Prestigio 5501 User Guide

MultiPhone PAP5501

Android Smartphone

User Manual

Version 1.0

www.prestigio.com

About this user manual

This user manual is specially designed to detail the device’s functions and features.

- Please read this manual before using the device to ensure safe and proper use.

- Descriptions are based on the device’s default settings.

- Images and screenshots may differ in appearance from the actual product.

- Prestigio continuously strives to improve its products. Due to software upgrading, some
contents in this user manual may be different from your product. Prestigio reserves the rights
to revise this user manual or withdraw it at any time without prior notice. Please take your
product as standard.

- The Android Applications which are provided by your device have been developed by
Android's users or other companies, not by Prestigio and are provided at no charge.
Unless otherwise indicated, Prestigio makes no promises nor representations and takes no
responsibilities about their performance, quality, content, or intellectual property rights.

Conventions used in this manual

In this user manual, we use the following symbols to indicate useful and important information:

Caution: provides safety precaution and important information.

Note: gives additional information.

Tips: usage tips.

> The order of options or menus you must select to perform a step.

Warranty Information

Prestigio MultiPhone PAP5501 has a two-year warranty.
You may find detailed warranty information at

http://www.prestigio.com/support/warranty-terms

© Copyright 2013 Prestigio. All rights reserved.

Contents

1. Unboxing ......................................................................................................................... 1

Open your package .................................................................................................................1

Your phone at a glance ...........................................................................................................1

Buttons .................................................................................................................................... 1

2. Getting started ................................................................................................................. 2

Install the SIM card .................................................................................................................2

Insert a memory card .............................................................................................................. 3

Insert the battery ....................................................................................................................4

Replace the back cover ...........................................................................................................4

Power on your phone ..............................................................................................................5

Home screens .......................................................................................................................... 5

List menu ................................................................................................................................. 6

3. Basics ............................................................................................................................... 7

Finger tips ................................................................................................................................7

Motion gesture .......................................................................................................................8

Charge the battery ..................................................................................................................9

Connect to your PC ...............................................................................................................10

Lock and unlock the screen ................................................................................................... 10

Voice control ......................................................................................................................... 12

Recently used apps ...............................................................................................................12

Notifications panel ................................................................................................................ 12

Enter text ..............................................................................................................................13

Use widgets ........................................................................................................................... 14

System upgrade ....................................................................................................................14

Status icons ...........................................................................................................................15

4. Phone ............................................................................................................................ 16

Make a call ............................................................................................................................16

Answer a call .........................................................................................................................16

Reject a call ...........................................................................................................................16

End a call ...............................................................................................................................16

Contacts ................................................................................................................................16

Use speed dial .......................................................................................................................18

Call a phone number in a text message ................................................................................18

Call a phone number in an email ..........................................................................................18

Set up a conference call ........................................................................................................19

Make an emergency call .......................................................................................................19

5. Messages ....................................................................................................................... 20

Send a message ..................................................................................................................... 20

Check your message .............................................................................................................. 20

Reply to a message ...............................................................................................................20

Forward a message ...............................................................................................................20

Delete messages ...................................................................................................................21

Create a conversation shortcut ............................................................................................. 21

WAP push messages .............................................................................................................21

6. Mail ............................................................................................................................... 22

Set up an email account ........................................................................................................ 22

Send a mail ............................................................................................................................ 22

View your mails ..................................................................................................................... 22

Reply to a mail .......................................................................................................................23

Delete mails ..........................................................................................................................23

Gmail ..................................................................................................................................... 23

7. Camera .......................................................................................................................... 25

Your camera at a glance ........................................................................................................ 25

Take a photo .........................................................................................................................25

Take a photo of yourself .......................................................................................................25

Take a panoramic photo .......................................................................................................26

Take continuous shots ..........................................................................................................26

Record a video ......................................................................................................................26

Camera scenes ......................................................................................................................26

Camera and video settings .................................................................................................... 26

8. Multimedia .................................................................................................................... 28

Gallery ..................................................................................................................................28

Video player ..........................................................................................................................31

