QLA®4010/4010C User’s Guide

1-Gb iSCSI to PCI-X Host Bus Adapters

IS0053302-00 B Page i

QLA4010/4010C User’s Guide

0

1-Gb iSCSI to PCI-X Host Bus Adapters

Information furnished in this manual is believed to be accurate and reliable. However, QLogic Corporation assumes no
responsibility for its use, nor for any infringements of patents or other rights of third parties which may result from its use.
QLogic Corporation reserves the right to change product specifications at any time without notice. Applications described
in this document for any of these products are for illustrative purposes only. QLogic Corporation makes no representation
nor warranty that such applications are suitable for the specified use without further testing or modification. QLogic
Corporation assumes no responsibility for any errors that may appear in this document.

No part of this document may be copied nor reproduced by any means, nor translated nor transmitted to any magnetic
medium without the express written consent of QLogic Corporation.

Adobe and Acrobat are registered trademarks of Adobe Systems, Inc.

Linux is a registered trademark of Linus Torvalds.

Microsoft and Windows 2000 are registered trademarks and Windows Server 2003 is a trademark of Microsoft
Corporation.

QLogic and QLA are registered trademarks of QLogic Corporation.

SANblade is a trademark of QLogic Corporation.

Red Hat and all Red Hat-based trademarks are trademarks or registered trademarks of Red Hat, Inc.

Solaris is a registered trademark of Sun Microsystems, Inc.

SPARC is a trademark of SPARC International, Inc. in the United States and other countries. Products bearing SPARC
trademarks are based upon an architecture developed by Sun Microsystems, Inc.

All other brand and product names are trademarks or registered trademarks of their respective owners.

Q

Document Revision History

Rev A, 12/15/03

Rev A.1, 6/28/04

Rev B, 8/20/04

Changes Document Sections Affected

Removed software driver installation sections; information now in readme.txt. Was 3–5

Removed SANsurfer Control iX; see SANsurfer iSCSI HBA Manager Application
User’s Guide (

IS0054602-00 A).

Was 6

© 2002–2004 QLogic Corporation. All rights reserved worldwide.

First Published: December 2002

Printed in U.S.A.

QLogic Corporation, 26650 Aliso Viejo Parkway, Aliso Viejo, CA 92656, [phone] or (949) 389-600

Page ii IS0053302-00 B

Table of Contents

Section 1 Introduction

1.1 How to Use this Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

1.2 General Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

1.3 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

1.4 Technical Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

1.4.1 Availability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

1.4.2 Training . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

1.4.3 Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Section 2 QLA4010/4010C

2.1 Installation in the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

2.2 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

2.3 Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

2.4 Agency Certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

2.4.1 QLA4010 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

2.4.2 EMI and EMC Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

2.4.3 Product Safety Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

2.4.4 QLA4010C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

2.4.5 EMI and EMC Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

2.4.6 Product Safety Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

Tables

Table Page

2-1 QLA4010/4010C HBA Operating Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

2-2 QLA4010/4010C HBA Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

IS0053302-00 B Page iii

Table of Contents

Q

Page viii PRELIMINARY PC0056105-00 C

1.1

How to Use this Guide

The SANblade™ QLogic® host bus adapters (HBAs) supported in this document
are described in the following paragraphs:

■ QLA

■ QLA

The QLA4010 HBA is 32/64-bit, 33/66/133-MHz PCI-X to iSCSI over Gigabit
Ethernet on optical media. The QLA4010C HBA is 32/64-bit, 33/66/133-MHz PCI-X
to iSCSI over Gigabit Ethernet on twisted-pair copper media.

This guide contains installation instructions for the hardware (QLA4010/4010C
HBA) supported software drivers, and BIOS configuration utility (Fast!UTIL). Install
these components in the following order:

1. Install the QLA4010/4010C HBA in your PC.

2. Install the software driver according to the directions in the appropriate section.

®

4010 (single channel, full-height bracket, optical media)

®

4010C (single channel, full-height bracket, copper media)

Section 1

Introduction

NOTE: For a Solaris SPARC system the driver must be installed before

installation of the HBA.

