Powersolve Xi User Manual

Uninterruptible Power Supplies

Xi Series

www.powersolve.co.uk

1-6kVA
True On-Line UPS

Features

• Rack-Mount/Standalone Format

• Universal Battery Design (Optional 10 year batteries)

• Dual Mains Input

• Dual Position Backlit LCD

• LCD Load Segment Control 2.5kVA & 3.0kVA

(European Models)

Electrical Specification

Input Voltage (full load 115VAC version: 80-138VAC / 208VAC version: 176-276VAC / 230VAC version: 176-276VAC
without using batteries)

Input Frequency 46-64Hz
Input Power Factor >0.98 at full load
Input Protection Fuse/Breaker (see notes on next page)
Output Voltage 115VAC nominal - 100/110/115/120VAC selectable

Output Regulation ±2% of nominal
Output Waveform Sine Wave
Output THD <3% linear load
Crest Factor 3:1
Output Protection Electronic Overload Protection (ultimately by fuse/breaker)
Efficiency (AC-AC) 86% up to 1.5kVA, 90% up to 6kVA
Overload Capacity See Overload Characteristics
Output Frequency 50/60Hz dependant on input
Internal Battery Type VRLA 5 year design life. For 10 year option add suffix ‘X’ to model number
Battery Replacement Hot-swap all models
Recharge <4 hours to 90%, standard battery only
Battery String Voltage 48VDC: 1.5kVA, 96VDC: 2.5kVA-3.0kVA, 192VDC: 4.0kVA-6.0kVA
Autonomy See Tables
Temperature Autonomy, recharge & battery life based on 25°C ambient
Input Receptacles See rear panel drawings
Output Receptacles See rear panel drawings
Display/Alarm Front panel LED menu driven, audible alarms. See front panel layout
Interface (Rear Panel) 1 x RS232 & 1 x USB (fitted in option slot)
Software Supplied bundled to support Windows 95, 98, ME, 2000, XP & NT
Fitted Fuse/Breaker Xi1000/Xi15000 - 10A, Xi2500/Xi3000 - 15A, Xi4000/Xi6000 - 30A, Xi1500L CE - 15A,

REPO Remote emergency power off, must be fitted for unit to function. Connector on rear of unit. Remove

Operating Temperature 0°C to +40°C
Storage Temperature -15°C to +50°C
Operating Humidity 0-95% RH non-condensing
Operating Altitude 3000m without derating
Acoustic Noise <45dBA at 1 metre
Ingress IP20
Emissions EN55022 level B, EN50091-2 level B
ESD Immunity EN61000-4-2, level 3
Radiated Immunity EN61000-4-3, level 2
EFT/Burst EN61000-4-4, level 2
Surge EN61000-4-5, level 3
Safety Approvals EN50091-1-1, EN60240-1-1, EN60950, CE, L versions: UL1778

208VAC nominal - 208/220/230/240VAC selectable
230VAC nominal - 208/220/230/240VAC selectable

Xi1500L - 15A, Xi3000L(208VAC) - 15A, Xi3000L 120 - 30A, Xi6000L - 32A

link to shut down output in AC mode or shut down unit in battery mode

Powersolve Electronics Ltd. 8A Arnhem Road, Newbury, RG14 5RU. England

Tel: [phone] Fax: [phone] Email: [e-mail]

Uninterruptible Power Supplies

www.powersolve.co.uk

Models and Ratings

MODEL OUTPUT POWER OUTPUT CURRENT AUTONOMY

Xi1000 1000VA 700W 4.3A 12 Minutes
Xi1500 1500VA 1050W 6.5A 9 Minutes
Xi2500 2500VA 1750W 10.8A 9 Minutes
Xi3000 3000VA 2100W 13.0A 7 Minutes
Xi4000 4000VA 2800W 17.3A 12 Minutes
Xi5000 5000VA 3500W 21.7A 9 Minutes
Xi6000 6000VA 4200W 26.0A 7 Minutes

