ProScan PLED2435A, PLED2400A, PLCD3992A, PLCD3992B, PLED1960A-F User Manual
...
please rea d t h i s m a n u a l c a r e f u l l y b e f o r e i n s t a l l i n g and operating the TV.
Keep this manual h a n d y f o r f u r t h e r r e f e r e n c e .
INSTRUCTION MANUAL
IMPORTANT
PLED2435A
- 1 -
SAFETY INSTRUCTIONS
Electricity is used to perform many useful functions, but it can also cause personal
injuries and property damage if improperly handled. This product has been
engineered and manufactured with the highest priority on safety. However,
improper use can result in electric shock and / or fire. In order to prevent potential
danger, please observe the following instructions when installing, operating and
cleaning the product. To ensure your safety and prolong the service life of your
Liquid Crystal Television, please read the following precautions carefully before
using the product.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade and the third
prong are provided for your safety. If the provided plug does not fit into your
outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at the
plugs, convenience receptacles, and the point where they exit from the
apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightening storms or when unused for long
periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
- 2 -
SAFETY INSTRUCTIONS
This product is designed and manufactured to operate within defined design limits, and misuse
may result in electric shock or fire. To prevent the product from being damaged, the following
rules should be observed for the installation, use and maintenance of the product. Read the
following safety instructions before operating the display. Keep these instructions in a safe
place for future reference.
• To avoid the risk of electric shock or
component damage, switch off the power
before connecting other components to
the TV.
• Unplug the power cord before cleaning
the TV. Please use the included custom
bezel cleaning cloth for cleaning the bezel
of the TV only. Do not use a liquid or a
spray cleaner for cleaning the product. Do
not use abrasive cleaners.
• Always use the accessories
recommended by the manufacturer to
insure compatibility.
• When moving the TV from an area of low
temperature to an area of high
temperature, condensation may form on
the housing. Do not turn on the TV
immediately after this to avoid causing fire,
electric shock or component damage.
• Do not place the TV on an unstable cart,
stand, or table. If the TV falls, it can injure
a person and cause serious damage to
the appliance. Use only a cart or stand
recommended by the manufacturer or
sold with the TV.
• Any heat source should maintain a
distance of at least 5 feet away from the
TV, i.e. radiator, heater, oven, amplifier
etc. Do not install the product too close to
anything that produces smoke or moisture.
Operating the product close to smoke or
moisture may cause fire or electric shock.
• Slots and openings in the back and
bottom of the cabinet are provided for
ventilation. To ensure reliable operation of
the TV and to protect it from overheating,
be sure these openings are not blocked or
covered. Do not place the TV in a
bookcase or cabinet unless proper
ventilation is provided.
• Never push any object into the ventilation
slots of the TV. Do not place any objects
on the top of the Product. It could short
circuit parts causing a fire or electric
shock. Never spill liquids on the TV.
• Do not use the TV in a portrait format (by
rotating 90 degrees) under high
temperature environment (25°C or higher),
since this would retard heat dissipation
and would eventually damage the TV.
• The TV should be operated only from the
type of power source indicated on the
label. If you are not sure of the type of
power supplied to your home, consult
your dealer or local power company.
• The power cable must be replaced when
using different voltage from that specified
in the User Manual. For more information,
contact your dealer.
• The TV is equipped with a three-pronged
grounded plug, a plug with a third
(grounding) pin. This plug will fit only into
a grounded power outlet as a safety
feature. If your outlet does not
accommodate the three-wire plug, have
an electrician install the correct outlet, or
use an adapter to ground the appliance
safely. Do not defeat the safety purpose
of the grounded plug.
• Do not overload power strips and
extension cords. Overloading can result in
fire or electric shock.
- 3 -
• The wall socket should be installed near
the equipment and should be easily
accessible.
• Only the marked power source can be
used for the product. Any power source
other than the specified one may cause
fire or electric shock.
• Do not touch the power cord during
thunderstorms. To avoid electric shock,
avoid handling the power cord during
electrical storms.
• Unplug the unit during a lightning storm or
when it will not be used for a long period
of time. This will protect the TV from
damage due to power surges.
