This manual should help you
understand your new product.
If you still have questions, call
our help line found on the
insert with this icon:
Or visit
www.polaroid.com/support.
Digital Television Transition Notice:
This device contains a digital television tuner, so it should receive digital over the air TV programming, with a suitable antenna, after the end of full-power analog TV broadcasting in the United States
on February 17, 2009. Some older television receivers, if they rely on a TV antenna, will need a TV
Converter to receive over the air digital programming, but should continue to work as before for other
purposes (e.g., for watching low-power TV stations still broadcasting in analog, watching pre-recorded
movies, or playing video games). When a Converter is used with an older television receiver, a signal
splitter might be necessary to continue to receive low-power analog broadcasts via an antenna. For
more information, please see www.DTV.gov. For information on the TV Converter program, and on
government coupons that may be used toward the purchase of one, see www.dtv2009.gov, or call the
NTIA at 1-888-DTV-2009.
“Polaroid” and “Polaroid and Pixel” are trademarks of Polaroid Corporation.
Changes are periodically made to this document. Changes, technical inaccuracies, and
typographic errors will be corrected in subsequent editions.
For service, support and warranty information, visit www.polaroid.com.
This product contains electrical or electronic materials. The presence of these materials may,
if not disposed of properly, have potential adverse effects on the environment and human
health. Presence of this label on the product means it should not be disposed of as unsorted
waste and must be collected separately. As a consumer, you are responsible for ensuring that
this product is disposed of properly. To fi nd out how to properly dispose of this product, please
go to www.polaroid.com and click on “Company“ or call the customer service number for your
country listed in the instruction manual.
This TV incorporates High-Defi nition Multimedia Interface (HDMITM) technology.
HDMI, the HDMI logo and High-Defi nition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC.
FCC
Federal Communications
Commission Statement
This equipment has been tested and found to comply with the limits of a class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
1. Reorient/Relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit which is different from what the receiver is
connected to.
4. Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the manufacturer
responsible for compliance could void the user authority to operate the
equipment.
ENGLISHENGLISH
3
Warnings and Precautions
Warnings and Precautions
To prevent any injuries, the following safety precautions should be observed in the installation, use,
servicing and maintenance of this equipment.
Before operating this equipment, please read this manual completely, and keep it nearby for future
reference.
This symbol is intended to alert the user to avoid the risk of electric shock.
WARNING
CAUTION
This equipment must not be disassembled by anyone except qualifi ed service personnel.
This symbol is intended to alert the user to the presence of important operating and
maintenance instructions in the literature accompanying the appliance.
To reduce the risk of fi re or electric shock, do not expose this equipment to rain or moisture.
▪ TO REDUCE THE RISK OF ELECTRIC SHOCK,
▪ DO NOT REMOVE COVER (OR BACK).
▪ NO USER-SERVICEABLE PARTS INSIDE.
▪ REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Use of controls, adjustments or performance of procedures other than those specifi ed herein
may result in hazardous radiation exposure.
Important Safety Instructions
This symbol indicates caution points.
This symbol indicates actions that should not be done.
This symbol indicates actions that must be performed.
▪ Do not place the equipment on any uneven or unstable carts, stands, tables, shelves etc.
The equipment may fall, causing serious injury to children or adults and serious damage to
the equipment itself.
▪ Use only a cart or stand recommended by the manufacturer. This equipment and
recommended cart or stand should be handled with care. Quick stops, excessive force, and
uneven surfaces may cause the equipment and cart/stand to overturn.
▪ Do not disable the 3-wire grounding type plug. The grounding pin on the 3-prong plug is an
important feature. Removing the grounding pin will increase the risk of damaging the
equipment.
▪ If you can not fi t the plug into the electrical outlet, contact an electrician to install a grounding
outlet.
▪ Always operate this equipment from the type of power source indicated on the rear of the
serial/model plate.
▪ Never overload wall outlets and extensions.
4
Warnings and Precautions
▪ Use and handle the power cord with care. Do not place any heavy objects on the AC
power cord.
▪ Do not pull the AC power cord. Do not handle the AC power cord with a wet hand.
▪ Do not touch the power cord and antenna cable during lightning.
▪ Remove the plug from the wall outlet, if the equipment will not be used for a long period
of time.
▪ Do not place, use or handle this equipment near water.
▪ Never expose the equipment to liquid, rain, or moisture.
Seek for service if any of the above is spilled into the equipment.
▪ Do not expose the equipment to extreme temperature or to direct sunlight, as the
equipment may heat up and suffer damage.
