Polaris RANGER SP 570 Owner's Manual

2022

For Maintenance and Safety

OWNER’S
MANUAL

RANGER SP 570
RANGER CREW SP 570

WARNING

!

Read, understand, and follow all of the instructions and safety

precautions in this manual and on all product labels.

Failure to follow the safety precautions

could result in serious injury or death.

WARNING

!

Operating, servicing, and maintaining a passenger vehicle or off-road

vehicle can expose you to chemicals including engine exhaust, carbon

monoxide, phthalates, and lead, which are known to the State of California

to cause cancer and birth defects or other reproductive harm. To minimize

exposure, avoid breathing exhaust, do not idle the engine except as

necessary, service your vehicle in a well-ventilated area and wear gloves

or wash your hands frequently when servicing your vehicle.

For more information go to www.P65Warnings.ca.gov/passenger-vehicle.

For videos and more information

about a safe riding experience with

your Polaris vehicle, scan this QR

Code® with your smartphone.

2022 Owner’s Manual

RANGER SP 570

RANGER SP 570 Premium

RANGER SP 570 NorthStar Edition

RANGER CREW SP 570

RANGER CREW SP 570 Premium

RANGER CREW SP 570 NorthStar

Edition

Unless noted, trademarks are the property of Polaris Industries Inc. Loctite®
is a registered trademark of Henkel Corporation. Recreational Off-Highway
Vehicle Association® and ROHVA® are registered trademarks of
Recreational Off-Highway Vehicle Association. WD-40® is registered to WD­40 Manufacturing Company. QR Code® is a registered trademark of DENSO
WAVE INCORPORATED. OSHA® is a registered trademark of the
Occupational Safety and Health Administration. U. S. Dept. of Labor,
MACPHERSON RIDE® is a trademark of Aftermarket Auto Parts Alliance,
Inc. NGK® is a registered trademark of NGK Spark Plug Co., Ltd. Tread
Lightly® is a registered trademark of the United States Department of
Agriculture. Autolite® is a registered trademark of BMO HARRIS BANK N.A.
Google Play® is a registered trademark of Google LLC. BatteryMINDer® is a
registered trademark of VDC Electronics Inc. Apple® and APP Store® are
registered trademarks of Apple Inc. NYOGEL® is a registered trademark of
Nye Lubricants, Inc.

Copyright 2022 Polaris Inc. All information contained within this publication is
based on the latest product information at the time of publication. Due to
constant improvements in the design and quality of production components,
some minor discrepancies may result between the actual vehicle and the
information presented in this publication. Depictions and/or procedures in this
publication are intended for reference use only. No liability can be accepted
for omissions or inaccuracies. Any reprinting or reuse of the depictions and/or
procedures contained within, whether whole or in part, is expressly
prohibited.

The original instructions for this vehicle are in English. Other languages are
provided as translations of the original instructions.

Printed in U.S.A.

9940229 R01

WELCOME

Thank you for purchasing a POLARIS vehicle, and welcome to our world-wide
family of POLARIS enthusiasts. Be sure to visit us online at www.polaris.com for
the latest news, new product introductions, upcoming events, career
opportunities and more.

Here at POLARIS we proudly produce an exciting line of utility and recreational
products. We believe POLARIS sets a standard of excellence for all utility and
recreational vehicles manufactured in the world today. Many years of experience
have gone into the engineering, design, and development of your POLARIS
vehicle, making it the finest machine we’ve ever produced.

For safe and enjoyable operation of your vehicle, be sure to follow the
instructions and recommendations in this owner’s manual. Your manual contains
instructions for minor maintenance, but information about major repairs is
outlined in the POLARIS Service Manual and can be performed by a factory
certified Master Service Dealer (MSD) technician.

Your POLARIS dealer knows your vehicle best and is interested in your total
satisfaction. Your POLARIS dealership can perform all of your service needs
during and after the warranty period.

For the most up-to-date owner’s manual visit https://www. polaris. com/en-us/
owners-manuals.

3

WELCOME

4

Introduction . . . . . . . . . . . . . . . . . . . . 7

Safety . . . . . . . . . . . . . . . . . . . . . . 11

Features and Controls . . . . . . . . . . . . . . 35

Operation . . . . . . . . . . . . . . . . . . . . 67

Winch Guide. . . . . . . . . . . . . . . . . . . 85

Emission Control Systems . . . . . . . . . . . . . 97

Maintenance . . . . . . . . . . . . . . . . . . 99

Specifications . . . . . . . . . . . . . . . . . . 153

POLARIS Products . . . . . . . . . . . . . . . . 159

Troubleshooting . . . . . . . . . . . . . . . . . 161

Warranty . . . . . . . . . . . . . . . . . . . . 167

Maintenance Log . . . . . . . . . . . . . . . . 177

5

6

INTRODUCTION

INTRODUCTION

BEFORE YOU RIDE

This POLARIS vehicle is an off-road vehicle. Familiarize yourself with all laws
and regulations concerning the operation of this vehicle in your area.

WARNING

Failure to heed the warnings and safety precautions contained in this manual

can result in severe injury or death. Your POLARIS vehicle is not a toy and can

be hazardous to operate. This vehicle handles differently than cars, trucks or

other off-road vehicles. A collision or rollover can occur quickly, even during

routine maneuvers like turning, or driving on hills or over obstacles, if you fail to

take proper precautions.

• Read this owner’s manual and review the safety DVD that came with your
vehicle. A free extra copy of the DVD can be obtained by contacting your
local POLARIS dealer. Understand all safety warnings, precautions and
operating procedures before operating the vehicle. Keep this manual with
the vehicle.

• Never operate this vehicle without proper instruction. Take an authorized
training course. See the Safety Training section for more information.

• This vehicle is an ADULT VEHICLE ONLY. You MUST be at least age 16
and have a valid driver’s license to operate this vehicle.