Music player .......................................................................................................................... 32

FM radio ................................................................................................................................ 33

Voice recorder ....................................................................................................................... 34

9. Web & network .............................................................................................................. 36

Connect to internet ............................................................................................................... 36

VPN........................................................................................................................................38

Web browse .......................................................................................................................... 39

10. Bluetooth & NFC ............................................................................................................ 41

Bluetooth ..............................................................................................................................41

NFC ........................................................................................................................................ 42

11. Apps............................................................................................................................... 43

Play store...............................................................................................................................43

Manage your apps.................................................................................................................43

12. eReader Prestigio ........................................................................................................... 44

Your eReader at a glance ......................................................................................................44

Download an eBook ..............................................................................................................44

Read an eBook ......................................................................................................................44

eReader settings ...................................................................................................................45

13. Travel & maps ................................................................................................................ 46

Find a location ....................................................................................................................... 46

Get directions ........................................................................................................................ 46

Navigation .............................................................................................................................47

Use Google maps ..................................................................................................................47

14. My files and storage ....................................................................................................... 48

My files .................................................................................................................................. 48

Storage .................................................................................................................................. 48

15. Utilities .......................................................................................................................... 50

Clock ...................................................................................................................................... 50

Calendar ................................................................................................................................ 51

Calculator ..............................................................................................................................51

ToDo list ................................................................................................................................52

Google search .......................................................................................................................52

16. Set up your phone .......................................................................................................... 54

Wireless & Networks ............................................................................................................. 54

Device .................................................................................................................................... 55

Personal ................................................................................................................................55

Accounts ................................................................................................................................ 56

System ................................................................................................................................... 56

17. Specifications ................................................................................................................. 57

18. Specific Absorption Rate Information ............................................................................. 58

International standards ......................................................................................................... 58

19. Troubleshooting ............................................................................................................. 59

1. Unboxing

Inside your package

•Prestigio MultiPhone •Earphones •Battery

•USB cable •AC/DC adapter •Stylish Carrying Case

•Quick start guide •Warranty card •Legal and safety notices

Your phone at a glance

Headset jack

Front camera

Earpiece

Power button

Touch screen

1

Micro USB port

Rear camera

Volume button

Home key

Menu key

Buttons

Button Definition Function

Power

Volume •Press to adjust the volume.

Menu

Home •Tap to return to Home screen.

Back

Speaker

Back key

Microphone

•Press and hold to power on or off your phone.

•Press to lock or unlock the screen display.

•Tap to open a list of options available on the current screen.

•Tap and hold to open the list of recent apps.

•Tap to return to the previous screen.

•Tap to hide the onscreen keyboard when it is opened.

User Manual MultiPhone PAP5501

1

2. Getting started

Congratulations on your purchase and welcome to Prestigio.
To get the most from your product and enjoy all that Prestigio has to offer,
please access:

http://www.prestigio.com/catalogue/MultiPhones

For more details about your product, please visit:

http://www.prestigio.com/support

Install the SIM card

Follow the steps below to insert your SIM card. Remember to turn off your mobile phone before
removing the back cover.

Please read the "MultiPhone legal and safety notices" on your package before use.

• Do not cover the antenna area with your hands or other objects. This may cause
connectivity problems or drain the battery.

• Do not allow water to contact the touch screen. The touch screen may malfunction
in humid conditions or when exposed to water.

2

1. Securely hold your MultiPhone with your fingers and remove the back cover.

2. With your thumb or any other finger, lift the battery from the battery compartment.

• Be careful not to damage your fingernails when removing the back cover.

•Do not bend or twist the back cover excessively. Doing so may damage the cover.

User Manual MultiPhone PAP5501

2

3. With the SIM card’s gold contacts facing down and its cut-off corner facing outwards, insert the
SIM card all the way into the SIM card slot. Push the SIM card in until it clicks into place.

Remove the SIM card: Push the SIM card in to eject it from its slot, and remove it.

Insert a memory card

You can expand the memory of your phone and store more multimedia files by adding a micro-SD
card. Depending on the memory card manufacturer and type, some memory cards may not be
compatible with your device.

