ProForm PETL616060 User Manual
Model No. PETL61606.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number Decal
QUESTIONS?
As a manufacturer, we are committed to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts,
please call:
08457 089 009
USER'S MANUAL
or write:
ICON Health & Fitness, Ltd.
Customer Service Department
Unit 4
Revie Road Industrial Estate
Revie Road
Beeston
Leeds, LS118JG
UK
email: csuk@iconeurope.com
CAUTION
Read all precautions and instruc
tions in this manual before using
this equipment. Save this manual
for future reference.
-
TABLE OF CONTENTS
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
HOW TO USE THE CHEST PULSE SENSOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
OPERATION AND ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
HOW TO FOLD AND MOVE THE TREADMILL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
CONDITIONING GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
ORDERING REPLACEMENT PARTS
Note: An EXPLODED DRAWING is attached in the center of this manual.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
PROFORM is a registered trademark of ICON IP, Inc.
2
IMPORTANT PRECAUTIONS
WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the
following important precautions and information before operating the treadmill.
1. It is the responsibility of the owner to ensure
hat all users of this treadmill are adequately
t
informed of all warnings and precautions.
2. Use the treadmill only as described.
3. Place the treadmill on a level surface, with at
least 2.5 m (8 ft.) of clearance behind it and
0.5 m (2 ft.) on each side. Do not place the
treadmill on a surface that blocks any air
openings. To protect the floor or carpet from
damage, place a mat under the treadmill.
4. Keep the treadmill indoors, away from mois-
ture and dust. Do not put the treadmill in a
garage or covered patio, or near water.
5. Do not operate the treadmill where aerosol
products are used or where oxygen is being
administered.
6. Keep children under the age of 12 and pets
away from the treadmill at all times.
7. The treadmill should be used only by persons
weighing 159 kg (350 lbs.) or less.
8. Never allow more than one person on the
treadmill at a time.
9. Wear appropriate exercise clothes when
using the treadmill. Do not wear loose clothes
that could become caught in the treadmill.
Athletic support clothes are recommended for
both men and women.
Always wear athletic
shoes. Never use the treadmill with bare feet,
wearing only stockings, or in sandals.
10. When connecting the power cord (see page
11), plug the power cord into an earthed cir
cuit. No other appliance should be on the
same circuit. When replacing the fuse, an
ASTA approved BS1362 type should be fitted
to the fuse carrier. A 13 amp fuse should be
used.
If an extension cord is needed, use only a 3-
11.
conductor, 1mm
longer than 1.5 m (5 ft.).
2
(14-gauge) cord that is no
-
12. Failure to use a properly functioning surge
uppressor could result in damage to the con-
s
trol system of the treadmill. If the control system is damaged, the walking belt may change
speed, accelerate, or stop unexpectedly,
which may result in a fall and serious injury.
13. Keep the power cord and the surge suppres-
sor away from heated surfaces.
14. Never move the walking belt while the power
is turned off. Do not operate the treadmill if
the power cord or plug is damaged, or if the
treadmill is not working properly. (See
TROUBLESHOOTING on page 26 if the treadmill is not working properly.)
15. Read, understand, and test the emergency
stop procedure before using the treadmill (see
HOW TO TURN ON THE POWER on page 13).
16. Never start the treadmill while you are stand-
ing on the walking belt. Always hold the
handrails while using the treadmill.
17. The treadmill is capable of high speeds.
Adjust the speed in small increments to avoid
sudden jumps in speed.
18. The pulse sensor is not a medical device.
Various factors, including the user's movement, may affect the accuracy of heart rate
readings. The pulse sensor is intended only
as an exercise aid in determining heart rate
trends in general.
19. Never leave the treadmill unattended while it
is running. Always remove the key, unplug
the power cord, and switch the on/off switch
to the off position when the treadmill is not in
use. (See the drawing on page 5 for the location of the on/off switch.)
