www.pyleaudio.com
amplifiers
damage.
improperly serviced, or subject to misuse, neglect, or accidental
This warranty will be considered void if theunit was tampered with,
replacement of the defective unit when it is returned to us prepaid.
Our obligation under this warranty is limited to the repair or
expiration date.
handling, and insurance, or provide your Visa/MC number with
• also include a check or money orderfor $18.00 for return shipping,
and R.A. number
• include in your letter your return address, daytime phone number,
• A brief letter indicating the problem you are experiencing
• A copy of your sales receipt or other proof of purchase
You must also include the following items:
Brooklyn, NY 11204
1600 63rd Street
Pyle Service Center
R.A.#
and shipped prepaid to:
When returning a product to usfor warranty service it must be carefullypacked
relating to your return.
R.A.# must appear on the outside of your package and on all paperwork
number at (718) 236-6948 to obtain a Return Authorization number. This
To obtain warranty service you must first call our Consumer Return Hotline
your unit will be repaired or replaced at the sole discretion of Pyle.
Should the product fail due to factory defects in material or workmanship,
warranty is limited to the original retail purchase.
in material and workmanship for two (2) years from the date of purchase. This
shipment. Products purchased in the USA are warranted to be free of defects
All Pyle products are carefully constructed and thoroughly tested before
limited warranty policy
user’s manual
PLA2180
PLA2280
PLA2380
PLA4180
PLA4280
PLA4380
PLA2480
PLA2580
PLA2680
high performance car audio amplifier
congratulations...
on your purchase of a Pyle
extends the Pyle tradition into a totally new series of amps, designed
from the ground up to deliver the power, performance and flexibility
the modern car audio enthusiast demands.
When you check the list of features offered by the PLA2180,PLA2280,
PLA2380,PLA2480,PLA2580,PLA2680,PLA4180,PLA4280,PLA4380,you’ll
Red Elite
Series amplifier. This amplifier
know you made the right choice with a Pyle
table of contents
general features
features and specifications
PLA2180/2280/2380
PLA2480/2580/2680
features and specifications
PLA4180/4280/4380
electrical connections
PLA2180/2280/2380
PLA2480/2580/2680
PLA4180/4280/4380
stereo input connections
PLA2180/2280/2380
PLA2480/2580/2680
mono input connections
PLA2180/2280/2380
PLA2480/2580/2680
2/4 channel input connections
PLA4180/4280/4380
2-5
6-11
12-15
16-17
18
19
20
Red Elite
high level input connections
amplifier.
PLA4180/4280/4380
mono input connections
PLA4180/4280/4380
high level mono input connections
PLA4180/4280/4380
speaker connections
PLA2180/2280/2380
PLA2480/2580/2680
speaker connections
PLA4180/4280/4380
speaker connections
PLA4180/4280/4380
mounting and installation
protection circuitry and troubleshooting
precautions
21
22
23
24
25
26
27
28
29
general features
PLA2180
High Performance 600 Watt 2 Channel
Bridgeable MOSFET Amplifier
· 300 Watts x 2 Output
· 600 Watts x 1 Bridged Output
· Variable Hi/Lo Electronic Crossover Network
· Variable Bass Boost (0 - +18 dB @ 60Hz)
· Variable Input Level (Gain) Control
· Remote Turn On/Off
· Gold Plated RCA Inputs
· High Level MOLEX Input
· Power ON LED Indicator
· LED Protection Indicator
· S/N Ratio: > 95 dB
· THD: <0.04%
· Thermal Protection
· Overload Protection
· Short Circuit Protection
· Anti-Thump Turn-On
· Blue LED Level Display
PLA2280
High Performance 1000 Watt 2 Channel
Bridgeable MOSFET Amplifier
· 500 Watts x 2 Output
· 1000 Watts x 1 Bridged Output
· Variable Hi/Lo Electronic Crossover Network
· Variable Bass Boost (0 - +18 dB @ 60Hz)
· Variable Input Level (Gain) Control
· Remote Turn On/Off
· Gold Plated RCA Inputs
· High Level MOLEX Input
· Power ON LED Indicator
· LED Protection Indicator
· Remote Bass Boost
· S/N Ratio: > 95 dB