1. Insert a memory card with the gold contacts facing downwards.

2. Push the memory card into the slot until it locks in place.

Some memory cards may not be fully compatible with the device. Using an
incompatible card may damage the device or the memory card, or corrupt the data
stored in it.

•Frequent writing and erasing of data shortens the lifespan of memory cards.

• When inserting a memory card into the device, the memory card’s file directory

appears in the ES File Explorer > SD card.

Remove the memory card: push the memory card until it disengages from the

device, and then pull it out.

User Manual MultiPhone PAP5501

3

Insert the battery

Insert the battery (with its exposed copper contacts first) into the battery compartment.

Please use only original batteries that came in the box or replacements that we
recommend.

Replace the back cover

1. Align the back cover onto the top part of your phone.

2. Press the sides and the bottom part of the back cover against your phone to lock the cover into
place.

You will hear a click when the back cover is locked in place.

User Manual MultiPhone PAP5501

4

Power on your phone

Press and hold the Power button for a few seconds to power on your phone.

1. When turning on the device for the first time, follow the on-screen instructions to set up your
device.

2. After setting up your phone, a Prestigio installer wizard will appear on the screen. It offers you
a few third-party apps, tap the apps you want to install on your phone. Follow the on-screen
instructions to install the apps.

3. It may take a few minutes for your phone to install the apps.

To turn off your phone, press and hold the Power button, and then tap Power off on
the pop up screen.

If you do not install the apps provided by the Prestigio installer wizard the first time,
you can tap on the Home screen to install the apps next time.

Home screens

Your Home screen is the starting point to access all of your phone’s features. The Home screen
can have multiple panels. To view other panels, swipe left or right. Tap to return to the center
Home screen. You can add your favorite applications, shortcuts, folders and widgets here so they
are always just a tap away. Your phone’s Home screen consists of the following areas:

Status bar

Applications and
widgets

Tap to enter the list
menu

Shortcut

Personalize your wallpaper

Pick your favorite photo as your Home wallpaper. Choose from the available wallpapers, or use
any photo you have taken with the camera.

1. On the Home screen, tap > Wallpaper.

2. Select one of the following: ES File Explorer, Gallery, Live wallpapers, Video wallpaper or
Wallpapers.

3. Select an image and tap Set wallpaper. Or, select an image, resize it by dragging the frame, and
then tap OK.

User Manual MultiPhone PAP5501

5

Add an app icon to Home screen

1. On the Home screen, tap to open the list menu.

2. Tap and hold an application icon.

3. Drag it into a panel preview.

Remove an item on the Home screen

1. Tap and hold an item to remove.

2. The Remove option appears at the top of the Home screen.

3. Drag the item to the Remove option.

4. When the Remove option turns red, release the item.

List menu

All yours apps' icons can be found on the list menu. You can also find find all the widgets of the
apps on the list menu. On the Home screen, tap to open the list menu. The list menu can have
multiple panels. To view other panels, swipe left or right. Tap or to return to the Home
screen. Your phone’s list menu consists of the following areas:

Applications tab

Widgets tab

Tap to enter
app shop

Applications

User Manual MultiPhone PAP5501

6

3. Basics

Finger tips

Only use your fingers to use the touch screen.

Tap

To open an application, to select a menu item,
to press an on-screen button, or to enter a
character using the on-screen keyboard, tap it
with a finger.

Swipe

Quickly swipe your finger vertically or
horizontally across the screen to go to other
Home pages, scroll through documents, and
more.

3

Tap and hold

Tap and hold an item for more than 2 seconds
to access available options.

Slide

Slide your finger vertically across the screen to
open drop-down menu.

Zoom in

Spread two fingers apart on a webpage, map,
or image to zoom in a part.

User Manual MultiPhone PAP5501

Zoom out

Pinch two fingers together on a webpage, map,
or image to zoom out a part.

7

Scroll

Drag up or down to scroll. On some screens,
such as webpages, you can also scroll side to
side.

