Proctor Silex 38526 User Guide

840236200

Electric Skillet

Poêles à frire

Sartén Eléctrico

READ BEFORE USE

LIRE AVANT UTILISATION

LEA ANTES DE USAR

English....................................... 2

USA: 1-800-851-8900
www.proctorsilex.com

Français ..................................... 9

Canada : 1-800-267-2826
www.proctorsilex.ca

Español ................................... 17

EE. UU.: 1-800-851-8900
México: 01 800 71 16 100
www.proctorsilex.com.mx

Le invitamos a leer cuidadosamente
este instructivo antes de usar su
aparato.

840236200 ENv06.indd 1 1/15/14 4:26 PM

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should
always be followed to reduce the risk of fire, electric shock, and/or
injury to persons, including the following:

1. Read all instructions.

2. This appliance is not intended for use by persons (including

children) with reduced physical, sensory, or mental capabilities,
or lack of experience and knowledge, unless they are closely
supervised and instructed concerning use of the appliance by a
person responsible for their safety.

3. Close supervision is necessary when any appliance is used by or
near children. Children should be supervised to ensure that they do
not play with the appliance.

4. Do not touch hot surfaces. Use handles or knobs, which may be
warm. Use oven mitts.

5. To protect against electrical shock, do not immerse cord, plug,
or temperature control in water or other liquid.

6. Unplug from outlet when not in use and before cleaning. Allow
to cool before putting on or taking off parts and before cleaning.

7. Do not operate any appliance with a damaged cord or plug,
or after the appliance malfunctions or has been dropped or
damaged in any manner. Call our toll-free customer service number
for information on examination, repair, or adjustment.

8. The use of accessory attachments not recommended by the
appliance manufacturer may cause injuries.

9. Do not use outdoors.

10. Do not let cord hang over edge of table or counter, or touch

hot surfaces, including the stove.

11. Do not place on or near a hot gas or electric burner, or in
a heated oven.

12. Extreme caution must be used when moving an appliance
containing hot oil or other hot liquids.

13. Always attach plug to appliance first; then plug cord into wall outlet.
To disconnect, turn any control to OFF and then remove plug from
wall outlet.

2

840236200 ENv06.indd 2 1/15/14 4:26 PM

14. Do not use appliance for other than intended use.

15. WARNING: To reduce the risk of fire, assemble feet before using.

16. Be sure that handles/feet are assembled and fastened properly.

17. See instructions for assembly of handles/feet on page 5.

18. Never leave appliance unattended while in use.

19. This appliance is not intended for deep frying foods.

20. Use only temperature-controlling plug provided by manufacturer.

Use of other temperature-control plug may cause injury.

SAVE THESE INSTRUCTIONS!

Other Consumer Safety Information

This appliance is intended for household use only.

WARNING! Shock Hazard: This product is provided with either a
polarized (one wide blade) or grounded (3-prong) plug to reduce the
risk of electric shock. The plug fits only one way into a polarized or
grounded outlet. Do not defeat the safety purpose of the plug by
modifying the plug in any way or by using an adapter. If the plug does
not fit fully into the outlet, reverse the plug. If it still does not fit, have
an electrician replace the outlet.

The length of the cord used on this appliance was selected to reduce
the hazards of becoming tangled in or tripping over a longer cord. If a
longer cord is necessary, an approved extension cord may be used.
The electrical rating of the extension cord must be equal to or greater
than the rating of the appliance. If the appliance is of the grounded
type, the extension cord should be a grounding-type, 3-wire cord. Care
must be taken to arrange the extension cord so that it will not drape
over the countertop or tabletop where it can be pulled on by children or
accidentally tripped over.

To avoid an electrical circuit overload, do not use another high-wattage
appliance on the same circuit with this appliance.

840236200 ENv06.indd 3 1/15/14 4:26 PM

3

Parts and Features

*To order parts:
US: 1.800.851.8900
www.hamiltonbeach.com
Canada: 1.800.267.2826
Mexico: 01 800 71 16 100

1. Lid Handle*

2. Glass Lid

3. Nonstick Skillet

4. Handle/Feet

5. Temperature Control*

OR

840236200 ENv06.indd 4 1/15/14 4:26 PM

4

Assembly

Assembly of handle/feet to
base is required. See below.

6. Long Screw

7. Split Lock Washer

8. Flat Washer

Tools Required: Phillips-head screwdriver. Do NOT

overtighten.

NOTE: Screws and washers may be partially screwed into base
for shipping purposes. Remove them to assemble handle/feet
to base. After assembly the handles/feet should feel secure.
If the handles/feet are loose, or the unit rocks when on a
flat surface, the handles are not installed properly. Loosen
the screws and realign handles; then retighten as shown.
Periodically check screws and retighten as necessary.

840236200 ENv06.indd 5 1/15/14 4:26 PM

5

How to Use

w WARNING

Burn Hazard.

• To reduce the risk of burns, do not carry or move the skillet
when it contains hot oil or food.

• To reduce the risk of burns due to oil splatter, do not put a
large amount of oil in a hot skillet. When frying, pour oil in
skillet and then preheat unit.

BEFORE FIRST USE: Wash skillet and lid in hot, soapy water.
Rinse and dry thoroughly.

1. Always use skillet on a dry, level, heat-resistant surface.

2. Plug the temperature control into the skillet. Set temperature

control dial to OFF; then plug cord into wall outlet.

