240 Watt Public Address Power Amplifier, w/ 70V Output & Mic
Talkover, USB/SD Card MP3 Player, Built-in FM Radio
MODEL:PT510 PA AMPLIFIER
FRONT PANEL- PT510
10
5
4
6
11 12 14 15
13 16
1 2
7
3
8 9
REAR PANEL- PT510
22 23
17 18 19 20 21
MODEL:PT51 0 PA AMPLIFIER
1. MIC1 Volume Control
-Volume control for MIC1.
2. MIC2 Volume Control
-Volume control for MIC2.
3. AUX-IN VOLU ME C ONTROL
- Allow you to control any high level sou nd s ource inputs (by 1/4"
Audio Input, 1/8 " iPod/MP3 input, and RCA Audio In pu t to connect
any high level sound source inputs) .
4.LOW Tone Control
-Lets you adjust the sound o f ba ss frequency to the acoustic of a
Particular performance enviro nm ent.
5. MID Tone Control
-Lets you adjust the sound o f mi ddle range frequency to the acoustic
of a Particular performance envir on ment.
6. HIGH Tone Control
-Lets you adjust the sound o f tr eble frequency to the acoustic of a
Particular performance enviro nm ent.
7. MIC1 1/ 4" Input Jack
8. MIC2 1/ 4" Input Jack
9. Audio 1/4" Input Jack
-allow you to connect any hi gh l ev el sound source, such as a CD
player, tape deck, or tuner, to the CD/ AUX jack.
10.IPOD/MP3 1 /8" Input Jack
-Let you easily connect th e co mputerized MP3 Device( play er )
sources, such as PC( CD ROM),Laptop, Walkman, iPo d, a nd C ell
Phone, iPhone, iPAD, ect.
11. MASTER Vo lu me C ontrol
-Lets you adjust the overa ll s ound level.
12.SD/MMC Soc ke t for Playing SD/MMC cards.
13.Function Blue LED Dis pl ay Window.
14.USB Socket for playin g th e USB function.
15.Keys for MP3(U SB/SD/MMC) Functi on C ontrol:
-EQ: Equalizer adjustm en t for the USB/ SD.
-SD/USB: Swit ch b etween the USB and SD playing.
-Vol-/V OL +: Adjust MP3(USB /SD) volume- or volume+
- Power on or off for MP3(U SB /SD/MMC)
MODEL:PT51 0 PA AMPLIFIER
-DOWN/UP: Song Selecti on C ontrol both for MP3(USB/SD/MMC)
and FM Tuner
-PLAY/PAUSE: Play or Pause control for MP 3( USB/SD/MMC) and
FM Tuner.
16.Power On/O ff for the Whole Machine.
17.AC INPUT
-When plug the power suppl y ca bl e on the machine, pls make sure
the swtich as above is in the proper posi ti on befor operating,
18.AC OUTLET
-Unswitched AC Accessa ry O utlet- 300W MAX.
19.Push-Terminal Connectors
-Let you easily connect th e sp eaker wires directly to the amplifier s
20.FAN: Cooling Fan
21.AUX INPUT JACK
-Allows you to connect any h ig h level sound source, such as a CD
player, tape deck, or tun er , to the CD/ AUX jack.
22.110V/ 22 0V Vo lt age Switch
-The amplifier has selec ta ble input voltage from 110V/ 60Hz which is
the standard in USA and CANADA. You c an a lso switch the input
voltage to 220V/ 50Hz for E UR OPEAN operation. Pls make sure the
swtich as above is in the proper positi on b efor operating,
23.ANT
-Connect for FM Antennas
510
mic1
mic2
Thi s exa mpl e sho ws a two
4 ohm spea ker, a nd th e
total im ped anc e is 8 ohm s
TO THE 8-OH M TE RM IN AL
Thi s exa mpl e sho ws
a 4 ohm spea ker
Thi s exa mpl e sho ws a two
4 ohm spea ker, a nd th e
tot al im ped anc e is 8 ohm s
4 ohm 10 W
speake r
50W
240W
12.6x7.48x3. 15
32x19x8(cm)
4.2KGS
