Introduction & useful information
Powersolve Electronics Ltd. has been in business as a specialist in power supplies and power
conversion technology since 1987. During this time we have supplied millions of power
conversion products such as AC-DC power supplies, DC-DC converters, DC-AC inverters, Battery
Chargers, Batteries, Uninterruptible Power Supplies and many other products. We are supplying
major customers in the electronics industry, communications, datacoms, telecoms, industrial, oil and
gas and in fact most types of industry where there is the need for power and power conversion
products. In particular we have a lot of experience in lithium batteries and lithium battery chargers
for the communication industry particularly in encrypted radio systems where we have
supplied many millions of pounds worth of intelligent battery chargers used in radio communication
equipment for the emergency services.
We have now added a new range of commercial mobile power bank products for charging devices
that use USB chargers such as mobile phones, GPS, MP3 players, tablet PC’s, digital cameras and
in fact anything that can be charged via a standard 5V USB output. All of our products have been
fully tested for battery capacity, conversion efficiency and battery protection circuits. All battery ratings
quoted are the “real” capacity of the batteries fitted. Most of our products are very slim, light weight
and compact and are manufactured using thin lithium polymer battery cells. They will fit easily into
the pocket or handbag. Conversion efficiencies of our products are high and recharge times are
kept to a minimum with 2A charging inputs on the higher powered products.
Some suppliers of these types of devices make wild claims about battery capacity, recharge times
and the number of charges achievable for your mobile phone from one battery pack. The first thing
to understand is that whatever the mAh rating of the battery in our battery power pack, not all of this
is available to charge your phone or other equipment. The Lithium battery is rated at 3.7V. The USB
output is 5VDC. Therefore the 3.7V has to be converted to 5VDC through an internal voltage
regulator, so there are losses in efficiency here. When you charge your mobile or other device this
will also have a 3.7V lithium battery fitted. So the 5V from our power pack now has to be dropped
to the charger level within the mobile, which is 4.2VDC, therefore resulting in more inefficiency. Add
to this the fact that the battery will give more of it’s capacity when operating at normal ambient
temperature than it will when it is cold. So you can understand the problem. On average the
conversion rate from our products is around 80 to 85% and up to 90% for some models. But this
does depend on temperature, discharge rate and age of the battery. In the specification attached
we have tried to give an indication of what performance you can expect when charging an average
mobile phone and also the recharge period for charging our battery pack. For example if you see
claims of 5 hours charge time for a 10,000mAh battery pack when it only charges at 5V 1 Amp input
then this is completely ridiculous! A 1 Amp charger would take more than 10 hours to charge a
10,000mAh (10Ah) battery! When charging our power bank battery packs you can use either a 5V
1A or 2A USB charger. If our model is rated at 1A input it will simply use only what is required from
a 2A charger. And if rated at 2A input it will obviously charge faster with 2A USB charger than with
a 1A version. Same applies to your mobile devices you can use either the 1A or 2A output where
fitted. The current limiting will be done in your device so you cannot overcharge your device.
Also included in this brochure are some USB travel charger products with interchangeable AC heads
that enable them to be used in most countries in the world. All of the USB products are not just CE
marked for Europe but with full safety approvals.
We hope that you will find this information useful and hope you will find our products of interest and
above all reliable when used with your mobile devices.
web: www.powersolve.co.uk email: [email protected]
Page 3
Solar Powered & Rechargeable Back Up Battery Packs
SOL1850 1850mAh
Features
• Compatible with mobile electronic devices that operate from 5V DC at
up to 1A such as USB powered products. ie mobile phones, GPS, MP3
players and digital camera’s etc. They offer extended battery operating
time and can be solar charged as well as by standard USB charger.
• LED indicator displays 3 stages of battery condition and solar function
• Built in software controls temperature, voltage and current
• High efficiency with low standby power
• Housed in robust and temperature resistant plastic case
• Simple operation, one push button switch
• Long battery life cycles
• 12 months warranty
• Can extend the charge of typical mobile phone giving up to double the
the normal standby or talk time. Complete with USB cable & connectors
Specification
• Battery Capacity: 1850mAh 3.7V Li-polymer battery with built in
protection circuit
• DC Output: 5V 1A max via USB port
• Charger Input (USB): 5V 1A via micro USB port
• Solar Panel: Monocrystal silicon panel 1.1W
• Charging Time: 10-15 hours by integral Solar panel or 3 hours
by 5V 1A USB charger
• Dimension: 147 x 76 x 10mm
• Weight: 105gms approx
£29.95
inc. vat
SOL5000 5000mAh
Features
• Compatible with mobile electronic devices that operate from 5V DC at
1A or 2A such as USB powered products. ie mobile phones, GPS, MP3
players iPads, tablet PC and digital camera’s etc., to give extended
battery operating time. Can be solar charged or via USB charger.
