Proel WM101 USER’S MANUAL

WM101

Wireless Microphone System

USER’S MANUAL

ITALIANO

ENGLISH

96MAN0106-R EV. 14/15

DISPOSAL OF OLD ELECTRICAL & ELECTRONIC EQUIPMENT ................................................................... 3

SAFETY INSTRUCTIONS ............................................................................................................................ 3

IN CASE OF FAULT .................................................................................................................................... 3

PACKAGING, SHIPPING AND COMPLAINT ............................................................................................... 4

WARRANTY AND PRODUCTS RETURN ..................................................................................................... 4

MAINTENANCE AND DISCLAIMER ........................................................................................................... 4

POWER SUPPLY ........................................................................................................................................ 4

USER’S WARNINGS AND CE CONFORMITY .............................................................................................. 5

INTRODUCTION ....................................................................................................................................... 6

DESCRIPTION ........................................................................................................................................... 6

WM101 RECEIVER .................................................................................................................................... 6

WM11M HANDHELD TRANSMITTER ....................................................................................................... 7

WM11B BODYPACK TRANSMITTER ......................................................................................................... 7

TECHNICAL SPECIFICATION ...................................................................................................................... 8

DISPOSAL OF OLD ELECTRICAL & ELECTRONIC EQUIPMENT

This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life. To prevent possible harm to the enviroment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.

Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take this item for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal.

SAFETY INSTRUCTIONS

• CAUTION - Before using this product read carefully the following safety instructions. Take a look of this

manual entirely and preserve it for future reference. When using any electric product, basic precautions should always be taken, including the following:

• To reduce the risk, close supervision is necessary when the product is used near children.

• Protect the apparatus from atmospheric agents and keep it away from water, rain and high humidity

places.

• This product should be site away from heat sources such as radiators, lamps and any other device that

generate heat.

• Care should be taken so that objects and liquids do not go inside the product..

• The product should be connected to a power supply only of the type described on the operating

instructions or as marked on the product.

IN CASE OF FAULT

• In case of fault or maintenance this product should be inspected only by qualified service personnel

when:  Liquids have spilled inside the product.

 The product has fallen and been damaged.  The product does not appear to operate normally or exhibits a marked change in performance.

• Do not operate on the product, it has no user-serviceable parts inside.

• Refer servicing to an authorized maintenance centre.

PACKAGING, SHIPPING AND COMPLAINT

• This unit package has been submitted to ISTA 1A integrity tests. We suggest you control the unit

conditions immediately after unpacking it.

• If any damage is found, immediately advise the dealer. Keep all unit packaging parts to allow inspection.

• Proel is not responsible for any damage that occurs during shipment..

• Products are sold “delivered ex warehouse” and shipment is at charge and risk of the buyer.

• Possible damages to unit should be immediately notified to forwarder. Each complaint for manumitted

package should be done within eight days from product receipt.

WARRANTY AND PRODUCTS RETURN

• Proel products have operating warranty and comply their specifications, as stated by manufacturer..

• Proel warrants all materials, workmanship and proper operation of this product for a period of two years

from the original date of purchase. If any defects are found in the materials or workmanship or if the product fails to function properly during the applicable warranty period, the owner should inform about these defects the dealer or the distributor, providing receipt or invoice of date of purchase and defect detailed description. This warranty does not extend to damage resulting from improper installation, misuse, neglect or abuse. Proel S.p.A. will verify damage on returned units, and when the unit has been properly used and warranty is still valid, then the unit will be replaced or repaired. Proel S.p.A. is not responsible for any "direct damage" or "indirect damage" caused by product defectiveness.

MAINTENANCE AND DISCLAIMER

• Clean only with dry cloth.

• Proel products have been expressly designed for audio application, with signals in audio range (20Hz to

20kHz). Proel has no liability for damages caused in case of lack of maintenance, modifications, improper use or improper installation non-applying safety instructions.

• Proel S.p.A. reserves the right to change these specifications at any time without notice..

• Proel S.p.A. declines any liability for damages to objects or persons caused by lacks of maintenance,

improper use, installation not performed with safety precautions and at the state of the art.

POWER SUPPLY

• This apparatus should only be connected to power source type specified in this owner’s manual or on the

unit.

• If the supplied AC power cable plug is different from the wall socket, please contact an electrician to

change the AC power plug.

• Hold the plug and the wall outlet while disconnecting the unit from AC power.