• Always use the cab nets (or doors) while riding in this vehicle. Always keep
hands, feet and all other body parts inside the vehicle at all times.

• Always wear a helmet, eye protection, gloves, long-sleeve shirt, long pants
and over-the-ankle boots.

• Never operate this vehicle under the influence of drugs or alcohol, as these
conditions impair judgement and reduce the operator’s ability to react.

• Complete the New Operator Driving Procedures outlined in this manual.
Never allow a guest to operate this vehicle until the guest has completed the
New Operator Driving Procedures.

• Never permit a guest to operate this vehicle unless the guest has reviewed
the owner’s manual and all safety labels and has completed a safety training

IMPORTANT

For more information about safety, contact an authorized dealer or visit the

Polaris website at www.polaris.com.

7

INTRODUCTION

SAFETY SYMBOLS AND SIGNAL WORDS

The following signal words and symbols appear throughout this manual and on
your vehicle. Your safety is involved when these words and symbols are used.
Become familiar with their meanings before reading the manual.

DANGER

DANGER indicates a hazardous situation which, if not avoided, WILL result in

death or serious injury.

WARNING

WARNING indicates a hazardous situation which, if not avoided, COULD result

in death or serious injury.

CAUTION

CAUTION indicates a hazardous situation which, if not avoided, COULD result

in minor to moderate injury.

NOTICE

NOTICE provides key information by clarifying instructions.

IMPORTANT

IMPORTANT provides key reminders during disassembly, assembly, and

inspection of components.

The Prohibition Safety Sign indicates an action NOT to take in
order to avoid a hazard.

The Mandatory Action Sign indicates an action that NEEDS to
be taken to avoid a hazard.

8

INTRODUCTION

VEHICLE IDENTIFICATION NUMBERS

Record your vehicle's identification numbers and key number in the spaces
provided. Remove the spare key and store it in a safe place. An ignition key can
be duplicated only by ordering a POLARIS key blank (using your key number)
and mating it with one of your existing keys. The ignition switch must be
replaced if all keys are lost.

Vehicle Identification Number

q

(VIN)

Vehicle Model Number:

Vehicle Identification Number (VIN):

Engine Serial Number:

Key Number

Engine Serial Number

w

9

INTRODUCTION

NEAR-FIELD COMMUNICATION (NFC)
(IF EQUIPPED)

Some Polaris vehicles come equipped with a near-field communication (NFC)
chip. The NFC chip is embedded in the Polaris emblem located at the front of
the vehicle and seamlessly connects you to a digital platform of vehicle
information and tools. See your dealer for more information.

IMPORTANT

Not all devices are equipped with an NFC reader. Additionally, some devices

require third party applications to access NFC content. For questions regarding

the NFC reader on your device, refer to the device’s user manual.

On models equipped with NFC, place your smartphone directly over the Polaris
emblem to do the following:

• View vehicle specific
information

• Access your Polaris Garage

• Download and view the
owner’s manual

• View accessory instructions

• Watch helpful videos

• Access warranty information

• Check for service notifications

RIDE COMMAND WITH NFC

Additional NFC features are available when using the Ride Command mobile
app. To access these features, do the following:

1. Download the Ride Command mobile app from the Apple App Store® or

Google Play® store.

2. Create or log in to an existing account.

3. From the Ride Command mobile app home screen, select Add Vehicle.

4. On the vehicle, tap the NFC-enabled badge with the phone to scan the

vehicle.

5. Confirm information, name your vehicle, and tap add to garage.

SYSTEM REQUIREMENTS

Refer to device manufacturer’s instructions to verify NFC read capability, and/or
NFC-capable add-ons.

10

SAFETY

SAFETY

SAFETY TRAINING

Safety training is a top priority for POLARIS. POLARIS strongly encourages you
and any family members who will be riding this vehicle to take a training course

ROHVA® (Recreational Off-Highway Vehicle Association®) provides both an
online safety e-course and a hands-on safety course. To access this valuable
training, visit www.rohva.org.

Your POLARIS vehicle is considered an off-road vehicle. Familiarize yourself
with all laws and regulations concerning the operation of this vehicle in your
area.

We strongly advise you to strictly follow the recommended maintenance
program outlined in your owner's manual. This preventive maintenance program
is designed to ensure that all critical components on your vehicle are thoroughly
inspected at specific intervals.

For more information about recreational off-road vehicle safety in the
United States, visit www.rohva.org or call POLARIS at 1-800-342-3764.

SAFE RIDING GEAR

Always wear a helmet, eye protection, gloves, long-sleeve shirt, long pants,
over-the-ankle boots and seat belt at all times. Protective gear reduces the
chance of injury.

11

SAFETY

RIDER COMFORT

Under certain operating conditions, heat generated by the engine and exhaust
system can elevate temperatures in the rider cab area. The condition occurs
most frequently when a vehicle is being operated in high ambient temperatures
at low speeds and/or high load conditions for an extended period of time. The
use of certain windshield, roof and/or cab systems may contribute to this
condition by restricting airflow.

Any discomfort due to heat buildup in this area can
be minimized by wearing proper riding apparel and
by varying speeds to increase airflow.

Helmet

q

Eye Protection

w

Long Sleeves

e

Gloves

r

Long Pants

t

Over-the-Ankle Boots

y

HELMET

Wearing a helmet can prevent a severe head injury. Whenever riding this
POLARIS vehicle, always wear a helmet that meets or exceeds established
safety standards. Clasp the buckle and pull each strap tight to ensure the helmet
is properly secured to the head.

Approved helmets in the USA and Canada bear a
U.S. Department of Transportation (DOT) label.

12

SAFETY

Approved helmets in Europe, Asia and Oceania
bear the ECE 22.05 label. The ECE mark consists
of a circle surrounding the letter E, followed by the
distinguishing number of the country which has
granted approval. The approval number and serial
number will also be displayed on the label.

