Powersolve GMB User Manual

Lithium Polymer

Rechargeable Batteries

GMB Series from 100mAH to 10,000mAH

www.powersolve.co.uk

Lithium ion polymer batteries are the new generation lithium ion
batteries. They not only give the same high voltage, long
recharge life, steady discharge rate and pollution free as liquid
lithium ion, but also eliminate the safety hazards associated
with these type of batteries. The battery design becomes more
flexible, convenient, light and easily moulded into a specific
size requirement. The performance has reached or exceeded
the technology parameters of liquid lithium ion batteries with
better reliability.
Applications include communication equipment, mobile phones
and radios, portable computer equipment or instruments, digital
cameras, camcorders, LED lamps and any equipment where
small size and high power density are important.

Lithium Polymer Standard Product List (small and medium capacity)

Type

GMB041235 120 3.7 4.0±0.2 12±0.5 35±1.0 3.0
GMB041430 120 3.7 4.0±0.2 14±0.5 30±1.0 3.0
GMB042025 120 3.7 4.0±0.2 20±0.5 25±1.0 3.0
GMB051235 150 3.7 5.0±0.2 12±0.5 35±1.0 3.5
GMB051430 150 3.7 5.0±0.2 14±0.5 30±1.0 3.5
GMB751919 200 3.7 7.5±0.2 19±0.5 19±1.0 4.3
GMB382030 150 3.7 3.8±0.2 21±0.5 30±1.0 3.9
GMB042030 180 3.7 4.0±0.2 20±0.5 30±1.0 4.0
GMB042527 200 3.7 4.0±0.2 25±0.5 27±1.0 4.3
GMB023048 220 3.7 2.0±0.2 30±0.5 48±1.0 4.5
GMB032436 220 3.7 3.0±0.2 24±1.0 36±1.0 4.5
GMB052025 180 3.7 5.0±0.2 21±0.5 26±1.0 4.5
GMB422229 240 3.7 4.2±0.2 22±0.5 29±1.0 4.8
GMB052030 250 3.7 5.0±0.2 20±0.5 30±1.0 5.0
GMB062025 250 3.7 6.0±0.2 20±0.5 25±1.0 5.0
GMB042043 300 3.7 4.0±0.2 20±0.5 43±1.0 6.5
GMB062030 300 3.7 6.0±0.2 20±0.5 30±1.0 6.5
GMB451745 300 3.7 4.5±0.2 17±1.0 45±1.0 6.5
GMB372838 310 3.7 3.7±0.2 28±0.5 38±1.0 7.0
GMB042436 330 3.7 4.0±0.2 24±1.0 36±1.0 7.2
GMB052040 330 3.7 5.0±0.2 20±0.5 40±1.0 7.2
GMB053028 330 3.7 5.0±0.2 30±0.5 29±1.0 7.2
GMB651540 330 3.7 6.5±0.2 15±0.5 40±1.0 7.2
GMB062036 350 3.7 6.0±0.2 20±0.5 36±1.0 7.8
GMB562830 350 3.7 5.6±0.2 28±1.0 30±1.0 7.8
GMB033048 380 3.7 3.0±0.2 30±0.5 48±1.0 8.0
GMB383040 400 3.7 3.8±0.2 30±1.0 40±1.0 8.2
GMB062436 430 3.7 6.0±0.2 24±1.0 36±1.0 8.4
GMB622043 440 3.7 6.2±0.2 20±0.5 43±1.0 8.5
GMB052540 450 3.7 5.0±0.2 24±1.0 40±1.0 8.7
GMB473037 460 3.7 4.7±0.2 30±0.5 37±1.0 8.9
GMB552540 480 3.7 5.5±0.2 25±1.0 40±1.0 9.0
GMB043048 550 3.7 4.0±0.2 30±0.5 48±1.0 10.5
GMB053040 550 3.7 5.0±0.2 30±1.0 40±1.0 10.5
GMB052547 600 3.7 5.0±0.2 25±0.5 47±1.0 12.0