MODEL OUTPUT POWER OUTPUT CURRENT AUTONOMY

Xi1500L CE 1500VA 1050W 13.0A 5 Minutes
Xi3000L 120 3000VA 2100W 26.0A 5 Minutes

Accessory Products

Xi 232 RS232 Option Card giving second RS232 function
Xi BM 110C Battery modules for Xi series UPS - fitted with 2 x Xi BP with additional 110V input charger for extended run times
Xi BP Battery pack - contains 4 x 7Ahr VRLA 5 year design life batteries
Xi BMC Battery module for Xi series UPS - populated with 2 x Xi BP, with additional charger for extended run times
Xi BB1K5

Xi BB3K

Xi BB6K

Xi R Telescopic rack guides for UPS and battery modules
Xi S SNMP Network Adaptor Option Card replaces USB port, allowing the UPS to be addressed directly on the LAN

Xi V

(1). Unit can be used without Xi V. However, there is no automatic protection against bypass operation while the unit is on inverter. Units must operate
with common neutral. Contact sales office for details.

(1)

Make before break dual input multi format bypass module for Xi1000 & Xi1500.
Provides safety interlock when used with Xi V.

(1)

Make before break dual input multi format bypass module for Xi2500 & Xi3000.
Provides safety interlock when used with Xi V.

(1)

Make before break dual input multi format bypass module for Xi4000 & Xi6000.
Provides safety interlock when used with Xi V.

AS400 Volt Free Contact Option Card replaces USB comms port with a 15 way D-type connector
Providing Utility Fail, Battery Low, Bypass & UPS Alarm Contacts

VA Watts (at 230VAC) (full load)

VA Watts (at 115VAC) (full load)

Option Order Codes

Xi

Power (VA) Options

E.G. Xi1000RX

Xi Series, 1000VA

With telescopic rail guides and 10 year design life batteries fitted

Options (Examples)
Add suffix ‘R’ to Model Number - Adds rack guides to unit for 19” rack mounting
Add suffix ‘S’ to Model Number - Adds internal SNMP to UPS (in place of USB port)
Add suffix ‘V’ to Model Number - Adds AS400 VFC to UPS for Utility Fail, Bypass, Battery Low and UPS Fault (in place of USB port)
Add suffix ‘X’ to Model Number - Replaces 5 year design life batteries with 10 year

(1) Options should be listed in alphabetical order

Powersolve Electronics Ltd. 8A Arnhem Road, Newbury, RG14 5RU. England

Tel: [phone] Fax: [phone] Email: [e-mail]

(1)

Uninterruptible Power Supplies

www.powersolve.co.uk

Models and Ratings (L versions)

MODEL OUTPUT POWER OUTPUT CURRENT OUTPUT CURRENT AUTONOMY

Xi1500 1500VA 1050W 13.0A N/A 9 Minutes
Xi3000 3000VA 2100W N/A 14.4A 7 Minutes
Xi3000L 120 3000VA 2100W 26.0A N/A 7 Minutes
Xi6000 6000VA 4200W N/A 28.8A 7 Minutes

Accessory Products

Xi 232 RS232 Option Card giving second RS232 function
Xi BM Battery modules for Xi series UPS - fitted with 2 x Xi BP
Xi BP Battery pack - contains 4 x 7Ahr VRLA 5 year design life batteries
Xi BB3KL

Xi BB6KL

Xi R Telescopic rack guides for UPS and battery modules (1 set of guides per 2U module, ie. Xi2500L needs 2 sets Xi R)
Xi S SNMP Network Adaptor Option Card. See Options/Accessories
Xi V

(1). Unit can be used without Xi V. However, there is no automatic protection against bypass operation while the unit is on inverter. Units must operate
with common neutral. Contact sales office for details.