▪ Do not install the equipment near any heat sources such as radiators, heat registers,
stoves, or any other apparatus that might produce heat.
▪ Do not attempt to service the equipment yourself.
▪ Opening and removing the covers may expose you to dangerous voltage or other
hazards and may void your warranty. Refer service to qualifi ed personnel.
▪ Do not place or drop any other objects on top.
▪ Do not insert anything into the ventilation holes of your equipment.
Inserting any metal or fl ammable objects may result to fi re or electric shock.
▪ Protect the power cord from being walked on or pinchrd particularly at plugs ,convenience
receptacles, and the point where they exit from the apparatus.
▪ Do not place the equipment on uneven or unstable carts, stands, tables, shelves etc. The
equipment may fall, causing serious injury to children or adults and serious damage to
the equipment itself.
Always place the equipment on the fl oor or on a surface that is sturdy, level, stable and
strong enough to support the weight of the equipment.
▪ Do not block any ventilating openings. Leave an open space around the equipment.
Never place the equipment :
on a bed, sofa, rug, or any other similar surfaces; too close to drapes/curtains/walls, in a
bookcase, built-in cabinet, or any other similar places that may cause poor ventilation.
▪ Unplug this apparatus during lightning storms or when unused for long periods of time.
▪ Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate normally, or has been dropped.
▪ Always remove the power cord from the outlet before cleaning the equipment.
▪ Never use liquid or aerosol cleaners on the equipment.
Clean only with a soft dry cloth.
ENGLISHENGLISH
▪ Only use attachments/accessories specified by the manufacturer.
5
Warnings and Precautions
Outdoor Antenna Safety Instructions
If an outdoor antenna is connected, follow the precautions below:
▪ An outdoor antenna should not be located in any area where it could come in contact with
overhead power lines, or any other electric light or power circuits.
▪ When installing an outdoor antenna system, extreme caution should be taken to prevent
contact with power lines. Direct contact with power lines may be fatal and should be avoided
at all costs.
Section 810 of National Electrical Code (NEC) provides information with respect to proper grounding of the
mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding
conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for
the grounding electrode.
Antenna lead-in wire
Ground clamps
Electric service
equipment
Ground clamps
Power service grounding
(NEC Art250 part H)
NEC : National Electrical code
EXAMPLE OF OUTDOOR ANTENNA GROUNDING
6
Antenna discharge unit
(NEC section 810-20)
Grounding conductors
(NEC section 810-20)
TABLE OF CONTENTS
Federal Communications Commission Statement .......................... 3
Warnings and Precautions
Important Safety Instructions ....................................................................................... 4
Various Audio/Video terminals for external equipment connection
▪ 2 sets of composite A/V input terminals
▪ 1 set of S-VIDEO terminals
▪ 2 sets of component Video input terminals
▪ 1 VGA/ Audio input terminals
▪ 2 HDMI/Audio input terminals
▪ 1 set of Audio(L/R) output terminals
▪ 1 headphone terminal
The built-in TV tuner to receive HD ATSC
▪ This function allows the reception of HD broadcasting without the addition of a set top
box.
High Definition Multimedia Interface (HDMI)
▪ High Defi nition Multimedia Interface (HDMI) is a small, user-friendly interconnect that
can carry up to 5 Gbps of combined video and audio in a single cable. This system
eliminates the cost, complexity and confusion of multiple cables used to connect
current A/V systems.
HDTV Component Video Inputs
▪ Offers the best video quality for DVD(1080i, 720p) and digital set-top-box (1080i, 720p)
connections.
3D Digital Noise Reduction
▪ This function can digitally reduce image noise to provide better picture quality.
Film-Mode Detection (3:2 Reverse Pull Down)
▪ This function can automatically detect content derived from fi lm and adjust the
interlacer’s frame matching to provide a more natural-looking, clearer image of the
moving picture.
8
Package Contents
DVR
Chapter 1 Introducing the LCD TV
Make sure all of the following contents are included.
LCD TV
Remote Control/
User’s Manual Quick Start Guide
AAA Batteries x 2
SET UP
CAB/
AUXDVD
TV
SAT
SLEEP
DVD MENU
PAGE
VOL CH
LAST
MUTE
ASPECT
LIVE TV
PIP
MENU
GUIDE
OK
EXIT
INFO
CC
DVR
2
3
1
ABC
DEF
5
4
JKL6MNO
GHI
9
7
8
WXYZ
PQRS
TUV
INPUT
0
ENTER
.