Nominal
capacity

mAh

Nominal

Voltage

Thickness

(mm)

Width

(mm)

Length

(mm)

Weight

(grams)

Powersolve Electronics Ltd. 8A Arnhem Road, Newbury, RG14 5RU. England

Tel: [phone] Fax: [phone] Email: [e-mail]

1

Lithium Polymer

Rechargeable Batteries

Lithium Polymer Standard Product List (small and medium capacity)

Type

GMB353559 600 3.7 3.5±0.2 35±0.5 59±1.0 12.0
GMB393448 600 3.7 3.9±0.2 34±0.5 48±1.0 12.0
GMB423048 600 3.7 4.2±0.2 30±0.5 48±1.0 12.0
GMB452848 600 3.7 4.5±0.1 28±0.5 48±1.0 12.0
GMB433048 600 3.7 4.3±0.2 30±1.0 48±1.0 12.6
GMB063040 650 3.7 6.0±0.2 30±0.5 40±1.0 12.8
GMB043457 750 3.7 4.0±0.2 34±0.5 57±1.0 13.5
GMB623048 800 3.7 6.2±0.2 30±0.5 48±1.0 14.5
GMB383553 850 3.7 3.8±0.2 35±0.5 53±1.0 15.2
GMB573450 900 3.7 5.7±0.2 34±0.5 50±0.2 19.0
GMB043090 1000 3.7 4.0±0.2 30±0.5 90±1.0 23.5
GMB045058 1000 3.7 4.0±0.2 51±0.5 58±1.0 23.5
GMB045068 1000 3.7 4.0±0.2 50±0.5 68±1.0 23.5
GMB045078 1000 3.7 4.0±0.2 50±0.5 78±1.0 23.5
GMB053559 1000 3.7 5.0±0.2 35±0.5 59±1.0 23.5
GMB063450 1000 3.7 6.0±0.2 34±0.5 50±1.0 23.5
GMB383875 1000 3.7 3.8±0.2 38±1.0 75±1.0 23.5
GMB425070 1000 3.7 4.2±0.2 50±0.5 70±1.0 23.5
GMB035585 1100 3.7 3.0±0.2 55±0.5 85±1.0 26.5
GMB045060 1100 3.7 4.0±0.2 50±0.5 60±1.0 26.5
GMB055050 1100 3.7 5.0±0.2 50±0.5 50±0.5 26.5
GMB554050 1100 3.7 5.5±0.2 40±0.5 50±1.0 26.5
GMB533759 1150 3.7 5.3±0.2 37±0.5 59±1.0 27.5
GMB073450 1200 3.7 7.0±0.2 34±0.5 50±4.0 28.0
GMB455058 1200 3.7 4.5±0.2 50±0.8 58±1.0 28.0
GMB055058 1300 3.7 5.0±0.2 50±0.5 58±1.0 29.0
GMB425068 1350 3.7 4.2±0.2 50±0.5 68±1.0 29.5
GMB454080 1350 3.7 4.5±0.2 40±0.5 80±1.0 29.5
GMB325585 1400 3.7 3.2±0.2 55±0.5 85±1.0 30.5
GMB554858 1400 3.7 5.5±0.2 48±0.5 58±1.0 30.5
GMB843553 1400 3.7 8.4±0.2 36±0.5 53±2.0 30.5
GMB065050 1450 3.7 6.0±0.2 50±0.5 50±0.5 31.0
GMB515058 1450 3.7 5.1±0.2 50±1.0 58±1.0 31.0
GMB053396 1500 3.7 5.0±0.2 33±0.5 98±1.0 33.0
GMB055068 1500 3.7 5.0±0.2 50±0.5 68±1.0 33.0
GMB455078 1500 3.7 4.5±0.2 50±0.5 78±1.0 33.0
GMB554080 1500 3.7 5.5±0.2 40±0.5 80±1.0 33.0
GMB823559 1500 3.7 8.2±0.2 35±0.5 59±3.0 33.0
GMB063480 1600 3.7 6.0±0.2 34±0.5 80±1.0 33.8
GMB065058 1600 3.7 6.0±0.2 51±0.5 58±1.0 33.8
GMB425375 1600 3.7 4.2±0.2 53±0.5 75±1.0 33.8

