Projecta TENSIONED ELPRO CONCEPT User Manual

TENSIONED ELPRO CONCEPT

Motorized projection screen for wall or ceiling installations

Watch the video:

Product specications:

• Electrically operated projection screen 230 volt (50Hz) with a usage of no more than 0.53 Ampere (121.9 Watt).

• The motor is mounted on the left side in the steel casing with rubber dampers to reduce sound.

• The motor is mounted inside the roller, 4 wire, 26 rotations per minute, maintenance free, integrated brake and thermal overload
cut-out.

• The 4 wire connection is integrated into the end cap and can be connected to the electric installation with the connector and
standard cable.

• Suitable for wall or ceiling mounting with the supplied mounting brackets which can be positioned within 50cm of either side of the
case.

• The leaf shaped steel casing (14,6 x 15,4cm) is galvanised on the inside and on the outside powder coated with a matte structure
coating (RAL 9016).

• The white end caps close the casing on both ends. After removing the left end cap an Easy Connectivity plug is accessible for
easy connecting of power and accessories.

• The triangular slat bar rolls into the case completely.

• The screen fabrics are ame retardant and seamless in the viewing area.

• Each side of the surface to have tab guide cable system to maintain even lateral tension and hold surface at.

• Custom slat bar with added weight maintains vertical tension on the screen surface. The ends of the slat to be protected by heavy
duty plastic caps enclosing a preset adjustable mechanism for screen tensioning.

• The projection fabrics have a black backing.

• Standard 3 position wall switch is supplied.

• The projection screen is CE marked and satises the strictest quality and safety requirements.

• Integrated RF receiver option: this version will have a 3 wire connection and will be supplied with a remote control.

Options: Aspect Ratios:

• RF - Radio frequency: Includes built-in radio frequency
receiver, making it possible to operate the screen using
the supplied remote control. Standard remote control
is supplied when selected this option.

Available dimensions

Minimum width:
Maximum width:

180 cm

380 cm

A BRAND OF MILESTONE AV TECHNOLOGIES BV www.milestone.com

P +31.(0)495.580.840 F +31.(0)495.580.845 [e-mail]

146 160

154

1

TENSIONED ELPRO CONCEPT

L2

500 mm 500 mm

L3
L1

Viewing Area Dimensions Black drop Net weight

cm L1 mm L2 mm L3 mm cm kg

119x190

131x210

144x230

169x270

181x290

194x310

206x330

218x350

231x370

96x170

107x190

118x210

129x230

152x270

163x290

174x310

186x330

197x350

208x370

72x170

81x190

89x210

98x230

115x270

123x290

132x310

140x 30

149x350

157x370

127x170

143x190

158x210

173x230

203x270

218x290

233x310

248x330

2331 1765 2127 30 27

2531 1965 2341 30 29

2731 2165 2515 30 31

3131 2565 2933 30 36

3331 2765 3145 30 38

3556 2990 3355 30 41

3776 3210 3567 30 43

3931 3365 3779 30 46

4131 3565 3991 30 49

2131 1565 1903 30 25

2331 1765 2113 30 27

2531 1965 2325 30 29

2731 2165 2539 30 31

3131 2565 2967 30 35

3331 2765 3181 30 38

3556 2990 3397 30 40

3776 3210 3615 30 43

3931 3365 3757 30 46

4131 3565 3969 30 48

2131 1565 1883 30 25

2331 1765 2091 30 27

2531 1965 2297 30 29

2731 2165 2505 30 31

3131 2565 2923 30 35

3331 2765 3131 30 37

3556 2990 3341 30 39

3776 3210 3551 30 42

3931 3365 3763 30 44

4131 3565 3973 30 47

2131 1565 1937 30 25

2331 1765 2155 30 27

2531 1965 2373 30 30

2731 2165 2537 30 32

3131 2565 2963 30 37

3331 2765 3177 30 39

3556 2990 3393 30 42

3776 3210 3609 30 44

16:10

16:9

2.35:1

4:3

129x200

141x220

154x240

179x280

191x300

204x320

216x340

228x360

241x380

102x180

117x200

128x220

139x240

162x280

173x300

184x320

196x340

207x360

218x380

82x180

91x200

99x220

108x240

125x280

133x300

142x320

150x340

159x360

167x380

138x180

153x200

168x220

183x240

213x280

228x300

243x320

258x340

A BRAND OF MILESTONE AV TECHNOLOGIES BV www.milestone.com

P +31.(0)495.580.840 F +31.(0)495.580.845 [e-mail]

