OWNER’S MANUAL SUPPLEMENT
A
I
S
N
D
D
I
N
N
G
T
1999 XLT SPECIAL
PN 9914857
IMPORTANT: This is a supplement to your owner’s manual. This information should remain with your owner’s
manual at all times.
Specifications
XLT SPECIAL
Body Style Aggressive
C
Rider Capacity 1
Coolant Capacity (qts) 3
P
A
Chaincase Oil
C
Capacity (oz.)
Dry Weight ± 4lbs. 503
T
I
Fuel Tank Capacity
E
U.S. Gal./Imp. Gal
Gearcase Oil Capacity (oz.) Not Applicable
A
Height (in.) 46.5
Length (in.) 108
D
Oil Capacity (Quarts) 2
Ski Center Distance (in.) 41
I
M
Width (in.) 46.5
E
Brake Type Hydraulic Disc
N
S
Drive Clutch Center
I
Distance
O
Clutch Type P-85
N
S Track Length 121
Track Width 15
Drive Chain Length 68 (3/4)
Reverse Transmission Accessory
Sprocket Ratio 22:41
9
11.8 / 9.7
12
Headlight Type Halogen
Headlight (watts) Voltage High=2x60
L
I
Indicator Lights Brake/Oil/Temp/Acc/High
G
H
Thumbwarmer Standard
Handwarmer Hi/Low
S
Low = 2 x 55
1
Engine Model # EC58PL160
E
I
A
D
O
O
I
N
U
N
N
E
U
S
Alternater Output 12V 280W
Bore x Stroke (mm) 65 X 60
Displacement 597
Carburetor/Throttle Body 3 Mikuni
N
G
Carburetor Model TM 38
Main Jet 360
N
E
Pilot Jet 35
Jet Needle XP5928/02ZC
A
N
Needle jet 0-6
Cutaway 3.0
C
Air Screw 1.5
Idle RPM ± 200 1600
O
L
Cooling Liquid
Cylinders 3
N
G
Ignition Timing 28° @ 3000
Ignition Type CDI
Oil Injection Yes
Spark Plug RN2C
XLT SPECIAL
Front Type X10 CRC
S
IFS Shocks/Spring Adj. Select with Threaded Adjust
Rear Type X-10
S
P
Front Torque Arm
E
Limiter
Rear torque Arm
S
Limiter
I
O
Front Track Shock Ryde FX
Rear Track Shock Fox IFP Position Sensitive
Electronic Fuel Gauge Accessory
F
Electric Start Accessory
Low Oil Indicator Standard
A
T
Parking Brake Standard
Speedometer Standard
R
E
Tachometer Standard
Easy Throttle Accessory
Wear Strips Accessory
Quick Adjust
Quick Adjust
2
1999 XLT Special
Engine Model: EC58PL160
AMBIENT
TEMPERATURE
0-900
(0-3000)
Altitude
Meters
(Feet)
900-1800
(3000-6000)
1800-2700
(6000-9000)
2700-3700
(9000-12000)
- Shaded zone should drop Jet Needle one position (raise E-Clip)
- Production Setting
Below -20°F
Below -29°C
380
-20°Fto
+10°
-29°Cto
-12°C
+10°F-+40°F
-12°C-+5°C
Above +40°F
Above +5°C
360 340 330
350 330 320 300
320 300 290 270
290 280 270 250
Warm Weather Starting Procedure (above 40° F)
In warmer temperatures, using full choke may cause the engine to “flood”, even if the engine is “cold”. Use the following procedure to prevent this from happening.
1. Turn key to “On”.
2. Pull kill switch (shut - off switch) up to “run” position.
3. Flip choke toggle to “Half On” position.
4. Grasp starter handle and pull slowly until recoil engages; then pull to start.
If engine does not start in 3 pulls, flip choke toggle to “Off” position and slightly depress the throttle (no more than 1/4²
open), then pull to start. As soon as the engine starts, release the throttle.
PN 9914857 Rev 02 7/98
Printed in U.S.A.
3
