840104600
Use & Care for Citrus Juicer.................................... 2
USA: 1-800-851-8900
Utilisation et entretien pour citrus juicer ....................
7
Canada : 1-800-267-2826
840104600 ENv02.qxd 12/11/02 4:37 PM Page 1
Digitally signed by Elizabeth DeMerchant
cn=Elizabeth DeMerchant, o=Hamilton Beach / Proctor-Silex, c=US
Date: 2002.12.13 15:18:52 -05'00'
Reason: I am approving this document
4.25 X 5.5", English/French, 12 pages, Black Ink, No Bleeds, Map
3
2
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS
When using electrical appliances basic safety precautions should be
observed, including the following:
1. Read all instructions.
2. To protect against risk of electric shock, do not immerse base,
cord, or plug in water or other liquid.
3. Close supervision is necessary when any appliance is used by or
near children.
4. UNPLUG FROM OUTLET WHEN NOT IN USE, before putting
on or taking off parts and before cleaning.
5. Avoid contact with moving parts.
6. Do not operate any appliance with a damaged cord or plug, or
after the appliance malfunctions, or is dropped or damaged in any
manner. Call our toll-free customer service number for information
on examination, repair, or electrical or mechanical adjustment.
7. The use of attachments not recommended or sold by Hamilton
Beach/Proctor-Silex, Inc. may cause fire, electric shock, or injury.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter or touch hot
surfaces, including stove.
This appliance intended for household use only.
This appliance is equipped with a polarized plug. This type of plug has
one blade wider than the other. The plug will fit into an electrical outlet
only one way. This is a safety feature intended to help reduce the risk of
electrical shock. If you are unable to insert the plug into the outlet, try
reversing the plug. If the plug should still fail to fit, contact a qualified
electrician to replace the obsolete outlet. Do not attempt to defeat the
safety purpose of the polarized plug by modifying the plug in any way.
CONSUMER SAFETY INFORMATION
The length of the cord used on this appliance was selected to
reduce the hazards of becoming tangled in, or tripping over a longer
cord. If a longer cord is necessary an approved extension cord may
be used. The electrical rating of the extension cord must be equal to
or greater than the rating of the juicer. Care must be taken to
arrange the extension cord so that it will not drape over the countertop or tabletop where it can be pulled on by children or accidentally
tripped over.
To avoid an electrical circuit overload, do not use another high
wattage appliance on the same circuit with your juicer.
Parts and Features
1. Lid
2. Reamer with pulp scrapers
3. Strainer
4. Pitcher with juice
level indicator
5. Center shaft
6. Base with cord storage
840104600 ENv02.qxd 12/11/02 4:37 PM Page 2
5
4
How to Use
1. Unplug from electrical outlet.
2. Place pitcher onto base. Hold base
and turn pitcher clockwise to lock.
The pitcher will stop when locked.
(Illustration A.)
3. To juice, place strainer and reamer
onto center shaft of juicer, aligning
handle of strainer with the handle of
the pitcher. (Illustration B.)
4. For juice with more pulp, separate
reamer from strainer by pulling apart.
Lock pitcher onto base following
instructions in 2. Place reamer onto
center shaft of juicer. (Illustration C.)
If reamer is used without strainer, the
juice will contain pulp and seeds.
When serving, pour juice through a
slotted spoon to remove the seeds.
5. Plug cord into 120 volt AC outlet.
6. Push down on reamer with halved
fruit to start the juicing action. Lift the
fruit up off the reamer and the juicer
stops. This juicer is designed with an
auto-reverse. It automatically reverses direction, from time to time, to
make juicing easier.
7. When finished juicing, unplug from outlet, then remove
reamer (and strainer if used).
How To Clean
1. Unplug from electrical outlet.
2. Lift off lid, reamer (and strainer if
used).
3. To unlock pitcher, hold base and
turn pitcher counterclockwise.
4. Lift pitcher to remove.
5 The lid, reamer, strainer, and pitcher
may be washed in hot, soapy water.
6. Wipe base with a damp cloth.
7. Wrap cord around cord storage (Illustration D).
Reassemble for storage.
Tips for Best Results
• This juicer is designed to juice citrus fruit such as oranges,
lemons, limes, and grapefruit.
• For maximum juice, fruit should be room temperature.
• Before juicing, roll fruit between countertop and palm of
your hand. Slice fruit in half, cutting across sections.
8. To unlock pitcher, hold base and turn pitcher counterclockwise. Place lid on pitcher.
9. Pour juice from pitcher. Store unused juice in pitcher in the
refrigerator.
Illustration B
Illustration A
Illustration C
Illustration D