3. Optionally, you can customize the QLA4010/4010C HBA and its attached
devices using the Fast!UTIL BIOS utility. See the associated readme.txt file for
detailed instructions.

1.2

General Description

The QLA4010/4010C is an iSCSI HBA that provides PCI connectivity to SCSI using
the iSCSI protocol. This release of the QLA4010/4010C HBA implements draft 20
of the IETF iSCSI standard, which creates a new industry standard SAN technology
based on internet protocols: TCP/IP. Any updates to the standard will be available
for downloads to the HBA. iSCSI enables new IP-based SANs, which are similar to
Fibre Channel SANs, as well as a new set of storage applications, for example,
remote storage.

The QLA4010/4010C HBA implements the complete protocol stack, including
TCP/IP, on the HBA and off-loads the host of any I/O protocol processing. Off-loading
the host frees the system to perform other tasks and deliver optimum total system
performance. The QLA4010/4010C HBA handles complete SCSI transactions,
iSCSI, TCP/IP, and Ethernet.

IS0053302-00 B 1-1

1 – Introduction
Features

1.3

Features

■ Compliance with PCI Local Bus Specification revision 2.2 and PCI-X

Specification revision 1.0a

■ Supports the IETF iSCSI standard, with soft upgrades as the standard evolves

■ 32/64-bit, 33/66/133-MHz universal PCI-X

■ 1-Gbps, full-duplex Ethernet

■ Complete TCP/IP protocol off-load

■ iSCSI initiator and target modes

■ RJ45 Gigabit Ethernet connector (QLA4010C HBA)

■ Small form factor (LC) fiber optic connector (QLA4010 HBA)

1.4

Technical Support

Q

1.4.1

Availability

1.4.2

Training

Customers should contact their authorized maintenance provider for technical
support of their QLogic HBA products. QLogic-direct customers may contact QLogic
Technical Support; others will be redirected to their authorized maintenance
provider.

Visit the QLogic support Web site listed in section 1.4.3 for the latest firmware and
software updates.

QLogic Technical Support is available from 7:00 AM to 7:00 PM Central Standard
Time, Monday through Friday, excluding QLogic-observed holidays.

QLogic offers certification training for the technical professional for both the
SANblade HBAs and the SANbox switches. From the training link at

www.qlogic.com

intensive "hands-on" Certification course.

Technical Certification courses include installation, maintenance and
troubleshooting QLogic SAN products. Upon demonstrating knowledge using live
equipment, QLogic awards a certificate identifying the student as a Certified
Professional. The training professionals at QLogic may be reached by email at

[e-mail]

, you may choose Electronic-Based Training or schedule an

.

1-2 IS0053302-00 B

Q

1.4.3

Contact Information

Address: QLogic Corporation

Telephone: [phone]

Fax: [phone]

Email:

Technical Service
Technical Training

HBA Support Web Site: support.qlogic.com

1 – Introduction

Technical Support

6321 Bury Drive
Eden Prairie, Minnesota 55346
USA

[e-mail]
[e-mail]

IS0053302-00 B 1-3

1 – Introduction
Technical Support

Notes

Q

1-4 IS0053302-00 B

QLA4010/4010C

2.1

Installation in the Computer

NOTE: For a Solaris SPARC operating system, the driver must be installed before

installation of the HBA. See the associated readme.txt file for detailed
instructions on how to install the driver.

Before you install the QLA4010/4010C HBA in your computer, you need the
following:

■ A screwdriver (usually a Phillips #1)

■ An optical mutimode cable with an LC-style duplex connector for the QLA4010

HBA.

■ A Cat5e or Cat6 straight-through cable (not cross-over cable) with an RJ45

connector for the QLA4010C HBA.

Section 2

CAUTION!