(1)

Make before break dual input bypass module for Xi2500L & Xi3000L
Provides safety interlock when used with Xi V

(1)

Make before break dual input bypass module for Xi4000L & Xi6000L
Provides safety interlock when used with Xi V

AS400 Volt Free Contact Option Card. See Options/Accessories

VA Watts (at 115VAC) (at 208VAC) (full load)

Option Order Codes

Xi L

Power (VA) Options

E.G. Xi1500LRX

Xi Series, 1500VA

With telescopic rail guides and 10 year design life batteries fitted

Options (Examples)
Add suffix ‘R’ to Model Number - Adds rack guides to unit for 19” rack mounting
Add suffix ‘S’ to Model Number - Adds internal SNMP to UPS (in place of USB port)
Add suffix ‘V’ to Model Number - Adds AS400 VFC to UPS for Utility Fail, Bypass, Battery Low and UPS Fault (in place of USB port)
Add suffix ‘X’ to Model Number - Replaces 5 year design life batteries with 10 year

(1) Options should be listed in alphabetical order

Powersolve Electronics Ltd. 8A Arnhem Road, Newbury, RG14 5RU. England

Tel: [phone] Fax: [phone] Email: [e-mail]

(1)

Uninterruptible Power Supplies

Option Card & REPO Details

Xi S Option Card

The Xi S card provides network connectivity and SNMP
management protocol capability to the Xi series of UPS.

Supplied with the option card is a CD which contains all
relevant software including the Manual and MIB.

The card can be factory fitted with this option on request

- please contact sales for assistance

www.powersolve.co.uk

Xi S Box Contents

Xi V Option Card

The Xi V card provides true volt free contact indication of the
following key parameters:

Mains Fail
Battery Low
Bypass
UPS Fault

These are 250VAC 2A rated contacts.

REPO

The REPO feature shuts down the protected equipment
immediately and does not follow the orderly shutdown
procedure initiated by any power management software.

This occurs when the link between pin 1 and 2 is broken.

Xi V Box Contents

Any devices which are operating on battery are also shutdown
immediately. When the REPO switch is closed, the equipment
will not return to battery power until the UPS input is re-cycled.

This can be done by shutting down the UPS and re-starting it.

Powersolve Electronics Ltd. 8A Arnhem Road, Newbury, RG14 5RU. England

Tel: [phone] Fax: [phone] Email: [e-mail]

Uninterruptible Power Supplies

www.powersolve.co.uk

Run Time Charts

UPS

Model

Xi1000 86 39 24 17 12
+1BM 328 142 90 62 49
+2BM 569 264 163 114 86
+3BM * 385 244 171 132
Xi1500(L) 86 39 24 17 12 9
+1BM 328 142 90 62 49 30
+2BM 569 264 163 114 86 55
+3BM * 385 244 171 132 80
Xi2500N
+1BM 201 86 55 39 30 18 12 9
+2BM 439 201 122 86 69 43 29 23
+3BM 684 325 199 140 108 68 49 38
+4BM * 467 296 207 161 100 71 54
Xi3000(L)N
+1BM 201 86 55 39 30 18 12 9 7
+2BM 439 201 122 86 69 43 29 23 18
+3BM 684 325 199 140 108 68 49 38 30
+4BM * 467 296 207 161 100 71 54 43
Xi4000N
+2BM 453 201 119 84 67 43 30 23 18 12
+4BM 990 453 288 201 151 97 67 53 43 30
+6BM * 718 453 328 253 151 110 82 67 49
+8BM * 990 600 453 351 214 151 117 92 67
Xi5000N
+2BM 453 201 119 84 67 43 30 23 18 12 9
+4BM 990 453 288 201 151 97 67 53 43 30 23
+6BM * 718 453 328 253 151 110 82 67 49 37
+8BM * 990 600 453 351 214 151 117 92 67 53
Xi6000(L)N
+2BM 453 201 119 84 67 43 30 23 18 12 9 7
+4BM 990 453 288 201 151 97 67 53 43 30 23 18
+6BM * 718 453 328 253 151 110 82 67 49 37 30
+8BM * 990 600 453 351 214 151 117 92 67 53 47

Recharge time will be extended as additional BM’s are added. * indicates time not calculated - consult sales office for details.

