Hardware Specification
QGD-1600P-4G
Management Type Web Managed
CPU Intel® Celeron® J4115 quad-core 1.8 GHz processor (burst up to 2.5 GHz)
CPU Architecture 64-bit x86
System Memory 4 GB
Rate Limiting Yes
IGMP Snooping Querier Yes
IGMP Snooping v2/v3 Yes
IP-based Access Control
List (ACL)
Yes
DSCP-based QoS Yes
VLAN-based QoS Yes
Port-based QoS Yes
Port Mirroring Yes
Trunking/LACP Yes
IEEE 802.1Q-based VLAN Yes
Port-based Private VLAN Yes
VLAN Configuration Yes
PoE Detection Yes
PoE Schedule Yes
PoE Status Yes
Auto-negotiation of Speed
and Duplex Modes
Yes
LLDP Yes
MAC Address Table
Display
Yes
Loop Protection Yes
Memory Slot 2 x SODIMM DDR4
File System: External Hard
Drive
EXT3, EXT4, NTFS, FAT32, HFS+, exFAT (optional license)
File System: Internal Hard
Drive
EXT4
SSD Cache Acceleration
Support
Yes
M.2 SSD Slots Optional via PCIe adapter
Hot-swappable Yes
Drive Compatibility 2.5-inch bays:
2.5-inch solid-state drives
2.5-inch hard disk drives
Flash Memory 4GB (Dual boot OS protection)
Maximum Memory 8 GB (2 x 4 GB)
SNTP/DNS/DHCP Client Yes
Hardware-accelerated
Transcoding
Optional via PCIe adapter
Encryption Engine Yes (AES-NI)
Floating Point Unit Yes
Graphics Processors Intel® HD Graphics 600
QTS Built-in Yes
Static MAC Address Yes
Port Configuration Yes
IEEE 802.3x Flow Control Yes
Port Statistics Yes
Drive Bays 2 x 2.5-inch SATA 6Gb/s
PCIe Slot Slot 1: PCIe Gen2 (x2)
Slot 2: PCIe Gen2 (x2)
Max. Power Consumption 418W
Power Supply Description Internal Power Supply Unit
HDMI Output 1
USB 3.1 Gen 2 (10Gbps)
Port
Optional via PCIe adapter
Management Port 1
USB 2.0 port 2
USB 3.0 port 1
Total PoE Power Budget 370W
Input Voltage Range 100-240VAC, 50/60 Hz
PoE Power Output Ports 1-4 (60W), Ports 5-16 (30W)
PoE++ PSE (802.3bt, 60W) Ports 1-4
PoE+ PSE (802.3at, 30W) Ports 1-16
PoE PSE (802.3af, 15.4W) Ports 1-16
Total PoE Ports 16
1GbE SFP/RJ45 Combo
Ports
2
1GbE (RJ45) 14
Number of Ports 16
Input Power Type AC
MAC Address Table 8K
Port Status Yes
Dimensions (HxWxD) 160 × 528 × 403 mm
Jumbo Frames 9k
Electromagnetic
Compliance
CLASS A, UL62368
Certifications CE, FCC, VCCI, BSMI RCM
Relative Humidity 5% to 95% non-condensing, wet bulb: 27˚C (80.6˚F)
Operating Temperature 0°C to 45°C (32°F to 113°F)
Weight (Gross) 5.56 kg
Weight (Net) 4.41 kg
Buttons Device PSU power button
Host power button
Host reset button(load default)
Switch reset button
Total Non-Blocking
Throughput
16Gbps
LCD Management Yes
LED Indicators Per Port: Link/Activity/Speed/PoE
Per System: Warning/PoE/Fan
Form Factor Rackmount
Supported Standards IEEE 802.3 10Tx Ethernet
IEEE 802.3u 100Tx Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3z 1000Base-X
IEEE 802.3x Full-duplex flow control
IEEE 802.3af/at/bt Power-over-Ethernet (PoE)
IEEE 802.1q Virtual LANs (VLAN)
IEEE 802.1p QoS Protocol for Traffic Prioritization
Fan System: 2 x 4 cm (12V DC)
Energy Efficient Ethernet
(IEEE 802.3az complaint)
Yes
Management Interface CLI/Web
Switching Capacity 32Gbps
Warranty 2 Years
