD-000285-00*

IMPORTANT SAFETY PRECAUTIONS AND EXPLANATION OF SYMBOLS

WARNING!

The lighting ﬂash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous” voltage within the product’s enclosure that may be of sufﬁcient magnitude to constitute a risk of electric shock to humans.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in this manual.

SAFEGUARDS

Electrical energy can perform many useful functions. This unit has been engineered and manufactured to assure your personal safety. Improper use can result in potential electrical shock or ﬁre hazards. In order not to defeat the safeguards, observe the following instructions for its installation, use and servicing.

Caution: To reduce the risk of electric shock, do not remove the cover. No user-serviceable parts inside. Refer servicing to qualiﬁed service personnel.

Warning: To prevent ﬁre or electric shock, do not expose this equipment to rain or moisture.

1. Maximum operating ambient temperature is 50°C (122°F).

2. Never restrict airﬂow through the device vents. Please insure that the side panel vents are unobstructed.

3. When installing equipment into a rack, distribute the units evenly. Otherwise, hazardous conditions could be created by an uneven distribution of weight.

4. Connect the unit only to a properly rated supply circuit. The DCP 300 is suitable for connection to 100-240VAC, 50-60Hz with no special considerations other than the appropriate IEC power cord.

5. Reliable earthing (grounding) of rack-mounted equipment should be maintained.

LITHIUM BATTERY WARNING

THE DCP 300 EQUIPMENT CONTAINS A NON-RECHARGEABLE LITHIUM BATTERY. LITHIUM IS A CHEMICAL KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER OR BIRTH DEFECTS. THE NON-RECHARGEABLE LITHIUM BATTERY CONTAINED IN THIS EQUIPMENT MAY EXPLODE IF IT IS EXPOSED TO FIRE OR EXTREME HEAT. DO NOT SHORT CIRCUIT THE BATTERY. DO NOT ATTEMPT TO RECHARGE THE NON-RECHARGEABLE LITHIUM BATTERY.

Warranty (USA only; other countries, see your dealer or distributor)

Disclaimer

QSC Audio Products, LLC (“QSC”) is not liable for any damage to amplifiers, loudspeakers, or other equipment that is caused by negligence or improper installation and/or use of this signal processing product. While QSC has endeavored to develop and produce the most dependable and robust ‘network’ audio product for your use, due to the myriad of network situations and equipment that may be encountered in its implementation, QSC cannot be held responsible for network conflicts and associated consequences that may result. For this reason, QSC strongly recommends that the network used for implementation of the DCP 300 product(s) be completely separate from all other networks, data or otherwise. As such, should you elect to integrate the DCP 300 product(s) with an existing network system, all risks attendant to such integration of the DCP 300 product(s) with an existing network or network systems are assumed by you. While QSC strives to provide the highest quality technical solutions for networked audio products, in no event will QSC or its suppliers be held liable for any damage, consequential, incidental or otherwise, including any claims for lost profits and/or savings resulting from any attempted integration of the DCP 300 product(s) with an existing network or network system. No agent, employee or representative of QSC has any authority to alter or modify in any manner, the disclosures and recommendations set forth herein.

QSC Audio Products 3-Year Limited Warranty

QSC Audio Products, LLC (“QSC”) guarantees the DCP 300 product to be free from defective materials and/or workmanship for a period of three (3) years from the date of sale and will replace defective parts and repair malfunctioning products under this warranty when the defect occurs under normal installation and use – provided the unit is returned to our factory or one of our authorized service stations via prepaid transportation with a copy of proof of purchase (i.e., sales receipt). This warranty provides that the examination of the returned product must indicate, in our judgment, a manufacturing defect. This warranty does not extend to any product which has been subjected to misuse, neglect, accident, improper installation, or where the date code has been removed or defaced. QSC shall not be liable for incidental and/or consequential damages. This warranty gives you specific legal rights. This limited warranty is freely transferable during the term of the warranty period.

Customers may have additional rights, which vary from state to state or from country to country. In the event that a provision of this limited warranty is void, prohibited or superseded by local laws, the remaining provisions shall remain in effect.

Periodically, this warranty is updated. To obtain the most recent version of QSC’s warranty statement, please visit www.qscaudio.com.

The QSC limited warranty is valid for a period of three (3) years from date of purchase in the United States and many (but not all) other countries.

For QSC warranty information in countries other than the United States, contact your authorized QSC international distributor. A list of QSC International distributors is available at www.qscaudio.com.

To register your QSC product online, go to www.qscaudio.com and select ”Product Registration”. Other questions regarding this warranty can be answered by calling, e-mailing or contacting your authorized QSC distributor.

© 2010, QSC Audio Products, LLC. Patents may apply or be pending. QSC is a registered trademark of QSC Audio Products, LLC. “QSC” and the QSC logo are registered with the U.S. Patent and Trademark Ofﬁce. All trademarks are the property of their respective owners.

FCC Interference Statement

NOTE: This equipment has been tested and found to be in compliance with the limits for a class B digital device, pursuant to part 15 of the FCC rules.

These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by switching the equipment on and off, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio or TV technician for help.

RoHS Statement

The DCP 300 product is in compliance with European Directive 2002/95/EC – Restriction of Hazardous Substances (RoHS). The DCP 300 product is in compliance with “China RoHS” directives. The following chart is provided for product use in China and its territories:

DCP 300 系列

有毒有害物质或元素

部件名称

(Part Name)

电路板组件

(PCB Assemblies)

机壳装配件

(Chassis Assemblies)

O: 表明这些有毒或有害物质在部件使用的同类材料中的含量是在 SJ/T11363_2006极限的要求之下。

O: Indicates that this toxic or hazardous substance contained in all of the homogeneous materials for this part is below the limit requirement in SJ/ T11363-2006.