• Do not attempt to repair or service the
product yourself. Opening or removing the
back cover may expose you to high
voltages, the risk of electric shock, and
other hazards. If repair is required, please
contact your dealer and refer all servicing
to qualified service personnel.
• Keep the product away from moisture. Do
not expose this appliance to rain or
moisture. If water penetrates into the
product, unplug the power cord and
contact your dealer. Continuous use in
this case may result in fire or electric
shock.
• Do not use the product if any abnormality
occurs. If any smoke or odor becomes
apparent, unplug the power cord and
contact your dealer immediately. Do not
try to repair the product yourself.
• Avoid using dropped or damaged
appliances. If the product is dropped and
the housing is damaged, the internal
components may function abnormally.
Unplug the power cord immediately and
contact your dealer for repair. Continued
use of the product may cause fire or
electric shock.
• Do not install the product in an area with
heavy dust or high humidity. Operating
the product in environments with heavy
dust or high humidity may cause fire or
electric shock.
• Hold the power connector when removing
the power cable. Pulling the power cable
itself may damage the wires inside the
cable and cause fire or electric shocks.
When the product will not be used for an
extended period of time, unplug the power
connector.
• To avoid risk of electric shock, do not
touch the connector with wet hands.
• Insert batteries in accordance with
instructions while using the remote control.
Incorrect polarities may cause damage
and leakage of the batteries, operator
injury and contamination the remote
control.
• If any of the following occurs please
contact the dealer:
o The power connector fails or
frays.
o Liquid sprays or any object
drops into the TV.
o The Display is exposed to rain
or other moisture.
o The Display is dropped or
damaged in any way.
o The performance of the
Display changes substantially.
• Operating environment: Temperature: 5°C
~ 35°C, Humidity: 10% to 90% noncondensing, Altitude: 0~10,000 ft.
- 4 -
IMPORTANT INFORMATION
Television Antenna Connection Protection
External Television Antenna Grounding
If an outside antenna or cable system is to be connected to the TV, make sure that the
antenna or cable system is electrically grounded to provide some protection against voltage
surges and static charges. Article 810 of the National Electrical Code, ANSI/NFPSA 70,
provides information with regard to proper grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna discharge unit, size of the grounding conductors,
location of antenna discharge unit, connection to grounding electrodes, and requirements of
the grounding electrode.
Lightning Protection
For added protection of the TV during a lightning storm or when it is left unattended or unused
for long periods of time, unplug the TV from the wall outlet and disconnect the antenna or
cable system.
Power Lines
Do not locate the antenna near overhead light or power circuits, or where it could fall into such
power lines or circuits.
- 5 -
Attaching or Removing the Stand
To attach the stand, place the display unit flat on a table. Afterwards match the 3 pins on the
neck to the 3 pin holes on the stand.
- 6 -
Table of Contents
SAFETY INSTRUCTIONS .............................................................................................. 1
SAFETY INSTRUCTIONS .............................................................................................. 2
IMPORTANT INFORMATION.........................................................................................4
Television Antenna Connection Protection................................................................ 4
Attaching or Removing the Stand................................................................................ 5
Table of Contents........................................................................................................... 6
Identifying Front and Rear Panel .................................................................................7
Front View .................................................................................................................7
Rear View Mounting Pattern ...................................................................................7
Side Control Buttons................................................................................................ 8
Rear View Connections ...........................................................................................9
Installing Batteries to the Remote Control.......................................................... 10
TV Remote Control ......................................................................................................11
Switching Sources....................................................................................................... 13
Ready to Watch Some TV? ......................................................................................... 14
If You’ve Connected Antenna or Cable to the TV… ........................................... 14
OSD (On Screen Display) Controls ............................................................................ 15
Via Remote Control ................................................................................................15
Via TV Side Panel Buttons..................................................................................... 15
OSD (On Screen Display) Options .............................................................................16
PICTURE..................................................................................................................17
SOUND.....................................................................................................................19
CHANNEL ................................................................................................................ 21
PARENTAL ..............................................................................................................22
SETUP......................................................................................................................2
4
OTHERS...................................................................................................................2
6
Detailed Explanations ................................................................................................. 27
USB Connection Explained ...................................................................................27
Closed Captioning (digital and analog) Explained ............................................. 2
9
Rating Explained .................................................................................................... 2
9
Aspect Ratio Explained ......................................................................................... 3
1
Shortcuts to Browsing Channels.......................................................................... 3
3
How do I clean the TV ? .........................................................................................3
4
Troubleshooting........................................................................................................... 3
5
Specification ................................................................................................................38
- 7 -
Identifying Front and Rear Panel
Front View
INDICATOR LIGHT – The light is red when power is plugged in but the TV is not turned on. The light turns
green when the TV is turned on. Because of the LED in the panel, the TV might take 10 – 12 seconds to
power on.
