Page 1
840091400
Use & Care for Steam Irons ............................2
USA: 1-800-851-8900
Page 2
Consumer Safety Information
This product is intended for household use only.
This appliance is equipped with a polarized plug. This type of plug
has one blade wider than the other. The plug will fit into an electrical
outlet only one way. This is a safety feature intended to help reduce
the risk of electrical shock. If you are unable to insert the plug into
the outlet, try reversing the plug. If the plug should still fail to fit,
contact a qualified electrician to replace the obsolete outlet. Do not
attempt to defeat the safety purpose of the polarized plug by modifying the plug in any way.
2
IMPORTANT SAFEGUARDS
When using your flatiron, basic safety precautions should always be
followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING
1. Use iron only for its intended use.
2. To protect against risk of electric shock, do not immerse the iron
in water or other liquids.
3. The iron should always be turned to OFF before plugging or
unplugging from outlet. Never yank cord to disconnect from
outlet; instead, grasp plug and pull to disconnect.
4. Do not allow cord to touch hot surfaces. Let iron cool completely
before putting away. Loop cord loosely around iron when storing.
5. Always disconnect iron from electrical outlet when filling with water
or emptying and when not in use.
6. Do not operate iron with a damaged cord or if the iron has been
dropped or damaged. To avoid the risk of electric shock, do not
disassemble the iron. Call our toll-free customer service number for
information on examination, repair or electrical or mechanical
adjustment. Incorrect reassembly can cause a risk of electric shock
when the iron is used.
7. Close supervision is necessary for any appliance being used by or
near children. Do not leave iron unattended while connected
or on an ironing board.
8. Burns can occur from touching hot metal parts, hot water, or steam.
Use caution when you turn a steam iron upside down–there may be
hot water in the reservoir.
SPECIAL INSTRUCTIONS
1. To avoid a circuit overload, do not operate another high wattage
appliance on the same circuit.
2. If an extension cord is absolutely necessary, a 10-ampere cord
should be used. Cords rated for less amperage may overheat.
Care should be taken to arrange the cord so that it cannot be
pulled or tripped over.
SAVE THESE INSTRUCTIONS!
1. Water Tank Opening
2. Adjustable Steam
Switch
3. Spray/Blast Buttons
4. Swivel Cord
5. Heel Rest
6. Temperature
Control Dial
7. Power On Light
8. Soleplate
9. Water Window
Parts and Features
3
Page 3
5
1. Unplug iron. Using a cup, slowly pour 4 ounces (1⁄2 cup) of
tap water into water tank opening. Plug iron into outlet.
2. Set Adjustable Steam Switch to STEAM.
3. Turn Temperature Control Dial to desired fabric setting in
steam range. Allow two minutes for the iron to reach desired
temperature.
Water: Please use ordinary tap water. If you have extremely
hard water, alternate between tap water and distilled water
for use in the iron.
To Steam Iron
To Dry Iron
1. Set Adjustable Steam Switch to 0 or empty water tank.
2. Turn Temperature Control Dial to desired temperature.
Allow two minutes for iron to reach desired temperature.
4
Features (not all features on all models)
Adjustable Steam Switch
This switch provides continuous steam
in the STEAM position. Push the
switch to 0 to change to dry iron.
Auto Shutoff Reset Button/Light
The light comes on when the iron is first
plugged in even if Temperature Control
Dial is set at Off. The light indicates that
the iron is plugged in. After one hour,
the iron will shut off and the light will
blink. Push the Reset Button to turn the
iron back on.
Power On Light
This light comes on when the iron is
plugged in and remains on until the iron
is unplugged. The light stays on even if
Temperature Control Dial is turned to Off.
Before First Use
• Steam vents should be cleaned before first use. Prepare
iron for steam ironing, then iron over an old cloth for a few
minutes while letting the iron steam.
• Many irons spit or sputter during the first few uses with
tap water. This happens as the steam chamber becomes
conditioned. This will stop after a few uses.
• During first use of the iron, it may appear to smoke. This
will stop and does not indicate a defect or hazard.
Reset
Button
Light
Power
Light
Page 4
7
6
Spray and Blast of Steam Buttons
Push spray button to release a fine spray
of water for difficult wrinkles in cotton or
linen. Push blast button for an extra blast
of steam.