GMB7518125 1600 3.7 7.5±0.2 18±0.5 125±1.0 33.8

GMB963450 1650 3.7 9.6±0.2 34±0.5 50±3.0 34.0
GMB055078 1700 3.7 5.0±0.2 50±0.5 78±1.0 35.0
GMB355585 1700 3.7 3.5±0.2 55±0.5 85±1.0 35.0
GMB045291 1800 3.7 4.0±0.2 52±0.5 91±1.0 38.5
GMB083565 1800 3.7 8.0±0.2 35±0.5 67±1.0 38.5
GMB103450 1800 3.7 10.0±0.2 34±0.5 50±1.0 38.5
GMB356096 1800 3.7 3.5±0.2 60±0.5 96±1.0 38.5
GMB555068 1800 3.7 5.5±0.2 50±0.5 68±1.0 38.5
GMB083666 1850 3.7 8.0±0.2 36±1.0 66±1.0 39.0
GMB093759 1900 3.7 9.0±0.2 37±0.5 59±1.0 39.0

Nominal
capacity

mAh

Nominal

Voltage

Thickness

(mm)

Width

(mm)

Length

(mm)

Weight

(grams)

Powersolve Electronics Ltd. 8A Arnhem Road, Newbury, RG14 5RU. England

Tel: [phone] Fax: [phone] Email: [e-mail]

2

Lithium Polymer

Rechargeable Batteries

Lithium Polymer Standard Product List (large capacity)

Type

GMB045396 2000 3.7 4.0±0.2 53±0.5 96±1.0 41.0
GMB056268 2000 3.7 5.0±0.5 62±0.5 68±1.0 41.0
GMB064080 2000 3.7 6.0±0.2 41±0.5 80±1.0 41.0
GMB074765 2000 3.7 7.0±0.2 47±0.5 65±1.0 41.0
GMB555078 2000 3.7 5.5±0.2 50±0.5 78±1.0 41.0

GMB3468100 2000 3.7 3.4±0.2 68±0.5 100±1.0 41.0

GMB056066 2100 3.7 5.0±0.2 60±0.5 66±1.0 42.0

GMB0445135 2100 3.7 4.0±0.2 45±0.5 135±1.0 42.0

GMB784765 2100 3.7 7.8±0.2 47±0.5 65±1.0 42.0
GMB085058 2200 3.7 8.0±0.2 51±0.5 58±1.0 44.0

GMB465585 2200 3.7 4.6±0.2 55±0.5 85±1.0 44.0
GMB0635128 2200 3.7 6.0±0.2 35±0.5 128±1.0 44.0
GMB0824130 2200 3.7 8.0±0.2 24±0.5 130±2.0 44.0
GMB3568100 2200 3.7 3.5±0.2 68±0.5 100±1.0 44.0

GMB075078 2300 3.7 7.0±0.2 50±0.6 78±1.0 48.0

GMB084868 2300 3.7 8.0±0.2 48±0.5 68±1.0 48.0

GMB093090 2300 3.7 9.0±0.2 30±0.5 90±1.0 48.0

GMB753396 2300 3.7 7.5±0.2 33±0.5 96±1.0 48.0

GMB084768 2400 3.7 8.0±0.2 47±0.5 68±1.0 50.0
GMB0535146 2500 3.7 5.0±0.2 35±0.5 146±1.0 53.0
GMB0545135 2500 3.7 5.0±0.2 45±0.5 135±1.0 53.0