X: 表明这些有毒或有害物质在部件使用的同类材料中至少有一种而含量是在SJ/T11363_2006极限的要求之上。

X: Indicates that this toxic or hazardous substance contained in at least one of the homogeneous materials used for this part is above the limit requirement in SJ/T11363-2006.

铅

(Pb)

X O O O O O

O O X O O O

汞

(Hg)

(Toxic or hazardous Substances and Elements )

镉

(Cd)

六价铬

(Cr(vi))

多溴联苯

(PBB)

多溴二苯醚

(PBDE)

Introduction

QSC’s DCP 300 is a powerful solution for today’s D-Cinema audio systems. From server to speakers, the DCP 300 offers a complete set of tools to facilitate all the signal processing, audio distribution, monitoring and automation control services required in a modern D-Cinema sound system.

The DCP 300 builds on the legacy of QSC’s DCM and BASIS™ products to provide all signal processing and monitoring functions for Digital Cinema in a single integrated system. Designed to be used with QSC’s Digital Cinema Ampliﬁers (DCA) and featuring advanced DSP presets for QSC’s Digital Cinema Speakers (DCS), the DCP 300 optimizes loudspeaker performance while simplifying cinema sound system wiring and conﬁguration. The DCP 300 covers cinema systems ranging from three to ﬁve screen channels, and is conﬁgurable for bi-amp, tri-amp or quad-amp operation. Though optimized to receive audio content directly from a D-Cinema server, the DCP 300 is also compatible with all analog cinema processor formats including Dolby® Digital Surround-EX and DTS-ES and features a 10 channel analog input for integration with 35 mm audio systems.

The DCP 300 is more than an audio processor. Whether designing a system for a single auditorium or designing a large multiplex, the DCP 300 offers the ﬂexibility in conﬁguration, networking, audio distribution and advanced management services to get the job done.

Features

• Digital inputs accept up to 16 channels of AES-3 audio from a D-Cinema server or other digital audio source

• Networked audio I/O via CobraNet™

• Analog inputs accept audio from ﬁlm processors

• Additional analog inputs accommodate non-sync and Mic/Line sources

• Master volume and full 1/3 octave EQ on all channels (except subwoofer)

• Booth monitor with touch screen control for easy operation

• Digital loudspeaker crossovers

• Three or ﬁve screen channels with 2-way, 3-way or 4-way crossovers

• Compatible with all existing QSC DCA ampliﬁers

• Dual internal power supplies with load sharing for seamless recovery in the event of a failure

• SD memory card for quick unit swap – restores all settings

• Multiple bypass modes – routes audio around failed components to ensure that the show will go on

• DSP presets for QSC’s DCS speakers for great “out of the box” performance and reduced setup time

• Crossovers support active 2-way, 3-way or 4-way systems

• QSControl.net™ software (including Venue Manager, QSCreator, Notify and API for 3rd Party control systems) offer ultimate ﬂexibility in

management and allow for the creation of custom control screens, remote access, fault reporting and diagnosis

• Easily integrates with existing ﬁlm processors for dual ﬁlm/digital projection systems

• CobraNet offers digital non-sync routing and future expansion capability

• Continued development of software and ﬁrmware will add new capabilities via easy updates

Digital Signal Processing

The DCP 300 digital signal processing capability outperforms traditional analog crossovers and equalizers for optimized speaker performance. Crossover frequency, 1/3 octave graphic EQ, parametric equalization, polarity, delay and gain can be precisely adjusted for each speaker in your system. Active 2-way, 3-way and 4-way crossovers are available. Advanced crossover presets for QSC DCS speakers speeds system set-up and ensures maximum performance.

Less Wiring, Faster Setup

The DCP 300 greatly simpliﬁes system wiring and setup, signiﬁcantly reducing installation time and labor cost. Input to the DCP 300 is provided via standard DB-25 cables from the D-Cinema server and/or 35 mm cinema processor. Connections to DCA ampliﬁers for input and monitor signals are made through a single QSC DataPort cable (VGA-style cable). All traditional XLR and barrier strip terminations are eliminated. DCP 300 processors simplify setup by using a menu-driven, PC-based software program for conﬁguration. The program includes a speaker data ﬁle that lists default parameters for popular cinema speaker models. Commonly used conﬁgurations can also be saved on a disk, or redistributed across a network,

allowing you to quickly load them into other DCP 300 processors throughout a theatre complex. All system conﬁguration data maybe saved to an SD memory card, allowing easy transfer of settings to a new (backup) DCP 300, should replacement ever be required.

Advanced Monitor Functions

In addition to audio monitoring of ampliﬁer inputs and outputs, the DCP 300 includes QSC’s exclusive “load fault” detection. The DCP 300 monitors all ampliﬁer outputs and indicates opens and shorts in the speaker system, providing conﬁrmation that all ampliﬁer outputs are functioning properly. Further, the DCP 300 detects all ampliﬁer clipping and protect modes and heat sink temperature for reporting via a QSControl™ Ethernet monitoring system.

The QSControl.net™ suite of applications allows for the creation of custom control screens via “drag and drop” design using the QSCreator software application. Screens can be designed to provide intuitive fault reporting and diagnosis that is accessible through remote network access. In addition, QSC’s PoE-enabled NAC 100 Ethernet remote control panel provides remote operation and status throughout a cinema multiplex from anywhere on the local network.