Perform the following steps to install the QLA4010/4010C HBA in your PC:

1. Check the motherboard and make any configuration changes necessary to
accommodate the QLA4010/4010C HBA.

The QLA4010/4010C HBA is self-configuring; however, some motherboards
require manual configuration. For example, some systems have a PCI Device
Configuration menu in the motherboard setup BIOS where you must enable
HBAs, bus master slots, and IRQ levels. If the motherboard supports triggering,
use level triggering for the QLA4010/4010C HBA. See the documentation
supplied with your computer, or contact your computer dealer to determine if
your motherboard requires configuration.

2. Power down the peripherals, then the computer.

3. Remove the computer cover and save the screws.

4. Choose any PCI bus slot that supports bus mastering. Most motherboards
automatically assign an IRQ level and interrupt line; if your motherboard does
not, you must assign the IRQ level and use interrupt line A for this slot.

The QLA4010/4010C HBA contains parts that can be damaged by
ESD. Before handling the QLA4010/4010C HBA, use standard
methods to discharge static electricity. Keep the QLA4010/4010C
HBA in the antistatic bag until you are ready to install it. Place the HBA
on the bag when you examine or configure it. Retain the bag for future
use.

IS0053302-00 B 2-1

2 – QLA4010/4010C
Installation in the Computer

NOTE:

Q

■ Some motherboards have two kinds of PCI bus slots: master and

slave. The QLA4010/4010C HBA must be in a PCI bus master slot.
(Some motherboards have PCI bus master slots that are shared with
onboard devices. QLA4010/4010C HBAs do not work in shared slots.)

■ PCI connectors vary among system HBA manufacturers. The

QLA4010/4010C HBA is a 64-bit PCI device that can function in a
32-bit PCI slot as long as the slot conforms to the PCI specification
(the rear edge of the PCI slot is notched). If you try to install the
QLA4010/4010C HBA into a PCI slot that does not conform to the PCI
specification, you may damage the QLA4010/4010C HBA.

■ PCI and PCI-X slots look the same. If the PC contains both PCI and

PCI-X slots, refer to the PC manufacturer’s instructions to determine
the slot type.

■ The QLA4010/4010C HBAs are designed and tested to operate at PCI

bus speeds of up to 66 MHz and PCI-X bus speeds of up to 133 MHz.

5. Remove the slot cover for the slot in which you will install the QLA4010/4010C
HBA.

6. Place the QLA4010/4010C HBA into the slot. Carefully press the HBA into the
slot until it seats firmly.

7. Secure the QLA4010/4010C HBA to the chassis. Follow the PC manufacturer’s
instructions.

8. Connect the appropriate cable from the devices to the corresponding connector.

9. Carefully reinstall the computer cover. Insert and tighten the computer cover
screws.

10. Power up the PC.

For Solaris SPARC systems, restart the system with the following command:

reboot -- -r

In addition, modify the system sd.conf file (/kernel/drv/sd.conf) for the operating
system (OS) to recognize new targets. QLogic recommends adding up to 255
targets. The QLA4010 supports up to 128 devices. The QLA4010 does not
support booting from a target attached to QLA4010.

11. Install the appropriate driver. See the associated readme.txt files for detailed
instructions on how to install the software drivers.

Optionally, you can customize the QLA4010/4010C HBA and its attached devices
using the Fast!UTIL BIOS utility. See the associated readme.txt file for detailed
instructions.

2-2 IS0053302-00 B

Q

2.2

Specifications

Tables 2-1 and 2-2 define the QLA4010/4010C HBA specifications.

Operating temperature 0°C/32°F 55°C/131°F

Storage temperature –20°C/–4°F 70°C/158°F

Relative humidity (noncondensing) 10% 90%

Storage humidity (noncondensing) 5% 95%

Universal PCI specifications PCI Local Bus Specification, revision 2.2

Standards IP v.4

Connectors Optical mutimode cable with an LC-style duplex connector

Form factor PCI short card

Operating power 15 watts

2 – QLA4010/4010C

Label

Table 2-1. QLA4010/4010C HBA Operating Environment

Environment Minimum Maximum

Table 2-2. QLA4010/4010C HBA Specifications

Type Specifications

PCI-X Specification, revision 1.0a
32/64-bit, 33/66/133 MHz

3.3-V and 5-V buses supported (± five percent)

SCSI Architecture Model (SAM-2)
SCSI-3 Command Set

(QLA4010 HBA)
Cat5e or Cat6 straight-through cable (not cross-over

cable) with an RJ45 connector (QLA4010C HBA)

2.3

Label

The transceiver on the QLA4010 HBA is a Class I laser product. It complies with
IEC 825-1 and FDA 21 CFR 1040.10 and 1040.11. The transceiver must be
operated under recommended operating conditions.

