USER’S MANUAL
PPHP1291 PPHP1591
PPHP1294A PPHP1594A
PPHP1299AI PPHP1599AI
www.pyleaudio.com
Before using your new Speaker System Please review the
following instructions, for the safety and investment.
INSTRUCTIONS
Before connecting the speaker, make sure the system is off and the controls on the minimum
level. On the contrary the system could damage
1. - Plug the power cable to the AC outlet and to the system and to the speaker
2. - Plug the Microphone in the “MIC” input
3.- Connect (CD, DECK, MP3, DVD, etc) on “LINE IN” input
4.- Turn on the systems. A green LED will light up to indicate the speaker is on
5.- Set the volume on the low level on the MIC and the LINE IN input
6.- Increase the master volume (place on the right side of LINE OUT* connector)
7.- Set TREBLE and BASS controls to equalize the sound.
8.- A red LED will light up when the system detects overload power. You will must decrease
the volume.
CAUTIONS
Do not place the microphone against the speaker, it can cause feedback echo and it will
damage the system
EXTRA FUNCTIONS
6.3 and canon connectors marked as LINE OUT can handle an amplifier or even another
powered speaker cabinet ,in cascade. On the bottom of the speaker there is a hole to place
a stand.
1
FEATURES:
PPHP1291: 12” 1000 Watt 2 Way Plastic Molded Speaker Cabinet
• 12'' Woofer
• 1.4'' Titanium Compression Driver
• 1/4” and Speakon Jacks input
• Frequency response: 50-20 KHz
• Power :1000 Watts
• Impedance: 8 ohm
• Crossover Frequency: 3.5K Hz
• 35mm Speaker Stand Mount
• Dimensions: W15.6” x D12” x H 23.3”
PPHP1294A: 12” 1000 Watt Powered 2 W ay P lastic Molded Speaker Cabinet
• 12" Woofer
• 1.4" Titanium Compression Driver
• Dual XLR and 1/4" Mic Inputs
• XLR Stereo RCA Line Input
• XLR and 1/4" Line Outputs
• Master Volume, Bass Treble Controls
• Frequency response: 50-20 KHz
• Power Output: 1000 Watts
• Crossover Frequency: 3.5K Hz
• 35mm Speaker Stand Mount
• 110/220 Voltage Selectable
• Dimensions: W15.6” x D12” x H 23.3”
PPHP1299AI: 12” 1000 Watt Powered 2 Way Plastic Molded Speaker Cabinet w/Built in
MP3 & Ipod Dock
• Power Switch and Digital amplifier.
• 12" Woofer
• 1.4" Titanium Compression Driver
• MP3 control with LCD display
• USB Terminal
• IPOD DOCK
• XLR and 1/4" Mic Inputs
• XLR Stereo RCA Line Input
• XLR and 1/4" Line Outputs
• Volume, Bass Treble Controls
• Frequency response: 50-20 KHz