DCP 300 Front Panel Features

2 3 76

1. Power “on” switch

2. 4.5" full-range monitor speaker

3. Monitor volume and parameter adjust (function depends on operating mode) Monitor mode: controls level to DCP 300 front panel speaker in monitor mode Setup mode: provides parameter control in setup mode

4. Setup mode LED – illuminates green when DCP 300 is in setup mode

5. Touch control LCD (4.3" 16:9 color display)

6. Fault LED – illuminates red when load faults or system errors are detected

7. Power “on” LED – illuminates green when AC power is applied

8. Mute button – illuminates red when engaged, illuminates green when disengaged

9. Auditorium volume control – global level control for all audio outputs

DCP 300 Rear Panel Features

1. Mono analog input – accepts microphone or line level signals (with phantom power)

2. Stereo analog inputs – accepts line level signals

3. Analog audio inputs – connect to D-Cinema server or ﬁlm processor with analog outputs Top connector: channels 1 through 8 Bottom connector: 6 auxiliary channels

4. Digital audio inputs – connect to D-Cinema server or ﬁlm processor with digital outputs Top connector: AES3 pairs 1 through 4 (digital audio channels 1 through 8) Bottom connector: AES3 pairs 5 through 8 (digital audio channels 9 through 16)

3 4

9 10 115 6 7 8

17161513 1412

5. S/PDIF input – multi-channel digital input for non-synch/alternative content

6. USB Type B port for DCP 300 conﬁguration and management via direct connection

7. 10/100 Mbps Ethernet port – for QSControl™ management and remote access including access via SNMP

8. 100 Mbps Ethernet ports – CobraNet™ audio network - Primary and Secondary (backup)

9. SD memory card – device conﬁguration storage supports quick unit replacement

10. Serial communications port – 3rd party control/automation via RS232

11. IEC inlet – AC mains power connector with cord lock

12. DataPort interface for QSC ampliﬁers – supports up to fourteen single port ampliﬁers

13. Hearing impaired and visually impaired special mix outputs

14. CMOS compatible logic outputs – for use as automation triggers, alerts, system status

15. Automation inputs – digitally sampled analog control inputs (control presets, levels etc.)

16. Relay outputs – mechanically decoupled control outputs (curtain, lighting control etc.)

17. Audio monitor output – tap from front panel monitor speaker (post DSP, pre ampliﬁer)

Monitor Mode: Controls volume to front panel speaker

MONITOR

VOLUME

Master auditorium

level control

FAULT

POWER

Touch Control User Interface

SETUP

Setup Mode:

Adjust parameter values

displayed on screen

Global Mute affects all Audio outputs

(all ampliﬁer inputs)

MUTE

Front Panel User Interface Details

Front Panel UI

The DCP 300 front panel includes a 480 x 272 pixel, 4.3", color TFT display with a touch control interface and a 16:9 wide screen aspect ratio. The touch control “user interface” allows authorized system operators to recall previously conﬁgured presets, adjust levels, change monitor tap points etc. The “Monitor Volume” knob is used to manipulate these parameters when the DCP 300 is in “setup mode” (indicated when the “SETUP” LED in the middle of the Monitor Volume knob is illuminated green).

The Monitor Volume is also used to change the level of the ampliﬁed monitor signal feeding the DCP 300 front panel speaker when the DCP 300 is in “monitor mode” (indicated when the “SETUP” LED is not illuminated).

The global “Mute” button, when engaged, mutes all audio outputs. Engagement of the Mute button is indicated when the red LED in the mute button cap is illuminated. Normal operation (non-muted) is indicated through illumination of the Mute button cap with a green LED.

The large rotary encoder knob to the right of the touch control LCD is the master level control for the auditorium sound system. Adjusting this control manipulates the level of the audio signal fed to the all audio outputs.

Setup Overview

Initial conﬁguration of the DCP 300 is performed through QSC’s DCP Manager™ software, which must be installed on a Windows® PC or laptop computer. Once the software is installed on the computer, the computer can then be connected to the DCP 300 product via a USB connection.

A system designer would typically begin high-level conﬁguration by deﬁning the basic system topology and distribution of audio within the DCP Manager application. This involves selecting the audio sources for the DCP 300 program inputs, auditorium sound format, ampliﬁcation and speaker design and whether additional devices (such as BASIS™ devices) are included in the system design for the purposes of expanding the quantity of DataPort outputs or for locating the ampliﬁers remotely for example: outside of the projection booth… behind the projection screen. Presets can be created to accommodate multiple audio sources or distribution topologies (i.e.., to support different conﬁgurations for the main theatre presentation and for alternative content/non-synch audio) and/or to support multiple auditorium mixes or multi-use applications.

Once the high-level conﬁguration is complete, the rest of system can be connected to the DCP 300 and/or powered up and completion of the DSP conﬁguration, assignment of levels, application of architectural delay etc. and system tuning can commence.

Note that recalling of system presets and adjustment of system parameters such as output and monitor levels, monitor tap points etc. can be made through the front panel user interface (the touch control LCD and associated rotary encoders) by authorized users.

The Setup Overview on the following pages is a general application guide showing the installation steps required for a basic system. Refer to the Help Files in DCP Manager and the QSControl.net™ suite of applications for detailed setup and conﬁguration instructions and for system examples. The QSC Cinema Products web pages are also a good source of information for application notes and system design assistance.