GMB555396 2500 3.7 5.5±0.2 53±0.5 96±1.0 53.0

GMB557070 2500 3.7 5.5±0.2 70±0.5 70±1.0 53.0
GMB0730140 2500 3.7 7.0±0.2 30±0.5 140±1.0 53.0

GMB476096 2550 3.7 4.7±0.2 57±0.6 96±1.0 54.0

GMB064596 2600 3.7 6.0±0.2 45±0.5 96±1.0 55.0

GMB456295 2600 3.7 4.5±0.2 62±0.5 95±1.0 55.0

GMB483096 2600 3.7 4.8±0.2 30±0.5 96±1.0 55.0

GMB655396 2600 3.7 6.5±0.2 53±1.0 96±2.0 55.0

GMB965060 2600 3.7 9.6±0.2 50±1.0 60±1.0 55.0
GMB3868100 2600 3.7 3.8±0.2 68±0.5 100±1.0 55.0
GMB6335128 2600 3.7 6.3±0.2 35±0.6 128±1.0 55.0

GMB686066 2700 3.7 6.8±0.2 60±0.5 66±3.0 57.0
GMB6535125 2700 3.7 6.5±0.2 35±0.6 125±1.0 57.0

GMB526186 2800 3.7 5.2±0.2 61±0.5 86±1.0 58.5
GMB0635135 2800 3.7 6.0±0.2 35±0.5 136±1.0 58.5
GMB0636140 2800 3.7 6.0±0.2 36±0.5 140±1.0 58.5
GMB4568100 2900 3.7 4.5±0.2 68±0.5 100±1.0 61.0
GMB6835135 2900 3.7 6.8±0.2 35±0.5 135±1.0 63.0
GMB0548135 3000 3.7 5.0±1.0 48±0.5 135±3.0 63.0

GMB556096 3000 3.7 5.5±0.2 60±0.5 96±2.0 63.0
GMB0645135 3000 3.7 6.0±0.2 45±0.5 135±1.0 63.0

GMB725085 3000 3.7 7.2±0.2 50±0.5 85±1.0 63.0
GMB0735158 3000 3.7 7.0±0.2 35±0.5 158±3.0 63.0
GMB5248125 3000 3.7 5.2±0.2 48±1.0 125±2.0 63.0

GMB075585 3100 3.7 7.0±0.2 55±0.5 85±1.0 64.0
GMB0730160 3100 3.7 7.0±0.2 30±0.5 160±1.0 64.0
GMB5553135 3100 3.7 5.5±0.2 53±0.5 135±1.0 64.0

GMB085085 3200 3.7 8.0±0.2 50±0.5 85±1.0 65.0

GMB086268 3200 3.7 8.0±0.2 62±0.5 68±1.0 65.0
GMB0568100 3200 3.7 5.0±0.2 68±0.5 100±1.0 65.0
GMB0648125 3200 3.7 6.9±0.2 48±0.5 125±2.0 65.0

Nominal
capacity

mAh

Nominal

Voltage

Thickness

(mm)

Width

(mm)

Length

(mm)

Weight

(grams)

Powersolve Electronics Ltd. 8A Arnhem Road, Newbury, RG14 5RU. England

Tel: [phone] Fax: [phone] Email: [e-mail]

3

Lithium Polymer

Rechargeable Batteries

Lithium Polymer Standard Product List (large capacity)

Type

GMB0835125 3200 3.7 8.0±0.2 35±0.5 125±2.0 65.0
GMB6527190 3200 3.7 6.5±0.2 27±0.5 191±1.0 65.0
GMB7530160 3300 3.7 7.5±0.2 30±0.5 160±1.0 66.0
GMB8235125 3300 3.7 8.2±0.2 35±0.5 125±1.0 66.0
GMB0410196 3400 3.7 4.0±0.2 10±0.5 196±1.0 68.0
GMB0735135 3400 3.7 7.0±0.5 35±0.5 135±5.0 68.0
GMB0837122 3400 3.7 8.0±0.2 37±0.5 122±1.0 68.0

