cool-touch Electric Griddle
• Ceramic nonstick surface for stick-free cooking
and easy cleaning.
• Cool-touch base on the front and both sides.
• Fully immersible with heat control removed.
Estas instrucciones también están disponibles en español. Para
obtener una copia impresa:
• Descargue en formato PDF en www.GoPresto.com/espanol.
• Envíe un correo electrónico a contact@GoPresto.com.
• Llame al 1-800-877-0441, oprima 2 y deje un mensaje.
Visit us on the web at www.GoPresto.com
2016 National Presto Industries, Inc.
INSTRUCTIONS
This is a Listed appliance. The following important safeguards are recommended by most portable appliance manufacturers.
IMPORTANT SAFEGUARDS
To reduce the risk of personal injury or property damage, when using electrical appliances basic safety precautions should always be
followed, including the following:
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against electrical shock, do not immerse heat control, cord, or plug in water or other liquid.
4. Close supervision is necessary when any appliance is used by or near children.
5. Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts and before cleaning
the appliance.
6. Do not operate any appliance with a damaged cord or plug or in the event the appliance malfunctions or has been damaged in any
manner. Do not operate if the legs and/or cool-touch base become cracked or damaged. Return the appliance to the Presto Factory
Service Department for examination, repair, or electrical or mechanical adjustment.
7. The use of accessory attachments not recommended by the appliance manufacturer may cause injuries.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter or touch hot surfaces.
10. Do not place on or near a hot gas or electric burner or in a heated oven.
11. It is recommended that this appliance not be moved when it contains hot oil or other hot liquid. If it must be moved when it contains
hot oil or other hot liquid, use extreme caution.
12. Always attach heat control to appliance first, then plug cord into wall outlet. To disconnect, turn control to OFF then remove plug
from wall outlet.
13. Do not use appliance for other than intended use.
SAVE THESE INSTRUCTIONS
THIS PRODUCT IS FOR HOUSEHOLD USE ONLY.
Important Cord Information
This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to fit
into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician. Do not attempt to modify the plug in any way.
1
A short power supply cord (or cord set) is provided to reduce the risk resulting from becoming entangled in or tripping over a longer
cord. Extension cords may be used if care is properly exercised in their use. If an extension cord is used, the marked electrical rating of
the extension cord should be at least as great as the electrical rating of the appliance. The extension cord should be arranged so that it
will not drape over the countertop or tabletop where it can be pulled on by children or tripped over unintentionally.
Connect the power supply cord to a 120VAC electrical outlet only.
How To Use
Before using for the first time, become familiar with the griddle features. Wash the griddle in warm, soapy water, rinse, and dry. Do not
immerse Control Master heat control in water or let it come in contact with any liquid.
NOTICE: This griddle is not intended to be used as a warming tray, hot
plate, or for heating any cookware. Using this product for purposes
different from those specified in the instruction manual may cause
Cool-touch base
damage to the product and will void the product warranty.
1. Place assembled griddle on a dry, level, heat-resistant surface
Ceramic nonstick surface
away from walls, cabinets, and other objects.
NOTICE: To prevent possible heat damage to your countertop,
place a heat-resistant counter protector, such as aluminum foil,
Drip tray
under the griddle; take care not to place the foil under the griddle’s
legs.
2. Slide the drip tray into place. Insert the Control Master heat control into the griddle so the two electrical pins on the griddle are fully
inserted into the heat control. Connect cord to a 120VAC electrical wall outlet only.
3. Turn Control Master heat control to desired temperature; see page 3 for temperature-timetable. Preheat griddle. Pilot light goes off
when selected temperature is reached, approximately 5 to 10 minutes.
NOTE: Occasionally you may hear a pop or clicking sound while the griddle is preheating; this is due to the expansion of the metal
as it heats. It is normal. You may also notice this sound as the unit cools down.
4. Prepare food for cooking. Because the griddle features a ceramic nonstick surface, food may be prepared with little or no oil.
NOTICE: Avoid using no-stick cooking sprays as they may cause the cooking surface to become tacky.
5. Place food on griddle and cook according to temperature-timetable. Heat should be adjusted according to personal preference and
particular food being cooked. During cooking, pilot light will go on and off indicating desired temperature is being maintained.
For best results use heat-resistant nylon, plastic, or wooden utensils. Do not use metal utensils as they may scratch the ceramic non-
stick surface. Do not cut foods on the cooking surface.
6. Turn heat control to OFF when cooking is completed. Unplug heat control from wall outlet then from appliance. Allow griddle to
cool before removing drip tray and before cleaning.
Control Master
heat control
Care and Cleaning
After each use, remove heat control and wash the griddle in warm, soapy water. Rinse and dry thoroughly. Make sure to also clean the
underside, as necessary. Do not use steel wool or abrasive kitchen cleaners. Do not immerse Control Master heat control in water
or let it come in contact with any liquid.