Setup Overview

1. Unpack Carton

Remove your DCP 300 product from its carton and inspect it carefully. Make sure that the carton contents are complete and that there are no signs of shipping damage. Retain all packaging for future unit storage or for the unlikely event that service is needed.

2. Install Software

Load the DCP Manager disc into a CD-ROM or DVD drive on a Windows® PC or laptop computer. Follow the installation instructions displayed on your computer’s screen.

Note: DCP Manager must be installed before connecting the DCP 300 to a Windows PC or laptop computer.

3. Conﬁgure DCP 300

After DCP Manager is installed, connect a USB cable between the DCP 300 and the computer. Turn the DCP 300 on, launch DCP Manager and follow the prompts on screen. Refer to the Help Files for instructions on how to conﬁgure the basic operating parameters of the DCP 300 (source inputs, format, presets, etc).

4. Attach Ampliﬁers

Connect DataPort outputs on the DCP 300 rear panel to DataPort inputs on QSC’s DCA or PL3 Series ampliﬁers using QSC approved DataPort cables.

Setup Overview

5. Connect Audio

Connect cinema audio sources to the appropriate DCP 300 rear panel input connectors. Main sources can come from digital content servers or analog ﬁlm processors. Additional analog and digital inputs are provided for alternative content sources, live feeds, DVD players, mic/paging sources etc.

Connect the Hearing Impaired and Visually Impaired special mix outputs and/or the Monitor Output feed to appropriate external devices as needed.

6. Connect Automation

Connect appropriate external control devices to the DCP 300’s automation Inputs. Connect the Logic Outputs and/or Relay Outputs to any external devices to be controlled.

7. Complete Installation

Remove protective ﬁlm covering the touch panel LCD surface. Insert the included SD Card into the rear panel receptacle. The SD Card provides DCP 300 conﬁguration storage for quick unit service/replacement.

8. Tune System

Once the basic DCP 300 operating conﬁguration is deﬁned and all of the connections are in place, it’s time to power up the rest of the rack, complete the DSP setup, tune the system and run through ﬁnal check.

Refer to additional information in this Hardware User Manual and in the software Help Files for further setup and conﬁguration details to complete this step.

Conﬁguration and Networking

The DCP 300 offers a variety of accessibility options for conﬁguring and managing the product and an entire cinema sound system locally or remotely. Local DCP 300 conﬁguration and system management are provided through directly applied connections to the DCP 300 via universal serial bus (USB), the DCP 300 front panel touch-control LCD or through a local Ethernet link (QSControl™). Remote and system-wide management are possible through more sophisticated network implementations and/or via wide area network (WAN) topologies, Internet access or 3rd party subscription services that make use of the DCP 300 3rd party API or SNMP.

Basic conﬁguration of the DCP 300 product is performed through the USB interface on the product rear panel. The system designer connects to the DCP 300’s rear panel USB port with a Windows laptop or PC running the DCP Manager software application. DCP Manager offers all the setup tools and system management objects to conﬁgure the auditorium audio format, selection of audio source material, conﬁgure the DSP signal path, apply crossovers, EQ etc., Deﬁne the routing of audio to the ampliﬁers, deﬁne the system speakers and speaker processing etc. Once the basic conﬁguration is complete, the system designer can deﬁne custom Presets that can be recalled for different auditorium setups. For example, a Preset can be created for the primary presentation content. Another Preset can be created for non-sync or alternative content. And yet another Preset can be created for live application use such as seminars or corporate events. Once these Presets are created they become accessible via the DCP 300 front panel touchcontrol LCD.

In addition to basic conﬁguration, DCP Manager can be used to monitor health, status and performance of the local system (the directly connected DCP 300) via the product’s rear panel USB interface.

USB connection to DCP 300

USB type B Port on DCP 300

Rear Panel

DCP Manger

USB cable

The image above illustrates a Windows® laptop connecting directly to the DCP 300 via the product’s rear panel USB Type B port. The Windows machine is running QSC’s DCP Manager Application, which is used to conﬁgure the DCP 300.

Once the DSP signal chain and audio format are conﬁgured, the DCP 300 can be connected to an Ethernet LAN for local or remote management using the QSControl.net™ suite of applications or via a custom application or control system using the DCP 300 3rd Party API.

A local Ethernet connection to a Windows laptop or PC that is running QSC’s Venue Manager Application provides the system designer with access to status, health and performance of the local system. Changes to Presets, audio levels and some automation control objects can be made through Venue Manager access.

DCP 300 ﬁrmware updates can also be performed through the Venue Manager Application. For more venue-speciﬁc needs, QSC’s QSCreator Application allows the system designer to create custom control screens with varying levels of password protection (authentication rights). QSCreator screens can be as elaborate as the system designer’s imagination and can be created to depict the physical layout of the auditorium or the entire cinema complex.

Since the QSControl.net™ suite of applications provide accessibility to the DCP 300’s network interface, these applications can be used to manage an entire sound system consisting of multiple DCP 300 products, QSC ampliﬁers, QSC speakers and other QSC network enabled products such as BASIS, RAVE and DSP 300 series products. Management can be localized (within the theatre complex) or remote, depending on the network implementation deployed. Remote management also available via SNMP.

Local Ethernet connection to DCP 300

QSControl Port on DCP 300

Rear Panel

CAT-5

Cables

10/100 Mbps

Ethernet Switch

The image above illustrates a Windows® laptop connecting to the DCP 300 via a network switch. The DCP 300 is also connected to the network switch via its rear panel QSControl™ port. The Windows® machine is running QSC’s QSControl.net suite of applications, which includes Venue Manager, QSCreator, Notify and the QSControl™ 3rd Party API.