CLASS I LASER PRODUCT

IS0053302-00 B 2-3

2 – QLA4010/4010C
Agency Certification

2.4

Agency Certification

The following sections contain a summary of EMC/EMI test specifications performed
on QLA4010/QLA4010C (IS0410401/IS0510401) to comply with radiated emission,
radiated immunity and product safety standards.

2.4.1

QLA4010

2.4.2

EMI and EMC Requirements

The QLA4010 conforms to the following requirements:

■ FCC Part 15, Class B

❑ Radiated Emission Class B
❑ Conducted Emission Class B
❑ ICES-003 Class B

Q

■ 89/336/EEC EMC Directive CE

❑ EN55022:1998/CISPR:1997 Class B

❑ Radiated Emission Class B
❑ Conducted Emission Class B

❑ EN55024:1998

❑ Immunity Standards
❑ EN61000-4-2:1995 ESD
❑ EN61000-4-3:1995 RF Electro Magnetic Field
❑ EN61000-4-4:1995 Fast Transient/Burst
❑ EN61000-4-5:1995 Fast Surge Common/Differential
❑ EN61000-4-6:1996 RF Conducted Susceptibility
❑ EN61000-4-8:1994 Power Frequency Magnetic Filed
❑ EN61000-4-11:1994 Voltage Dips and Interrupt

❑ EN61000-3-2:1995 Harmonic Current Emission

❑ EN61000-3-3:1994 Voltage Fluctuation and Flicker

■ VCCI, Class B

■ CNS 13438, Class B

■ AS/NZS 3548, Class B

2-4 IS0053302-00 B

Q

2.4.3

Product Safety Requirements

■ UL, cUL

❑ UL60950
❑ CSA C22.2 No.60950 Third Edition 2000
❑ Class I laser product per DHHS 21CFR J

■ 73/23/EEC Low Voltage Directive

❑ TUV:

❑ EV60950-1:2001
❑ EN60825-1:1994+A11+A2

2.4.4

QLA4010C

2.4.5

EMI and EMC Requirements

2 – QLA4010/4010C

Agency Certification

The QLA4010C conforms to the following requirements:

■ FCC Part 15, Class B

❑ Radiated Emission Class B
❑ Conducted Emission Class B
❑ ICES-003 Class B

■ 89/336/EEC EMC Directive CE

❑ EN55022:1998/CISPR:1997 Class B

❑ Radiated Emission Class B
❑ Conducted Emission Class B

❑ EN55024:1998

❑ Immunity Standards
❑ EN61000-4-2:1995 ESD
❑ EN61000-4-3:1995 RF Electro Magnetic Field
❑ EN61000-4-4:1995 Fast Transient/Burst
❑ EN61000-4-5:1995 Fast Surge Common/Differential
❑ EN61000-4-6:1996 RF Conducted Susceptibility
❑ EN61000-4-8:1994 Power Frequency Magnetic Filed
❑ EN61000-4-11:1994 Voltage Dips and Interrupt

❑ EN61000-3-2:1995 Harmonic Current Emission

❑ EN61000-3-3:1994 Voltage Fluctuation and Flicker

IS0053302-00 B 2-5

2 – QLA4010/4010C
Agency Certification

■ VCCI, Class B

■ CNS 13438, Class B

■ AS/NZS 3548, Class B

2.4.6

Product Safety Requirements

■ UL, cUL

❑ UL60950 Third Edition 2000
❑ CSA C22.2 No.60950

■ 73/23/EEC Low Voltage Directive

❑ TUV:

❑ EV60950-1:2001

Q

2-6 IS0053302-00 B