Xi1000 + 3 BM + 1 BMC 509 235 176
Xi1000 + 3 BM + 2 BMC 624 296 230
Xi1000 + 3 BM + 3 BMC 772 356 280
Xi1500 + 3 BM + 1 BMC 509 235 176 110
Xi1500 + 3 BM + 2 BMC 624 296 230 139
Xi1500 + 3 BM + 3 BMC 772 356 280 170
Xi2500N+ 4 BM + 1 BMC 569 264 201 126 86 69
Xi2500N+ 4 BM + 2 BMC 718 328 253 156 109 82
Xi2500N+ 4 BM + 3 BMC 835 385 302 187 132 102
Xi3000N+ 4 BM + 1 BMC 569 264 201 126 86 69 55
Xi3000N+ 4 BM + 2 BMC 718 328 253 156 109 82 69
Xi3000N+ 4 BM + 3 BMC 835 385 302 187 132 102 80
Xi4000N + 8 BM + 2 BMC * 569 453 288 201 156 126 86
Xi4000N + 8 BM + 4 BMC * 718 545 351 253 193 156 109
Xi4000N + 8 BM + 6 BMC * 835 665 410 302 234 187 132
Xi5000N + 8 BM + 2 BMC * 569 453 288 201 156 126 86 69
Xi5000N + 8 BM + 4 BMC * 718 545 351 253 193 156 109 82
Xi5000N + 8 BM + 6 BMC * 835 665 410 302 234 187 132 102
Xi6000N + 8 BM + 2 BMC * 569 453 288 201 156 126 86 69 55
Xi6000N + 8 BM + 4 BMC * 718 545 351 253 193 156 109 82 69
Xi6000N + 8 BM + 6 BMC * 835 665 410 302 234 187 132 102 80

Recharge as per standard battery pack. * indicates time not calculated - contact sales office for details. Not available for L versions.

200VA 400VA 600VA 800VA 1000VA 1500VA 2000VA 2500VA 3000VA 4000VA 5000VA 6000VA

(140W) (280W) (420W) (560W) (700W) (1050W) (1400W) (1750W) (2100W) (2800W) (3500W) (4200W)

UPS

Model

400VA 800VA 1000VA 1500VA 2000VA 2500VA 3000VA 4000VA 5000VA 6000VA

(280W) (560W) (700W) (1050W) (1400W) (1750W) (2100W) (2800W) (3500W) (4200W)

Standard Run Time in Minutes (Autonomy vs Load)

Extended Run Time in Minutes (Autonomy vs Load)

Powersolve Electronics Ltd. 8A Arnhem Road, Newbury, RG14 5RU. England

Tel: [phone] Fax: [phone] Email: [e-mail]

Uninterruptible Power Supplies

www.powersolve.co.uk

Mechanical Formats

Xi1000 & Xi1500(L) Xi2500 & Xi3000(L) Xi4000 Xi5000 & Xi6000(L)

Standard unit with internal batteries 2U Standard unit with internal batteries 4U Standard unit with internal batteries 8U

Each additional battery adds 2U Each additional battery adds 2U Each additional battery comprises

2 x BM (2 x 2U)

Mechanical Formats

Xi1000 & Xi1500(L) Xi2500 & Xi3000(L) Xi4000, Xi5000 & Xi6000(L)

Unit supplied in 1 box Unit supplied in 2 boxes Unit supplied in 3 boxes

BOX 1 BOX 1 BOX 1

UPS with battery pack fitted (2U) UPS electronics module (2U) UPS electronics module (4U)

1 x Input Cable 1 x Input Cable Input & Output Hard Wired
1 x Output Cable 1 x Output Cable REPO Connector
REPO connector REPO connector RS232 Cable / USB Cable

RS232 Cable / USB Cable RS232 Cable / USB Cable Software CD

Software CD Software CD Manual (on CD)