QSControl.net

Venue Manger

QSCreator

Unpacking

There are no special unpacking precautions. However, it is recommended that you keep the original packing materials for reuse in the rare event that service is required. If service is required and the original packing material is not available, ensure that the unit is adequately protected for shipment (use a strong box of appropriate size, sufﬁcient packing/padding material to prevent load shifting or impact damage) or call QSC’s Technical Services Group for replacement packing material and a carton.

DCP 300 Product Carton Contents

1. DCP 300 product

2. Hardware User Manual

3. DCP 300 software CD(s)

4. IEC power cord and wire cord retainer

5. Euro style connector plug kit

6. SD card (2 GB)

7. Warranty card

Mounting

The DCP 300 product is designed to be mounted in a standard 19" (480 mm) equipment rack and requires 3 vertical rack spaces (refer to IEC 60297 for additional rack dimensions and design details). Rack mounting provides the DCP 300 with stability and a convenient means for dressing the cables connecting to the product. Some rack systems also provide climate control and/or conditioned power.

Rack mount the DCP 300 product by supporting it from underneath while aligning the four front panel mounting holes (in the rack ears) with the threaded screw holes in the rack rails. Install all four mounting screws and washers and tighten securely. The DCP 300 product comes with rear rack support ears. Ensure that these rear mounting points are securely fastened to rear rack rails or rack side walls.

Computer Requirements

Your PC or laptop must meet the following minimum requirements:

1. IBM PC compatible computer (Windows PC)

2. Intel Pentium 4 CPU or better

3. CPU speed of 2.0 GHz or faster

4. 1 GB of RAM or greater

5. Hard drive with at least 1 GB of space available

6. Display resolution of at least 1024 x 768

7. CD-ROM drive for installing DCP 300 software

8. Windows® XP Pro, Windows Vista®, Windows® 7 operating System (Supports 32 or 64 bit systems) In addition to these minimum requirements, your PC or laptop must have a 10/100 or 10/100/1000 Mbps Network Adapter (NIC) in order to join a

QSControl™ network.

Software Installation

Installing the DCP Manager™ and QSControl.net™ suite of software applications is easy. All you need to do is choose the folder where the application is to reside (the default setting is acceptable for most users).

1. Start your Windows® PC or laptop

2. Close any running applications

3. Place the DCP Manager software CD into your CD-ROM drive.

4. The DCP Manager software should auto-run. If not, select run from the star menu. Browse to the ﬁle named setup.exe on your CD-ROM drive.

5. Click the Install DCP Manager button

6. Follow the on-screen prompts/instructions

7. Repeat steps 1 through 6 to install QSControl.net™

USB Driver Warning

DCP Manager must be installed on your PC or laptop prior to connecting it to the DCP 300 product. This ensures that the USB driver is properly installed on your PC or laptop prior to establishing a connection to the DCP 300 product via the computer’s USB port.

Conﬁguring the DCP 300

DCP Manager™ is used to conﬁgure the DCP 300 product. This includes conﬁguring the device properties, the DSP objects, audio and control I/O and Presets. The network communications properties and audio networking features can also be conﬁgured using DCP Manager™ so that all networking properties are in place before the DCP 300 is added to a local area network (if your deployment requires networking). Alternately the DCP 300 is accessible via SNMP remote management.

Once the DCP 300 product is conﬁgured via DCP Manager™, the QSControl.net™ suite of applications (Venue Manager, QSCreator™, Notify and the QSControl™ 3rd Party API) can then be used to manage one or more DCP 300 products over a local area network.

Refer to the information in the DCP Manager™ and QSControl.net™ application Help Files for additional information on product conﬁguration, management and network connectivity.

Connections

AC Power Cord

Insert the molded receptacle of the AC power cord into the AC power inlet on the back of the DCP 300 product. Plug the AC line connector into an AC outlet. The power supply on the DCP 300 product will accept from 100 to 240V, 50 to 60 Hz. If a different type of IEC power cord is required than that supplied with the product, consult QSC’s Technical Services Group.

QSControl™ Network

Connect one end of a data communications cable terminated with an RJ45 plug into the QSControl™ receptacle on the rear panel of the DCP 300 product. Ensure that the lock tab on the cable engages with the RJ45 receptacle on the DCP 300 rear panel connector. Note: data communications cabling must be rated CAT-3 or better for 10 Mbps network connections or rated CAT-5 or better for 100 Mbps network connections.

CobraNet Network

Connect one end of a data communications cable terminated with an RJ45 plug into the CobraNet™ Primary receptacle on the rear panel of the DCP 300 product. Ensure that the lock tab on the cable engages with the RJ45 receptacle on the rear panel DCP 300 connector. For systems requiring redundant network connections, connect a second data communications cable terminated with an RJ45 plug into the CobraNet™ Secondary receptacle on the rear panel of the DCP 300 product. Note: data communications cabling must be rated CAT-5 or better for all CobraNet™ connections.

Connections Continued

Hearing and Visually Impaired Outputs

The Hearing Impaired and Visually Impaired special mix outputs are balanced outputs that are combined into a single 5-terminal Euro style (a.k.a. Phoenix) receptacle. This combo receptacle includes a common ground for both the H.I and V.I. outputs. Terminate the mating 5-terminal Euro plug and insert it into the DCP 300 rear panel receptacle as shown in the image to the right. The DCP 300 rear panel label provides a pin-out of the receptacle signals. Note: a standard 3-terminal plug may be used if only one output is required.