• LED indicator displays 3 stages of battery condition and solar function
• Built in software controls temperature, voltage and current
• High efficiency with low standby power
• Housed in robust and temperature resistant plastic case
• Simple operation, one push button switch
• Long battery life cycles
• 12 months warranty
• Can considerably extend the standby or talk time of a typical mobile
phone etc. Typically you could get 2 or 3 full charges for the average
mobile phone. Complete with USB cable & connectors.
Specification
• Battery Capacity: 5000mAh 3.7V Li-polymer battery with built in
protection circuit
• DC Output: 5V 1A and 5V 2.1A via USB port
• Charger Input (USB): 5V 1A via micro USB port
• Solar Panel: Monocrystal silicon panel 0.7W
• Charging Time: 30 hours by Solar or 5-6 hours by 5V 1A USB
charger
• Dimension: 115 x 70 x 15mm
• Weight: 125gms approx
£38.95
inc. vat
web: www.powersolve.co.uk email: [email protected]
Page 4
Slimline Rechargeable Back Up Battery Packs
SPB2801 2800mAh
Features
• Compatible with mobile electronic devices that operate from 5V DC at
up to 1A such as USB powered products. ie mobile phones, GPS, MP3
players, and digital camera’s etc., to give extended battery operating time
• A 4LED display indicates battery state of charge
• Ultra slim (11mm) black plastic housing fits easily into the pocket
• Li polymer battery cell can reach high life cycles.
• Simple operation, one push button switch, with LED torch
• High power conversion efficiency
• 12 months warranty
• Can considerably extend the standby or talk time of a typical mobile
smart phone etc. Typically you would get one full charge or more for a
typical smart phone.Complete with USB cable & connectors.
Specification
• Battery Capacity: 2800mAh 3.7V Li-polymer battery with built in
protection circuit
• DC Output: 5V 1A and via USB port
• Charger Input (USB): 5V 1A via micro USB port
• Charging Time: 4 hours by 5V 1A USB charger
• Dimension: 91 x 51 x 11mm
• Weight: 67gms approx
£25.95
inc. vat
SPB8001 8000mAh
Features
• Compatible with mobile electronic devices that operate from 5V DC at
1A or 2A such as USB powered products. ie mobile phones, GPS, MP3
players, iPads, tablet PC and digital camera’s etc., to give extended
battery operating time
• A 4 LED display indicates battery state of charge
• Ultra slim (12mm) black plastic housing fits easily into the pocket
• Powerful 8000mAh lithium polymer cell offers high life cycles.
• Simple operation, one push button switch
• High power conversion efficiency
• 12 months warranty
• Can considerably extend the standby or talk time of a typical mobile
phone or iPad etc. Typically you could get 3-4 full charges for a typical
smart phone. Complete with USB cable & connectors
Specification
• Battery Capacity: 8000mAh 3.7V Li-polymer battery with built in
protection circuit
• DC Output: 5V 2A via USB port
• Charger Input (USB): 5V 1-2A via micro USB port
• Charging Time: 5-9 hours by 5V 1A or 2A USB charger
• Dimension: 135 x 67 x 12mm
• Weight: 175 gms approx
£42.95
inc. vat
web: www.powersolve.co.uk email: [email protected]
Page 5
Slimline Rechargeable Back Up Battery Packs
PSB3800 3800mAh
Features
• Compatible with mobile electronic devices that operate from 5V DC at
1A or 2A such as USB powered products. ie mobile phones, GPS, MP3
players, iPads, tablet PC and digital camera’s etc., to give extended
battery operating time
• A 4 LED display indicates battery state of charge
• Ultra slim (11 mm) black plastic housing fits easily into the pocket
• Li polymer battery cell can reach up to 1000 life cycles.
• Simple operation, one push button switch, with LED torch
• Very high power conversion efficiency
• 12 months warranty
• Can considerably extend the standby or talk time of a typical mobile
phone etc. Typically you could get one and a half full charges for the average
mobile phone. Complete with USB cable & connectors
Specification
• Battery Capacity: 3800 mAh 3.7V Li-polymer battery with built in
protection circuit
• DC Output: 5V 2A via USB port
• Charger Input (USB): 5V 1A via micro USB port
• Charging Time: 4 hours fast charge by 5V 1A USB charger
• Dimension: 100 x 59 x 11mm
• Weight: 97gms approx
£34.95
inc. vat
PSB8000 8000mAh
Features
• Compatible with mobile electronic devices that operate from 5V DC at
1A or 2A such as USB powered products. ie mobile phones, GPS, MP3
players, PC tablets and digital camera’s etc., to give extended battery
operating time
• A 5 LED display indicates battery state of charge
• Ultra slim (13 mm) black plastic housing fits easily into the pocket
• Li polymer battery cell can reach up to 1000 life cycles.
