Polaroid DVP-0600 User Manual

DVD Player

Operation Manual

DVP 0600

- 1 -

Contents

Important Safety Instructions ---------------------------------------------------------------------

Features ------------------------------------------------------------------------------------------------

About Discs --------------------------------------------------------------------------------------------

Care of Discs --------------------------------------------------------------------------------------------

Elements of Operation--------------------------------------------------------------------------------

Front Panel -----------------------------------------------------------------------------------------

Display Panel --------------------------------------------------------------------------------------

Rear Panel ----------------------------------------------------------------------------------------

Remote Control Handset Button Functions --------------------------------------------------

Usage of the Remote Control ---------------------------------------------------------------------

Connections ------------------------------------------------------------------------------------------

Connecting to a TV ------------------------------------------------------------------

Connecting to an Analog Amplifier ----------------------------------------------

Connecting to an Amplifier with 5.1 CH Audio Output --------------------------

Connecting to an Amplifier with Dolby Digital Decoder --------------------------

Disc Play Operation ------------------------------------------------------------------------------

DVD Playback -------------------------------------------------------------------------------------

CD Playback ----------------------------------------------------------------------------------------

MP3 Playback ---------------------------------------------------------------------------------------

JPEG Playback -----------------------------------------------------------------------------------

Playback Functions ----------------------------------------------------------------------------------

System Setup -----------------------------------------------------------------------------------------

Troubleshooting --------------------------------------------------------------------------------------

Specifications --------------------------------------------------------------------------------------------

- 2 -

Important Safety Instructions

The lighting flash with arrowhead symbol within a triangle

alerts the user to “dangerous voltage” which could cause electric shock.

The exclamation point within a triangle alerts the user to read important operating and maintenance instructions in the manual.

NOTES

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

Do not block any ventilation openings. Install in accordance with the

7) manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories specified by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified by the

manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15) Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus.

- 3 -

WARNING: To reduce the risk of fire or electric shock, DO NOT expose this product to rain or moisture.

IMPORTANT FOR LASER PRODUCTS

CLASS 1 LASER PRODUCT

1. DANGER: Visible laser radiation when open and interlock failed or defeated. Avoid direct exposure to beam.

2. CAUTION: Do not open the top cover. There are no user service-able parts inside the unit, leave all servicing to qualified service

ersonnel.

Features

DUAL COMPATIBILITY

Supports both “Progressive scan” and

“Interlaced” televisions.

Progressive Scan creates a picture signal

with double the scan lines of a

conventional DVD, resulting in higher

picture resolution and sharper image

quality.

HIGH QUALITY PROPERTIES

■ DIVX FUNCTIONALITY

Plays DivX5, DivX4, DivX3 and DivX

Video Content. (In compliance with DivX

Certified Technical Requirements).

The maximum bit rate supported is 4

Mbit/s. The average bit rate is 2 Mbit/s.

■ HIGH RESOLUTION

MPEG2 decoding format to achieve

horizontal resolution more than 500 lines.

■ EXCELLENT TIMBRE

Build-in Dolby Digital decoder to output

digital audio signal to reproduce high

quality sound effects.

■ SCREEN

Supports 4:3 and 16:9 aspect ratios.

■ SPECIAL FUNCTION

Supports multi-angle and multi-language

playback for enjoying unique video

features.

■ VIDEO OUT

Standard Video, S-Video and easy

PAL/NTSC shift.

■ AUDIO OUT

2CH and 5.1CH analog audio output,

optical and coaxial digital audio output

can be connected to any amplifiers.

GENERAL FUNCTIONS

■ COMPATIBILITY

DVD, CD, CD-R, CD-RW, MP3 and DivX

discs compatible.

■ ZOOM FUNCTION

If desired, the picture can be enlarged to

further enhance your enjoyment.

■ ALL PLAYBACK FUNCTIONS

Fast forward and reverse

Slow playback

Frame playback

Repeat playback

Program playback

■ SEARCH BY TIME

Search for scenes by times; ideal for

finding your favorite scenes.

■ LAST MEMORY PLAYBACK

Continue playing from the last point you

stopped.

- 4 -

About Discs

Disc Formats Supported by this Player

The unit can play discs bearing any of the following logos:

DISC LOGO DIAMETER

DVD

MP3 12cm 600 min

DIVX

 The operating method of some DVD discs is specified by the software maker.

Please refer to the instruction manual of the disc.

 The DVD Player will play most recordable (CD-R) or erasable (CD-RW) CDs, but

playback of CD-R or CD-RW discs created on a computer requires proper formatting and finalization of the disc for audio playback. Some computers and/or software programs may not be capable of creating compatible discs.

About Disc Terms

- Title

Generally, pictures or music compressed on a DVD are divided into several sections, “title”.

- Chapter

The smaller section unit of picture or music in a DVD under the title, usually one title

is comprised of one or more chapters and each of them is numbered for easy searching. But some discs may not have a recording chapter.

- Track

A segment of picture or music on a CD. Each track is numbered for searching.

12cm

12cm 74 min

8cm 20 min

12cm

PLAYBACK TIME/ PLAYABLE SIDES

133 minSS-SL

242 minSS-DL

266 minDS-SL

484 minDS-DL

- 5 -

Care of Discs

How to hold discs

When loading or removing discs, try not

to touch their playing surfaces.

Cleaning

Fingerprints or other dirt on the disc

may affect sound and picture quality. To

clean your discs, use a soft clean cloth

to wipe them. If necessary, moisten a

soft cloth with diluted neutral detergent

to remove heavy dirt or fingerprints.

Do not wipe in a circular direction

(Concentric scratches in the disc groove

tend to cause noise.) Gently wipe from

the inside to the outer edge.

Cleaning Care

Use a soft, dry cloth for cleaning. For

stubborn dirt, soak the cloth in a

detergent solution; ring well first and

wipe. Use a dry cloth to wipe it dry. Do

not use any volatile agents such as

benzine or paint thinner, as they may

damage the surface of the player.

Lens cleaner

The player’s pickup lens should not

become dirty under normal use, but is

for some reason it should malfunction

due to soiling, contact your nearest

WACA authorized service center. Lens

cleaners are commercially available, but

special care should be exercised in their

use since some may cause damage to

the lens.

- 6 -

Elements of Operation – Front Panel

1. Standby-on button

-Press to turn off the power.

2. Remote sensor

-Receiving remote control signal for

operation.

3. Display panel

-Indicates the current status of the

unit.

4. Disc tray

-Used to load disc

5. EJECT button

-Press to open/close the disc tray.

6. PLAY button

-Press to begin the playback of the inserted disc.

Display Panel

7. STOP button

-Press to stop playback.

8. PREV button

-Press to select the previous track or menu page.

9. NEXT button

-Press to select the next track or menu page.

10. MENU button

-Press to display/close the menu.

- 7 -

Rear Panel

1. 5.1CH Audio output jacks

2. 2CH Audio output jacks

3. Coaxial digital audio output

4. Optical digital audio output jack

5. S-video output jack

jack

6. Video output jack

7. Component (Y/Y, Pb/Cb, Pr/Cr)

output jacks

8. Switch between progressive and

interlace scan

9. Power-supply cord

- 8 -