GMB094985 3500 3.7 9.0±0.2 49±0.5 85±1.0 71.0
GMB0748125 3500 3.7 7.0±0.2 48±0.5 125±2.0 71.0
GMB0830160 3500 3.7 8.0±0.2 30±0.5 160±3.0 71.0
GMB6545135 3500 3.7 6.5±0.2 45±0.5 135±1.0 71.0
GMB8235128 3500 3.7 8.2±0.2 35±0.5 128±1.0 71.0
GMB0565125 3600 3.7 5.0±0.2 65±0.5 125±2.0 74.0
GMB0632200 3600 3.7 6.0±0.2 32±0.5 200±1.0 74.0

GMB656096 3600 3.7 6.5±0.2 60±0.5 96±1.0 74.0

GMB656696 3600 3.7 6.5±0.2 66±0.5 96±1.0 74.0
GMB5550140 3600 3.7 5.5±0.2 50±0.5 140±1.0 74.0
GMB8235135 3600 3.7 8.2±0.5 35±0.5 135±3.0 74.0
GMB8537122 3600 3.7 8.5±0.2 37±0.5 122±1.0 74.0

GMB095974 3700 3.7 9.0±0.2 59±0.5 74±1.0 75.0
GMB0827190 3700 3.7 8.0±0.2 27±0.5 190±1.0 75.0

GMB096066 3800 3.7 9.0±0.2 60±0.5 66±1.0 77.0
GMB0835158 3800 3.7 8.0±0.2 35±0.5 158±3.0 77.0
GMB4273135 3800 3.7 4.2±0.2 73±0.5 135±3.0 77.0

GMB058792 3900 3.7 5.0±0.2 87±0.5 92±1.0 79.0

GMB078080 4000 3.7 7.0±0.2 80±0.5 80±0.5 82.0

GMB085396 4000 3.7 8.0±0.2 53±1.0 96±2.0 82.0
GMB0548165 4000 3.7 5.0±0.2 48±0.5 165±1.0 82.0
GMB0560136 4000 3.7 5.3±0.2 60±0.5 136±2.0 82.0
GMB0732200 4000 3.7 7.0±0.2 32±0.5 200±1.0 82.0
GMB0835146 4000 3.7 8.0±0.2 35±0.5 146±1.0 82.0
GMB4565145 4000 3.7 4.5±0.2 65±0.5 145±1.0 82.0
GMB6548135 4000 3.7 6.5±0.2 48±0.5 135±1.0 82.0
GMB6567100 4000 3.7 6.5±0.2 67±0.5 100±1.0 82.0
GMB7836140 4000 3.7 7.8±0.2 36±0.5 140±3.0 82.0
GMB8730160 4000 3.7 8.7±0.2 30±0.5 160±1.0 82.0

GMB087070 4000 3.7 8.0±0.2 70±0.5 70±1.0 82.0
GMB0469153 4000 3.7 4.0±0.2 69±0.5 153±1.0 82.0

GMB076696 4200 3.7 7.0±0.2 66±0.5 96±1.0 86.0
GMB0653135 4200 3.7 6.0±0.5 53±0.5 135±3.0 86.0
GMB0831190 4200 3.7 8.0±0.2 30±1.0 190±2.0 86.0
GMB7545135 4200 3.7 7.5±0.2 45±0.5 135±3.0 86.0
GMB7548125 4200 3.7 7.5±0.2 48±0.5 125±1.0 86.0
GMB8535146 4200 3.7 8.5±0.2 35±0.5 146±1.0 86.0
GMB0565143 4400 3.7 5.0±0.2 65±0.5 143±2.0 87.0

GMB087085 4500 3.7 8.0±0.2 70±0.5 85±1.0 93.0
GMB0582120 4500 3.7 5.0±0.2 82±0.5 120±1.0 93.0
GMB6568100 4500 3.7 6.5±0.2 68±0.5 100±1.0 93.0
GMB0848125 4600 3.7 8.0±0.2 48±0.5 125±1.0 96.0
GMB8535158 4600 3.7 8.5±0.2 35±0.5 158±1.0 96.0
GMB0753135 4800 3.7 7.0±0.2 53±0.5 135±10 100.0
GMB0935158 4800 3.7 9.0±0.2 35±0.5 158±2.0 100.0

Nominal
capacity

mAh

Nominal

Voltage

Thickness

(mm)

