Pro-Ject 2Xperience Classic User Manual

INSTRUCTIONS FOR USE

Pro-Ject 2 Xperience Acryl

Pro-Ject 2 Xperience Classic

5

2

© Audio Trade GmbH · Pro-Ject 2 Xperience Acryl / Classic / Ortofon 2M Red · Revision 2014.4.1

Pro-Ject 2 Xperience Acryl / Classic

Controls, features and connections

1 Motor transport locks
2 Stepped drive pulley
3 Drive belt * 3a Hook *
5 Sandwich platter *
6 Tonearm counterweight * 6a Downforce scale
7 Tonearm lift lever
8/18 Tonearm rest and removable transport lock
9 Tonearm tube 9a Tonearm base
10 Lid *
11 Lid hinges
12 Hinge fasteners
13 Power supply socket
14 Phono output sockets and earth connection
15 Anti-skating stub with anti-skating weight adjustment scale
16 Anti-skating weight *
17 Anti-skating weight support hoop
20 Power switch
21 Headshell with finger lift and optional fitted cartridge Ortofon 2M Red
22 Motor
23 Adjustable tip-toe feet with anti-scratch cups *

Screw-down record clamp (not shown) *
Connection cable (not shown) *
Power supply (not shown) *
Single adapter (not shown) *

Dear music lover,
thank you for purchasing a PRO-JECT AUDIO record player.

In order to achieve maximum performance and reliability with this record player you should study these instructions
for use carefully.

!

Warning of a hazard for the user, the unit or possible misuse.

Important notice.

The record player is supplied with a factory fitted and adjusted cartridge as an option.
** The following instructions for adjusting the cartridge are provided in case the cartridge is replaced by a
different model at a later date.
During assembly and adjustment of the deck small parts could be lost if not carefully placed in a suitable
receptacle. Before starting assembly make yourself acquainted with the parts listed above and correspondingly
numbered in the technical drawings above. Separately packed items are marked with an asterisk *.

Safety instructions

AC outlet voltages vary from country to country. Before connecting to the mains, make sure that the
voltage in your area meets the voltage requirements printed on the power supply.

The power supply is used to disconnect the unit from the mains. Make sure that the power supply is easily
accessible at all times.

!

Avoid letting liquids enter the device or the power supply. Never place any item containing liquid,
such as a flower vase on or near the device. Never spill any liquid on the device or the power supply.
Never place any naked flame sources, such as lighted candles on or near the device. The product shall not
be used in damp or wet locations, next to a bathtub, sink, swimming pool or any other similar conditions.

Keep plastic bags away from children to prevent any risk of suffocation.

Never handle the device, the power supply while your hands are wet or damp.

© Audio Trade GmbH · Pro-Ject 2 Xperience Classic / Acryl / Ortofon 2M Red · Revision 2014.4.1

3