Manual (on CD) Manual (on CD) 19” rack ears and screws

Mounting feet 19” rack ears and screws 2 x battery connection cables

19” rack ears and screws

Box 2 Box 2

Battery module with 2x Xi BP fitted (2U) Battery module with 2x Xi BP fitted (2U)

Battery connection cable Battery connection cable
19” rackears and screws 19” rackears and screws

1 x key lock kit 1 x key lock kit

Box 3

Battery module with 2x Xi BP fitted (2U)

Battery connection cable
19” rackears and screws

1 x key lock kit

Powersolve Electronics Ltd. 8A Arnhem Road, Newbury, RG14 5RU. England

Tel: [phone] Fax: [phone] Email: [e-mail]

Uninterruptible Power Supplies

www.powersolve.co.uk

Front Panel Layouts

Number Description

1 Remove panel to access battery compartment (up to 1.5kVA only - other models have separate battery module)
2 Top/bottom clips for releasing LCD display (to rotate through 90°) for standalone applications
3 Backlit full function LCD display
4 Keys for menu selection, bypass and menu select. See below
5 Input breaker

Xi LCD Display

To allow for use in either rack-mount or standalone format, the
LCD display can be rotated using the top/bottom clip as shown
to the right.

A retaining screw is then used to fix the panel in place.

Never rotate panel while UPS is on.

Information available from LCD:

Input Voltage: VAC
Output Frequency: Hz
Output Voltage: VAC
Battery Voltage: VDC
Load: %
Ambient Temperature: °C
Heatsink Temperature: °C
Output Current: A

Xi Front Panel Buttons

Turn on/off the inverter or force unit to
bypass. Start UPS from battery when mains
is not available.

Select the status shown on the second
(bottom) row of the LCD. Used for setting the
function or parameter.

Select the status shown in the first (top) row
of the LCD or review parameters in the M
menu.

Enter edit menu. Selects standard UPS
parameters including output voltage, battery
test, etc.

Powersolve Electronics Ltd. 8A Arnhem Road, Newbury, RG14 5RU. England

Tel: [phone] Fax: [phone] Email: [e-mail]

Uninterruptible Power Supplies

Rear Panel Layouts

Xi1000 & Xi1500(L CE)

Xi 2500 & Xi3000L Electronic Module

www.powersolve.co.uk

Xi4000 - Xi6000

Xi BM Battery Module Xi BMC Battery Module

No. Item Description

1 Option Slot Option slot allows user to fit AS400 Dry Contact Card or SNMP Internal Network Adaptor
2 Comms. Port Standard Serial RS232 Communications via 9 pin D-type connector
3 REPO Remote Emergency Power Off (remove link to shutdown)
4 Input/Output Fuses Overload Protection
5 External Battery Allows user to connect external battery packs
6 Maintenance Bypass Allows unit to be isolated for maintenance
7 Input Breaker Input breaker for 4, 5 & 6kVA Models
8 Hardware Terminals For Input, Output & Battery (if required)
9 Battery Breaker Breaks DC voltage to/from battery module
10 Battery Connector Remove plates to access battery connectors

Powersolve Electronics Ltd. 8A Arnhem Road, Newbury, RG14 5RU. England

Tel: [phone] Fax: [phone] Email: [e-mail]

Uninterruptible Power Supplies

Rear Panel Layouts

Xi1000 & Xi1500L

www.powersolve.co.uk

Xi3000L Electronic Module

Xi6000L*

Xi BM Battery Module Xi BMC Battery Module

Xi3000L 120V Electronic Module

* Plug & Play version also available ­contact sales office

No. Item Description

1 Option Slot Option slot allows user to fit AS400 Dry Contact Card or SNMP Internal Network Adaptor
2 Comms. Port Standard Serial RS232 Communications via 9 pin D-type connector
3 REPO Remote Emergency Power Off (remove link to shutdown)
4 Input/Output Fuses Overload Protection
5 External Battery Allows user to connect external battery packs
6 Maintenance Bypass Allows unit to be isolated for maintenance
7 Input Breaker Input breaker for 4, 5 & 6kVA Models
8 Hardware Terminals For Input, Output & Battery (if required)
9 Battery Breaker Breaks DC voltage to/from battery module
10 Battery Connector Remove plates to access battery connectors