Features (not all features on all models)
Blast of
Steam
Spray
Dry Iron
Steam Range
1
Setting To Iron
Ironing Instructions
Acetate, Silk
Acrylic, Nylon
Polyester, Rayon
Dry iron on the wrong side of
the fabric.
For wool, use a press cloth and
steam iron on the wrong side.
2
3
4
Cotton Blends
5
Wool
6
Cotton
7
Linen
0
Off
Iron on wrong side of fabric
while still damp.
For polyester, dry iron while the
fabric is still damp.
Iron cottons while still damp,
using steam and/or spray.
Dry iron using spray if necessary.
Iron using steam or spray for
difficult wrinkles.
Fabric/Setting Chart
Caring for Your Iron
Iron
1. Turn temperature control dial to Off. Unplug and let cool.
The iron takes longer to cool down than it does to heat up.
2. To empty water from iron, slowly tilt pointed end of iron
down over a sink. Water will run out of water tank opening.
3. Wrap cord loosely around iron and store iron in an upright
position. Do not store iron laying flat on soleplate.
Soleplate
1. Never iron over zippers, pins, metal rivets, or snaps, as
these may scratch the soleplate.
2. To clean occasional build-up on the soleplate, wipe with
a sudsy cloth. Do not use abrasive cleansers or metal
scouring pads.
3. Always store iron upright in the heel rest position.
Troubleshooting
Won’t heat.
• Is the iron plugged in and the outlet working? Check the
outlet by plugging in a lamp.
• Is the Temperature Control Dial turned to a fabric setting?
• If auto shutoff model, is the Automatic Shutoff Light blink-
ing? If so, push Reset Button to reset.
Water is leaking.
• Do not overfill the water tank.
• If steam ironing, is the Temperature Control Dial in the
steam range and did the iron have enough time to preheat?
• If dry ironing, make sure the Adjustable Steam Switch is in
the 0, dry iron position.
Page 5
LIMITED WARRANTY
This product is warranted to be free from defects in material and workmanship for a
period of one hundred eighty (180) days from the date of original purchase, except
as noted below. During this period, we will repair or replace this product, at our option,
at no cost. THE FOREGOING WARRANTY IS IN LIEU OF ANY OTHER WARRANTY,
WHETHER EXPRESS OR IMPLIED, WRITTEN OR ORAL INCLUDING ANY WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. ANY LIABILITY
IS EXPRESSLY LIMITED TO AN AMOUNT EQUAL TO THE PURCHASE PRICE PAID,
AND ALL CLAIMS FOR SPECIAL, INCIDENTAL AND CONSEQUENTIAL DAMAGES
ARE HEREBY EXCLUDED. There is no warranty with respect to the following, which
may be supplied with this product: glass parts, glass containers, cutter/strainer, blades
and/or agitators. This warranty extends only to the original consumer purchaser and
does not cover a defect resulting from abuse, misuse, neglect, use for commercial
purposes, or any use not in conformity with the printed directions. This warranty gives
you specific legal rights, and you may also have other legal rights which vary from
state to state, or province to province. Some states or provinces do not allow limitations on implied warranties or special, incidental or consequential damages, so the
foregoing limitations may not apply to you.
If you have a claim under this warranty, DO NOT RETURN THE APPLIANCE TO THE
STORE! Please call our CUSTOMER SERVICE NUMBER. (For faster service please
have model, series, and type numbers ready for operator to assist you.)
CUSTOMER SERVICE NUMBERS
In the U.S. 1-800-851-8900
In Canada 1-800-267-2826
Web site address: www.proctorsilex.com
KEEP THESE NUMBERS FOR FUTURE REFERENCE!
Troubleshooting (continued)
Won’t steam.
• Check the water level.
• Is the Adjustable Steam Switch in the STEAM position?
• Has the iron had enough time to preheat?
Leaves spots.
• ALWAYS empty the water tank of the iron after using. Water
left in the tank may discolor clothing and soleplate.
12/01
H
AMILTONBEACHPROCTOR-SILEX,INC
.P
ROCTOR-SILEXCANADA,INC
.
263 Yadkin Road, Southern Pines, NC 28387
Picton, Ontario K0K 2T0
840091400
Web site address: www.proctorsilex.com