· THD: <0.04%
· Thermal Protection
· Overload Protection
· Short Circuit Protection
· Anti-Thump Turn-On
· Blue LED Level Display
PLA2380
High Performance 1400 Watt 2 Channel
Bridgeable MOSFET Amplifier
· 700 Watts x 2 Output
· 1400 Watts x 1 Bridged Output
· Variable Hi/Lo Electronic Crossover Network
· Variable Bass Boost (0 - +18 dB @ 60Hz)
· Variable Input Level (Gain) Control
· Remote Turn On/Off
· Gold Plated RCA Inputs
· High Level MOLEX Input
· Power ON LED Indicator
· LED Protection Indicator
· Remote Bass Boost
· S/N Ratio: > 95 dB
· THD: <0.04%
· Thermal Protection
· Overload Protection
· Short Circuit Protection
· Anti-Thump Turn-On
· Blue LED Level Display
2
PLA2480
High Performance 1600 Watt 2 Channel
Bridgeable MOSFET Amplifier
· 800 Watts x 2 Output
· 1600W x 1 Bridged Output
· Variable Hi/Lo Electronic Crossover Network
· Variable Bass Boost (0 - +18 dB @ 60Hz)
· Variable Input Level (Gain) Control
· Remote Turn On/Off
· Gold Plated RCA Inputs
· High Level MOLEX Inputs
· Power ON LED Indicator
· LED Protection Indicator
· Remote Bass Boost
· S/N Ratio: > 95 dB
· THD: <0.04%
· Thermal Protection
· Overload Protection
· Short Circuit Protection
· Anti-Thump Turn-On
· Blue LED Level Display
PLA2580
High Performance 1800 Watt 2 Channel
Bridgeable MOSFET Amplifier
· 900 Watts x 2 Output
· 1800W x 1 Bridged Output
· Variable Hi/Lo Electronic Crossover Network
· Variable Bass Boost (0 - +18 dB @ 60Hz)
· Variable Input Level (Gain) Control
· Remote Turn On/Off
· Gold Plated RCA Inputs
· High Level MOLEX Inputs
· Power ON LED Indicator
· LED Protection Indicator
· Remote Bass Boost
· S/N Ratio: > 95 dB
· THD: <0.04%
· Thermal Protection
· Overload Protection
· Short Circuit Protection
· Anti-Thump Turn-On
· Blue LED Level Display
PLA2680
High Performance 2400 Watt 2 Channel
Bridgeable MOSFET Amplifier
· 1200 Watts x 2 Output
· 2400W x 1 Bridged Output
· Variable Hi/Lo Electronic Crossover Network
· Variable Bass Boost (0 - +18 dB @ 60Hz)
· Variable Input Level (Gain) Control
· Remote Turn On/Off
· Gold Plated RCA Inputs
· High Level MOLEX Inputs
· Power ON LED Indicator
· LED Protection Indicator
· Remote Bass Boost
· S/N Ratio: > 95 dB
· THD: <0.04%
· Thermal Protection
· Overload Protection
· Short Circuit Protection
· Anti-Thump Turn-On
· Blue LED Level Display
3
features and controls
2 ch amp PLA2180.PLA2280
PLA2180
PLA2280
power LED
protection LED
remote bass boost
(PLA2180 without)
high pass frequency control
low pass frequency control
speaker connections
power fuse
high level inputs
low level inputs
input level control
crossover mode selector
bass boost level
power terminals
6
crossover mode selector
input level control
low pass frequency control
high pass frequency control
Remote Bass Boost
bass boost level control
low level inputs
high level inputs
power LED
protection LED
power fuse
power terminals
speaker connections
features and specifications
2 ch amp PLA2180.PLA2280
when used with normal, full range systems, set this switch to “FULL.” If
you wish to use the internal crossoverto power a driver of specific frequency
range, use the “LOWPASS” or “HIGHPASS” settings.
use this control to match the outputs of your head unit to the amplifier.
Starting with your head unit set at about the 2 o’clock position, increase
the amp level control until distortion begins to occur, and reduce slightly
from this point.
when the crossover selector switch is in “low pass” mode,this control sets
the upper frequency limit for audio program sent to the speakers.
when the crossover selector switch is in “high pass” mode, this control
sets the lower frequency limit for audio program sent to the speakers.
Plug in the Remote Bass Boost Control wire in here.
this control permits adjustment of the bass level up to an increase of
approximately 18 dB.
this amp features gold-plated RCA input jacks for high impedance input.
