PDA6846-SS & PDA6848-SS Stainless Steel U-Bolt Kits
Instruction Manual
CONTENTS
PDA6846-SS (1 U-bolt)
• All hardware is
stainless steel
• Two (each) washers,
lock washers & nuts
• One U-bolt
PDA6846-SS U-Bolt Kit
(1 U-Bolt)
PDA6848-SS U-Bolt Kit
(2 U-Bolts)
KEY FEATURES
• Mounts Instruments to 1.5" or 2" Pipes
• Kits with One and Two U-Bolts
• All Necessary Hardware Provided
• 316 Stainless Steel
OVERVIEW
The PDA6846-SS and PDA6848-SS U-Bolt Kits provide
convenient ways to mount Precision Digital instruments
to 1.5" or 2" pipes. The PDA6846-SS kit consists of one
U-bolt and hardware and the PDA6848-SS kit consists of
two U-bolts and hardware. The U-bolt kits are made from
316 stainless steel and include all necessary hardware to
mount the instrument to the pipe.
MOUNTING INSTRUCTIONS
PDA6846-SS (1 U-bolt)
1. Orient the groove on the back of the instrument with
the pipe and secure it to the pipe with the U-bolt and
hardware provided.
PDA6848-SS (2 U-bolts)
1. Orient the groove on the back of the instrument with
the pipe and secure it to the pipe with the two U-bolts
and hardware provided.
PDA6848-SS (2 U-bolts)
• All hardware is stainless steel
• Four (each) washers, lock washers & nuts
• Two U-bolts
MOUNTING REAR VIEW
Figure 1: Rear Views of PDA6846 (left) and
PDA6848 (right) both mounted on 1.5" pipe
ORDERING INFORMATION
Model Description Compatible Instruments
PDA6846-SS Stainless Steel U-Bolt Kit (1 U-bolt) for 1.5" or 2" pipe PD67XX, PD68XX, PD69XX
PDA6848-SS Stainless Steel U-Bolt Kit (2 U-bolts) for 1.5" or 2" pipe PD8 Series
Disclaimer
The information contained in this document is subject to change without notice. Precision
Digital Corporation makes no representations or warranties with respect to the contents
hereof, and specifically disclaims any implied warranties of merchantability or fitness for a
particular purpose. See Warranty Information and Terms & Conditions on www.predig.com
for complete details.
© 2023 Precision Digital Corporation. All rights reserved.
PRECISION DIGITAL CORPORATION
233 South Street • Hopkinton MA 01748 USA • Tel (800) 343-1001
WARNING
Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Weight lb (kg)
0.20 (0.09)
0.40 (0.18)
LIM6846_B 08/23