Automation Inputs, Logic Outputs, Monitor Output

The automation inputs, logic outputs and monitor output all use a 2-terminal or 6-terminal Euro style (a.k.a. Phoenix) receptacle. The Automation Inputs can be connected to relay contacts, a switch or a 10K potentiometer. Logic Outputs are CMOS compatible. And the Monitor Output is a single-ended balanced impedance source. All connections require a 2-terminal or 6-terminal Euro style plug. The DCP 300 rear panel label provides all necessary signal information. The negative terminal of each receptacle is at chassis potential.

Relay Outputs

Two relay outputs are provided via two 3-terminal Euro style (a.k.a. Phoenix) receptacles. Relay contacts are ﬂoating and rated for 30 VDC at 1A. Each output includes one common terminal, one normally open contact (N.O.) and one normally closed (N.C.) contact. These terminals are labeled C, NO and NC, respectively on the DCP 300 rear panel. When the relay is not energized, the C terminal is connected to the NC contact and the NO contact is not connected. When the relay is energized, the C terminal is connected to the NO contact and the NC contact is not connected.

DataPorts

QSC DataPorts on the DCP 300 rear panel are intended to interface to QSC ampliﬁers with v1 DataPorts. These are the all-capable DataPorts, which are included on DCA and PL3 series ampliﬁers. All DataPorts use the HD15 connector format and connect to QSC ampliﬁers via data communications cables having male HD15 connectors on both ends. These are commonly referred to as VGA cables. Note: though many off-the-shelf VGA cables may work with satisfactory results, the QSC DataPort speciﬁcation requires that all conductors be present and that all audio I/O conductors be shielded. Therefore, only QSC supplied DataPort cables should be used. A variety of lengths are available through QSC’s Technical Services Group. To connect a DataPort cable between a DCP 300 DataPort and an ampliﬁer DataPort, attach the cable’s male connectors to the HD15 ports and ﬁnger tighten the thumb screws on the connectors.

Ancillary Interfaces

A single Mic/Line Input is accessible on the DCP 300 rear panel. This input can be used for mono nonsynch sources or for connecting a microphone for local paging or announcements into the auditorium or to support various corporate or live events requiring a microphone. Phantom power may be enabled via DCP Manager™ conﬁguration. The Mic/Line Input uses a standard 3-conductor XLR receptacle.

L/R analog line input connectors and a multi-channel digital S/PDIF input are accessible on the DCP 300 rear panel. These RCA connectors accommodate non-synch sources appropriate for alternative content, advertising, corporate or live event feeds.

A USB Type B interface is provided for directly connecting to a Windows® PC or laptop. All conﬁguration and local management of the DCP 300 via DCP Manager software is performed through this portal.

Note: all ancillary interfaces use standard cables that are readily available through retailers specializing in computer equipment, musical equipment, pro audio or home electronics.

Main Analog Input Connector Pinout

25-pin male D-Sub to 25-pin male D-Sub

Pin # Description Pin # Description

1 Chassis ground 14 Left 2 Left + 15 Chassis ground 3 Left extra - 16 Left extra + 4 Chassis ground 17 Center 5 Center + 18 Chassis ground 6 Right extra - 19 Right extra + 7 Chassis ground 20 Right 8 Right + 21 Chassis ground 9 Chassis ground 22 Chassis ground 10 Surround left - 23 Surround left + 11 Surround right + 24 Surround right + 12 Subwoofer - 25 Subwoofer + 13 Chassis ground Shell Chassis ground

Auxiliary Analog Input (Surround EX) Pinout

25-pin male D-Sub to 25-pin male D-Sub

Main Analog Input

8 6 4 2

11 7

13 9

23 19

25 21

5 13

20 18 16 14

17 15

Pin # Description Pin # Description

1 (not used) 14 Left extra + 2 (not used) 15 Left extra 3 Back surr left - 16 Back surr left + 4 (not used) 17 (not used) 5 (not used) 18 (not used) 6 Back surr right - 19 Back surr right + 7 (not used) 20 (not used) 8 (not used) 21 (not used) 9 Right extra + 22 Right extra 10 Surr left - 23 Surround left+ 11 Surround right - 24 Surround right + 12 (not used) 25 (not used) 13 (not used) Shell Chassis ground

Digital (AES3) Input Connector Pinout

25-pin male D-Sub to 25-pin male D-Sub

Pin # Description Pin # Description

1 AES 1: Gnd 14 AES 1: Pos 2 AES 1: Neg 15 AES 2: Gnd 3 AES 2: Pos 16 AES 2: Neg 4 AES 3: Gnd 17 AES 3: Pos 5 AES 3: Neg 18 AES 4: Gnd 6 AES 4: Pos 19 AES 4: Neg 7 (not used) 20 (not used) 8 (not used) 21 (not used) 9 (not used) 22 (not used) 10 (not used) 23 (not used) 11 (not used) 24 (not used) 12 (not used) 25 (not used) 13 (not used) Shell Chassis ground

Auxiliary Analog Input

8 6 4 2

11 7

13 9

23 19

25 21

5 13

20 18 16 14

17 15

Digital Input

(the connector providing AES3 pairs 1-4 and the connector providing AES3 pairs 5-8 are wired the same and with the same pair sequence)