REMOTE SENSOR – The remote sensor receives all the commands from the remote control.
Rear View Mounting Pattern
Mounting Specification : 100mm x 100mm using screw size M4. Length of screw should not exceed 8mm.
Please Note : The 8mm length of screw refers to how deep the screw can go inside the mounting holes.
When you’re buying screws, you should add the original 8mm to the thickness of your mounting plate in
order to get the total screw length.
Indicator light
Remote sensor
- 8 -
Side Control Buttons
1. INPUT – This button switches between all the different sources of the TV. When the
OSD is active, this button acts as the enter button and confirms the menu selection.
2. MENU – This button activates the On Screen Display (OSD). If a sub-menu is active,
pressing this button will exit the OSD.
3. V+ – This button increases the TV’s volume. If a sub-menu is active, pressing this button
will move the select right.
4. V- – This button decreases the TV’s volume. If a sub-menu is active, pressing this button
will move the selection left.
5. P+ – This button changes the TV channel up. If the OSD is active, this button functions
as up for the menu.
6. P- – This button changes the TV channel down. If the OSD is active, this button
functions as down for the menu.
7. POWER – Turn on the TV by pressing the button once. Press the button again to turn off
the TV.
- 9 -
Rear View Connections
1. HEADPHONE – This connection is for headphones to be attached to the TV.
2. Audio In - This connection port is for people who want to provide audio to the TV
when using a PC or a DVI video device. The sources use 3.5mm mini-jack audio
cable.
3. TV – This connection is for digital or analog cable without the cable box or over-theairwave antennas. The tuner is a hybrid tuner that tunes to both analog and digital
channels. This connection uses coaxial RF cable.
4. VGA - This connection port connects to a PC for video using VGA cable. Be sure to
connect your audio cable to the VGA Stereo input if you want sound out of VGA
video source.
5. Video – Video connects to devices that use composite video cables such as VCR or
DVD player or Wii™. Connect the yellow for video and the red / white for audio.
This port shares the audio jacks with YPbPr.
6. HDMI– HDMI connects to devices that use HDMI cable, such as Blu-ray or HD DVD
player, or HD cable / satellite set-top box. This connection port receives pure digital
audio and high definition signal through one single cable. This port also can accept
a HDCP video device for video.
7. USB – USB connects to USB flash drives for playing music and picture. The USB
port is also used for updating the TV’s firmware.
- 10 -
8. YPbPr – This connection port is for DVD players or satellite / cable set-top boxes
that use component cables. From left to right, connect green, blue, and red for
video, and then connect white for left channel audio, and red for right channel audio.
This port shares the audio jacks with Video.
9. SPDIF - This connection port is used for sending out digital audio signals to digital
surround sound receivers. The orange (COAX SPDIF OUT) connector sends out
either bit-stream or PCM digital sound signal to a home theater receiver with digital
coax input.
Please Note:
• This TV features a power saving function which will turn off the TV
automatically after 10 minutes of idling on a connection with no signal. This
feature is present on all connection.
Installing Batteries to the Remote Control
Please insert the AAA batteries into the remote control. Make sure the (+) side and the (-) side are
installed correctly. When you are installing the battery, the remote’s backside should be facing up.
Afterwards, re-attach the battery cover.
Please note:
• Only use AAA batteries.
• Inserting the batteries incorrectly may also result in cracking or leakage that may pose a fire risk or
lead to personal injury.
• Dispose the batteries in accordance with local laws and regulations.
• Keep the batteries away from children and pets.
• If the remote control is not used for a long time, remove the batteries.
• Keep the remote control away from moisture, sunlight, and high temperatures.
- 11 -
TV Remote Control
1
3
2
4
5
6
7
8
9
11
10
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
30
29
Loading...