Stand Assembly Guide
PLEASE
READ THIS BEFORE
REMOVING PRODUCT
FROM THE BOX
Simple Steps for
Attaching Your TV Stand
Widescreen Television
Stand Attachment Guide
243
THESE INSTRUCTIONS ARE
DESIGNED TO HELP YOU ATTACH
YOUR STAND EASILY AND SAFELY.
PLEASE READ CAREFULLY.
IMPORTANT:Attach the stand to your
TV with the bottom foam packaging
material still attached.
Place on stable surface and
remove protective bag
Protective
Bag
Packaging Material
6
Place TV upright and remove
packaging material
Unit
Packaging Material
"Polaroid" and "Polaroid and Pixel" are trademarks of Polaroid Corporation, Waltham, MA, USA.
Product features, specifications, and appearances are subject to change without notice.
Lift from the bottom.
1
We’ve provided:
A. LCD TV
B. Stand
C. Screwdriver
D. Screws (6)
If you prefer to mount your TV, do not attach
the stand. Use the instructions in your
wall-mounting kit (not included).
Remove top packaging
material and lift TV out of box
Packaging Material
Packaging Material
5
Use all six screws to attach
stand to TV
7
Find your Quick Start Guide
for simple steps to connect
your TV to A/V devices.
Questions?
Consult your user’s manual
or give us a call. Our helpful
customer service will answer
all your questions.
Unit
Packaging Material
6 Screws
Unit
Stand
Packaging Material
Look for the insert
with this icon:
or visit www.polaroid.com
22” HD LCD TV & DVD Combo
Your TV may look different from the one pictured.
Cleaning Cloth
ENGLISH
Bottom Stand /
Screw Driver and Screws 4
Make sure all of the above contents are included in the package. If you are missing
any items, please call 1-888-896-9859.
9
Chapter 1 Introducing the LCD TV
Setting Up Your LCD TV
How to install the TV Stand
Read all instructions before continuing with the stand installation.
Attach the Stand the TV with the bottom foam packaging material still
attached.
a. Lift foam packaging material from the top of the LCD out of the box.
b. Lift LCD out of the box, with the bottom foam packaging material still attached, and place
onto a stable surface.
ab
Stand
Shipping box
c. Remove protective bag from LCD unit, but DO NOT remove the bottom foam packaging
material from the TV.
d. Locate the place on the back of the TV to attach the stand. Secure the stand to the LCD
with all four screws.
Protective bag
Table
c
Unit
Table
Stand
Packaging material
d
Unit
Screws
Stand
Table
Packaging material
10
How to remove the TV Stand
Chapter 1 Introducing the LCD TV
If you prefer to mount your new Polaroid TV on a wall instead of attaching it to the stand, please
reference the instructions included in the wall mounting kit (sold separately).
Verify your TV’s model and be sure to use the wall mounting kit specifi ed
for your TV model only. Contact a qualifi ed technician for assistance when
installing the wall mounting kit.
To prevent damaging the surface of the LCD TV, place the TV on a soft cloth.
Soft cloth
Remove the screws of the table stand and detach the table stand from the TV.
Soft cloth
ENGLISH
Table stand
Align the holes on the wall mounting hook units with the corresponding holes on the rear
of the TV and fasten four screws.
4 screws (supplied
with the wall mount
kit)
Wall mounting hook
unit (supplied with the
wall mount kit)
Soft cloth
11
Chapter 1 Introducing the LCD TV
How to setup the TV
Use a supplied antenna cable to connect the VHF/UHF signal to the LCD TV’s ANT terminal.
Connect the AC power cord at the back of the TV and connect the power cord to wall outlet.
Insert the 2 batteries supplied in remote control.
Step1 Slide the back cover up to open the
battery compartment of the remote
control.
Step2 Insert two AA size batteries.
Make sure to match the (+) and
( - ) ends of the batteries with
the (+) and ( - ) ends indicated
in the battery compartment.
Slide the cover back into place.
Connect other an external AV device.
12
Your LCD TV
Chapter 1 Introducing the LCD TV
Front/Right Side View and Controls
VOLUME
+-
Adjusts the volume up and down.
Selects the main-menu item and change
values for items when in the OSD mode.
LED
The LED light indicates when the LCD TV is
activated.
VIDEO1 IN
VIDEO
L
Connects to the composite
Video and Audio output jacks
on external video equipment.
ENGLISH
IR
Infrared
Receiver
CHANNEL▲▼
Scans up and down through channels.
Selects sub-menu item when in the OSD
mode.
MENU
Press once to display the OSD (on screen
display), press again to turn the OSD off.
INPUT
Chooses from different input signal sources.
