ProAction
–
Dishwasher
Installation & User Instructions – Please keep for future reference 478
478/
9114
9145
Important – Please read these instructions fully before installing or using
These instructions contain important information which will help you get the best from your
appliance and ensure safe and correct installation, use and maintenance.
If you need help or have damaged or missing parts, call the
Customer Helpline: 0845 600 4632
Issue – 0 1
2 7/26/
1
Contents
Safety Information 2
Parts 3
Installation 4-6
Water supply connection 4
Drain hose connection 4
Position the appliance 4
Water pressure 5
Electrical connection 6
User Instructions 7-15
Before first use 7-10
Water softener 7
Rinsing aid 8
Detergent 9
Loading your appliance
1
Guarantee 19
Wash
cycle table
Using your appliance
Care and Maintenance 15
Filtering system 1
General 1
Trouble Shooting 16
Error codes 1
Technical Data
Disposal information 18
Sheet
1 0
1
3
1
4
5
5
6
17
Product codes
WQP12-9250G – White
WQP12-9250G – Silver
1
Safet
y
y
Information
Important – Please read these instructions full
Before use
The installation of this appliance is best carried out
by 2 people.
y Dispose of all packaging carefully and
responsibly.
y The appliance is designed for indoor use only
and must be protected from rain, moisture and
extreme temperature variations.
y This appliance is designed for household use.
Do not use the appliance for industrial and
commercial use, or any other purpose.
y The appliance MUST be positioned on a firm
level base.
y Do not place the appliance near a heat source or
in direct sunlight.
y Only suitable household utensils should be
placed in the dishwasher. Avoid utensils that are
non-heat-resistant, metal decorated, etc.
y Do not use detergent not designed for
dishwasher. This may damage the appliance.
y Do not spray water on the appliance. It may
cause electrical parts failure or electric shock.
y Do not stand or sit on the door when it is open. It
may cause deformation or failure of your
dishwasher. The appliance could tip forward.
y Do not put any heavy objects on top of the
appliance. It will damage the appliance.
y This appliance is fitted with a safety function that
automatically stops the operation of the
dishwasher when it is exposed to heavy
disturbance on its mains.
y The appliance is to be connected to the water
supply using new hose set and that old hose set
should not be used.
y The door should not be left in open position since
this could present a tripping hazard.
y This appliance must be positioned so that the
plug is accessible.
y
This appliance is intended to be used in household
and similar applications such as:
-staff kitchen areas in shops, offices and other
working environments;
-farm houses;
-by clients in hotels, motels and other residential
type environments;
-bed and breakfast type environments.
before installation
During use
y This appliance is not intended for use by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety. Children should be supervised to
ensure that they do not play with the appliance.
y This appliance is not intended for use by young
children or infirm persons unless they have been
adequately supervised by a responsible person to
ensure that they can use the appliance safely.
Young children should be supervised to ensure
that they do not play with the appliance.
y Do not touch the visual heating element during or
immediately after use.
y
Do not operate your dishwasher unless all enclosure
panels are properly in place. Open the door carefully
if the dishwasher is operating, there is a risk of water
squirting out.
y WARNING: Knives and other utensils with sharp
points must be loaded in basket with their points
down or placed in a horizontal position. Avoid
damage to the door seal.
y Load plastic items so that they do not come into
contact with the visible heating element.
y Dishwasher detergents are strongly alkaline, they
can be extremely dangerous if swallowed. Avoid
contact with skin and eyes and keep children
away from the dishwasher when the door is open.
y The door should not be left open, since this could
increase the risk of tripping.
y Keep detergents away from children.
y Do not attempt to repair the appliance yourself.
Contact the Customer Helpline: 0845 600 4632.
2
If you have damaged or missing parts,
/
Part
call the Customer Helpline: 0845 600 4632
Please familiarize yourself with the parts and accessories listed below
1. ON/OFF button
2. Power light
3. Rinse aid warning light
ON
OFF
2h 4h 6h 8h
Delay
Inten. Normal Eco Rinse
4. Salt warning light
5. Program indicator light.
Rapid
3in1
6. Program buttons
WQP12-9250G
7. Delay start button
8. Delay indicators
1. Upper basket
2. Spray arms
3. Lower basket
4. Salt container
5. Main filter
6. Detergent dispenser
Accessories included
ProAction
Installation & User Instructions
–
Dishwasher
–
Please keep for future reference 478
9114
478/
9145
7. Cup shelf
8. Cutlery basket
9. Coarse basket
10. Rinse aid dispenser
11. Drain pipe connector
12. Inlet pipe connector
Important
–
Please read these instructions fully before installing or using
These instructions contain important information which will help you get the best from your
appliance and ensure safe and correct installation, use and maintenance.
If you need help or have damaged or missing parts, call the
Instructions x 1 Hose x 1 Salt Filler x 1 Measuring Spoon x 1 Measuring Cup x 1
Customer Helpline: 0845 600 4632
Inlet Hose x 1
3
Installation
Water supply connection
Caution: 2 people are required to
unpack and handle the appliance, it is
recommended that gloves are worn.
y Carefully remove all packaging materials
including the foam base, dispose of correctly.
y Connect the cold water supply hose to a
threaded ¾” connector and make sure that it is
fastened tightly in place.
y If the water pipes are new or have not been
used for an extended period of time, let the
water run to make sure that the water is clear.
This will prevent the water inlet to be blocked
and damage the appliance.
WARNING:
Please closethe hydrantafter using.
Drain hose connection
1. Make a hooked end at the end of drain hose
with the plastic U-bend fitting (provided). The
hooked end should be dropped into a
drainage standpipe between 40cm and
100cm from the floor level.
2. The free end of the hose must not be
immersed in water to avoid the flow back.
3. You may connect the water inlet hose onto
the kitchen sink tap. You must obtain a
correct adaptor to match the inlet hose
connector for a secure connection. However,
permanent plumbing is recommended.
4. If leakage is observed, immediately shut off
the water supply and check the hose
connections fully. Tighten connections if
necessary.
Position the appliance
1. The dishwasher must be installed on a solid
level surface.
2. Position the appliance in the desired location.
The back should rest against the wall behind
it, and the sides along the adjacent cabinets
or wall. The water supply and drain hoses
can be positioned either to the left or right
side to facilitate proper installation.
3. To level the dishwasher, adjust the 4 level
screws (feet) under the dishwasher.
4
Installation
Water pressure
For best operating results, incoming water
pressure should be between 0.04 and 1 Mpa.
Your dishwasher cleans by spraying a mixture of
hot clean water and detergent (under pressure)
against the soiled surface of dishes. The water
is pumped through a rotating spray arm, drained
through a filter removing food and soiled
particles and pumped back through the spray
arm.
Note: Hard water conditions will adversely affect
the performance of your dishwasher. To
minimise this condition, it is recommended to
periodically operate/rinse the dishwasher in
empty condition using 1 cup of white vinegar (at
least once a week).
Important: Once you open the water
supply (even if it is closed immediately
thereafter), the water inlet hose will be
pressurised.
5