Flick

Flick left or right on the Home screen or the
Applications screen to see another panel. Flick
up or down to scroll through a webpage or a
list, such as contacts.

Motion gesture

Rotate your phone for a better view

For many screens, you can automatically change the screen orientation from portrait to landscape
by turning your phone sideways. When entering text, you can turn your phone sideways to bring
up a bigger keyboard.

To prevent the display from rotating automatically, open the notifications panel and
deselect Auto rotation.

• Some applications do not allow screen rotation.

•Some applications display a different screen depending on the orientation.

User Manual MultiPhone PAP5501

8

Charge the battery

A new battery is partially charged. The battery icon at the upper-right corner shows the level of
charging status.

1. Plug the small end of the charger into the micro USB port of the device, and plug the large end
of the charger into an electric socket.

2. After being fully charged, disconnect the device from the charger. First unplug the charger from
the device, and then unplug it from the electric socket.

Always use authentic accessories to optimize your battery performance. Non­authentic accessories (eg. chargers) can damage your battery and even your phone.

• You can use the phone while it is charging.

• Keeping the charger plugged to the phone when the battery is fully charged will

not damage the battery. The only way to turn off the charger is to unplug it, so it is
advisable to use an easily accessible power socket.

• If you do not intend to use your phone for several days, we recommend that you
remove the battery.

•If a fully charged battery is left unused, it will lose its charge over time.

• If a battery is being used for the first time or the battery has not been used for a

prolonged period, it may take longer time to recharge.

Optimize your battery performance

Here are some steps to help you optimize your battery performance.

- Always ensure that your phone profile is appropriately set to meet your actual usage. Profile
setting significantly impacts the phone’s battery performance. In general, Outdoor Mode is
the most power-draining setting while Silent Mode consumes the least amount of power.

- If you are not using applications like Bluetooth, WIFI, GPS and Apps, turn them off. And be
sure to lock your phone to prevent accidental pressing of the keys with the auto-lock feature.

- Adjust the intensity of your display screen’s backlight to low or medium level and for the
shortest duration. In general, the lower the backlight level and the shorter the duration, the
more power you will save.

- Avoid using or placing your phone near magnetic objects (eg. a radio or television) or on
metal surfaces, which will impact the network connection and ultimately drain power from
your battery.

User Manual MultiPhone PAP5501

9

Connect to your PC

You may need to connect your phone to a PC in order to complete activation. Your phone’s micro
USB port allows you to exchange media and other files with a PC.

- Connect your phone to the PC using the supplied USB cable.

Connect as a media device

1. Connect your phone to the PC by using the included USB cable.

2. Open the notifications panel, and then tap Connected as a media device > Media device (MTP).

3. Transfer files between your phone and the PC.

Connect with Windows Media Player

Ensure that Windows Media Player is installed on the PC.

1. Connect your phone to the PC by using the USB cable.

2. Open the notifications panel, and then tap Connected as a media device > Media device (MTP).

3. Run Windows Media Player and sync music files.

Tap Camera (PTP) on USB computer connection screen if your PC does not support
Media Transfer Protocol (MTP) nor have any appropriate driver installed.

Lock and unlock the screen

When not in use, lock your phone to prevent unwanted operations and save the battery power.

- Lock: press the power button.

When your phone is locked, nothing happens if you touch the screen.
Your phone can still:

•Receive calls, text messages, and other updates.

•Play music.

•Adjust the volume.

You can use the earphones to answer a call or listen to music.

- Unlock: press the power button, and then slide the lock icon to unlock your screen.

Auto lock

You can set a time span for the screen to be locked automatically.

1. On Home screen, tap to open the list menu.

User Manual MultiPhone PAP5501

10

2. Tap >Display > Sleep.

3. Select your desired time span.

You can also access System settings by taping on the Home screen or list menu.

Set screen lock pattern

Protect your personal information and prevent others from using your phone without your
permission by setting a screen lock pattern, Face Unlock, PIN, or password. You will be asked to
unlock the screen every time your phone is powered on or when it is idle for a certain period of
time.

