PTX8000 / PTX8001 / PTX8100
Heavy Duty Utility Table – 36” , 72” and Combo Kit
ASSEMBLY INSTRUCTIONS
IMPORTANT
Please read these instructions carefully before beginning to
assemble this display. Save instructions for future reference.
9601 Newton Avenue South, Suite A
Bloomington, MN 55431
www.poly-tex.com
REV: AB-120329
U.S. & Canada Toll Free
( 844) 822-7009
(651) 463-7009
Page 2
PARTS IDENTIFICATION
CH8003
TABLE TOP 24" x 72"
(2)
CH8002
TABLE LEG 34"
NB1974
3/16" WRENCH HEX
(1)
CH8004
TABLE TOP 24" x 36"
(2)
5/16-18 x 3/4" BUTTON
HEAD CAP SCREW
5/16" LOCK WASHER
NB1970
NB1872
5/16" HEX NUT
5/16" FLAT WASHER
2
TOOLS & EQUIPMENT REQUIRED
A 3/16" hex wrench (provided) and a 1/2" open end (or adjustable) wrench
are required for assembly.
Page 3
CH8002 - 4
NB1970 - 16
NB1886 - 16
NB1862 - 16
NB1872 - 16
ASSEMBLY INSTRUCTIONS CH8000
LOWER SHELF
MOUNTS INSIDE LEGS
TYPICAL LEG TO
TABLE TOP CONNECTION
LEGS MOUNT INSIDE
UPPER TABLE TOP
3
Page 4
CH8002 - 4
NB1970 - 16
NB1886 - 16
NB1862 - 16
NB1872 - 16
ASSEMBLY INSTRUCTIONS CH8001
TYPICAL LEG TO
TABLE TOP CONNECTION
LOWER SHELF
MOUNTS INSIDE LEGS
4
LEGS MOUNT INSIDE
UPPER TABLE TOP
Page 5
CH8002 - 8
NB1970 - 28
NB1886 - 28
NB1862 - 28
NB1872 - 28
ASSEMBLY INSTRUCTIONS CH8100
PLACE LEGS
INSIDE UPPER
TABLE TOPS
TYPICAL LEG TO
TABLE TOP CONNECTION
CH8004 24" x 36"
TABLE TOP(2)
CH8003 24" x 72"
TABLE TOP (2)
CH8002 34" TABLE
LEG (8)
LOWER SHELVES
MOUNT INSIDE LEGS
LEGS MOUNT INSIDE
UPPER TABLE TOPS
5
Page 6
SAFETY GUIDELINES
Do not climb, sit on, or use this product as a ladder. Injuries may occur.
Do not place or install electrical items on this product. Wet conditions are typical and
electrical shock may occur.
Do not place this product on a slope that exceeds 3 degrees.
CARE & MAINTENANCE
To clean, use a clean damp cloth to wipe off dirt and debris.
Limited Warranty
Poly-Tex, Inc. warrants its products to be free from defects in material and workmanship for a
period of (1) year from date of invoice. This warranty is provided to the original purchaser of the
product and is not transferable. Poly-Tex does not warrant parts not manufactured by Poly-Tex,
but does assign any transferable manufacturer or supplier warranties. Should any defect be
found, full repair or replacement will be rendered to the customer at no cost following inspection
by a Poly-Tex representative and the return of the defective product to our Castle Rock, MN
factory. Expenses for removal or reinstallation of defective products will not be covered by the
warranty.
POLY-TEX SHALL NOT BE HELD RESPONSIBLE FOR ANY SPECIAL OR
CONSEQUENTIAL DAMAGES, OR FOR ANY DELAY IN PERFORMANCE OF THIS
WARRANTY
ALL OTHER WARRANTIES WHETHER IMPLIED, WRITTEN OR ORAL INCLUDING THE
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
This warranty does not cover damage from customer abuse, misuse, improper installation,
customer modifications, customer negligence in performing normal maintenance, damage
resulting from acts of nature.
BEYOND OUR CONTROL. THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF
Poly-Tex, Inc.
9601 Newton Avenue South, Suite A
Bloomington, MN 55431
Toll free (844) 822-7009
www.poly-tex.com