Powersolve Electronics Ltd. 8A Arnhem Road, Newbury, RG14 5RU. England

Tel: [phone] Fax: [phone] Email: [e-mail]

Uninterruptible Power Supplies

www.powersolve.co.uk

UPS Topology

The Xi series of On Line UPS provides a high integrity AC power source with zero transfer time on mains fail conditions to battery.
This On Line double conversion topology ensures that the load is protected against noise and transients.

The Xi series also offers dual input feeds ensuring that even if the main input fails, and the auxiliary supply is available, the load will
continue to be protected against power failure.

The Xi series also incorporates load segment control (2.5kVA and 3kVA European models), allowing the user to turn off (via the LCD
front panel menu) any load that is surplus to the critical part of the system. This then ensures that any critical component connected
can achieve the longest run time available.

Xi Series Schematic

Weights & Dimensions

Model Unit Dimensions Inches (mm) Unit Weight Shipping Dimensions Inches (mm) Shipping
Number Height Depth Width (total kg) Height Depth Width Weight

Xi1000 3.5 (88.9) 20.1 (510) 16.8 (426) 24 (24) 8.3 (210) 25.6 (650) 21.3 (540) 28 1 Box
Xi1500(L) 3.5 (88.9) 20.1 (510) 16.8 (426) 24 (24) 8.3 (210) 25.6 (650) 21.3 (540) 28 1 Box
Xi2500 7.0 (177.8) 20.1 (510) 16.8 (426) 14+32 (46) 8.3 (210) 25.6 (650) 21.3 (540) 18 1 of 2

8.3 (210) 25.6 (650) 21.3 (540) 35 2 of 2
53 2 Boxes

Xi3000(L) 7.0 (177.8) 20.1 (510) 16.8 (426) 14+32 (46) 8.3 (210) 25.6 (650) 21.3 (540) 18 1 of 2

8.3 (210) 25.6 (650) 21.3 (540) 35 2 of 2
53 2 Boxes

Xi4000 14.0 (355.6) 20.1 (510) 16.8 (426) 28+32+32 (92) 13.4 (340) 27.6 (700) 23.6 (600) 31 1 of 3

8.3 (210) 25.6 (650) 21.3 (540) 35 2 of 3

8.3 (210) 25.6 (650) 21.3 (540) 35 3 of 3

101 3 Boxes

Xi5000 14.0 (355.6) 20.1 (510) 16.8 (426) 28+32+32 (92) 13.4 (340) 27.6 (700) 23.6 (600) 31 1 of 3

8.3 (210) 25.6 (650) 21.3 (540) 35 2 of 3

8.3 (210) 25.6 (650) 21.3 (540) 35 3 of 3

101 3 Boxes

Xi6000(L) 14.0 (355.6) 20.1 (510) 16.8 (426) 28+32+32 (92) 13.4 (340) 27.6 (700) 23.6 (600) 31 1 of 3

8.3 (210) 25.6 (650) 21.3 (540) 35 2 of 3

8.3 (210) 25.6 (650) 21.3 (540) 35 3 of 3

101 3 Boxes

Xi BM 3.5 (88.9) 20.1 (51.0) 16.8 (426) 32 (32) 8.3 (210) 25.6 (650) 21.3 (540) 35 1 Box
Xi BMC 3.5 (88.9) 20.1 (51.0) 16.8 (426) 32 (32) 8.3 (210) 25.6 (650) 21.3 (540) 36 1 Box
Xi BP 12 (12) 15.0 1 Box

Depth shown excludes front panel. Total depth is 21.65” (550mm)

Boxes

Powersolve Electronics Ltd. 8A Arnhem Road, Newbury, RG14 5RU. England

Tel: [phone] Fax: [phone] Email: [e-mail]

Uninterruptible Power Supplies

www.powersolve.co.uk

Software Options

The Xi Series is supplied as standard with XProtect software. However, the Xi Series has been designed to work with UPSilon
software packages, which allow the user to use the Xi Series where MSXP UPS have previously been used.