• If the unit will not be used for a long period of time, please unplug the power cord from AC power outlet.

• To av oid unit power cord damage, please do not strain the AC power cable and do not bundle it.

• In order to avoid unit power cord damage, please ensure that the power cord is not stepped on or

pinched by heavy objects.

USER’S WARNINGS AND CE CONFORMITY

• LICENSING INFORMATION: This radio equipment operates in the 863-865 MHz harmonized European

band dedicated to SRD (short range devices) like wireless microphone and IEM personal monitor systems, so in the countries specified in the below table no personal license is required for use it.

• The use of this wireless microphone equipment in some countries could be intended for professional use,

so the licensability depends on the country it operates. Proel suggests the user to contact the appropriate telecommunications authority concerning proper licensing.

• This equipment may be capable of operating on some frequencies not authorized in your country. Please

contact your national authority to obtain information on authorized frequencies for wireless microphone products in your region.

• The product is in compliance with Directive LVD 2006 / 95 / EC as stated in EN 60065 and EN 50371

standard.

• PROEL S.p.A hereby, declares that this wireless microphone system complies with the essential

requirements and other relevant provisions of Directive R&TTE 1999 / 5 / EC as stated in EN 300422-1; EN 300422-2; EN 301489-01; EN 300489-09 standard.

• The full and detailed declaration of conformity can be downloaded from the web site:

www.proel.com

TAB LE OF THE AUTHORIZED FREQUENCIES FOR THE WM101 WIRELESS MICROPHONE SYSTEM IN EUROPE

UPDATED WITH REFERENCE TO ERC-REC 70-03E DOCUMENT DATED FEBRUARY 7 2014

COUNTRY CODE

WM11M / WM11B TRANSMITTING FREQUENCIES

863.100

864.350

864.850

AT BE CY CZ DK EE DE GR HU IT LV LT LU NL

PL PT SK SI SE GB IS LI CH BG RO TR UA IE MT NO ES FR

• • •

Individual license required

GE RU

NOT IMPLEMENTED

IN ALL COUNTRIES THE USE OF WIRELESS MICROPHONES SYSTEMS IS SUBJECT TO ANY TELEVISION AND

BROADCAST TRANSMISSION

CONSULT LOCAL OR NATIONAL RADIO SPECTRUM AUTHORITIES FOR INFORMATION ON POSSIBLE

RESTRICTIONS OR NECESSARY AUTHORIZATIONS BEFORE USING THIS SHORT RANGE DEVICE.

INTRODUCTION

Thank you for choosing this PROEL product and for your trust in our brand, synonymous of professionalism, accuracy, high quality and reliability. All our products are CE approved and designed for continuous use in professional systems.

DESCRIPTION

The WM101 Wireless Microphones series is a UHF, quartz controlled, fixed frequency device, which provides a reliable, high quality signal transmission.

WM101 Wireless Microphone system features 3 units: WM101 receiver, WM11M handheld transmitter and WM11B body pack transmitter. The system is available in three different configurations, each of them including an ABS carrying case:

WM101M : WM101 + WM11M WM101H : WM101 + WM11B + Headset WM101KIT : WM101 + WM11M + WM11B + Headset

Three factory pre-build frequencies are available, which have been selected to allow the simultaneous use of 3 devices without interference between them (depending on the circumstances):

1. 863.100 MHz

2. 864.350 MHz

3. 864.850 MHz

WM101 RECEIVER

See FIG. 1 at page 15:

1. DC IN

Socket for the AC/DC adaptor connection, use only the adaptor supplied with the system.

2. AUDIO OUT (UNBALANCED)

Unbalanced audio output with line level: connect it through a mono 6.3mm jack cable to a mixer input.

3. PWR / VOLUME

On/off switch and volume potentiometer: set this control to a proper level that doesn’t saturate the mixer input channel.

4. ON

Red LED: if lighted states that the power supply is present and the receiver is turned on.

5. RF

Green LED: if lighted states that the transmitter is sending a radio signal to the receiver.

6. AF

Yellow LED: illuminates when an audio signal is present.

7. ANTENNA

This is the receiving antennas. Raise it up during the use and, to obtain a better reception, place the receiver away from other metal objects and no more distant than 25m from the transmitter.

8. RECEIVING FREQUENCY

In this label, together with the general data of the receiver, you can find the receiving radio frequency. In case of use of more radio apparatus it must correspond to the frequency of the wireless transmitter that will be used.