Use these with car stereo output which uses RCA-type connector cables.
if your car stereo lacks RCA-type output jacks, you may connect speaker
output leads to these input connectors.
this indicator is illuminated when power is applied.
this indicator is illuminated when built-in protection circuitry is activated.
the fuse protects the amplifier and your car’s electrical system from short
circuit conditions.
use these connectors to deliver power, groundand remote turn-on control
to the amplifier.
these terminals are 14K gold plated to guarantee high conductivity and
minimum signal loss.
output power @ 14.4v DC, 1KHz
RMS Power @ 4 Ohms
RMS Power @ 2 Ohms
Maximum Power Output
frequency response
input impedance
low level inputs
high level inputs
input sensitivity
low level inputs
high level inputs
power supply voltage
matching speaker impedance
stereo mode
bridged mode
maximum current draw
dimensions (WxHxL)
mm
inches
PLA2180
2 channel amplifier
40 Watts x 2
70 Watts x 2
300 Watts x 2
15 Hz-30 KHz
10K Ohms
100 Ohms
250mV
2.5V
14.4V DC Neg. Ground (10.5-16V)
2-4 Ohms
4-8 Ohms
15A
276 x 69.5 x 209
10.9 x 2.7 x 8.25
PLA2280
2 channel amplifier
75 Watts x 2
110 Watts x 2
500 Watts x 2
20A
276 x 69.5 x 305
10.9 x 2.7 x 12
7
features and controls
2 ch amp PLA2380.PLA2480
PLA2380
PLA2480
power LED
protection LED
remote bass boost
high pass frequency control
low pass frequency control
speaker connections
power fuse
high level inputs
low level inputs
input level control
crossover mode selector
bass boost level
power terminals
8
crossover mode selector
input level control
low pass frequency control
high pass frequency control
Remote Bass Boost
bass boost level control
low level inputs
high level inputs
power LED
protection LED
power fuse
power terminals
speaker connections
features and specifications
2 ch amp PLA2380.PLA2480
when used with normal, full range systems, set this switch to “FULL.” If
you wish to use the internal crossoverto power a driver of specific frequency
range, use the “LOWPASS” or “HIGHPASS” settings.
use this control to match the outputs of your head unit to the amplifier.
Starting with your head unit set at about the 2 o’clock position, increase
the amp level control until distortion begins to occur, and reduce slightly
from this point.
when the crossover selector switch is in “low pass” mode,this control sets
the upper frequency limit for audio program sent to the speakers.
when the crossover selector switch is in “high pass” mode, this control
sets the lower frequency limit for audio program sent to the speakers.
Plug in the Remote Bass Boost Control wire in here.
this control permits adjustment of the bass level up to an increase of
approximately 18 dB.
this amp features gold-plated RCA input jacks for high impedance input.
Use these with car stereo output which uses RCA-type connector cables.
if your car stereo lacks RCA-type output jacks, you may connect speaker
output leads to these input connectors.
this indicator is illuminated when power is applied.
this indicator is illuminated when built-in protection circuitry is activated.
the fuse protects the amplifier and your car’s electrical system from short
circuit conditions.
use these connectors to deliver power, groundand remote turn-on control
to the amplifier.
these terminals are 14K gold plated to guarantee high conductivity and
minimum signal loss.
output power @ 14.4v DC, 1KHz
RMS Power @ 4 Ohms
RMS Power @ 2 Ohms
Maximum Power Output
frequency response
input impedance
low level inputs
high level inputs
input sensitivity
low level inputs
high level inputs
power supply voltage
matching speaker impedance
stereo mode
bridged mode
maximum current draw
dimensions (WxHxL)
mm
inches
PLA2380
2 channel amplifier
100 Watts x 2
150 Watts x 2
700 Watts x 2
15 Hz-30 KHz
10K Ohms
100 Ohms
250mV
2.5V
14.4V DC Neg. Ground (10.5-16V)
2-4 Ohms
4-8 Ohms
30A
276 x 69.5 x 343
10.9 x 2.7 x 13.5
PLA2480
2 channel amplifier
125 Watts x 2
180 Watts x 2
800 Watts x 2
30A
276 x 69.5 x 381
10.9 x 2.7 x 15
9
Loading...
