26” / 32” / 37” 16:9 HD-READY LCD TV
Your TV may look different from the one pictured above.
Questions? Need some help?
This manual should help you understand your new product.
If you still have questions, call |
Or visit |
|
our help line found on the |
||
www.polaroid.com/support. |
||
insert with this icon: |
|
|
TABLE OF CONTENTS |
|
1 |
Important Considerations to Follow................................................. |
1 |
|
1.1 Cleaning the screen and cabinet................................................................. |
1 |
|
1.2 Disposing of your TV at the end of service life............................................. |
1 |
2 |
Features of your new television........................................................ |
2 |
|
2.1-Special Features......................................................................................... |
2 |
3 |
Important Safety Instructions............................................................ |
3 |
4 |
Start..................................................................................................... |
6 |
|
4.1-Antenna connection.................................................................................... |
6 |
|
4.2-Powering on your device and the initial use................................................. |
6 |
|
4.3-Batteries..................................................................................................... |
6 |
5 |
Your new television has..................................................................... |
7 |
|
5.1-TV Control Panel......................................................................................... |
7 |
|
5.2- External Connections................................................................................. |
7 |
|
5.3-External Connections Table........................................................................ |
8 |
|
5.4-Remote Control.......................................................................................... |
8 |
6 |
Performing the initial power-on settings.......................................... |
9 |
|
6.1-TV controls................................................................................................. |
9 |
|
6.2-Automatically tuning and storing the programs on your television.............. |
10 |
|
6.3-Manually tuning and storing the programs on your television..................... |
10 |
|
6.4-Fine Tuning............................................................................................... |
11 |
|
6.5-Program Table.......................................................................................... |
12 |
7 |
The settings on your new television:.............................................. |
13 |
|
7.1-Setting-up the Volume Menu.................................................................... |
13 |
|
7.2-Picture Menu Settings............................................................................... |
14 |
|
7.3-Features Menu Settings............................................................................ |
15 |
8 |
Teletext.............................................................................................. |
17 |
9 |
External equipment connection:..................................................... |
19 |
|
9.1-Connection types for external devices....................................................... |
20 |
10 |
Help and tips..................................................................................... |
22 |
11 |
Technical specifications chart........................................................ |
23 |
1 Important Considerations to Follow
Polaroid. Add a little colour to your life.
Since 1937, people have turned to Polaroid for their photography needs. Today, families look to Polaroid for consumer electronics that define the digital age: plasma and LCD TVs, portable and standard DVD players, digital cameras, personal media players,
and so much more. And while our selection has changed, you will still receive the same friendly, helpful service that made Polaroid an icon. Congratulations on your new Polaroid TV purchase. To ensure your new TV provides you with years of enjoyment, please read this guide carefully.
The LCD panels are produced with state-of-the-art technology. However, there may be missing or lit spots on the screen under certain circumstances. That does not mean that the product is faulty.
1.1 Cleaning the screen and cabinet...
After powering off, wipe the screen and the cabinet clean with a soft and dry cloth. We recommend that you do not use patented polishes or solvents on the screen or cabinet since they may cause damage.
1.2 Disposing of your TV at the end of service life...
The cold cathode fluorescent lamp found in your LCD screen contains a very small amount of mercury. Once your TV set has completed its physical life, please dispose of it in accordance with local government regulations or leave it at a recycling centre.
This product contains electrical or electronic materials. The presence of
these materials may, if not disposed of properly, have potential adverse effects on the environment and human health. Presence of this label on
the product means it should not be disposed of as unsorted waste and must be collected separately. As a consumer, you are responsible for
ensuring that this product is disposed of properly. To find out how to properly dispose of this product, please go to www.polaroid.com and click on “Company“ or call the customer service number for your country listed
in the instruction manual.
©2008 Polaroid. All rights reserved.
“Polaroid” and “Polaroid and Pixel” are trademarks of Polaroid Corporation. Changes are periodically made to this document.
Changes, technical inaccuracies, and typographic errors will be corrected in subsequent editions.
For service, support and warranty information, visit www.polaroid.com.
