PULSE 1048B-BN User Manual
Niagara ShowerSpa
Model #1048B-BN
Owner’s Manual
NIAGARA
Niagara ShowerSpa Model 1048B-BN
Please Read The Following Instructions
C O M P L E T E LY Before Beginning!
Our goal is to ensure your installation goes smoothly and safely. Please read these
instructions carefully and follow recommendations for plumbing and mounting. After
reading instructions, if you determine you do not have the necessary skills and/or
tools, we recommend that a licensed plumbing contractor complete the installation.
If you encounter any problems during installation
CALL TECHNICAL SUPPORT
TOLL FREE at 888-785-7320
Before returning your ShowerSpa to the store
You Will Need The Following Tools
Soft pencil or felt pen to mark tile
4mm allen wrench
Safety glasses
Tape measure
Level
Reciprocating saw w/metal cutting blade (Sawzall®)
Channel locks or adjustable wrench
Drill (Preferably cordless)
¼" Masonry drill bit
Phillips screwdriver
2
325 mm
12.80 in
70 mm
2.76 in
660 mm
25.98 in
700 mm
27.56 in
135 mm
5.31 in
135 mm
5.31 in
630 mm
24.80 in
250 mm
9.84 in
1350 mm
53.15 in
160 mm
6.3 in
300 mm
11.81 in
1150 mm
45.28 in
450 mm
17.72 in
Measured
To Top
Of Mount
Bracket
Measured
To Top
Of Mount
Bracket
Product Dimensions
3