EYE PROTECTION

Do not depend on eyeglasses or sunglasses for eye protection. Whenever riding
this POLARIS vehicle, always wear shatterproof goggles or use a shatterproof
helmet face shield. POLARIS recommends wearing approved Personal
Protective Equipment (PPE) bearing markings such as VESC 8, V-8, Z87.1, or
CE. Make sure protective eye wear is kept clean.

GLOVES

Wear gloves for comfort and for protection from sun, cold weather and other
elements.

BOOTS

Wear sturdy over-the-ankle boots for support and protection. Never ride a
POLARIS vehicle with bare feet or sandals.

CLOTHING

Wear long sleeves and long pants to protect arms and legs.

13

SAFETY

SAFETY LABELS AND LOCATIONS

Warning labels have been placed on the vehicle for your protection. Read and
follow the instructions of the labels on the vehicle carefully. If any of the labels
depicted in this manual differ from the labels on your vehicle, always read and
follow the instructions of the labels on the vehicle.

If any label becomes illegible or comes off, contact your POLARIS dealer to
purchase a replacement. Replacement safety labels are provided by POLARIS
at no charge. The part number is printed on the label.

BELT WARNING

The Belt Warning label is located on the clutch cover.

WARNING

Improper service or maintenance of this
PVT system can result in vehicle
damage, SEVERE INJURY or DEATH.

Always look for and remove debris
inside and around clutch and vent
system when replacing belt.

Read owner’s manual or see authorized
Polaris dealer.

Part number: 7177469 (English),
7177469–F (French Canadian)

14

SAFETY

PROPER USE WARNING

The Proper Use Warning label is located on the ROPS.

WARNING

Improper vehicle use can result in SEVERE INJURY or DEATH

WARNING

Drive Responsibly

Avoid loss of control and rollovers:

• Avoid abrupt maneuvers, sideways sliding, skidding, or fishtailing, and never
do donuts.

• Avoid hard acceleration when turning, even from a stop.

• Plan for hills, rough terrain, ruts, and other changes in traction and terrain.
Avoid paved surfaces.

• Avoid side hilling (riding across slopes).

Require Proper Use of Your Vehicle

Do your part to prevent injuries:

• Do not allow careless or reckless driving.

• Make sure operators are 16 or older with a valid driver’s license.

• Do not let people drive or ride after using alcohol or drugs.

• Do not allow operation on public roads (unless designated for off-highway
vehicle access) — collisions with cars and trucks can occur.

• Do not exceed seating capacity: 2 occupants.

Part Number: 7300524 (English), 7300524–F (French Canadian)

15

SAFETY

PROPER USE WARNING (CREW MODELS ONLY)

The Proper Use Warning label is located on the ROPS.

WARNING

Improper vehicle use can result in SEVERE INJURY or DEATH

WARNING

Drive Responsibly

Avoid loss of control and rollovers:

• Avoid abrupt maneuvers, sideways sliding, skidding, or fishtailing, and never
do donuts.

• Avoid hard acceleration when turning, even from a stop.

• Plan for hills, rough terrain, ruts, and other changes in traction and terrain.
Avoid paved surfaces.

• Avoid side hilling (riding across slopes).

Require Proper Use of Your Vehicle

Do your part to prevent injuries:

• Do not allow careless or reckless driving.

• Make sure operators are 16 or older with a valid driver’s license.

• Do not let people drive or ride after using alcohol or drugs.

• Do not allow operation on public roads (unless designated for off-highway
vehicle access) — collisions with cars and trucks can occur.

• Do not exceed seating capacity: 4 occupants.

Part Number: 7300525 (English), 7300525–F (French Canadian)

16

PASSENGER/ TIRE PRESSURE WARNING

The Passenger/ Tire Pressure Warning is located on the cargo box.

WARNING

• Never carry passengers in cargo box.

• Passengers can be thrown off. This
can cause serious injury or death.

• If total payload is greater than 500
lbs, the vehicle must be operated in
LOW range.

WARNING
IMPROPER TIRE PRESSURE OR
OVERLOADING CAN CAUSE LOSS
OF CONTROL RESULTING IN
SERIOUS INJURY OR DEATH.

SAFETY

• Reduce speed and allow greater

distance for braking when carrying
cargo.

• Overloading or carrying tall, off-

center, or unsecured loads will
increase your risk of losing control.
Loads should be centered and
carried as low as possible in box.

• For stability on rough or hilly terrain,

reduce speed and cargo.

Read Operation & Maintenance

Manual for more detailed loading information.

RANGER RANGER SP 570 RANGER SP 570

MAXIMUM
CARGO BOX
LOAD

500 (226 kg) 500 (226 kg) 500 (226 kg)

PREMIUM

RANGER SP 570

NORTHSTAR

EDITION

TIRE PRESSURE
IN PSI (KPa)

Front 10 (69)
Rear 10 (69)

Front 10 (69)
Rear 10 (69)

Front 10 (69)
Rear 10 (69)

17

SAFETY

RANGER RANGER SP 570 RANGER SP 570

PREMIUM

MAXIMUM
WEIGHT
CAPACITY
INCLUDES
WEIGHT OF
OPERATOR,
PASSENGER,
CARGO, AND
ACCESSORIES

Read Operation & Maintenance Manual for more detailed loading information.

RANGER CREW RANGER CREW

MAXIMUM

CARGO BOX

LOAD

1000 (454 kg) 925 (420 kg) 700 (318 kg)

RANGER CREW

SP 570

500 (226 kg) 500 (226 kg) 500 (226 kg)

SP 570 PREMIUM

RANGER SP 570

NORTHSTAR

RANGER CREW

NORTHSTAR

EDITION

SP 570

EDITION

TIRE PRESSURE
IN PSI (KPa)

MAXIMUM
WEIGHT
CAPACITY
INCLUDES
WEIGHT OF
OPERATOR,
PASSENGER,
CARGO, AND
ACCESSORIES

Read Operation & Maintenance Manual for more detailed loading information.