Width

(mm)

Length

(mm)

Weight

(grams)

Powersolve Electronics Ltd. 8A Arnhem Road, Newbury, RG14 5RU. England

Tel: [phone] Fax: [phone] Email: [e-mail]

4

Lithium Polymer

Rechargeable Batteries

Lithium Polymer Standard Product List (large capacity)

Type

GMB6265125 4800 3.7 6.2±0.2 65±0.5 125±2.0 100.0
GMB8545135 4900 3.7 8.5±0.2 45±0.5 135±3.0 102.0
GMB0832200 5000 3.7 8.0±0.2 32±0.5 200±1.0 102.0
GMB0848135 5000 3.7 8.0±0.2 48±1.0 135±1.0 102.0
GMB7553135 5000 3.7 7.5±0.2 53±0.5 135±1.0 102.0
GMB0932200 5400 3.7 9.0±0.2 32±0.5 200±1.0 106.0

GMB45103122 5500 3.7 4.0±0.2 103±0.5 122±1.0 110.0

GMB0853135 6000 3.7 8.0±0.2 53±0.5 135±3.0 128.0
GMB1050140 6500 3.7 10.0±0.2 50±0.5 140±1.0 135.5
GMB0890170 10000 3.7 8.0±0.2 90±0.5 170±1.0 240.0
GMB7872196 10000 3.7 7.8±0.2 72±0.6 196±1.0 240.0
GMB9560120 6800 3.7 9.5±0.2 60±0.5 120±1.0 145.0

Note: All batteries above can be supplied in multiple packs to increase voltage or current. Custom sizes
can also be accommodated but these will be subject to tooling charges and minimum order quantities.
Consult sales office for details. All cells and battery packs are provided with Protective
Circuit Modules (PCM) to protect against over charging, over discharging and over current.

Nominal
capacity

mAh

Nominal

Voltage

Thickness

(mm)

Width

(mm)

Length

(mm)

Weight

(grams)

Electrical Specification

Charge Voltage 4.2V per single cell

Nominal Voltage 3.7V per single cell (open circuit voltage 3.6 to 3.85V when shipped)

Nominal Capacity At 0.2C discharge down to 2.75V cut off voltage

Cycle Life ≥300 Cycles, one cycle refers to one charge period and one discharge period.

Impedance Cell impedance ≤100mΩ

Charging Methods
Charging Current
Low Temperature Charging (0º-10ºC)
Standard Charging (0º-45ºC)
Fast Charging (10º- 45ºC)
Charge Time

Standard Discharge Current (-10º-45ºC)
Max Discharge Current

Discharge Cut Off Voltage 2.75V

Operating Temperature Discharge -10ºC to +45ºC, Charge 0ºC to +45ºC. Cells must be stored at 3.6 to 3.9V. Over

Operating Humidity 45-75% relative humidity

Long Term Storage Temperature -5ºC to +35ºC, relative humidity 45-75%, Voltage 3.8V±0.1V

Test condition Charge 0.2C to 4.2V discharge 0.2VC to 2.75V. The cycle time is when the
discharge capacity is about 75% of the rated capacity.

Standard Constant Current: 0.2C, Fast Constant Current: 0.5C
Below 0.1C CC from 2.75V to 4.2V, then CV to 0.05C cut off
Standard 0.2C constant current to 4.2V, constant voltage at 4.2V to cut off current ≤0.05C
Fast Charge 0.5Cconstant current to 4.2V, constant voltage at 4.2V to cut of current ≤0.05C
Standard Charge 8 hours, Fast Charge time 2.8 hours

Constant discharge at 0.2C to cut off voltage of 2.75V
1C

long storage periods cells should be cycled every 90 days. The method is to do a
charge/discharge cycle with standard method, then charge to 3.6 to 3.9V

Safety Tests

Test Test Conditions and Method Results

Overcharge After standard charging, the cell is connected for 8 hours while the constant voltage

Short Circuit A charged battery is short circuited for 1 hour at 0.04Ω No explosion or fire