2

TENSIONED ELPRO CONCEPT

High Contrast Cinema Vision Projection Screen

Da-Tex Projection Screen

Matte White (tensioned) Projection Screen

Gain

Pearlescent Projection Screen

HD Progressive 1.1 Projection Screen

Available standard resolution projection surfaces

All screen surfaces are seamless in the viewing area.

Matte White

Gain: 1.0
Viewing Angle: 120°
Base material: Vinyl
Fire retardancy: B2
Black backing: Yes
Opacity rating: > 99 %
Seamless: Yes
GreenGuard certification: Yes

Pearlescent

Gain: 1.5
Viewing Angle: 80°
Base material: Vinyl
Fire retardancy: B2
Black backing: Yes
Opacity rating: > 99 %
Seamless: Yes
GreenGuard certification: Yes

High Contrast Cinema Vision

Gain: 1.1
Viewing Angle: 100°
Base material: Vinyl
Fire retardancy: B2
Black backing: Yes
Opacity rating: > 99 %
Seamless: Yes
GreenGuard certification: Yes

Standard: UL 2818 - 2013

Standard for Chemical Emissions
for Building Materials, Finishes and
Furnishings

Certication number

Greenguard ­5100-410

Greenguard Gold ­5100-420

Standard: UL 2818 - 2013

Standard for Chemical Emissions
for Building Materials, Finishes and
Furnishings

Certication number

Greenguard ­5115-410

Greenguard Gold ­5115-420

Standard: UL 2818 - 2013

Standard for Chemical Emissions
for Building Materials, Finishes and
Furnishings

Certication number

Greenguard ­5112-410

Greenguard Gold ­5112-420

Gain

1.2

1.0

0.8

0.6

0.4

0.2

0.0

60° 55° 50° 45° 40° 35° 30° 25° 20° 15° 10° 5°

1.6

1.4

1.2

1.0

0.8

0.6

0.4

0.2

0.0

60° 55° 50° 45° 40° 35° 30° 25° 20° 15° 10° 5°

Gain

1.2

1.0

0.8

0.6

0.4

0.2

0.0
60° 55° 50° 45° 40° 35° 30° 25° 20° 15° 10° 5°

1.00

1.00

0.98

0.98

0.94

0.94

0.90

0.90

0.85

0.85

0.83

0.83

0° 5° 10° 15° 20° 25° 30° 35° 40° 45° 50° 55° 60°

Degrees Off Axis

1.50

1.38

1.19

1.03

0.90

0.83

0.79

0.76

0.73

0° 5° 10° 15° 20° 25° 30° 35° 40° 45° 50° 55° 60°

Degrees Off Axis

1.10

1.06

0.99

0.91

0.82

0.74

0.68

0° 5° 10° 15° 20° 25° 30° 35° 40° 45° 50° 55° 60°

Degrees Off Axis

0.81

0.81

0.80

0.80

0.78

0.78

0.77

0.77

0.76

0.76

0.74

0.74

0.72

0.72

0.71

0.68

0.66

0.63

0.64

0.61

0.58

0.56

0.54

0.52

Da-Tex (rear projection)

Gain: 1.3
Viewing Angle: 60°
Base material: Vinyl
Fire retardancy: B2
Seamless: Yes
GreenGuard certification: Yes

Available perforated projection surfaces

All screen surfaces are seamless in the viewing area.