1. On the Home screen, tap to open the list menu.

2. Tap >Security > Screen lock.

Setting a slide unlock

1. On the Home screen, tap to open the list menu.

2. Tap >Security > Screen lock > Slide.

Setting a Face Unlock

1. On the Home screen, tap to open the list menu.

2. Tap >Security > Screen lock > Face Unlock.

3. Fit your face in the frame to be captured.

Setting a voice unlock

1. On the Home screen, tap to open the list menu.

2. Tap >Security > Screen lock > Voice Unlock.

3. Follow the prompts to record your voice.

Setting a pattern

1. On the Home screen, tap to open the list menu.

2. Tap >Security > Screen lock > Pattern.

3. Draw a pattern by connecting four dots or more, and then draw the pattern again to verify it.

Setting a PIN

1. On the Home screen, tap to open the list menu.

2. Tap >Security > Screen lock > PIN.

3. Enter at least four numbers, and then enter the PIN again to verify it.

Setting a password

1. On the Home screen, tap to open the list menu.

2. Tap >Security > Screen lock > Password.

3. Enter at least four characters including numbers and symbols, and then enter the password
again to verify it.

Unlock your phone

Turn on the screen by pressing the Power button, and enter the unlock code.
If you have forgotten your screen lock pattern, you have up to five attempts to try and unlock your
phone. If this fails, take the device to your dealer to reset it.

User Manual MultiPhone PAP5501

11

Adjust the volume

Press the volume button to adjust the volume. Press the top of the button to turn up the volume,
and press the bottom of the button to lower it.

Recently used apps

You can easily access apps you have just recently opened.

1. Press and hold the Home button to open the list of recently used apps.

2. Slide your finger up and down to see recently opened apps.

- To switch back to an app, tap it.

- To remove an app from the list, swipe it.

Notifications panel

To help make sure you do not miss important events, many apps can provide alerts. An alert can
appear briefly as a banner at the top of the screen, which goes away if you do not respond to it, or
as a notice in the center of the screen that remains until you acknowledge it.
When you get a new notification, you can open the notifications panel to see what event
notification or new information you have received. You can also quickly access settings from the
notifications panel.

- To open the notifications panel, slide down from the top of the screen.

- To close the notifications panel, drag up the bar that is at the bottom of the screen.

- To dismiss the notification, tap .

- To enter system settings, tap .

Using Quick Settings

The Quick Settings tab allows you to easily turn airplane mode, Wi-Fi, and other functions on and
off. It also provides a quick shortcut to change the mode, set the brightness and auto rotation.

- Tap or to switch between notifications and quick settings list.

You can view your phone’s current status and use the
following options:

- Airplane mode: turn on or off your phone's wireless radios.

- Battery: check the battery status.

- Wi-Fi: activate or deactivate the Wi-Fi feature.

- Bluetooth: activate or deactivate the Bluetooth feature.

- Data connection: activate or deactivate the data connection.

- Data usage: check the data usage of the data connection.

- Audio profiles: switch to general, silent, meeting or outdoor

- profiles quickly.

- Brightness: adjust the brightness of the screen.

- Timeout: adjust the screen timeout.

- Auto rotation: allow or prevent the interface from rotating

when you rotate the device.

- Air shuffle: turn on or off Air shuffle when you are capturing
photos, browsing photos, listening to music or FM radio. You
can capture a photo, browse the next photo, listen to next
song or channel by moving you hand. The sensor is behind the
front camera.

User Manual MultiPhone PAP5501

12

Enter text

Use the on-screen keyboard to enter text, such as contact information, mail, and web addresses.
Depending on the app and the language you are using, the keyboard may correct misspellings,
predict what you are typing, and even learn as you use it.

Change the input method

You can download an input app or use the input method pre-installed on your phone. To change
the input method, follow these steps:

1. On the Home screen, tap to open the list menu.

2. Tap >Language & input > Default.

3. Choose the desired input method.

Use the Prestigio keyboard

Tap a text field to bring up the keyboard, and then tap keys on the keyboard.
You can enter the text with the built-in QWERTY keyboard.