20. Do not attempt to raise, lower, or move the
treadmill until it is properly assembled. (See
ASSEMBLY on page 6, and HOW TO FOLD
AND MOVE THE TREADMILL on page 24.) You
must be able to safely lift 20 kg (45 lbs.) to
raise, lower, or move the treadmill.
3
21. Do not change the incline of the treadmill by
lacing objects under the treadmill.
p
22. When folding or moving the treadmill, make
sure that the frame is held securely by the pin
n the latch knob.
o
23. Inspect and properly tighten all parts of the
readmill regularly.
t
24. Never insert or drop any object into any
opening.
25.
DANGER: Always unplug the power
ord immediately after use, before cleaning
c
the treadmill, and before performing the main-
enance and adjustment procedures de-
t
scribed in this manual. Never remove the
motor hood unless instructed to do so by an
authorized service representative. Servicing
other than the procedures in this manual
should be performed by an authorized service
representative only.
26. The treadmill is intended for in-home use
only. Do not use the treadmill in a commercial, rental, or institutional setting.
WARNING: Before beginning this or any exercise program, consult your physician. This
is especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. ICON assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.
SAVE THESE INSTRUCTIONS
The decals shown here have been placed on the
treadmill. If a decal is missing or illegible, call
the telephone number on the front cover of this
manual and request a free replacement decal.
Apply the decal in the location shown. Note:
The decals may not be shown at actual size.
4
BEFORE YOU BEGIN
Thank you for selecting the revolutionary PROFORM
20 V treadmill. The 620 V treadmill offers an impres-
6
sive selection of features designed to make your workouts at home more enjoyable and effective. And when
you’re not exercising, the unique 620 V treadmill can
e folded up, requiring less than half the floor space of
b
other treadmills.
For your benefit, read this manual carefully before
using the treadmill
TV Console
Accessory Tray
Handrail
Pulse Sensor
. If you have questions after read-
®
ing this manual, please see the front cover of this man-
al. To help us assist you, note the product model
u
number and serial number before contacting us. The
model number of the treadmill is PETL61606.0. The
serial number can be found on a decal attached to the
readmill (see the front cover of this manual for the lo-
t
cation).
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
Book Holder
Key/Clip
Fan
Walking Belt
Foot Rail
Rear Roller
Adjustment Bolts
Circuit Breaker
On/Off Switch
Cushioned
Walking Platform
5
ASSEMBLY
1/2” Silver Screw
(48)–1
3/4” Tek Screw (58)–4
Spacer Screw (60)–2
4
1/2” Bolt (78)–4
W
asher (96)–8
Pfostenschraube (72)–4
3/4” Schraube (4)–4
Pfosten-Zahnscheibe
(90)–10
Haltestangenschraube (64)–6
ssembly requires two persons.Set the treadmill in a cleared area and remove all packing materials. Do not
A
dispose of the packing materials until assembly is completed.
Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a
small amount of lubricant may be transferred to the top of the walking belt or the shipping carton. This is a normal
condition and does not affect treadmill performance. If there is lubricant on top of the walking belt, simply wipe off
the lubricant with a soft cloth and a mild, non-abrasive cleaner.
Assembly requires the included hex key and your own phillips screwdriver . For help
identifying the assembly hardware, see the drawings below.
is the key number of the part, from the PART LIST on pages 30 and 31. The number following the parentheses is
the quantity needed for assembly.
the parts bag, check to see if it has been preassembled. To avoid damaging plastic parts, do not use
power tools for assembly.
Note: Some small parts may have been preassembled. If a part is not in
The number in parentheses below each drawing
1. Make sure that the power cord is unplugged.
With the help of a second person, lift the front of
the treadmill and insert the crossbar on the Base
(83) into the cutout in the cardboard stand as
shown at the right. Have the second person
securely hold the cardboard stand and the
treadmill until assembly step 2 is completed.