NOTICE: Repeated washings in a dishwasher will cause the nonstick properties of the ceramic coating to slowly diminish. In addition,
the bottom of the griddle will likely discolor due to the caustic nature of the dishwasher detergent. A gray residue may also form on the
griddle bottom which may transfer onto towels and/or skin.
In time, the nonstick finish may darken over the heating element. To minimize or remove this discoloration, sprinkle baking soda over
the discolored area. Add enough water to make a paste. Allow paste to sit for several minutes and then scour with a plastic scouring pad,
such as Scotch-Brite* Dobie* Cleaning Pad, or a damp cloth. Wash and dry thoroughly. Repeat the procedure, if necessary.
Periodically check the screws on the griddle frames for looseness. Retighten, if necessary, with a standard slotted screwdriver.
NOTICE: Continuing to tighten, once secure, can result in stripping of screws or cracking of frames.
IMPORTANT: To ensure continued accuracy of the Control Master heat control, avoid rough handling in use and storage.
*Scotch-Brite and Dobie are registered trademarks of 3M Company. Presto is not affiliated with this company.
2
Temperature–Timetable
Food Temperature Cooking Time Food Temperature Cooking Time
Bacon 325°–350° 5–8 minutes Potatoes, cottage fried 300°–350° 10–12 minutes
Canadian Bacon 325°–350° 3–4 minutes Sausage, link 325°–350° 20–30 minutes
Eggs, fried 275°–300° 3–5 minutes Sausage, precooked 325°–350° 10–12 minutes
Fish 325°–375° 5–10 minutes Sandwiches, grilled 325°–350° 5–10 minutes
French Toast 325°–350° 4–6 minutes Steak, beef, 1 inch thick
Ham, ½ inch thick 325°–350° 10–12 minutes Rare 350°–400° 6–7 minutes
Ham, ¾ inch thick 325°–350° 14–16 minutes Medium 350°–400° 10–12 minutes
Hamburgers , ½ inch thick 325°–375° 8–12 minutes Steak, beef, 1½ inch thick
Minute Steak 375°–400° 4–5 minutes Rare 350°–400° 8–10 minutes
Pancakes 350°–400° 2–3 minutes Medium 350°–400° 18–20 minutes
Pork Chops, ½ inch thick 325°–375° 15–20 minutes
Pork Chops, ¾ inch thick 325°–375° 20–25 minutes
Consumer Service Information
If you have any questions regarding the operation of your Presto appliance or need parts for your appliance, please contact us s:
• Call 1-800-877-0441 weekdays 8:00 AM to 4:00 PM (Central Time)
• Email us through our website at www.GoPresto.com/contact
• Write: National Presto Industries, Inc., Consumer Service Department
3925 North Hastings Way, Eau Claire, WI 54703-3703
Inquiries will be answered promptly by telephone, email, or letter. When emailing or writing, please include a phone number and a time
when you can be reached weekdays, if possible. When contacting the Consumer Service Department, please indicate the model and series
numbers for the griddle. The model number can be found on the bottom of the plug guard and the series number can be found stamped
in the bottom center of the griddle.
Please record this information:
Model _______________ Series _______________ Date Purchased _________
The Presto Factory Service Department is equipped to service Presto appliances and supply genuine Presto replacement parts. Genuine
Presto replacement parts are manufactured to the same exacting quality standards as Presto appliances and are engineered specifically
to function properly with its appliances. Presto can only guarantee the quality and performance of genuine Presto replacement parts.
“Look-alikes” might not be of the same quality or function in the same manner. To ensure that you are buying genuine Presto replacement parts, look for the Presto trademark.
Canton Sales and Storage Company, Presto Factory Service Department
555 Matthews Drive, Canton, MS 39046-3251
This quality Presto appliance is designed and built to provide many years of satisfactory performance under normal household use. Presto pledges to the
original owner that should there be any defects in material or workmanship during the first year after purchase, we will repair or replace it at our option. Our
pledge does not apply to damage caused by shipping. Outside the United States, this limited warranty does not apply.
To obtain service under the warranty, please call our Consumer Service Department at 1-800-877-0441. If unable to resolve the problem, you will be instructed
to send your Presto appliance to the Presto Factory Service Department for a quality inspection; shipping costs will be your responsibility. When returning
an appliance, please include your name, address, phone number, and the date you purchased the appliance, as well as a description of the problem you are
encountering with the appliance.
We want you to obtain maximum enjoyment from using this Presto appliance and ask that you read and follow the instructions enclosed. Failure to follow
instructions, damage caused by improper replacement parts, abuse, misuse, disassembly, alterations, or neglect will void this pledge. This warranty gives you
specific legal rights, and you may also have other rights which vary from state to state. This is Presto’s personal pledge to you and is being made in place of
all other express warranties.
2016 National Presto Industries, Inc. Form 76-390BR-2017
PRESTO Limited Warranty
(Applies only in the United States)
NATIONAL PRESTO INDUSTRIES, INC.
EAU CLAIRE, WI 54703-3703
3