UPSilon software must be used with the supplied RS232 cable. It will not function if used with the green UPSilon cable.

UPSilon is also available for Unix operating systems - please consult sales office for details.

XProtect Features:

• Simple installation & configuration

• Read/write function allows for engineer configuration of UPS

• Simple meter display of load battery capacity & temperature

• Complete data & event logging as standard

• Configurable tool bars

All models within the Xi range are provided as standard with shutdown &
monitoring software.

This software is supplied on a CD and covers all Windows® based
platforms. The software offers all of the functionality of standard shutdown
packages with some additional features for remote monitoring and
control.

Monitoring is achieved either locally through the RS232 cable (supplied)
or remotely via a connected network. This can provide the user with
information about major input and output parameters along with alarm
information as and when it appears.

Control is via the console in the software and allows the user (again
locally via the serial connection or remotely via network connection) to
schedule remote system shutdown (password controlled) and general
UPS housekeeping.

In combination with its very flexible shutdown features, the software also
lets the user know which programs were shutdown at last mains failure,
to ensure that no saved files go unmissed.

Powersolve Electronics Ltd. 8A Arnhem Road, Newbury, RG14 5RU. England

Tel: [phone] Fax: [phone] Email: [e-mail]

Uninterruptible Power Supplies

Xi2500 Overload Characteristic

(145%,9s)

(143%,10s)

(139%,11s)

(136%,12s)

(133%,14s)

(129%,16s)

(126%,17)

(124%,19s)

(121%,21s)

(119%,22s)

(117%,25s)

(115%,27s)

(114%,30s)

(112%,37s)

(109%,49s)

(108%,50s)

0

5

10

15

20

25

30

35

40

45

50

55

105 110 115 120 125 130 135 140 145 150

LOAD(%)

Xi1000-1500 Overload Characteristic

(110%,47s)

(113%,36s)

(116%,28s)

(119%,24s)

(122%,20s)

(125%,17s)

(128%,14s)

(131%,13s)

(135%,12.5s)

(146%,9s)

(143%,10s)

(140%,11s)

(137%,12s)

0

5

10

15

20

25

30

35

40

45

50

105 110 115 120 125 130 135 140 145 150

LOAD(%)

Xi3000-Xi6000 Overload Characteristic

(112%,38.4s)

(106%,72s)

(109%,50.5s)

(144%,14.5s)

(142%,11s)

(137%,12.3s)

(134%,14s)

(132%,14.5s)

(129%,16s)

(126%,17.1s)

(123%,19.4s)

(120%,22.5s)

(118%,25.5s)

(115%,30.6s)

0

10

20

30

40

50

60

70

80

105 110 115 120 125 130 135 140 145 150

LOAD(%)

TIME (seconds)

TIME (seconds)

55

Overload Graphs

NOTE:
Once the parameters shown are exceeded, the UPS
will go into bypass mode. If the overload is greater
than 160%, it will latch in bypass mode until mains is
manually recycled.

www.powersolve.co.uk

Modular Design & Key Lock Function

The Xi series modular design makes for a one man install up to 3kVA. For 4-6kVA models, two men are needed to install. The
weight of each part of the system is no greater than 30kg.

Part of the design concept is to allow one unit to be created from a number of modules. When using the modules in free-standing
mode, a key lock facility is provided. The basic principle of the key lock is illustrated below.

A key lock kit is provided with every battery module.

Key lock bolt

fixing points on

electronics module

The UPS will support the load in bypass mode until
the fuse/breaker ratings are reached. At this point the
unit will trip and shutdown.

Powersolve Electronics Ltd. 8A Arnhem Road, Newbury, RG14 5RU. England

Tel: [phone] Fax: [phone] Email: [e-mail]