HD Progressive 1.1 Perf

Gain: 1.1
Viewing Angle: 170°
Base material: Vinyl
Fire retardancy: B2
Black backing: Yes
Opacity rating: > 99 %
Seamless: Yes
GreenGuard certification: Yes
Hole diameter: 0.7 mm
Open area: 8.65%

Standard: UL 2818 - 2013

Standard for Chemical Emissions
for Building Materials, Finishes and
Furnishings

Certication number

Greenguard ­5106-410

Greenguard Gold ­5106-420

Standard: UL 2818 - 2013

Standard for Chemical Emissions
for Building Materials, Finishes and
Furnishings

Certication number

Greenguard ­11067-410

Greenguard Gold ­11067-420

Gain

1.4

1.2

1.0

0.8

0.6

0.4

0.2

0.0

60° 55° 50° 45° 40° 35° 30° 25° 20° 15° 10° 5°

Gain

1.2

1.0

0.8

0.6

0.4

0.2

0.0

60° 55° 50° 45° 40° 35° 30° 25° 20° 15° 10° 5°

1.30

1.09

0.82

0.61

0.48

0.41

0.37

0.33

0.31

0° 5° 10° 15° 20° 25° 30° 35° 40° 45° 50° 55° 60°

Degrees Off Axis

1.10

1.07

1.03

0.98

0.94

0.89

0.86

0.84

0° 5° 10° 15° 20° 25° 30° 35° 40° 45° 50° 55° 60°

Degrees Off Axis

0.29

0.28

0.27

0.25

0.82

0.81

0.78

0.76

0.73

A BRAND OF MILESTONE AV TECHNOLOGIES BV www.milestone.com

P +31.(0)495.580.840 F +31.(0)495.580.845 [e-mail]

3

TENSIONED ELPRO CONCEPT

HD Progressive 1.1 Projection Screen

HD Progressive 0.6 Projection Screen

HD Progressive 0.9 Projection Screen

Degrees Off Axis

HD Progressive 1.3 Projection Screen

Available High Resolution projection surfaces

All screen surfaces are seamless in the viewing area.

HD Progressive 0.6

Gain: 0.6
Viewing Angle: 170°
Base material: Vinyl
Fire retardancy: B2
Black backing: Yes
Opacity rating: > 99 %
Seamless: Yes
GreenGuard certification: Yes

HD Progressive 0.9

Gain: 0.9
Viewing Angle: 170°
Base material: Vinyl
Fire retardancy: B2
Black backing: Yes
Opacity rating: > 99 %
Seamless: Yes
GreenGuard certification: Yes

HD Progressive 1.1

Gain: 1.1
Viewing Angle: 170°
Base material: Vinyl
Fire retardancy: B2
Black backing: Yes
Opacity rating: > 99 %
Seamless: Yes
GreenGuard certification: Yes