• Simple operation, one push button switch, with LED torch
• Very high power conversion efficiency
• 12 months warranty
• Can considerably extend the standby or talk time of a typical mobile
phone etc. Typically you could get 3 to 4 full charges for the average
mobile phone. Complete with USB cable & connectors
Specification
• Battery Capacity: 8000 mAh 3.7V Li-polymer battery with built in
protection circuit
• DC Output: 5V 1A & 2A via USB port
• Charger Input (USB): 5V 1-2A via micro USB port
• Charging Time: 4-5 hours fast charge by 5V 2A USB charger
• Dimension: 124 x 70 x 13 mm
• Weight: 178 gms approx
£57.95
inc. vat
web: www.powersolve.co.uk email: [email protected]
Page 6
Compact Rechargeable Back Up Battery Packs
SPB5001 5000mAh
Features
• Very high quality metal alloy and glass effect case measuring
only 105 x 58 x 14mm
• Compatible with mobile electronic devices that operate from 5V
DC at 1A such as USB powered products. ie mobile phones,
GPS, MP3 players and digital camera’s etc., to give extended
battery operating time.
• A 4 LED display indicates battery state of charge
• 5000mAh lithium polymer battery with high life cycles
• High power conversion efficiency.
• 12 months warranty
• Can considerably extend the standby or talk time of a typical
mobile phone etc. Typically you could get 2 or more full charges for
the average mobile phone. Complete with USB cable & connectors
Specification
• Battery Capacity: 5000mAh 3.7V Li-polymer battery with built in
protection circuit
• DC Output: 5V 1A via USB port
• Charger Input (USB): 5V 1A via micro USB port
• Charging Time: 5-6 hours charge time by 5V 1A USB charger
• Dimension: 105 x 58 x 14 mm
• Weight: 177 gms approx
£34.95
inc. vat
PAF10AH4 10,400mAh
Features
• Compatible with mobile electronic devices that operate from 5V DC at
1A or 2A such as USB powered products. ie mobile phones, GPS, MP3
players, PC tablets and digital camera’s etc., to give extended battery
operating time
• A 4 LED display indicates battery state of charge
• Compact 2 tone black and beige plastic housing
• Fitted with 4 x Samsung 2600mAh lithium ion cylindrical batteries
• Simple operation, one push button switch, with LED torch
• Very high power conversion efficiency of over 90%
• 12 months warranty
• Can considerably extend the standby or talk time of a typical mobile
phone etc. Typically you could get 5 full charges for the average mobile phone.
Complete with USB cable & connectors
Specification
• Battery Capacity: 4 X 2600mAh 3.7V li ion cylindrical cells with built
in protection circuit
• DC Output: 5V 1A & 5V 2A via dual USB ports
• Charger Input (USB): 5V 2A via micro USB port
• Charging Time: 6.5 hours charge time by 5V 2A USB charger
• Dimension: 136 x 58 x 22 mm
• Weight: 232 gms approx
£49.95
inc. vat
web: www.powersolve.co.uk email: [email protected]
Page 7
USB Adaptor Chargers
PKS06-USB 5 Volt 1 Amp
Features
• Universal AC input of 90-264VAC 50/60Hz
• Interchangeable AC heads for UK, EU, USA and Australia
• No load power consumption max 0.3W meets MEPS level V
efficiency standards
• Input fuse protected
• Output 5 Volts 1 Amp via standard USB socket
• Output short circuit, over load and over voltage protected
• Operating temperature 0-40°C
• Full international safety approvals and CE marked
• 2 years warranty
This product is compatible with electronic devices that operate
from a standard USB adaptor charger such as smart phones,
tablet PC’s, digital cameras, etc.
£9.95
inc. vat
PKS11-USB 5 Volt 2.1 Amp
Features
• Universal AC input of 90-264VAC 50/60Hz
• Interchangeable AC heads for UK, EU, USA and Australia
• No load power consumption max 0.3W meets MEPS level V
efficiency standards
• Input fuse protected
• Output 5 Volts 2.1 Amp via standard USB socket
• Output short circuit, over load and over voltage protected
• Operating temperature 0-40°C
• Full international safety approvals and CE marked
• 2 years Warranty
This product is compatible with electronic devices that operate
from a standard USB adaptor charger such as smart phones,
tablet PC’s, digital cameras, etc.
£13.95
inc. vat
PKS15-2USB Dual Output 5 Volt 1 Amp & 5V 2 Amps
Features
Universal AC input of 90-264VAC 50/60Hz
•
• Interchangeable AC heads for UK, EU, USA and Australia
• No load power consumption max 0.3W
• Input fuse protected
• Outputs 5 Volts 1A & 5V 2.1 Amp via standard USB sockets
• Output short circuit, over load and over voltage protected
• Operating temperature 0-40°C
• Full international safety approvals and CE marked
• 2 years warranty
This product is compatible with electronic devices that operate
from a standard USB adaptor charger such as smart phones,
tablet PC’s, digital cameras, etc. Can charge two devices via
standard USB cables.
£15.95
inc. vat
web: www.powersolve.co.uk email: [email protected]
Loading...