8 6 4 2

11 7

13 9

23 19

25 21

5 13

20 18 16 14

17 15

Speciﬁcations

Dimensions (H/W/D): 5.25" x 19" x 15" Audio Input Performance

Line voltage requirements 100 VAC – 240 VAC, 50/60 Hz A/D conversion 24-bit delta-sigma, 48 kHz

Accessories included 6 ft UL/CSA line cord, User Manual Software CD Dynamic range (unweighted) > 105 dB

Front Panel Controls CMRR typical (max) 20 Hz – 20 kHz > 60dB (> 50dB)

Power switch Rocker switch Main Analog Input

Mute control Push button Input stage type Active balanced

Auditorium fader Rotary encoder Input impedance 22 k Ohms

Monitor volume/parameter adjust Rotary encoder Max analog input level +14.2 dBu (4.0 Vrms)

Menu-driven LCD Touch control LCD THD+N at +4dBu (nominal) 0.005%

Indicators Mic/Line Input

Mute engage/disengage Button illumination Input stage type Active balanced

Monitor level/parameter focus Encoder knob illumination Input impedance 6.81 k Ohms

Power on indicator Green LED Max analog input level +28 dBu (19.45 Vrms)

Fault detect indicator Red LED THD+N at 2dB below clip (max) 0.05%

Rear Panel Connectors Digital Input (AES/EBU)

D-Cinema input group 1 DB-25 — AES3/EBU channels 1-8 Input type Balanced

D-Cinema input group 2 DB-25 — AES3/EBU channels 9-16 Input impedance 120 Ohms

Main analog input DB-25 — Analog audio channels 1-8 Input sample rate 48 kHz or 96 kHz

Extended surround input DB-25 — DB-25 - Surround and Le/Re Channels Audio Output Performance

Universal Mic/Line input XLR — Mic (+ phantom pwr) or line level DataPort outputs

S/PDIF input

RCA (L/R) inputs

DataPort outputs HD-15 (14) — QSC amplifier interface D/A conversion 24-bit delta-sigma, 48 kHz

Automation inputs 2-pin Euro-style (x6) – 8-bit resolution DSP Performance

Logic output 2-pin Euro-style (x2) – CMOS levels Filter topology 24-bit digital IIR

Relay outputs 3-pin Euro-style (x2) – max 30 VDC Crossover filters Linkwitz-Riley or Butterworth (6 - 48 dB/octave)

Monitor output 2-pin Euro-style (x1) – max 15W

H.I./V.I. output 5-pin Euro-style (x1) – common GND

Serial Control DB-9 RS-232 Serial Interface Graphic EQ 28 band a octave with up to ±12 dB cut/boost

RCA — Stereo digital audio interface

and Lt/Rt Matrix

RCA (2) — Stereo Left and Right

and Lt/Rt Matrix

Output level range +6 dB to -18 dB in .1 dB steps

Dynamic range (unweighted): >105 dB

THD+N at +12dBu input level <.005 %

Frequency response 20 Hz to 20 kHz

Parametric EQs

Digital bandpass filter with ±10 dB of boost/cut. Q is programmable in 1/10th octave steps from 1/10th to 4 octaves

USB Type B port Config and management interface

QSControl RJ45 10/100 Mbps network management

CobraNet RJ45s 100 Mbps primary/backup network audio

SD card receptacle Configuration memory card (1 GB min)

Bass

Treble

Digital shelf filter with up to ±10 dB of cut/boost programmable knee

Speciﬁcations Continued

Subsonic (high-pass) filter

CD Horn EQ

Screen EQ

All pass filter

Band polarity Normal, inverted Output type Mechanical relay contacts

Band delay Programmable in 21μs steps from 0 ms to 10 ms Compatible

Channel delay

Master delay

Mute Individual channel mutes, global mute Format 16 x 9

Bass management

Digital high-pass filter programmable as .707 (flat) or 2 dB (B6 boost)

Digital shelf filter with up to ±10 dB of cut/boost programmable from 20 Hz to 20 kHz

2nd order all pass filter programmable from 20 Hz – 2 kHz

Programmable in 1ms steps from 0 ms to 175 ms (0 to 4 frames)

Programmable in 1ms steps from 0 ms to 420 ms (0 to 10 frames)

Weighted sum of screen channels may be low pass filtered and mixed with sub output

Automation inputs

Input type OMNI (discrete state or potentiometer)

Compatible sources

Logic Outputs

Output type Two-state logic

Compatible CMOS compatible output levels

Relay outputs

Liquid crystal display

Display type Active color TFT

Display area dimensions 4.3" diagonal viewing area

Touch panel type Resistive 4-wire

Audio network

Accepts contact closure (switches, relays) or 10K pot. Input is sampled and converted to 8-bit digital value

Max 30VDC output at 1A. Can be wired as N.O. or N.C

Surround bass management

Amplifier A.C. Control

Monitor speaker Ports 1 Primary, 1 Backup (auto-failover)

Speaker 4" full-range

Impedance 4 Ohms

Amplifier output power 15 watts Class D QSControl™ network / SNMP

Frequency response 20 Hz – 20 kHz (± 2 dB)

Dynamic processing 1.5:1 compression

H.I. and V.I. impaired outputs Data rate 10/100 Mbps

Output stage type Single ended (balanced Z)

Output impedance 50 Ohms

Nominal output level -11.8 dBu (200 mVrms)

Loading requirements Rmin = 2k Ohms, Cmax = 4nF

Weighted sum of surround or screen channels may be low pass filtered and mixed with aux output A.