1 I k
2 Features of your new television
We would like this product, which has been manufactured in modern facilities in accordance with total quality principles, to offer you the best performance. Therefore, we would like you to read this entire manual carefully before you use your product and keep it for future reference.
2.1-Special Features
•Available for cable broadcasts
•Wide angle of vision
•Scart socket, AV Socket and external sound system connection
•S-VHS and Cinch inputs for S-Video connection
•PC connection
•Low energy consumption
•AVL
•Programmable power on
•Programmable power off
•10 page / 250 (*) page Teletext
•Toptext (*)
•Graphic equalizer
•Sharpness feature in Color Transitions (CTI)
•Sharpness feature and picture resolution (LTI) in black-white transitions
•A clearer Picture made possible with a Digital Comb Filter
•On-screen viewing of all settings, program numbers and all the processes
•Manual Fine Tuning
•100 Program memory
•Infrared Remote Control equipped with all functions
•Child Lock
•Panel Lock
•Feature of viewing the NTSC broadcast via Scart input
•Easy performance of the processes with the advanced menu system
•Ability to choose 26 different menu languages
•4:3, 16:9, 14:9 Letterbox(*), Subtitle(*) and Panorama(*) picture formats
•HDMI feature (*)
•HDCP feature (*)
•HD-Ready (*)
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.
(*): These features are optional and they are not available ion all models.
2 I k
3 Important Safety Instructions
This symbol is used to warn the user about the “dangerous voltage” contained inside the housing of the product that may create a risk of electrical shock.
This symbol is used to remind the user important usage and service instructions supplied with the device.
1)Please READ the operating instructions
before using the device
for the first time. 2) Please observe the
instructions contained in the Operating Instructions.
3)Please consider all warnings.
4)MAKE SURE that all
power connections
(network communication,
extension cables and the
connections between
the device components)
have been made properly and in accordance with the manufacturer’s instructions. Before making or changing the connections, power off the device and unplug the mains connection plug.
5)If you have any doubts regarding the installation, operation or safety of the device, please REFER to the vendor.
6)BE CAREFUL with glass panels and covers on the device. The screen glass may break and cause serious injuries if something hits it.
7)To ensure adequate ventilation,
please leave a clearance area of at least 10 cm around the television. This clearance prevents the TV from overheating and consequently causing damage.
•Using the device in dusty environments should also be avoided.
•Never block the slots and openings by placing the TV on a bed, sofa, pillow or other similar surfaces.
•Never install the TV into closed places such as bookcases or cabinets unless adequate ventilation is provided.
8)DO NOT COVER the ventilation openings of the device with items such as newspapers, table-clothes, curtains, etc. Overheating causes damage and shortens the service life
of the device.
9) Your TV may be damaged
if you place it under
direct sunshine or
close to a heater. Please abstain from using the product in very hot or
humid locations or in places where the temperature is likely to decrease below
5°C (41°F). DO NOT
PLACE on or near the device any hot objects
or items with open flame such as candles or any night lamps. The high
temperature can melt plastic parts and cause a fire.
3 I k
10) Never operate
electrical devices close to water. Operating such devices, for example,
neara bathtub, washbasin, kitchen washbasin, washing basin, wet basement, swimming pool can cause fire or electric shock.
•Do not allow your TV to get wet. Never
pour any liquids onto the TV. Do not operate your TV if any
solid or liquid substance enters into it. This can cause electric shock and your TV may be damaged. Have it checked immediately by qualified personnel.
• Keep open flame sources (such as candles) away from
TV in order to avoid risk of fire.
11)DO NOT USE headphones at extremely
high volume levels
since this may cause permanent loss of hearing.
12) Operate your TV only in
the 230 V 50Hz voltage range. Use the AC power cable supplied with the product. If your
TV is a grounded (Class I) product, then it must certainly be connected to a grounded socket.
•The socket into which you plug in the AC power cable or the adaptor must be within easy reach.
•Turn off your device with the ON/OFF button and then unplug it in order to disconnect it from mains.
Note: If your device has an adaptor, then use the adaptor and AC power cable supplied with your product. Do not use defective sockets. Make sure
that the plug is firmly inserted into the socket. If the plug remains loose, then it can cause fire due to arching. Refer to an electrician to have your socket replaced.