3. Refer to the Cooking Chart that follows for selecting the
correct heat setting.

4. Preheat skillet, uncovered, 5 to 10 minutes until desired
temperature is reached.

5. When the indicator light on the temperature control goes out,
the cooking temperature has been reached. Food may now
be added. Heat may be increased or decreased, depending
upon personal preference and the type or amount of food
being prepared.

6. When finished cooking, remove food, turn temperature
control to OFF, and unplug unit from wall outlet.

NOTES: Only use wooden or plastic cooking utensils to prolong
the life of the nonstick coating.

Never use the skillet and the cover in the oven or microwave
oven, or on the range top.

840236200 ENv06.indd 6 1/15/14 4:26 PM

6

Cooking Chart

FOOD TEMPERATURE TIME

1

Hamburgers (

[151 g] each)

Bacon 350°F (180°C) 10 to 15 minutes

Sausage links and patties 350°F (180°C) 15 minutes

Fried Chicken 375°F (190°C) 20 to 30 minutes

Pork Chops 325°F (160°C) 20 to 30 minutes

⁄3 lb.

350°F (180°C) 15 to 20 minutes

Cooking times are based on fresh ingredients.

Care and Cleaning

Electrical Shock Hazard.

w WARNING

To reduce the risk of electrical shock, do not immerse the
cord, plug, or temperature control in water or any other liquid.

1. When finished cooking, turn temperature control to OFF;
unplug from outlet and then from skillet.

2. Let skillet cool completely.

3. Clean skillet and lid with hot, soapy water, using a nylon

scouring pad. Rinse; then dry. Skillet and lid may also be
washed in a dishwasher.

NOTE: Do not use metal scouring pads or abrasive cleansers.
This will damage the nonstick coating.

4. If necessary, wipe the temperature control and cord with a
damp cloth and then wipe dry.

840236200 ENv06.indd 7 1/15/14 4:26 PM

7

LIMITED WARRANTY

This warranty applies to products purchased and used in the U.S. and
Canada. This is the only express warranty for this product and is in lieu
of any other warranty or condition.

This product is warranted to be free from defects in material and workmanship
for a period of one (1) year from the date of original purchase. During this
period, your exclusive remedy is repair or replacement of this product or
any component found to be defective, at our option; however, you are
responsible for all costs associated with returning the product to us and our
returning a product or component under this warranty to you. If the product or
component is no longer available, we will replace with a similar one of equal
or greater value.

This warranty does not cover glass, filters, wear from normal use, use
not in conformity with the printed directions, or damage to the product
resulting from accident, alteration, abuse, or misuse. This warranty extends
only to the original consumer purchaser or gift recipient. Keep the original
sales receipt, as proof of purchase is required to make a warranty claim. This
warranty is void if the product is used for other than single-family household
use or subjected to any voltage and waveform other than as specified on the
rating label (e.g., 120V ~ 60 Hz).

We exclude all claims for special, incidental, and consequential damages
caused by breach of express or implied warranty. All liability is limited to
the amount of the purchase price. Every implied warranty, including any

statutory warranty or condition of merchantability or fitness for a
particular purpose, is disclaimed except to the extent prohibited by
law, in which case such warranty or condition is limited to the duration
of this written warranty. This warranty gives you specific legal rights. You

may have other legal rights that vary depending on where you live. Some
states or provinces do not allow limitations on implied warranties or special,
incidental, or consequential damages, so the foregoing limitations may not
apply to you.

To make a warranty claim, do not return this appliance to the store.
Please call 1.800.851.8900 in the U.S. or 1.800.267.2826 in Canada or
visit proctorsilex.com in the U.S. or proctorsilex.ca in Canada. For faster
service, locate the model, type, and series numbers on your appliance.

840236200 ENv06.indd 8 1/15/14 4:26 PM

8

PRÉCAUTIONS IMPORTANTES

Pour utiliser un appareil électroménager, vous devez toujours prendre
des mesures élémentaires de sécurité pour réduire le risque d’incendie,
d’électrocution et/ou de blessure corporelle, en particulier les mesures
suivantes :

1. Lire toutes les instructions.

2. Cet appareil n’est pas destiné à être utilisé par des personnes (y

compris les enfants) dont les capacités physiques, sensorielles
ou mentales sont réduites, ou manquant d’expérience et de
connaissance, sauf si elles sont étroitement surveillées et instruites
sur l’utilisation de l’appareil par une personne responsable de leur
sécurité.

3. Une surveillance étroite est requise pour tout appareil utilisé par
ou près des enfants. Surveiller que les enfants ne jouent pas avec
l’appareil.

4. Ne pas toucher aux surfaces chaudes. Utiliser les poignées ou
boutons; ceux-ci peuvent être chauds au toucher. Utiliser des
mitaines de four.

5. Afin de vous prémunir contre le risque de choc électrique, ne pas
immerger le cordon, la fiche ou la commande de température dans
l’eau ou tout autre liquide.

6. Débrancher la poêle de la prise de courant lorsque vous ne l’utilisez
pas et avant le nettoyage. Laisser la poêle refroidir avant d’enlever
ou de remettre des pièces en place et avant de la nettoyer.

7. Ne pas faire fonctionner un appareil avec un cordon ou une fiche
endommagé(e), ou lorsque l’appareil ne fonctionne pas bien,
est tombé ou a été endommagé d’une manière quelconque.
Appeler notre numéro sans frais de service à la clientèle pour
des renseignements concernant l’examen, la réparation ou
l’ajustement.

8. L’utilisation de tout accessoire non recommandé par le fabricant de
l’appareil peut causer des blessures.

9. Ne pas utiliser à l’extérieur.

840236200 FRv02.indd 9 1/15/14 4:09 PM

9