WARNING: Serious injury
may occur if the treadmill moves forward or backward and falls off the cardboard stand. A second person must securely hold the cardboard stand and the
treadmill until assembly step 2 is completed to prevent the treadmill from
moving, tipping, or falling.
1
83
Cardboard
Stand
6
2. Identify the Left Upright (73) and the Right
Upright (74). Hold the Right Upright near the
ight Base Cover (77) as shown. Insert the
R
Upright Wire Harness (75) up through the rec-
angular hole in the bottom of the Right Upright
t
and out of the top of the Right Upright.
Gently pull up on the Upright Wire Harness (75)
as you set the Right Upright (74) on the Base
(83) inside the Right Base Cover (77). Be care-
ful not to pinch the Upright Wire Harness.
Attach the Right Upright (74) to the Base (83)
with two Upright Bolts (72) and two Star
Washers (90). Note: It may be necessary to tip
the top of the Right Upright forward slightly as
you thread the Upright Bolts into the Right
Upright.
Attach the Left Upright (73) to the Base (83) in
the same way. Note: There is not an upright wire
harness on the left side.
2
3
7
5
7
74
77
83
90
With the help of a second person, lower the
treadmill and discard the cardboard stand.
3. Identify the Right Upright Sleeve (96) and the
Left Upright Sleeve (95). Slide the Right Upright
Sleeve onto the Right Upright (74) and the Left
Upright Sleeve onto the Left Upright (73).
72
3
95
73
“Left”
74
“Right”
96
7
4. With the help of a second person, hold the console assembly near the Uprights (73, 74).
Connect the Upright Wire Harness (75) to the
onsole Wire Harness (71). M
C
nect the connectors properly (see the inset
drawing). The connectors should slide together easily and snap into place.
not, turn one connector and try again. IF THE
CONNECTORS ARE NOT CONNECTED
PROPERLY, THE CONSOLE MAY BE DAMAGED WHEN THE POWER IS TURNED ON.
ake sure to con-
If they do
4
Console
Assembly
73
71
75
5. Insert the brackets on the Handrails (99) into the
Right Upright (74) and the Left Upright (73).
Make sure that no wires are pinched.
71
75
5
99
73
74
74
99
Finger
6.
three Star Washers (90) into the Right Upright
(74). Next, finger tighten three Handrail Bolts
with three Star Washers (not shown) into the
Left Upright (73). Then, firmly tighten all six
Handrail Bolts.
tighten three Handrail Bolts (64) with
6
73
64
90
74
90
64
8
7. Slide the Right Upright Sleeve (96) against the
console assembly. Attach the Right Upright
leeve with two 3/4" Screws (4).
S
ttach the Left Upright Sleeve (not shown) to the
A
Left Upright (73) in the same way.
7
3
7
4
96
4
8. Make sure that all parts are properly tightened before you use the treadmill. Keep the included hex key
in a secure place; the hex key is used to adjust the walking belt (see page 27). To protect the floor or carpet
from damage, place a mat under the treadmill.
74
9
HOW TO USE THE CHEST PULSE SENSOR
OW TO PUT ON THE CHEST PULSE SENSOR
H
he chest pulse sensor consists of two components:
T
the chest strap and the sensor unit (see the drawing
below). Insert the tab on one end of the chest strap into
the hole in one end of the sensor unit, as shown in the
inset drawing. Press the end of the sensor unit under
the buckle on the chest strap. The tab should be flush
with the front of the sensor unit.
Chest Strap
Tabs
Tab
Sensor Unit
Next, wrap the chest
pulse sensor around
your chest and attach
the other end of the
chest strap to the
sensor unit. Adjust
the length of the
chest strap, if necessary. The chest pulse
sensor should be under your clothes, tight against your
skin, and as high under the pectoral muscles or
breasts as is comfortable. Make sure that the logo on
the sensor unit is facing forward and is right-side-up.
Sensor
Unit
Buckle
Store the chest pulse sensor in a warm, dry place.