Turns the LCD TV on and into standby mode.
13
R
VIDEO1 IN
HEADPHONE
Connects to the external
headphone for private
listening.
Chapter 1 Introducing the LCD TV
Rear View and Jacks
VIDEO2 IN
Connects to the composite VIDEO and AUDIO(L/R) output jacks on external video equipment.
HDMI1 IN/HDMI2 IN
Connects the all digital AV equipment with HDMI connector.HDMI supports enhanced,
high-defi nition video and two-channel digital audio. The AUDIO(L/R) of HDMI IN is for
DVI connection.
S-VIDEO IN
Connects to the S-VIDEO and AUDIO(L/R) output jacks on external
video equipment.
VGA IN
Connects the PC, or other AV equipment with VGA and
AUDIO(L/R) output jacks.
YPbPr1 IN/YPbPr2 IN
Connects to the DVD player, Digital Set-Top-Box, or other AV
equipment with component(YPbPr) video and audio output jacks.
AUDIO OUT-STEREO
Connects to the AUDIO(L/R) input jacks on AV equipment.
AUDIO OUT-COAXIAL
Connects to the COAXIAL AUDIO jack on the digital/standard 5.1
audio system.
TV CABLE/AIR
Connects RF input from VHF/UHF antenna or cable
to receive high/standard defi nition television.
AC IN
Connects to the AC power cord.
14
Your Remote Control
DVR
Chapter 1 Introducing the LCD TV
This package includes a Polaroid remote that enables control of up to four devices.
To select a device, simply select one of the following device mode controls: TV, CBL/SAT, DVD/VCR,
or AUDIO.
Turns the LCD TV on and off
2
3
SET UP
TV
CAB/
SAT
SLEEP
DVD MENU
1
AUXDVD
4
5
1
SET UP Remote control universal code setup.
2
2
For more information on setting up your
remote control, please see the
“Programming Your Remote Control”
section (refer to page 56)
TV Controls the LCD TV/Built-in DVD/USB /
3
SD card reader.
11
6
VOLCH
8
9
MUTE
GUIDE
ASPECT
LIVE TV
PIP
OK
LAST
MENU
PAGE
7
CAB/SAT Controls Cable Converter or Satellite
Receiver
10
DVD Controls DVD player or Video player
AUX Controls Audio Amplifi er
4
2
SLEEP Cycles through the LCD TV sleep time:
off/10/20/30/40/50/60/90/120 mins
5
INFO
1
4
GHI
7
PQRS
INPUT
.
CC
2
ABC
DEF
5
JKL6MNO
8
WXYZ
TUV
0
ENTER
EXIT
3
9
► Other device function keys
6
VOL+- Increases and decreases volume
7
CH▲▼ Change channel up and down
8
ASPECT Cycles through Wide mode settings:
NORMAL/FULL//ZOOM/WIDE
ENGLISH
9
MUTE Pressing once mutes audio. Pressing
again restores audio
10
LAST Returns to previously selected channel
11
GUIDE In TV mode, pressing GUIDE displays
the Program Guide on the screen
15
Chapter 1 Introducing the LCD TV
DVR
SET UP
CAB/
TV
SAT
SLEEP
DVD MENU
AUXDVD
12
PIP Other device function key
13
MENU Displays the OSD menu on the
screen.
◄►▲▼,OK Cycles through OSD options and selects
14
individual menu items. OK confi rms option
OK In TV mode, pressing OK to display a
channel list
settings
14
15
16
18
19
VOLCH
MUTE
GUIDE
INFO
1
4
GHI
7
PQRS
INPUT
.
ASPECT
LIVE TV
PIP
OK
CC
2
ABC
5
JKL6MNO
8
TUV
0
PAGE
LAST
MENU
EXIT
3
DEF
9
WXYZ
ENTER
12
13
17
INFO Displays information on the LCD TV
15
screen such as input source, channel,
program title.
CC Cycles through the Closed Caption:
16
Analog Closed Caption:OFF/CC1/
CC2/CC3/CC4/TEXT1/TEXT2/
TEXT3/TEST4
Digital Closed Caption: Allow to set the digital closed caption
EXIT Exits the OSD menu
17
18
0-9/ENTER Pressing a number selects a channel.
Following selection, pressing ENTER
activates the channel, or channel
activates automatically in 3 seconds
INPUT Pressing INPUT to display a source
19
list, use ▲▼ to select the video
equipment connected to the video
inputs of your LCD TV and press OK to
confi rm:
The remote can control the LCD TV from up to 5m away, if pointed directly at the receiver.