Front 16 (110)

Rear 16 (110)

1225 (510 kg) 1100 (499 kg) 750 (340 kg)

Front 16 (110)

Rear 16 (110)

Part number: 7300521 (English), 7300521–F (French Canadian)

Front 16 (110)

Rear 16 (110)

18

SAFETY

SEAT BELT/ DRIVER RESPONSIBLY WARNING

WARNING

Improper vehicle use can result in SEVERE INJURY or DEATH

Be Prepared

• Fasten seat belts.

• Wear an approved helmet and protective gear.

• ALWAYS use vehicle cab doors if equipped.

• Each rider must be able to sit with back against seat, feet flat on the floor, and
hands on steering wheel or handholds. Stay completely inside the vehicle.

Be Sure Riders Pay Attention and Plan Ahead

If you think or feel the vehicle may tip or roll, reduce your risk to injury:

• Keep a firm grip on the steering wheel or handholds and brace yourself.

• Do not put any part of your body outside of the vehicle for any reason.

Part number: 7300523 (English), 7300523–F (French Canadian)

19

SAFETY

MAXIMUM PAYLOAD WARNING

WARNING

The Maximum Payload Warning label is
located on the cargo box.

RANGER NEVER EXCEED

SP 570

CREW SP 570

CAUTION

To avoid transmission damage, shift only when the vehicle is stationary and at
idle. When the vehicle is stopped, place shift in parked position.

Part number: 7300582 (English), 7300582–F (French Canadian)

30 mph (49 kph) 480 lbs (218 kg)

35 mph (56 kph) 750 lbs (340 kg)

IF TOTAL PAYLOAD

EXCEEDS

CLUTCH COVER WARNING

The Clutch Cover Warning label is located on the clutch cover.

WARNING

• Moving parts hazard under belt­clutch guard. To prevent serious
injury, do not operate vehicle with
guard removed

• Do not modify engine or clutch. Doing
so can cause part failure, possible
imbalance, and excessive engine
RPM which can result in serious
injury or death.

Part number: 7175488 (English),
7175488–F (French Canadian)

20

FUEL TRANSPORT WARNING

The Fuel Transport Warning label is located in the cargo box.

WARNING

NEVER carry fuel or other flammable
liquids on this vehicle

Failure to follow this instruction could
lead to serious burn injuries or death.

Part number: 7186122 (English),
7186122–F (French Canadian)

SAFETY

AIR FILTER CAUTION

The Air Filter Caution label is located on the air filter housing.

CAUTION

Use a Polaris approved air filter. The
use of a non-Polaris approved air lter
may cause engine damage. Before
installing lter, ensure there is no dirt or
debris in the clean side of the intake
tube. The air lter must be properly
seated before the lid is reinstalled.
Please reference your owner’s manual
for additional information regarding air
lter service.

Part Number 7195873 (English),
7195873–F (French Canadian)

21

SAFETY

OPERATOR SAFETY

WARNING

Serious injury or death can result if you do not follow these instructions and
procedures, which are outlined in further detail within your owner's manual.

• Read this entire manual and all labels carefully. Follow the operating
procedures described.

• Never allow anyone under the age of 16 to operate this vehicle and never
allow anyone without a valid driver's license to operate this vehicle.

• Do not carry a passenger until you have at least two hours of driving
experience with this vehicle.

• No person under the age of 12 may ride as a passenger in this vehicle. All
riders must be able to sit with backs against the seat, both feet flat on the floor
and both hands on the steering wheel (if driving) or on a passenger hand hold
(if equipped).

• The driver and all passengers must wear helmet, eye protection, gloves, long­sleeve shirt, long pants, over-the-ankle boots and seat belt at all times.

• Always use the cab nets (or doors) while riding in this vehicle.

• Always keep hands and feet inside the vehicle at all times.

• Always keep both hands on the steering wheel and both feet on the
floorboards of the vehicle during operation.

• Never permit a guest to operate this vehicle unless the guest has read this
manual and all product labels.

• To reduce rollover risk, be especially careful when encountering obstacles
and slopes and when braking on hills or during turns.

• This vehicle is approved for on-road operation.

• Never consume alcohol or drugs before or while operating this vehicle.

• Never operate at excessive speeds. Always travel at a speed proper for the
terrain, visibility and operating conditions, and your experience.

• Never attempt jumps or other stunts.

• Always inspect the vehicle before each use to make sure it's in safe operating
condition. Always follow the inspection procedures described in this manual.

• Always travel slowly and use extra caution when operating on unfamiliar
terrain. Be alert to changing terrain.

• Never operate on excessively rough, slippery or loose terrain.

• Always follow proper procedures for turning. Practice turning at slow speeds
before attempting to turn at faster speeds. Never turn at excessive speeds.

• Always have this vehicle checked by an authorized POLARIS dealer if it has
been involved in an accident.

• Never operate this vehicle on hills too steep for the vehicle or for your abilities.
Practice on smaller hills before attempting larger hills.

22

SAFETY

• Always follow proper procedures for climbing hills as described in this manual.
Check the terrain carefully before attempting to climb a hill. Never climb hills
with excessively slippery or loose surfaces. Never apply throttle suddenly.
Never make sudden gear changes. Never go over the top of a hill at high
speed.

• Always follow the proper procedures outlined in this manual for traveling
downhill and for braking on hills. Check the terrain carefully before
descending a hill. Never travel downhill at high speed. Avoid going downhill at
an angle, which would cause the vehicle to lean sharply to one side. Travel
straight down the hill where possible.

• Always check for obstacles before operating in a new area. Never attempt to
operate over large obstacles such as large rocks or fallen trees. Always follow
the proper procedures outlined in this manual when operating over obstacles.

• Always be careful of skidding or sliding. On slippery surfaces such as ice,
travel slowly and exercise caution to reduce the chance of skidding or sliding
out of control.

