President MC 8000 DSC User Manual [ru]

MC-8000 DSC

Owner’s Manual

Contents

Included with your MC-8000 DSC.........................................................................................4

Controls and Indicators.........................................................................................................5

Fornt Panel/Microphone ............................................................................................5

Rear Panel Connectors .............................................................................................6

ACC Connectors........................................................................................................6

LCD Display............................................................................................................... 7

Flow Chart for Menu Operation .................................................................................8

Installation.............................................................................................................................9

Choosing a Location..................................................................................................9

Engine Noise Suppression ........................................................................................ 9

Installing the MC-8000 DSC ...................................................................................... 9

Operation ............................................................................................................................10

Power On/Off ........................................................................................................... 10

Last Channel Memory ............................................................................................. 10

Squelch.................................................................................................................... 11

Channel 16/Channel 9 Communications................................................................. 11

Triple Watch .............................................................................................................12

Manual Tuning ......................................................................................................... 12

Mem (Entering channel numbers into Memory Scan) ............................................. 12

Triple Watch Scan ................................................................................................... 12

Normal Scan ............................................................................................................13

Transmitting.............................................................................................................13

Setting TX Output ....................................................................................................13

Distress....................................................................................................................13

Switching the Inland waterway Mode / Seagoing Mode ..........................................1 5

P.A. ..........................................................................................................................15

High/Low Battery betect .......................................................................................... 15

GPS .........................................................................................................................16

UIC...........................................................................................................................16

Menu Operation ..................................................................................................................17

Digital Selective Calling (DSC) ................................................................................17

Individual ...................................................................................................... 17

Group ........................................................................................................... 18

All Ships .......................................................................................................19

Position Request .......................................................................................... 20

Position Send ............................................................................................... 21

Standby ........................................................................................................21

Call Wait....................................................................................................... 22

Setup ....................................................................................................................... 23

Alarm Clock ..................................................................................................23

Local Time Adjust......................................................................................... 25

Daylight Savings On/Off ...............................................................................25

Directory .......................................................................................................26

Auto Channel Switch ....................................................................................27

Position Reply ..............................................................................................2 8

CH Tag .........................................................................................................29

Group MMSI .................................................................................................30

User MMSI....................................................................................................30

Atis ID........................................................................................................... 31

System..................................................................................................................... 32

Contrast........................................................................................................32

Lamp Adjust .................................................................................................32

Key Beep...................................................................................................... 33

NMEA Technical Setup .......................................................................................................33

VHF FM Marine Radio Telephone Channel and Functions (International Channels)......... 34

EXTENDED CH .................................................................................................................. 35

Specification........................................................................................................................36

Troubleshooting ..................................................................................................................37

Warranty ............................................................................................................................37

Certificate of Conformity .....................................................................................................38

Included with your MC-8000 DSC

Controls and Indicators

Front Panel/Microphone

Alphanuméric keyboard for direct input of channels ans names

1. PTT Switch - Press to transmit and release to receive.

2. CHANNEL ▲ / ▼ - These keys are used to change the channel number up/down. These buttons are also used to move the cursor in Menu mode.

3. STEP/SCAN - Press this key to activate the step operation. Every time this key is pushed, the radio will step to the next channel that has placed into Memory . Pressing and holding this key for 2 seconds will activate the channel scan feature.

4. MEM - Pressing this key will place the currently selected channel into Memory.

5. PA / MODE - Press this key to enable the PA (Public Address) feature / Inland Waterway Mode

6. PWR/VOL (On/Off/Volume) - Turns the unit On or Off and adjusts the speaker volume.

7. SELECT - In the Menu mode this is used to select the menu options.

8. MENU - Press this key to enter the Menu mode.

9. HI/LO - Press this key to change the transmit power to either High or Low.

10. 16/9/TRI - Press this key instantly change to Channel 16, Channel 9 or current channel. Pressing and holding this key for 2 seconds will activate the triple Watch Feature.