Standard: UL 2818 - 2013

Standard for Chemical Emissions
for Building Materials, Finishes and
Furnishings

Certication number

Greenguard ­11065-410

Greenguard Gold ­11065-420

Standard: UL 2818 - 2013

Standard for Chemical Emissions
for Building Materials, Finishes and
Furnishings

Certication number

Greenguard ­11066-410

Greenguard Gold ­11066-420

Standard: UL 2818 - 2013

Standard for Chemical Emissions
for Building Materials, Finishes and
Furnishings

Certication number

Greenguard ­11067-410

Greenguard Gold ­11067-420

Gain

0.6

0.5

0.4

0.3

0.2

0.1

0.0

60° 55° 50° 45° 40° 35° 30° 25° 20° 15° 10° 5°

Gain

1.0

0.9

0.8

0.7

0.6

0.5

0.4

0.3

0.2

0.1

0.0

60° 55° 50° 45° 40° 35° 30° 25° 20° 15° 10° 5°

Gain

1.2

1.0

0.8

0.6

0.4

0.2

0.0

60° 55° 50° 45° 40° 35° 30° 25° 20° 15° 10° 5°

0.53

0.52

0.51

0.49

0.47

0.46

0° 5° 10° 15° 20° 25° 30° 35° 40° 45° 50° 55° 60°

Degrees Off Axis

0.90

0.89

0.86

0.82

0.78

0.75

0.72

0.71

0° 5° 10° 15° 20° 25° 30° 35° 40° 45° 50° 55° 60°

Degrees Off Axis

1.10

1.07

1.03

0.98

0.94

0.89

0° 5° 10° 15° 20° 25° 30° 35° 40° 45° 50° 55° 60°

Degrees Off Axis

0.44

0.43

0.42

0.41

0.40

0.39

0.38

0.69

0.68

0.66

0.65

0.62

0.86

0.84

0.82

0.81

0.78

0.76

0.73

HD Progressive 1.3

Gain: 1.3
Viewing Angle: 150°
Base material: Vinyl
Fire retardancy: B2
Black backing: Yes
Opacity rating: > 99 %
Seamless: Yes
GreenGuard certification: Yes

Certications

• Products are manufactured in an ISO14001 certied facility

• Projecta is an ISO 9001 certied company

• REACH - Registration, Evaluation, Authorisation and Restriction of Chemical substances.

• RoHS - Restriction of Hazardous Substances.

• WEEE - Waste Electronic and Electrical Equipment Regulations.

Customisation

Give exact the sizes of the projection screen you need:
Viewing size: _________ Heigth (cm.) x _________ width (cm.)
Surface: ________________________________Border top: _________ (cm.) Border bottom: _______ (cm.)
RAL color case and plastic parts: RAL _________
Motor positioned on right side Screen fabric mounted reversely

Remarks: _________________________________________________________________________________

Standard: UL 2818 - 2013

Standard for Chemical Emissions
for Building Materials, Finishes and
Furnishings

Certication number

Greenguard ­42729-410

Greenguard Gold ­42729-420

Gain

1.4

1.2

1.0

0.8

0.6

0.4

0.2

0.0

60° 55° 50° 45° 40° 35° 30° 25° 20° 15° 10° 5°

1.30

1.21

1.08

0° 5° 10° 15° 20° 25° 30° 35° 40° 45° 50° 55° 60°

A BRAND OF MILESTONE AV TECHNOLOGIES BV www.milestone.com

0.95

0.87

0.81

0.78

0.76

0.74

0.73

0.71

0.69

0.66

P +31.(0)495.580.840 F +31.(0)495.580.845 [e-mail]

4

TENSIONED ELPRO CONCEPT

Accessories - control options

For projection screens with a standard motor / delivered as standard with a wall switch

□ Easy Install RF remote control (868,3 Mhz)
□ Easy Install wireless projectorcoupling (868,3 Mhz)
□ Easy Install wireless RF wall switch (868,3 Mhz)
□ Easy Install RF remote control with projectorcoupling (868,3 Mhz)
□ Easy Install projectorcoupling with cable
□ Easy Install IR remote control
□ Easy Install plug & play relaybox with potential free contacts
□ Easy Install plug & play RS232/RS422 control kit
□ Easy Install plug & play RS232/RS422 with IP control kit
□ Keyswitch

For projection screens with an RF motor / delivered as standard with a remote control

□ RF wall-mounted transmitter (433,92 Mhz)
□ 4-channel RF remote control (433,92 Mhz)
□ Easy Install plug & play connector cable for RF screens 10 m

□ Easy Install plug & play connector cable for RF screens 5 m

Accessories - installation

□ Ceiling brackets (100 cm.)
□ Set extension brackets (75 cm.)
□ Set extension brackets (30 cm.)
□ Set extension brackets (10 cm.)

□ Bracket kit for easy mounting in soft

Elpro Concept - mounting bracket included

(Dimensions in mm)

front view top view side view

Warranty

Projecta provides a limited 5 year warranty on the Elpro Concept range and a limited 2 year warranty on all other
products. The warranty on the motor of electrical screens is 5 year. All warranties are in effect beginning the date the
product was invoiced by Projecta.

A BRAND OF MILESTONE AV TECHNOLOGIES BV www.milestone.com

P +31.(0)495.580.840 F +31.(0)495.580.845 [e-mail]

5