Enter text

As you type, each letter appears above your thumb or finger. The letter is not entered until you
choose your desired word.

- Type uppercase: tap the Shift key before tapping a letter. Or touch and hold the Shift key,
then tap a letter.

- Type lowercase: tap the Shift key again and then tap a letter.

- Enter numbers, symbols or punctuation: tap .

Enter text by voice

You also can enter the text by activating the voice input feature and then speak into the
microphone. Your phone displays what you speak.

Voice typing: open the Prestigio keyboard, tap .

- If the device does not recognize your words correctly, tap the underlined text and select an
alternative word or phrase from the dropdown list.

- To change the language or add languages for the voice recognition, tap and select
Add more languages.

User Manual MultiPhone PAP5501

13

Copy and paste text

1. After you have selected the text you want to copy, tap . The selected text is then copied to
the clipboard.

2. In a text entry field, press and hold at the point where you want to paste the text.

3. Tap Paste.

Move a text

1. After you have selected the text you want to cut, tap . The selected text is then cut to the
clipboard.

2. In a text entry field, press and hold at the point where you want to paste the text.

3. Tap Paste.

You can tap to select all the text you have entered.

Use widgets

Widgets put at-a-glance important information and media content up front on your Home screen.
Some widgets are already added to your Home screen for your convenience. You can add more
from the available selections of widgets.

Add a widget to the Home screen

1. On the Home screen, tap to open the list menu.

2. Tap WIDGETS to open the widgets list.

3. Scroll left or right on the widgets panel.

4. Tap and hold the desired widgets to add it to the Home screen.

• Some widgets connect to web services. Using a web-based widget may result in
additional charges.

•The widgets available may vary depending on the region or service provider.

System upgrade

Your phone can check and notify you if there is a new upgrade available. You can also manually
check if there is an available update.
You can set this option in Settings > About phone > System updates.

Do not press any buttons while the device is upgrading.

User Manual MultiPhone PAP5501

14

Status icons

The icons in the status bar at the top of the screen give information about your phone:

Icons What it means Icons What it means

Silent mode activated. 3G network connected.

Vibration mode activated. Wi-Fi connected.

Airplane mode activated.

Battery power level. Bluetooth is activated.

Call in progress. Connected to PC.

Missed call.

New SMS or MMS. Wired headset connected.

GPRS network connected. No SIM card detected.

EDGE network connected. Alarm is set.

HSPA network connected.

Roaming (outside of normal
service area).

Wired microphone headset
connected.

User Manual MultiPhone PAP5501

15

4. Phone

Learn to use calling functions, such as making and answering calls, using options
available during a call or customizing and using call-related features.

4

Make a call

1. Tap to open the dial pad, enter your number directly. Or enter the first few digits of a
phone number, then choose a contact.

2. Tap .

You also can use the following methods to make a call:

- Make a call from the history of incoming and outgoing calls and messages.

- Make a call from the contacts list.

- Make a call from the list of favourite contacts.

The phone dialer’s SmartDial features makes it quick and easy for you to make a call.
Simply enter the phone number or first few letters of the person’s name you want
to call. SmartDial automatically searches and filters your stored contacts and the
phone numbers from the call history.

Answer a call

When you receive a phone call from a contact, the incoming call screen appears. To pick up the
phone, do the following:

- Slide to .

• If there is a headset connected to your phone, you can pick up a call by pressing
the center button of your headset.

• If the call waiting service is active, another call can be made. When the second call
is answered, the first call is put on hold.

Reject a call

When a call comes in, do the following to reject the call:

- Slide to , reject the call immediately.

- Slide to , you can send a message to the caller or create a task for returning the call.

- Press the Power button or Volume button to mute the ringing sound without rejecting the
call.

End a call

Tap to end a call. Or press the center button of your headset.

Contacts

Contacts are stored in one of the two available phonebooks: SIM phonebook (located on your
SIM card, by which the number of entries you can store depends on its capacity) or the Smart
Phonebook (located on your phone). When adding new contacts, the contacts will only be added
to the phonebook you have selected.

User Manual MultiPhone PAP5501

16