•
Do not store the chest pulse sensor in a plastic bag
r other container that may trap moisture.
o
• Do not expose the chest pulse sensor to direct sun-
ight for extended periods of time; do not expose it to
l
temperatures above 50° C (120° F) or below -10° C
(15° F).
• Do not excessively bend or stretch the sensor unit
when using or storing the chest pulse sensor.
• Clean the sensor unit using a damp cloth—never
use alcohol, abrasives, or chemicals. The chest
strap may be hand washed and air dried.
CHEST PULSE SENSOR TROUBLESHOOTING
The instructions on the following pages explain
how the chest pulse sensor is used with the console. If the chest pulse sensor does not function
properly, try the steps below.
• Make sure that you are wearing the chest pulse sensor as described at the left. Note: If the chest pulse
sensor does not function when positioned as described, move it slightly lower or higher on your chest.
• Use saline solution such as saliva or contact lens
solution to wet the two electrode areas on the sensor
unit. If heart rate readings do not appear until you
begin perspiring, rewet the electrode areas.
• As you walk or run on the treadmill, position yourself near the center of the walking belt. For the con-
sole to display heart rate readings, the user must
be within arm’s length of the console.
Next, pull the sensor unit away from your body a few
inches and locate the two electrode areas on the inner
side (the electrode areas are covered by shallow
ridges). Using saline solution such as saliva or contact
lens solution, wet both electrode areas. Return the
sensor unit to a position against your chest.
CHEST PULSE SENSOR CARE AND MAINTENANCE
• Thoroughly dry the chest pulse sensor after each
use. The chest pulse sensor is activated when the
electrode areas are wetted and the heart rate
monitor is put on; the chest pulse sensor shuts off
when it is removed and the electrode areas are
dried. If the chest pulse sensor is not dried after
each use, it may remain activated longer than necessary, draining the battery prematurely.
The chest pulse sensor is designed to work with
•
people who have normal heart rhythms. Heart rate
reading problems may be caused by medical conditions such as premature ventricular contractions
(pvcs), tachycardia bursts, and arrhythmia.
• The operation of the chest pulse sensor can be affected by magnetic interference caused by high
power lines or other sources. If it is suspected that
this is a problem, try relocating the treadmill.
• The CR2032 battery may need to be replaced (see
page 28).
10
OPERATION AND ADJUSTMENT
THE PRE-LUBRICATED WALKING BELT
Your treadmill features a walking belt coated with high-performance lubricant. IMPORTANT: Never apply silicone spray or other substances to the walking belt or the walking platform. Such substances will deteriorate the walking belt and cause excessive wear.
HOW TO PLUG IN THE POWER CORD
This product must be earthed. If it should malfunction or break
down, earthing provides a path of least resistance for electric current to reduce the risk of electric shock. This product is equipped
with a power cord having an equipment-earthing conductor and an
earthing plug.
be replaced with a manufacturer-recommended power cord.
See drawing 1. Plug the indicated end of the power cord into the
socket on the treadmill.
See drawing 2. Press the pins on the power cord into the metal clips
in the adapter as shown. Close the adapter cover over the end of the
power cord and tighten the screw in the adapter.
sure that the adapter cover is secure and the screw has been
tightened before using the power cord.
See drawing 3. Plug the power cord into an appropriate outlet that is
properly installed and earthed in accordance with all local codes and
ordinances. Important: The treadmill is not compatible with
GFCI-equipped outlets.
Important: If the power cord is damaged, it must
Important: Make
1
2
Screw
Adapter
3
Socket on treadmill
Adapter
Cover
Pins
Metal
Clips
Outlet
DANGER: Improper connection of the equipment-earthing conductor can result in an in-
creased risk of electric shock. Check with a qualified electrician or serviceman if you are in doubt as
to whether the product is properly earthed. Do not modify the plug provided with the product—if it will
not fit the outlet, have a proper outlet installed by a qualified electrician.
1
1
Loading...