11. DISTRESS - Press this key to send a signal of distress in case of emergency.

12. SQUELCH - Rotate this knob eliminate background noise when a signal is not being received.

13. CLR - Press this key to delete a character.

Rear Panel Connectors

ACC Connectors

1. DC Jack

2. ACC Connector

3. Remote Connector

4. Antenna Connector

LCD Display

456

1. TX (Transmit) - Indicates transmitting.

2. HI (High) - Indicates transmit output is 25 Watts.

3. DSC - Indicators the radio is in the DSC mode.

4. TRI (Triple Watch) - Indicates Triple Watch Mode is in effect.

5. MEM (Memory) - Indicates Memory Scan Mode status for each channel selected. (Alarm Icon) - It appears when the alarm clock is set.

7. LO (Low) - Indicates transmit output is 1 Watt.

8. (GPS Icon) - It appears while GPS module is receiving the data.

9. WX - It appears when Inland Waterway Mode is selected.

10. CH TAG - This area is used for Channel Tag, Menu, DSC, GPS. These messages will continually scroll from right to the left.

11. Channel Display - Indicates Channel Number in use.

2 3

Flow Chart for Menu Operation

DSC CALL

INDIVIDUAL

GROUP

ALL SHIPS

POS REQUEST

POS SEND

STANDBY

CALL WAIT

EXIT

SETUP

ALARM CLOCK

LOCAL TIME ADJUST

DAYLITYE SAVE

DIRECTORY

AUTOCHSW

POS REPLY

CH TAG

GROUP MMSI

USER MMSI

ATIS ID

EXIT

SYSTEM

CONTRAST

LAMP ADJUST

KEY BEEP

EXIT

Notes: “POS SEND”, “LOCAL TIME ADJUST”, “DAYLITE SAVE”, and “ALARM CLOCK”

are not displayed in Menu when GPS module is not connected. When the radio is in one of the following modes: Channel 16/9 mode, Scan Mode,

or Triple Watch mode, and the user presses the Menu key, all the of these modes are cancelled.

The menu mode will be cancelled if the radio receives a DSC call or EXIT is selected.

Installation

Caution:The MC-8000 DSC will only operate with a nominal 12 volt negative ground battery

system.

It is important to carefully determine the most suitable location for your radio on your vessel. Electrical, mechanical, and environmental considerations must all be taken into account. You should select the optimum relationship among these considerations.

Keep in mind the flexibility designed into the MC-8000 DSC so that you can most conveniently use it. Features which should be considered are:

1. The universal mounting bracket may be installed on either the top or bottom of a shelf, on a bulkhead, or for overhead mounting.

2. The REMOTE speaker wires can be used with an auxiliary speaker.

3. All connections are “plug-in” type for easy removal of the radio.

Choosing a Location

Some important factors to consider in selecting the location for your MC-8000 DSC.

1. Select a location that is free from spray and splash.

2. Keep the battery leads as short as possible. Direct connection to the battery is most desirable.

3. Keep the antenna lead as short as possible. Long antenna leads can cause substantial loss of performance for both receiving and transmitting.

4. Locate your antenna as high as possible and clear from metal objects. The reliable range of coverage is a direct function of the antenna height.

5. Select a location that allows free air flow around the heat sink on the rear of the radio.

6. Select a location well away from the ship’s compass. Auxiliary speakers also should be located away from the compass.

Engine Noise Suppression

Interference from the noise generated by the electrical systems of engines is sometimes a problem with radios. The MC-8000 DSC has been designed to be essentially impervious to ignition noise and alternator noise. However, in some installations it may be necessary to take measures to further reduce the effect of noise interference. All DC battery wires, antenna lead, and accessory cables should be routed away from the engine and engine compartment, and from power cabling carrying high currents.

Installing the MC-8000 DSC

After you have carefully considered the various factors affecting your choice of location, position the radio (with the bracket, microphone, power cord, antenna and any auxiliary cables installed) into the selected location to assure there is no interference with the surrounding items. Mark the location of the mounting bracket. Remove the bracket from the radio and use it as a template to mark the holes to be drilled for the mounting hardware. Drill the holes and mount the bracket with hardware compatible with the material of the mounting surface.

Note: This HEXAGON HEAD BOL T is only for mounting the bracket

with hardware. Do not use it for installing the radio in the mounting bracket.