• Never operate your vehicle in fast-flowing water or in water deeper than that
specified in this manual. Wet brakes may have reduced stopping ability. Test
your brakes after leaving water. If necessary, apply them lightly several times
to let friction dry out the pads.

• Always be sure there are no obstacles or people behind your vehicle when
operating in reverse. When it’s safe to proceed in reverse, move slowly. Avoid
turning at sharp angles in reverse.

• Always use the proper size and type of tires specified in this manual. Always
maintain proper tire pressure as specified on safety labels.

• Never modify this vehicle through improper installation or use of non­POLARIS approved accessories.

• Never exceed the stated load capacity for this vehicle. Cargo should be
properly distributed and securely attached. Reduce speed and follow the
instructions in this manual for hauling cargo or pulling a trailer. Allow a greater
distance for braking.

• Always place the transmission in PARK before getting out of the vehicle.

• Always engage the park brake when leaving the vehicle unattended.

• Always stop the engine before refueling. Remove flammable material
containers from the box before filling them with fuel. Make sure the refueling
area is well ventilated and free of any source of flame or sparks. Gasoline is
extremely flammable.

• Always remove the ignition key when the vehicle is not in use to prevent
unauthorized use by someone under the age of 16 or without a driver’s
license and proper training, or accidental starting.

23

SAFETY

EQUIPMENT MODIFICATIONS

Do not install any non-POLARIS approved accessory or modify the vehicle for
the purpose of increasing speed or power. Any modifications or installation of
non-POLARIS approved accessories could create a substantial safety hazard
and increase the risk of bodily injury.

The warranty on your POLARIS vehicle will be terminated if any non-POLARIS
approved equipment and/or modifications have been added to the vehicle that
increase speed or power.

The addition of certain accessories, including (but not limited to) mowers,
blades, tires, sprayers, or large racks, may change the handling characteristics
of the vehicle. Use only POLARIS-approved accessories, and familiarize
yourself with their function and effect on the vehicle.

For more information about safety, contact an authorized POLARIS

dealer or visit the POLARIS web site at http://www.polaris.com

24

PROPER OPERATION

Failure to operate the RANGER
properly can result in a collision, loss of
control, accident or rollover, which may
result in serious injury or death. Heed all
safety warnings outlined in this section
of the owner’s manual. See the
OPERATION section of the owner’s
manual for proper operating
procedures.

SAFETY

OPERATING WITHOUT INSTRUCTION

Operating this vehicle without proper
instruction increases the risk of an accident.
The operator must understand how to
operate the vehicle properly in different
situations and on different types of terrain. All
operators must read and understand the
Owner's Manual and all warning and
instruction labels before operating the
vehicle.

25

SAFETY

AGE RESTRICTIONS

This vehicle is an ADULT VEHICLE ONLY. NEVER operate this vehicle if you
are under age 16 and NEVER operate without a valid driver’s license.

Never operate with a passenger under the age of 12. All riders must be able to
sit with backs against the seat, both feet flat on the floor and both hands on the
steering wheel (if driving) or on a passenger hand hold (if equipped).

USING ALCOHOL OR DRUGS

Never consume alcohol or drugs before or
while operating this vehicle.

Operating this vehicle after consuming
alcohol or drugs could adversely affect
operator judgment, reaction time, balance
and perception.

26

SEAT BELTS

Riding in this vehicle without wearing the seat belt
increases the risk of serious injury in the event of
rollover, loss of control, other accident or sudden
stop. Seat belts may reduce the severity of injury in
these circumstances.

All riders must wear seat belts at all times.

PROTECTIVE APPAREL

Riding in this vehicle without wearing an
approved helmet and protective eyewear
increases the risk of a serious injuries in the
event of an accident. Operator and all
passenger must always wear an approved
helmet that fits properly and eye protection
(goggles or face shield).

SAFETY

JUMPS AND STUNTS

CAUTION

Exhibition driving increases the risk of an accident or rollover. DO NOT do

power slides, “donuts”, jumps or other driving stunts. Avoid exhibition driving.

27

SAFETY

CARRYING A PASSENGER

A passenger must always be seated in a passenger
seat with seat belt secured. Carrying more than one
passenger in a 2-seat vehicle can affect the
operator’s ability to steer and operate the controls,
which increases the risk of loss of control and
accident or rollover.

Never carry more than one passenger in a 2-seat
vehicle.

CAB NETS (IF EQUIPPED)

Riding in this vehicle without using the cab nets (or doors, if equipped) increases
the risk of serious injury or death in the event of an accident or rollover. Cab nets
(or doors) must be used by both operator and passengers at all times. Make
sure all latches are secure before operating the vehicle.

Always inspect cab nets and latches for tightness, wear and damage before
each use of the vehicle. Use the strap adjusters to tighten any loose straps.
Promptly replace worn or damaged cab nets and latches with new cab nets and
latches. Your POLARIS dealer can assist.

FAILURE TO INSPECT BEFORE OPERATING

WARNING

Failure to inspect and verify that the vehicle is in safe operating condition

before operating increases the risk of an accident. Always perform the Pre-

Ride Inspection outlined in the Operation chapter before each use of your

vehicle to make sure it's in safe operating condition. Always follow the

inspection and maintenance procedures and schedules described in this

owner’s manual. See the Periodic Maintenance section of the Maintenance

chapter.

28

SAFETY

OPERATING WITH A LOAD ON THE VEHICLE

The weight of the cargo, operator, and passengers impacts vehicle operation
and stability. For your safety and the safety of others, carefully consider how
your vehicle is loaded and how to safely operate the vehicle. Follow the
instructions in this manual for loading, tire pressure, gear selection and speed.

• Do not exceed vehicle weight capacities. The vehicle’s maximum weight
capacity is listed in the specifications section of this manual and on a label on
the vehicle. When determining the weight you are adding to the vehicle,
include the weight of the operator, passengers, accessories, loads in the rack
or box and the load on the trailer tongue. The combined weight of these items
must not exceed the maximum weight capacity.