13)Make sure that the power cable is not stepped on and that there is no bending at the plug
sections, plug heads and
device output point.
14) Use only the add-ons/ accessories specified by the manufacturer.
15)Use only together with the carts, bases, tripods, brackets or stands
specified by the
manufacturer or sold along
with the product. When
using a cart, pay attention
that it won’t overturn while
carrying the cart/device
combination and cause injuries. The device must be fixed to the floor or wall as indicated in the
installation instructions in order to avoid any possible damages. Place your device on a level surface.
16)Unplug the power cable during thunderstorms or when you will not use your device for a long
period of time.
17) Consult authorized service personnel for service requirements.
Never attempt to
repair the device
yourself. Opening the
cabinet can expose
you to dangerous
voltages or other hazardous situations.
Service is required in situations such as damage to the power cable of the device or its plug, water spills or
substances falling into the device, the device is subjected to rain or moisture, it does not operate normally or it is dropped.
4 I k
18) Wipe the TV cabinet
clean with a soft and dry cloth. Wipe dust from the screen gently with a soft cloth. Stubborn stains can be cleaned
with a cloth slightly moistened with soap and lukewarm water. Never use solvents such as thinner or gasoline for cleaning. Unplug the AC power cable from the socket when cleaning the TV. Otherwise, there is the risk of electric shock.
19)Do not dispose of the batteries in fire.
• Do not short circuit, dismantle or overheat
the batteries. There is the risk of explosion
if the batteries are not replaced correctly. Replace only with the same or equivalent type batteries.
20) Disposing of the exhausted batteries:
•Dispose of the exhausted
batteries in accordance with
the local laws and regulations in order to protect our environment.
21) Do not dispose of your TV with regular household waste. Observe local laws and regulations for disposal.
Note 1:This is a Class A product. During operation, the device can cause radio interference. In this case the user may have to remedy this. Please contact your specialist dealer.
Note 2: Electromagnetic fields can cause temporary performance degradation. This can be distinguished as noise in the image.
5 I k
4 Start
Remove your television carefully from its box. You can keep the packaging of your television to use in future.
Contents of the box
Power cable Remote control
2 batteries
Note: The Scart, HDMI, VGA and RCA cables are not supplied with the device.
4.1-Antenna connection
If you use a 75 Ohm coaxial cable (round cable) as an antenna cable, connect the antenna plug directly to the antenna input located on the TV.
Motorized vehicles, energy lines and telecommunication lines affect your antenna. Therefore, be careful to install your antenna away from these and metal surface in such a way that it shall not swing. Do not make your antenna cable longer than required and do not coil it . Make sure that it is not crimped passing through a window or door. Your antenna and cable might be affected by natural phenomena such as rain, wind, smoke and humidity over time. Periodically check
your antenna and equipment.
4.2-Powering on your device and the initial use
1.Insert the power cable into the power supply input located on the back panel of the LCD TV.
2.Insert the power cable plug supplied with the device into the socket.
Note 1: Your TV will switch to the standby mode in five minutes if there is no
broadcast signal from antenna.
Note 2: Your TV is equipped to operate with TV buttons in case your R/C is broken or the batteries are exhausted.
3. Press the power on/off button
located on the LCD TV.
4. To power on your television, press any numerical key or
PR+ or PR- keys on the remote control. For this process, you can also use the buttons on your TV. The picture will appear on
the screen after a short while.
Note: If you are not going to use your television for a long time, unplug its power cable from the socket.
Initial power on and performing settings
To set up your television, read the sections on the TV controls and performance of the broadcast settings.
4.3-Batteries
Open the lid of the battery compartment and make sure that you have placed the batteries in the correct direction. For this remote control, UM-4, IEC R03 or AAA
1.5 V batteries are suitable.
Do not burn your old batteries, discard them in a dedicated waste area for this purpose.
Do not mix used batteries with new ones or different types of batteries together.
The performance of the remote control will be reduced at a distance of 8 meters from or at an angle of 30 degrees beyond the centre of the TV.
6 I k
