CD4000 4 level circle display
ASSEMBLY INSTRUCTIONS
IMPORTANT
Please read these instructions carefully before beginning to
assemble this display. Save instructions for future reference.
P.O. Box 458
27725 Danville Avenue
Castle Rock, MN 55010
www.poly-tex.com
REV: AB-120329
U.S. & Canada Toll Free
800-852-3443
(651) 463-7009
fax (651) 463-2479
Page 2
PARTS IDENTIFICATION
CD4005
20" SHELF
CD4004
24" SHELF
CD4001
BASE
CD4002
POST
CD4003
28" SHELF
NB1848
5/16" x 2" HEX BOLT
(3)
NB1978
5/16" SET SCREW
(5)
NB1979
5/32" HEX WRENCH
OPTIONAL COMPONENTS
NB1903
5/16" WING NUT
(3)
CD4006
SIGN POST 22 1/2"
TOOLS & EQUIPMENT REQUIRED
No additional tools are required.
CD4007
SIGN HOLDER, 3 SIDE
2
Page 3
20" TOP SHELF
24" MIDDLE SHELF
ASSEMBLY INSTRUCTIONS
INSERT CASTER
INTO STUB
OF BASE
28" BOTTOM SHELF
5/16" WING NUT
(3)
TWIST CASTER
UNTIL TIGHT
POST
5/16" x 2" HEX BOLT
BASE
(3)
1. INSERT END OF POST INTO THE BASE. SLIDE SHELVES ONTO POST AND FASTEN
WITH A 5/16" X 2" BOLT & WING NUT.
3
Page 4
ASSEMBLY INSTRUCTIONS
4
2. USE 5 SET SCREWS TO HOLD POST AND SHELVES FIRMLY IN PLACE.
Page 5
OPTIONAL SIGN HOLDER ASSEMBLY
1. SLIDE RECESSED END OF SIGN POST INTO TOP OF POST. SLIDE SIGN HOLDER
ONTO TOP OF SIGN POST.
CASTER USE INSTRUCTIONS
ONCE THE DISPLAY IS IN PLACE, ALL CASTERS MUST BE LOCKED
INTO PLACE USING THE CASTER BRAKES TO PREVENT DISPLAY
MOVEMENT. THE BRAKE IS ACTIVATED BY ROTATING THE LEVER
FROM THE "OFF" POSITION TO THE "ON" POSITION AS SHOWN.
5
Page 6
SAFETY GUIDELINES
Do not climb, sit on, or use this product as a ladder. Injuries may occur.
Do not place or install electrical items on this product. Wet conditions are typical and
electrical shock may occur.
Do not place this product on a slope that exceeds 3 degrees.
Do not move this display after product is in place. Damage to display and injuries may occur.
Lock casters (when provided) once display is in place to prevent movement.
Remove all debris or obstacles from caster's path before moving.
CARE & MAINTENANCE
To remove loose soil and debris, simply spray the soiled areas with a garden hose.
Prior to storage, all surfaces of this product should be sprayed down with water and allowed to dry
completely.
Limited Warranty
Poly-Tex, Inc. warrants its products to be free from defects in material and workmanship for a
period of (1) year from date of invoice. This warranty is provided to the original purchaser of the
product and is not transferable. Poly-Tex does not warrant parts not manufactured by Poly-Tex,
but does assign any transferable manufacturer or supplier warranties. Should any defect be
found, full repair or replacement will be rendered to the customer at no cost following inspection
by a Poly-Tex representative and the return of the defective product to our Castle Rock, MN
factory. Expenses for removal or reinstallation of defective products will not be covered by the
warranty.
POLY-TEX SHALL NOT BE HELD RESPONSIBLE FOR ANY SPECIAL OR
CONSEQUENTIAL DAMAGES, OR FOR ANY DELAY IN PERFORMANCE OF THIS
WARRANTY BEYOND OUR CONTROL. THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF
ALL OTHER WARRANTIES WHETHER IMPLIED, WRITTEN OR ORAL INCLUDING THE
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
This warranty does not cover damage from customer abuse, misuse, improper installation,
customer modifications, customer negligence in performing normal maintenance, damage
resulting from acts of nature.