• The recommended tire pressures are listed in the specifications section of this
manual and on a label on the vehicle.

Always follow these guidelines:

UNDER ANY OF THESE CONDITIONS: DO ALL OF THESE STEPS:

Operator and/or cargo exceeds half the
maximum weight capacity

Operating in rough terrain

Operating over obstacles

Climbing an incline

Towing

1. Slow down.

2. Verify tire pressure.

3. Use extra caution when operating.

29

SAFETY

HOT EXHAUST SYSTEMS

WARNING

Exhaust system components are very hot during and after use of the vehicle.

Hot components can cause burns and fire. Do not touch hot exhaust system

components. Always keep combustible materials away from the exhaust

system.

Use caution when traveling through tall grass, especially dry grass and when

traveling through muddy conditions. Always inspect the underside of the

vehicle and areas near the exhaust system after driving through tall grass,

weeds, brush, other tall ground cover, and muddy conditions. Promptly remove

any grass, debris or foreign matter clinging to the vehicle and pay particular

attention to the exhaust system area.

EXPOSURE TO EXHAUST

Engine exhaust fumes are poisonous and can cause loss of consciousness or
death in a short time. Never start the engine or let it run in an enclosed area.

The engine exhaust from this product contains chemicals known to cause
cancer, birth defects or other reproductive harm. Operate this vehicle only
outdoors or in well-ventilated areas.

IMPROPER TIRE MAINTENANCE

WARNING

Operating this vehicle with improper tires or with improper or uneven tire

pressure could cause loss of control or accident. Always use the size and type

of tires specified for your vehicle. Always maintain proper tire pressure as

described in the owner's manual and on safety labels.

UNAUTHORIZED USE OF THE VEHICLE

Leaving the keys in the ignition can lead to unauthorized use of the vehicle by
someone under the age of 16, without a drivers license, or without proper
training. This could result in an accident or rollover. Always remove the ignition
key when the vehicle is not in use.

30

SAFETY

TURNING IMPROPERLY

CAUTION

Turning improperly could cause loss of traction, loss of control, accident or

rollover. Always follow proper procedures for turning as described in this

owner’s manual.

Avoid sharp turns. Never turn while applying heavy throttle. Never make abrupt
steering maneuvers. Practice turning at slow speeds before attempting to turn at
faster speeds.

IMPROPER HILL CLIMBING

CAUTION

Improper hill climbing could cause loss of control or rollover. Use extreme

caution when operating on hills. Always follow proper procedures for hill

climbing as described in this owner's manual.

DESCENDING HILLS IMPROPERLY

CAUTION

Improperly descending a hill could cause loss of control or rollover. Always

follow proper procedures for traveling down hills as described in this owner’s

manual.

STALLING WHILE CLIMBING A HILL

CAUTION

Stalling or rolling backwards while climbing a hill could cause a rollover.

Maintain a steady speed when climbing a hill.

If you lose all forward speed:

Apply the brakes gradually until the vehicle is fully stopped. Place the
transmission in reverse and slowly allow the vehicle to roll straight downhill while
applying light brake pressure to control speed.

If you begin rolling downhill:

Never apply engine power. Apply the brakes gradually until the vehicle is fully
stopped. Place the transmission in reverse and slowly allow the vehicle to roll
straight downhill while applying light brake pressure to control speed.

31

SAFETY

SKIDDING OR SLIDING

CAUTION

Failure to use extra caution when operating on excessively rough, slippery or

loose terrain could cause loss of traction, loss of control, accident or rollover.
Do not operate on excessively slippery surfaces. Always slow down and use

additional caution when operating on slippery surfaces.

CAUTION

Skidding or sliding due to loss of traction can cause loss of control or rollover (if

tires regain traction unexpectedly). Always follow proper procedures for

operating on slippery surfaces as described in this owner's manual.

OPERATING ON FROZEN BODIES OF WATER

WARNING

Serious injury or death can result if the vehicle and/or the operator fall through

the ice. Never operate the vehicle on a frozen body of water unless you have

first verified that the ice is sufficiently thick to support the weight and moving

force of the vehicle, you and your cargo, together with any other vehicles in

your party.

Always check with local authorities and residents to confirm ice conditions and
thickness over your entire route. Vehicle operators assume all risk associated
with ice conditions on frozen bodies of water.

OPERATING A DAMAGED VEHICLE

CAUTION

Operating a damaged vehicle can result in an accident. After any rollover or

other accident, have a qualified service dealer inspect the entire machine for

possible damage, including (but not limited to) seat belts, rollover protection

devices, brakes, throttle, and steering systems.

OPERATING AT EXCESSIVE SPEEDS

CAUTION

Operating this vehicle at excessive speeds increases the operator's risk of

losing control. Always operate at a speed that's appropriate for the terrain, the

visibility and operating conditions and your skills and experience.

32

SAFETY

OPERATING ON PAVEMENT

This vehicle's tires are designed for off-road use only, not for use on pavement.
Operating this vehicle on paved surfaces (including sidewalks, paths, parking
lots and driveways) may adversely affect the handling of the vehicle and may
increase the risk of loss of control and accident or rollover. Avoid operating the
vehicle on pavement. If it's unavoidable, travel slowly, travel short distances and
avoid sudden turns or stops.

OPERATING IN UNFAMILIAR TERRAIN

CAUTION

Failure to use extra caution when operating on unfamiliar terrain could result in

an accident or rollover.

CAUTION

Unfamiliar terrain may contain hidden rocks, bumps, or holes that could cause

loss of control or rollover.

Travel slowly and use extra caution when operating on unfamiliar terrain. Always
be alert to changing terrain conditions.

REFUELING

Gasoline is highly flammable and explosive under certain conditions.

• Always exercise extreme caution whenever handling gasoline.

• Always turn off the engine when refueling.

• Always refuel outdoors or in a well ventilated area free of any source of flame

or sparks.

