Pyle PUCVC38 User Manual

IMPORTANT SAFE GUARDS

When using an electrical appliance, basic safety preacautions should be observed, including
following:

READ ALL INSTRUCTIONS BEFORE USING YOUR VACUUM CLEANER
Warning: To reduce the risk of re, electrical shock, or injury

1. Do not leave appliance when plugged in. Unplug from outlet when not in use.

2. Do not use outdoors or on wet surfaces.

3. Do not allow to be used as a toy. Close attention is necessary when used by or near children.

4. Use only as described in this manual. Use only manufacturer's recommended attachments.

5. Do not use with damaged cord or plug. Do not use vacuum if it has been dropped,
damaged, left outdoors, or dropped in water. Return it to an authorized service center.

6. Do not pull or carry by cord, use cord as a handle, or pull cord around sharp edges or
corners.

7. Do not run appliance over cord. Keep cord away from heated surfaces.

8. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.

9. Do not handle plug or appliance with wet hands.

10. Do not put any object into openings. Do not use with any opening blocked; keep free of
dust, lint, hair and anything that may reduce air ow.

11. Keep hair, loose clothing, ngers, and all parts of body away from openings and moving
parts.

12. Do not pick up anything that is burning or smoking, such as cigarettes, matches, or ashes.

13. Turn o the control before unplugging.

14. Use extra care when cleaning stairs.

15. Do not use to pick up ammable or combustible liquids such as gasoline or use in areas
where they may be present.

16. Look on your vacuum and follow all label and marking instructions.

17. Keep end of hose, wands and other openings away from your face and body.

18. Do not use the vacuum cleaner without dust cup lter in place.

19. Always unplug this appliance before connecting or disconnecting vacuum hose.

20. Store the vacuum indoors. Put the vacuum away after us to prevent tripping accidents.

21. Using improper voltage may result in damage to the motor and possible injury to the user.
Correct voltage is listed on the rating label.

22. Use only on dry, indoor surfaces.

23. Do not use in any purpose other than described in this user's guide.

24. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualied persons in order to avoid a hazard..

1

www.PyleUSA.com

VACUUM CLEANER

PUCVC38

1. MAIN FLOOR BRUSH

2. EXTENSION TUBE

3. DUST TANK LOCK

4. POWER SWITCH

5. DUST TANK

6. DUST TANK UPPER PART RELEASE BUTTON

7. DUST TANK BOTTOM RELEASE BUTTON

8. MULTI CREVICE BRUSH

9. UNIVERSAL MULTI BRUSH

10. PET BRUSH

2

www.PyleUSA.com

PRECAUTIONARY MEASURES

If the opening that suck in the air, the brush or extension tubes are blocked, you should switch
o the vacuum cleaner at once. First clear the blocked substance before you attempt to start
the vacuum cleaner again.

1. Do not operate the
vacuum cleaner too close to
heaters like radiators,
cigarette butts etc.

2. Before you insert the plug
into the wall contact, make
sure your hand is dry.

3. Before you start using the
vacuum cleaner, please
remove large or sharp
objects from the oor in
order to prevent damage to
the lters. Do not use the
vacuum to clean anything
that can easily burn, such as
gas and cigarettes.

4. When you want to pull the
plug from the wall contact,
please pull the plug by itself
and not by the electrical
cable.

3

www.PyleUSA.com

ASSEMBLING VACUUM CLEANER

Always remove the plug from the power socket before tting or removing accessories!

1. Fitting the vacuum
cleaner

Install the brush to the
body before using the
vacuum.
Attach the brush properly
to the body.

2. Extension tube

You can use the extension
tubes to connect the
sucking mouth of the
machine directly with the
oor brush.
Connect the Multi brush(2
in 1 ) to the sucking
mouth of the machine to
clean furnitures, TV,
shelves,etc.

3. Remove and install the
dust cup
(a) Remove dust cup from
body: push the release

button of dust cup. Then
take out the dust cup from
body. (g. A)

(b) Install dust cup on
body: make the underside

of dust cup to connect with
the body. (pls pay attention
to the tting position and
direction). Then push the
dust cup to close the body.
The dust cup will be locked
after a voice of "kata".(g.B).

1. Push Here

2. Move

g. A

g. B

www.PyleUSA.com

4

CLEANING THE APPLIANCE

A.How to drop dust and clean the
dust cup

1. Remove the dust cup from body.

2. Press the dust cup bottom release
button, then the dust will fall down
automatically. (fig. A)

3. If the plastic filter system is too
dirty, please press the dust cup cover
(for air exhaust) release button, take
out the filter assembly out of the dust
cup, then you can clean them with soft
brush or wash them with water. You
should dry them completely before
you use it again.(fig.B).

B.Changing or cleaning the sponge
and HEPA filter

1. Remove the dust cup from body.

2. Rotate the dust cup cover counter­clockwise from “close” to “open”, take
out the dust cup cover. Draw out the
sponge and HEPA filter set. (fig. A)

3. Pull up the knob of the filter frame,
and pull out the sponge filter and
HEPA filter from the case box. Clean
the Sponge and HEPA filter by soft
brush or rinse it in lukewarm water
and dry them completely before using
again. All the filters are washable. (we
recommend you to clean the filters
when the suction power becoming
weak.) (fig.B)

Note: The above filters should be
equipped in correct places when the
vacuum machine is working.

Sponge and

HEPA Filter

g. A

5

g. B

www.PyleUSA.com

TROUBLESHOOTING GUIDE

PROBLEM POSSIBLE REASON POSSIBLE SOLUTION

Hand Vacuum won’t
operate

Hand Vacuum won't
pick up or suction
power is weak

Dust escaping from
hand vacuum

Hand Vacuum brush
wont pickup

1. No power in electrical
outlet supplying the
transformer.

2. The unit needs to be
serviced

1. The DUST CUP may be full

2. Dust cup lter needs
cleaning

1. Dust cup is full.

2. The dust lter dust cup
and cup bottom may not be
attached properly

3. Puncture/hole in dust cup
lter

1. Dust cup is full.

1. Check the fuse or breaker
and replace them.

1. Empty dust cup
(see page 7).

2.Connect the charger.

1. Empty the dust cup

2. Review dust cup lter
instructions

3. Replace dust cup lter

1.Empty and clean dust cup
container.