Heat Shock The cell is placed in a thermal chamber and temperature is raised to 120±2ºC at the rate of

Humidity and

heat test

is held at 4.5V and standard charging current flow through it

5±2ºC min and held for 10 minutes, then cooled to room temperature at the rate of 5±2ºC min

A battery is placed in a box for 48 hours where the temperature is 40ºC±2ºC and the relative
humidity is 90-95%

No explosion or fire

No explosion or fire

No explosion or fire

Powersolve Electronics Ltd. 8A Arnhem Road, Newbury, RG14 5RU. England

Tel: [phone] Fax: [phone] Email: [e-mail]

5

Lithium Polymer

Rechargeable Batteries

High & Low Temperature Tests

Test Test Conditions and Method Results

High Temperature

Low Temperature

Charge Maintenance

Test Test Conditions and Method Results

Charge Maintanence A charged battery sits for 28 days at an ambient temperature of

Handling Precaution & Guidelines

Charging Current The charging current must be less than the maximum charge current specified in the electrical

Charging Voltage The charging voltage must be less than the maximum nominal voltage 4.2V and the charging

Charging Temperature The cell must be charged within the range specified in the electrical specification

Reverse Polarity Since charging is done with a constant current or a constant voltage, reverse charging is prohibited. If

Discharging Current The cell shall be discharged at less than the maximum discharge current specified in the electrical

Discharge Temperature The operating temperature when discharging the battery should always be within the range specified in

Over Discharge Over discharging will cause cell degradation and functional losses. The cell can degrade into an over

Protective Circuit Module

(PCM)

Long Term Storage

Handling of Cells • Don’t charge the cells and keep them in a charged state for long periods

A charged battery is placed in an oven for 2 hours at 55ºC±2ºC,
then discharged at a 0.5C current to the termination voltage Discharge 90% of the original Capacity

A charged battery is placed in a thermal chamber for 2 hours at

-10ºC±2ºC, then discharged a 0.1C to the termination voltage

25ºC±1C, then discharged at 0.2C current to termination voltage

specification

voltage upper limit is 4.3V per single cell

the cell is connected in reverse polarity it cannot be charged. Reverse polarity can damage the cell and
lead to degradation of cell performance, impair cell safety and cause heat generation or leakage

specification. A high discharge current may reduce discharge capacity significantly and cause
overheating

the electrical specification

discharge state through self discharging. In order to prevent this the cell should be charged periodically
to retain between 3.6V and 3.9V

Cells should be used with a PCM that can protect against over charging, over discharging and over
current

If cells are to be stored for 3 months or longer they should be held in a dry cool environment. Voltage
during storage needs to be maintained between 3.6 and 3.9V. If stored for long periods keep in a half
charged state

• Avoid any short circuit, it will cause the leads to get hot and lose electronic functions

• Packaging is easily damaged by sharp objects. Avoid touching with sharp objects during handling

• Next to leads is sealed edge, Don’t bend or fold sealed edges it is sensitive to movement

• Don’t open the folded edge on the side of the cells

• Don’t bend the tabs as these are sensitive and could be damaged

• Avoid mechanical shock to the cells

• Do not place cells in an oven, washing machine or high voltage container

• Use only recommended charger

• You should immediately stop charging if cell overheats, emits odour, changes shape or colour etc.

• Adults should supervise the use of batteries by children

• Before using batteries carefully read and understand handling guidelines.

• Avoid electro static discharge when using, charging and storing cells.

• Avoid accidentally putting battery in contact with metal conductors, which may cause a short.

• Don’t short circuit battery output terminals during assembly

• Never incinerate or dispose of the cells in a fire

Discharge more than 85% of the
original capacity

Discharge >85% of the original Capacity

For any further details or information please do not hesitate to contact our sales office
either by phone or email where we are able to offer our expert technical advise

Powersolve Electronics Ltd. 8A Arnhem Road, Newbury, RG14 5RU. England

Tel: [phone] Fax: [phone] Email: [e-mail]

6