• NEVER carry fuel or other flammable liquids on this vehicle. Failure to follow

this instruction could lead to serious burn injuries or death.

• Do not smoke or allow open flames or sparks in or near the area where

refueling is performed or where gasoline is stored.

• Do not overfill the tank. Do not fill the tank neck.

• If gasoline spills on your skin or clothing, immediately wash it off with soap

and water and change clothing.

LIGHTNING AND POWERLINES

Avoid operating this vehicle when lightning could occur and when near
powerlines. Rubber tires, rubber handgrips, and a foam seat will not protect a
rider from lightning strikes or electrical surges. Always seek safe shelter when
lightning is imminent, and keep a safe distance from powerlines at all times.

33

34

FEATURES AND CONTROLS

FEATURES AND CONTROLS

COMPONENT LOCATIONS

ROPS (Roll Over

q

Protection System)

Headlight

w

Front Bumper/ Brush

e

Guard

Tie Down Point

r

Radiator (behind

t

removable grille)

Cargo Box

y

Tailgate

u

Muffler (Spark Arrestor)

i

Cargo Box Lever

o

Fuel Cap

a

Seatbelt

s

Electrical Compartment

d

(under seat)

35

FEATURES AND CONTROLS

CONSOLE

Left Switch Panel

q

Instrument Cluster

w

Ignition Switch

e

12V Auxiliary Port

r

Gear Selector (Shifter)

t

Cup Holder

y

Battery Trickle Charging Port

u

Storage Compartment

i

12V Auxiliary Port

o

Right Switch Panel

a

Steering Wheel Adjustment Lever

s

36

FEATURES AND CONTROLS

CONSOLE (NORTHSTAR MODELS ONLY)

Left Switch Panel

q

Instrument Cluster

w

Ignition Switch

e

12V Auxiliary Outlet

r

Gear Selector (Shifter)

t

Battery Trickle Charging

y

Outlet

Storage Compartment

u

12V Auxiliary Outlet

i

Heater Controls (If Equipped)

o

Right Switch Panel

a

Steering Wheel Adjustment Lever

s

ADJUSTABLE STEERING WHEEL

The steering wheel can be tilted upward or downward for rider preference.

Lift and hold the adjustment lever toward you while moving the steering wheel
upward or downward. Release the lever when the steering wheel is at the
desired position.

37

FEATURES AND CONTROLS

AUXILIARY OUTLET

The vehicle is equipped with 12–volt accessory
outlets on the dash. Use the outlets to power an
auxiliary light or other optional accessories or
lights. For service, the dash outlet connection is
under the dash.

BATTERY TRICKLE-CHARGING OUTLET

The vehicle is equipped with a dedicated outlet for trickle-charging the battery
during periods of extended inactivity.

If you do not drive the vehicle for more than TWO
WEEKS, Polaris recommends using a
BatteryMINDer® 2012 AGM - 2 AMP charger (PN

2415295), which can be ordered through your
dealer.

Polaris provides a charging accessory with your
vehicle that allows easy connection to the battery
through the Battery Trickle-Charging Outlet,
located on the dash. While charging, place the
charger outside of the vehicle and protect it from
moisture.

GEAR SELECTOR

Low gear is the primary driving range for the RANGER. High gear is intended for
use on hard-packed surfaces with light loads. Using high gear for heavy loads,
hilly terrain or in wet, muddy conditions will increase the chance of drive belt
burning. See the Drive Belt Wear/Burn section for details.

H: High Gear

L: Low Gear

N: Neutral

R: Reverse

P: Park

38

FEATURES AND CONTROLS

To shift gears, brake to a complete stop. When the engine is idling, move the
lever to the desired gear.

NOTICE

Shifting gears with the engine speed above idle or while the vehicle is moving

could cause transmission damage. Always shift when the vehicle is stationary

and the engine is at idle.

TIP

Maintaining shift linkage adjustment is important to assure proper transmission

function. See your dealer if you experience any shifting problems.

USING LOW GEAR

Always shift into low gear for any of the following conditions.

• Operating in rough terrain or over obstacles

• Loading the vehicle onto a trailer

• Towing heavy loads

• Driving frequently at low RPM or at ground speeds below 11 km/h (7 MPH)

SWITCHES

MODE BUTTON

The MODE button is located on the instrument cluster. Use the MODE button to
toggle through mode options available in the instrument cluster.

IGNITION SWITCH

The ignition switchqis a four-position,
key-operated switch. The key can be
removed from the switch when it is in
the OFF position.

STANDARD MODELS

OFF The engine is off. Electrical circuits are off.

SYSTEM ON Electrical circuits are on. Electrical equipment can be

used. Headlights are off.

39

FEATURES AND CONTROLS

ON Electrical circuits are on. Electrical equipment can be

used. Headlights are on.

START Turn the key to the START position to engage the electric

starter. The key returns to the ON position when released.

PREMIUM MODELS

OFF The engine is off. Electrical circuits are off.

ACCESSORY The engine is off. Powers the gauge and terminal block.

Check engine and steering warning indicators will appear
on the gauge in this mode, but will turn off when the
vehicle is started if no issues are present.

SYSTEM ON Electrical circuits are on. Electrical equipment can be

used.

START Turn the key to the START position to engage the electric

starter. The key returns to the ON position when released.

DRIVELINE MODE SWITCH

The Driveline Mode Switch has three positions: All Wheel Drive (AWD),
Differential Lock/Two Wheel Drive (2WD) and Off (Turf Mode).

AWD: Press the top of the switch to

q

engage All Wheel Drive (AWD).

2WD: Move the switch to the center

w

position to lock the differential and operate in
two wheel drive (2WD).

TURF Mode: Press the bottom of the

e

switch for Turf Mode (unlocked differential
power). In Turf Mode, the rear drive wheels
operate independently (1WD) depending on
tire traction. This mode of operation is well
suited to turf driving or when active traction is
not needed.