The remote can control the LCD TV from up to 5m away, if pointed directly at the receiver.
16
Chapter 2 Installing the LCD TV
Chapter 2
Installing the LCD TV
Refer to the owner’s manual of any external equipment to be connected.
When connecting any external equipment, do not connect any AC power cords to wall outlets
until all other connections are completed.
Connecting a TV Cable or an Antenna
Antenna Connection
The antenna requirements for good color TV reception are more important than those for a black &
white TV reception. For this reason, a good quality outdoor antenna is strongly recommended.
The following is a brief explanation of the type of connection that is provided with the various antenna
systems.
■ A 75-ohm system is generally a round cable (not included) with F-
type connector that can easily be attached to a terminal without
tools.
F-type connector
75-ohm coaxial cable (round)
■ A 300-ohm system is a flat twin-lead cable (not included) that can
be attached to a 75-ohm terminal through a 300 -75-ohm adapter
(not included).
ENGLISH
17
Chapter 2 Installing the LCD TV
Use one of the following two diagrams when connecting an outdoor antenna.
A: Shows how to use a VHF/UHF combination outdoor antenna.
B: Shows how to use a separate VHF and/or UHF outdoor antenna.
A. Combination VHF/UHF antenna
VHF/UHF
Antenna
300-ohm twinlead cable
300/75-ohm adapter
(not included)
B. Separate VHF and/or UHF antennas
75-ohm
coaxial cable
VHF/UHF
Antenna
18
Combiner
(not included)
IN
OUT
300-ohm twinlead cable
75-ohm
coaxial cable
300-ohm twinlead cable
UHF
Antenna
VHF
Antenna
Cable TV (CATV) Connection
Chapter 2 Installing the LCD TV
This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the
National Electrical Code (NEC) that provides guidelines for proper grounding and, in particular,
specifi es that the cable ground shall be connected to the grounding system of the building
accurately, or as close to the point of cable entry as possible. Use of this TV for other than
private viewing of programs broadcasted on UHF, VHF or transmitted by cable companies for
the use of the general public may require authorization from the broadcast/cable company, and/
or program owner.
■ A 75-ohm coaxial cable connector is built into the set for easy hookup.
When connecting the 75 -ohm coaxial cable to the set, connect the 75-
ohm cable into the ANT. terminal.
■ Some cable T V companies of fer premium pay channels. Since the
signals of these premium pay channels are scrambled, a cable TV
converter/descrambler is generally provided to the subscriber by the
cable TV company.
This converter/descrambler is necessary for normal viewing of scrambled channels.
(Set your TV to channel 3 or 4, typically one of these channels is used. If this is unknown,
consult your cable TV company.)
For more specifi c instructions on installing cable TV, consult your cable TV company.
One possible method of connecting the converter/descrambler provided by your cable TV
company is shown in the diagram below.
RF switch
(not included)
2 set signal
splitter
(not included)
Cable TV Line
OUT
A
IN
B
ENGLISH
Cable TV converter/
descrambler
VHF/UHF IN
(not included)
■The RF switch (not included) is required to provide two inputs (A and B). Setting
the RF switch to position A allows viewing of all unscrambled channels by using
the TV channel keys.
■ Setting the RF switch to position B allows viewing of all scrambled channels via
the converter/descrambler by using the converter channel keys.
19
Chapter 2 Installing the LCD TV
Use a supplied antenna cable to connect the TV signal to the LCD TV’s TV CABLE terminal.
HDTV/TV
Air/CABLE
VHF/UHF IN
Connect the AC power cord at the back of the TV and connect the power cord to wall outlet.
HDTV/TV
Air/CABLE
VHF/UHF IN
This TV is equipped with a safety fuse. In the event of an electrical storm or power outage
the safety fuse is designed to protect your TV. If your TV has no power, check the fuse by
prying the cover off, following the illustration below.
If the fuse is blown, visit your local hardware store and ask for a 4A 250V - 5x20mm Time
Lag Fuse (Slow Blow) to replace the fuse.
Firm Plastic Prying Tool
(Using a metal tool may cause shock)
4A 250V
Back of TV
BE SURE TO UNPLUG AC POWER CORD BEFORE REMOVING THE FUSE.
5x20mm
Fuse
Press the button on the remote to turn on the LCD TV.
Always disconnect the LCD TV from the main voltage when the LCD TV will not
be used for a long period of time. The POWER button on the front panel is only
used for switching the LCD TV into standby, it does not disconnect the device
from the main voltage. To completely disconnect the main voltage, please
remove the power plug from the socket.
20
Loading...
+ 45 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