All amps power on with DCP 300 activation and can be placed into standby via user interface

Protocol CobraNet version 2 protocol

Data rate 100 Mbps (Fast Ethernet)

Connection requirements

Protocol

Connection requirements

Cat-5 UTP cable or better (100m maximum length), direct connection to wired network switch ports only, dedicated LAN or VLAN

Standard TCP/IP implementation over Ethernet or Fast Ethernet

Cat-5 UTP cable or better (100m maximum length), direct connection to wired network switch ports only, dedicated LAN or VLAN

Appendix A:

DCP 300 Serial Port Automation Control Protocol Rev 1.0 Description

This appendix describes the serial port automation control protocol for managing QSC’s DCP 300 Digital Cinema Processor. Serial port automation is handled via ASCII text commands sent via RS-232 from an external device. All commands must be terminated with a CR [0Dh] or LF[0Ah].

NOTE: Settings manipulated via serial port automation commands may be overridden or modiﬁed by commands issued from the DCP 300 front panel display, by commands sent over the network using QSC’s Third Party Control Protocol, or by triggers coming in through other automation inputs on the DCP 300 rear panel.

1.1 Communication Settings

The serial port settings required to communicate with the serial interface on the DCP 300 are as follows:

• Baud rate of 115200 bits per second

• 8 Data Bits

• No Parity

• 1 Stop Bit

• Flow Control: none

• Straight through cable (not a null modem)

1.2 Command Protocol

A communication terminal program such as Hyper Terminal can be used for initial testing of the DCP 300 automation commands. After connecting the serial port cable (no null modem) and conﬁguring a communication session you should see the following command prompt indicating that the DCP 300 unit is ready to accept serial automation commands, (you may need to use a <CR> to see the prompt):

cmd>

1.3 Automation Command Reference

The following serial commands are currently supported by the DCP 300:

dcp300preset

Selects the preset speciﬁed (1 – 32). If no preset number is entered following the ‘=’ character, then the currently selected audio preset is returned. Examples:

To select preset 1: cmd>dcp300preset=1 Return value: dcp300preset=1 To query currently selected audio preset (presets 1-16): cmd>dcp300preset= Return value: dcp300preset=1

If invalid, disabled preset number, or out of range value entered: cmd>dcp300preset=50 Return value: dcp300preset=invalid

Note: Currently selected preset will remain active

dcp300mute

Turns the Master Mute on or off (1 = mute, 0 = unmute). If no value is entered following the ‘=’ character, then the current state of the Master Mute is returned. Examples:

To turn master mute on: cmd>dcp300mute=1

Return value: dcp300mute=1

To turn master mute off: cmd>dcp300mute=0 Return value: dcp300mute=0

To query current state of master mute: cmd>dcp300mute= Return value: dcp300mute=1

If invalid or out of range value entered: cmd>dcp300mute=a Return value: dcp300mute=invalid

Note: Current state of Master Mute will remain active

dcp300fader

Sets the Master Volume level to the value speciﬁed in dB (-90.0 to 10.0 in .5dB increments). If no value is entered following the ‘=’ character, the current Master Volume level is returned. If a ‘+’ character is entered following the ‘=’ character, then the volume is incremented by .5 dB (not to exceed the maximum allowable volume of 10.0 dB). If a ‘–‘ character is entered following the ‘=’ character, then the volume is decremented by .5 dB. Examples:

To set Master Volume to 5 dB: cmd>dcp300fader=5.0 Return value: dcp300fader=5.0

To increment volume by .5 dB: cmd>dcp300fader=+ Return value (assuming volume previously set to 5 dB): dcp300fader=5.5

To decrement volume by .5 dB cmd>dcp300fader=Return value (assuming volume previously set to 5 dB): dcp300fader=4.5

To query current volume: cmd>dcp300fader= Return value: dcp300fader=4.5

If invalid or out of range value entered: cmd>dcp300fader=20.0 Return value: dcp300fader=invalid

Note: Master Volume will remain at current level

dcp300version

Returns the version of the DCP 300 ﬁrmware (in the form: major.minor.build). Example:

To read the DCP 300 ﬁrmware version: cmd>dcp300version= Return value: dcp300version=1.00.0039

Mailing Address:

QSC Audio Products, LLC

1675 MacArthur Boulevard

Costa Mesa, CA 92626-1468 USA

Telephone Numbers:

Main Number: (714) 754-6175

Sales & Marketing: (714) 957-7100 or toll free (USA only) (800) 854-4079

Customer Service: (714) 957-7150 or toll free (USA only) (800) 772-2834

Facsimile Numbers:

Sales & Marketing FAX: (714) 754-6174

Customer Service FAX: (714) 754-6173

World Wide Web:

www.qscaudio.com

E-mail:

info@qscaudio.com

service@qscaudio.com

©2010 QSC Audio Products, LLC. All rights reserved. QSC, the QSC logo, QSControl.net, QSControl, BASIS, RAVE, QSCreator, DCP Manager, Digital Cinema Amplifier (DCA), Digital Cinema Processor (DCP) and Intrinsic Correction are registered trademarks of QSC Audio Products, LLC in the U.S. Patent and Trademark office and other countries.

Windows is a trademark of Microsoft Corp. Dolby is a registered trademark of Dolby Laboratories. DTS is a registered trademark of DTS, Inc. CobraNet is a trademark of

Cirrus Logic. All other trademarks are the property of their respective owners. Patents may apply or be pending.

Qsc audio DCP 300 REV B User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
