Product information
Pro-Ject 1 Xpression III Comfort
Manual turntable with electronic
speed change, automatic
cut-off and fitted cartridge
Ortofon 2M Red
Turntable
Chassis piano-lacquered dark grey
A quiet running AC motor with a two-step metal pulley drives the hub and platter via a flat-ground belt.
The medium density fibre plinth stands on three height-adjustable rubber-damped aluminium cones.
The motor is decoupled from the plinth to reduce vibration transmission.
The resonance-optimised platter is a sandwich construction utilising the hub and an acrylic platter.
The platter's low-tolerance chrome-plated stainless-steel axle runs on a polished ball bearing in a brass
bearing housing.
Electronic speed change for 33 /45 r.p.m.. Switching to 78 r.p.m. is done manually.
An opto-electronic switch stops the motor as soon as the cartridge has reached the run-out groove.
Connection to the phono input of the amplifier can be made with connecting cables of your taste through the
gold plated phono sockets and earth screw. A standard cable is provided.
External power supply avoids potential electro-mechanical interference.
Tonearm Pro-Ject 8.6c
The turntable is supplied with Ortofon 2M Red-cartridge fitted.
Conical carbon-fibre armtube avoids standing wave reflections.
Low mass aluminium headshell securely glued to armtube.
The inverted bearings consist of four hardened stainless steel points bearing in sapphire cushes.
Flexible counterweight shaft avoids vibration at undesirable frequencies.
Solid armbase permits accurate height adjustment of armtube and VTA (vertical tracing angle).
Single-screw fixing of armtube allows rotation for easy adjustment of needle azimuth despite fixed headshell.
The straight armtube with an effective length of 8,6" reduces toe-in error.
Silicone-damped armlift can be adjusted to suit working height of the arm.
The internal wiring consists of flexible high-purity copper from the headshell right through to the gold-plated
phono sockets.
Dimensions W x H x D: With dust cover closed 415 x 118 x 320mm, dust cover open 415 x 365 x 405mm.
Cartridge: Output voltage 5,5mV. Recommended load resistance 47kohms (MM-input).
The manufacturer reserves the right to alter the technical specifications without notice.
The colours in the picture may differ slightly from the actual article due to inaccuracies in the printing process.