Connect the red wire of the supplied power cord to the positive (+) battery supply. Connect the black wire of the power cord to the negative (-) battery supply. The power cord is equipped with a fuse to protect the radio. Use only a six (6) ampere fast blow fuse for replacement. Connect the power cord to the keyed connector on the power “pigtail”.

Connect the antenna and all other auxiliary cables and accessories.

Install the radio in the mounting bracket and connect all cables and accessories to the appropriate jacks and connectors.

Note: Do not use any other mounting knobs than the ones en-

closed. Do not insert the knobs without attaching the bracket.

Operation

Power On/Off

Turn the unit On by rotating the PWR/VOL control clockwise. Adjust the volume to a comfortable level. When you turn the unit On, you will hear a beep, and the greet-

ing message below appears on the LCD for 3 seconds.

Note: When you turn On the radio for the first time after purchase, the channel 16 will

appear on the LCD.

Last Channel Memory

The MC-8000 DSC memorizes the last channel selected before you turn Off the radio. For example, if you turn Off the radio on CH 12, it will be on that channel when turned back On.

Note: In order for the last channel to be memorized, you must have the radio on that

channel for 3 seconds.

Squelch

Turn SQUELCH fully clockwise. This raises the “Squelch Gate” so high that only very strong signals can get through.

Turn SQUELCH fully counterclockwise until you hear a hiss. This lowers the “Squelch Gate” so that everything gets through - noise, weak signals, and strong signals.

Turn SQUELCH back clockwise until the hiss stops. Now the “Squelch Gate” allows only strong signals through.

Channel 16/Channel 9 Communications

T o access Channel 16 or Channel 9 communications, press 16/9/TRI. You can access 16 CH instantly while tuned to another channel. Press 16/9/TRI again for Channel 9 Calling commu-

nications. Press 16/9/TRI a third time to return to the channel selected prior to accessing Channel 16/Channel 9 communications.

The display will indicate the selected channel. To cancel Channel 16/Channel 9 communications:

• Press 16/9/TRI until the previous channel setting appears.

- - or - -

▲▲

▼▼

▲

, CH

▼

• Press CH

▲▲

or STEP/SCAN.

▼▼

Triple Watch

Triple Watch monitors Channel 16, Channel 9, and the current Marine Channel. To activate Triple Watch, press and hold 16/9/TRI for 2 seconds.

TR I appears on the LCD, indicating Triple Watch mode is in effect. If a signal is received on either Channel 16 or Channel 9, the radio remains on that channel until the signal ends.

Press and hold 16/9/TRI for 2 seconds to cancel the Triple W atch mode.

Note: While in Triple Watch mode, you can change the cur-

▲▲

rently selected channel using CH A momentary press of the 16/9/TRI button interrupts Triple Watch mode and re-

mains on channel 16, or on channel 9 if you press 16/9/TRI once more. T o return to the Triple Watch mode, simply press the button again.

▲

▲▲

or CH

▼▼

▼

▼▼

Manual Tuning

To manually select a channel, press CH and press SELECT. Communication channels are located on channel 01-28 and 60-88. Channel 70 is used for DSC only, user cannot select this channel.

▲▲

▲

▲▲

or CH

▼ ▼

▼

or use the number key pad on the mic

▼ ▼

Mem (Entering channel numbers into Memory Scan)

You can enter channels into Memory Scan for instant scanning at any time. When a channel is selected for Memory Scan, MEM appears on the LCD display .

To enter a channel into Memory Scan, select the channel you

▲▲

want to store by using CH on the mic and press SELECT, and then press MEM. The channel is stored in Memory Scan and MEM appears on the LCD display.

To cancel the channel in Memory, press MEM. The MEM icon disappears.

▲

▲▲

or CH

▼ ▼

▼

or use the number key pad

▼ ▼

Triple Watch Scan

To turn Triple Watch Scan On, press and hold STEP/SCAN for 2 seconds. While the current channel is scanned, Channel 16 and Channel 9 are also scanned every 2 seconds. Then TRI appears.

+ 28 hidden pages
