BD3000 circular display 32-54
ASSEMBLY INSTRUCTIONS
IMPORTANT
Please read these instructions carefully before beginning to
assemble this display. Save instructions for future reference.
P.O. Box 458
27725 Danville Avenue
Castle Rock, MN 55010
www.poly-tex.com
REV: AB-120329
U.S. & Canada Toll Free
800-852-3443
(651) 463-7009
fax (651) 463-2479
Page 2
PARTS IDENTIFICATION
BD1000
BASE (32")
NB1972
1/4" x 1 1/2" HEX BOLT
BD1001
SHELF (32")
NB1840
1/4" x 3/4" HEX BOLT
BD1002
SHELF (16")
SUPPORT (50")
NB1860
1/4" LOCK WASHER
BD1003
NB1870
1/4" HEX NUT
2
TOOLS & EQUIPMENT REQUIRED
(2) 7/16" WRENCHES
Page 3
ASSEMBLY INSTRUCTIONS
ATTACH SUPPORT TO BASE
USING 1/4" x 3/4" HEX BOLTS,
LOCK WASHERS, AND HEX
NUTS AS SHOWN. FINGER
TIGHTEN ONLY AT THIS TIME.
SUPPORT
1/4" x 3/4" HEX BOLT,
LOCK WASHER,
& HEX NUT
BASE
3
Page 4
ASSEMBLY INSTRUCTIONS
DETERMINE THE REQUIRED HEIGHT OF
THE SHELF. ALIGN THE SHELF (32")
WITH THE HOLES IN SUPPORT AND
ATTACH USING 1/4" x 1 1/2" HEX BOLTS,
LOCK WASHERS, AND HEX NUTS AS
SHOWN. FINGER TIGHTEN ONLY AT
THIS TIME.
SHELF (32")
4
1/4" x 1 1/2" HEX BOLT, LOCK WASHER,
& HEX NUT.
Page 5
ASSEMBLY INSTRUCTIONS
POSITION SHELF (16") BETWEEN TOP OF SUPPORTS AND ATTACH USING
1/4" x 3/4" HEX BOLTS, LOCK WASHERS, AND HEX NUTS AS SHOWN.
STRAIGHTEN DISPLAY AND TIGHTEN BOLTS SECURELY.
SHELF (16")
1/4" x 3/4" HEX BOLT,
LOCK WASHER,
& HEX NUT
5
Page 6
SAFETY GUIDELINES
Do not climb, sit on, or use this product as a ladder. Injuries may occur.
Do not place or install electrical items on this product. Wet conditions are typical and
electrical shock may occur.
Do not place this product on a slope that exceeds 3 degrees.
Do not move this display after product is in place. Damage to display and injuries may occur.
Lock casters (when provided) once display is in place to prevent movement.
Remove all debris or obstacles from caster's path before moving.
CARE & MAINTENANCE
To remove loose soil and debris, simply spray the soiled areas with with water from a garden hose.
Prior to storage, all surfaces of this product should be sprayed down with water and allowed to dry
completely.
Limited Warranty
Poly-Tex, Inc. warrants its products to be free from defects in material and workmanship for a
period of (1) year from date of invoice. This warranty is provided to the original purchaser of the
product and is not transferable. Poly-Tex does not warrant parts not manufactured by Poly-Tex,
but does assign any transferable manufacturer or supplier warranties. Should any defect be
found, full repair or replacement will be rendered to the customer at no cost following inspection
by a Poly-Tex representative and the return of the defective product to our Castle Rock, MN
factory. Expenses for removal or reinstallation of defective products will not be covered by the
warranty.
POLY-TEX SHALL NOT BE HELD RESPONSIBLE FOR ANY SPECIAL OR
CONSEQUENTIAL DAMAGES, OR FOR ANY DELAY IN PERFORMANCE OF THIS
WARRANTY BEYOND OUR CONTROL. THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF
ALL OTHER WARRANTIES WHETHER IMPLIED, WRITTEN OR ORAL INCLUDING THE
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
This warranty does not cover damage from customer abuse, misuse, improper installation,
customer modifications, customer negligence in performing normal maintenance, damage
resulting from acts of nature.
