Pulse IMPSTAR 40 User Manual

40W Moving Head Beam with Halo

USER MANUAL

!

Keep This Manual For Future Need

Introduction

Unpacking: Thank you for purchasing the LED BEAM moving head wash, every
fixture has been thoroughly tested and has been shipped in perfect operating

condition. Carefully check the shipping carton for damage that may have
occurred during shipping. If the carton appears to be damaged, carefully
inspect your fixture for any damage and be sure all accessories necessary to
operate the unit has arrived intact. In the case damage has been found or
parts are missing, please contact the manufacturer or your dealer for further
instructions. Do not return this unit to your dealer without first contacting.

Warning! To prevent or reduce the risk of electrical shock or fire, do not
expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not attempt
any repairs yourself; doing so will void your manufactures warranty. In the
unlikely event your unit may require service please contact the manufacturer
or your dealer.

Features:

◇ Extremely small, fast and powerful LED moving beam.
◇ DMX Channels: 16/21 CH
◇ Pan: 540°; Tilt: 210°
◇ Electronic strobe with pulse and random effects
◇ High efficiency, low power consumption
◇ Super compact, low weight
◇ Beam angle: 8°

Voltage: 100V~240V, 50/60Hz
Light source: 40W RGBW LED with 5050 SMD 3-in-1
Power: 60W
Dimension: 290*210*270mm
Net Weight: 4.0 kg

Temperature

Press the ENTER button to when the Temperature test is blink on the
display. Pressing Enter button and the display will show the temperature of
the unit. To go back to the functions without any change press the MENU
button again. Hold and press the MENU button about one second or wait for
one minute to exit the menu mode.

Pro defaults

Press the MENU button to show PRO Defaults on the display. Use the DOWN
and UP button to select the YES (run built-in program to set the fixture to Pro
defaults settings) or No., Press the ENTER button to setup. To go back to the
functions without any change press the MENU button again. Hold and press the
MENU button about one second or wait for one minute to exit the menu mode.

How to control the unit

You can operate the unit in three ways.

1.Master/slave built-in preprogram function

2.Easy controller

3.Universal DMX controller
No need to turn the unit off when you change the DMX address ,as new DMX
address setting will be effect at once .Every time you turn the unit on. It will show
CM-120 on the display and move the motors to their position and you may hear
some noises for about 20 seconds. After that the unit will be ready to receive
DMX signal or run the built in programs

Sound sense

Select Sound sense, press the enter button to confirm, present mode will blink
On the display use the down and up button to change the sound sense from
0-100.once the mode has been selected .press the ENTER button to setup, to go
back to the functions without any change the MENU button again. Hold and
press the MENU button about one second or wait for one minute to exit the menu
mode.

Pan Reverse

With this function you can reverse the Pan-movement.

Tilt Reverse

With this function you can reverse the Tilt-movement.

17

000-010

No Function

011-044

5050 SMD section 1 Red

045-079

5050 SMD section 1 Green

080-114

5050 SMD section 1 Blue

115-149

5050 SMD section 1 Red mix Green

150-184

5050 SMD section 1 Red mix Blue

185-219

5050 SMD section 1 Green mix Blue

220-255

5050 SMD section 1 RGB

18

000-010

No Function