THROTTLE PEDAL

Push the throttle pedal
returns the pedal to the rest position when released. Always check that the
throttle pedal returns normally before starting the engine.

40

down to increase engine speed. Spring pressure

q

FEATURES AND CONTROLS

TIP

If the throttle pedal and brake pedal are applied simultaneously, engine power

may be limited.

BRAKE PEDAL

Depress the brake pedal
starting the engine.

to slow or stop the vehicle. Apply the brakes while

w

41

FEATURES AND CONTROLS

SEAT

SEAT BELTS

This vehicle is equipped with three-point lap and diagonal seat belts for the
operator and passenger. Always make sure the seat belts are secured for all
riders before operating. The driver’s seat belt is equipped with a seat belt
interlock. Vehicle speed will be limited to 15 MPH (24 km/h) if the seat belt is not
secured.

The center of the seat is NOT equipped with a seat belt. Never allow a
passenger to ride between the operator and passenger seats.

WARNING

Falling from a moving vehicle could result in serious injury or death. Always

fasten your seat belt securely before operating or riding in the vehicle.

To wear the seat belt properly, follow this procedure:

1. For 3-point belts, pull the seat belt latch
toward the buckle at the inner edge of the seat. The belt should fit snugly
across your hips and diagonally across your chest. Make sure the belt is not
twisted.

downward and across your chest

q

2. Push the latch plate

3. Release the strap, and pull to tighten.

4. To release the seat belt, press the square red button in the buckle’s center.

42

into the buckle

q

until it clicks.

w

FEATURES AND CONTROLS

SEAT BELT INSPECTION

Inspect all seat belts for proper operation before each use of the vehicle.

1. Push the latch plate into the buckle until it clicks. The latch plate must slide
smoothly into the buckle. A click indicates that it's securely latched.

2. Push the red release latch in the middle of the buckle to make sure it
releases freely.

3. Pull each seat belt completely out and inspect the full length for any damage,
including cuts, wear, fraying or stiffness. If any damage is found, or if the seat
belt does not operate properly, have the seat belt system checked and/or
replaced by an authorized dealer.

4. To clean dirt or debris from the seat belts, sponge the straps with mild soap
and water. Do not use bleach, dye or household detergents. Rinse the entire
length of the belt webbing. Use a garden hose to flush out the retractor and
latch housings regularly.

SEAT AND STORAGE COMPARTMENTS

The electrical compartment is located under the center rear-most seat. Never
use this area for storage. Storage compartments are located under all other
seats. Remove the storage bin under the right rear-most passenger seat to
access the battery.

If your model is equipped with a storage console and cup holders located
between the front seats, lift the console lid to access the storage compartment.

Pull the rear edge of a seat upward to release the latch pins from the grommets.
Roll the seat forward to access the under-seat area. To completely remove a
seat, roll the seat forward and lift the seat tabs from the seat base mounts.

Always make sure all seats are properly installed and securely latched before
operating. Push down firmly on the rear of each seat until the latch pins are fully
seated into the grommets.

SEAT REMOVAL

To remove the seat:

1. Lift up on the back of the seat.

2. Detach the seat assembly from the seat hinges.

3. Remove the seat from the vehicle.

43

FEATURES AND CONTROLS

ELECTRONIC POWER STEERING
(IF EQUIPPED)

Electronic power steering (EPS) engages when the ignition key is turned to the
ON position. EPS remains engaged whether the vehicle is moving or idle. To
conserve battery power, the EPS will shut down 5 minutes after the engine is
stopped if the key remains in the ON position. The EPS warning indicator will
illuminate to indicate the EPS has shut down. Turn the key off and on to reset
the unit. If the light remains on after starting the engine, the EPS system is
inoperative. See your POLARIS dealer, or other qualified person, as soon as
possible for repair. Continued operation could result in permanent damage to the
EPS unit and increased steering effort.

FUEL CAP

NOTICE

Never use fuel blends with more than 10% ethanol. Engine damage could

occur.

The fuel tank filler cap
the right-hand side of the vehicle near
the passenger seat. When refueling,
always use either leaded or unleaded
gasoline with a minimum pump octane
number of 87 R+M/2 octane. Do not use
fuel with ethanol content greater than
10 percent, such as E-85 fuel.
Compatible fuels: E5 and E10

is located on

q

44

FEATURES AND CONTROLS

CAB NETS (IF EQUIPPED)

Riding in this vehicle without using the cab nets (or doors, if equipped) increases
the risk of serious injury or death in the event of an accident or rollover. Cab nets
(or doors) must be used by both operator and passengers at all times. Make
sure all latches are secure before operating the vehicle.

Always inspect cab nets and latches for tightness, wear and damage before
each use of the vehicle. Use the strap adjusters to tighten any loose straps.
Promptly replace worn or damaged cab nets and latches with new cab nets and
latches. Your POLARIS dealer can assist.

SECURING THE NET

1. After entering the vehicle, connect the latch
the receiver latch mounted on the front frame.

at the top edge of the net to

q

OPENING THE NET

1. To exit the vehicle, release the top front latchq.

2. Allow the net to hang freely outside the vehicle while dismounting.

45

FEATURES AND CONTROLS

ROLLOVER PROTECTIVE STRUCTURE (ROPS)

The Rollover Protective Structure (ROPS)qon this vehicle meets OSHA®

1928.53 rollover performance requirements. Always have your authorized
POLARIS dealer thoroughly inspect the ROPS if it ever becomes damaged in
any way.

No device can assure occupant protection in the event of a rollover. Always
follow all safe operating practices outlined in this manual to avoid vehicle
rollover.

WARNING

Vehicle rollover could cause severe injury or death. Always avoid operating in

a manner that could result in vehicle rollover.

TRAILER HITCH BRACKET

This vehicle is equipped with a receiver hitch bracket for a trailer hitch. To avoid
injury and property damage, always heed the warnings and towing capacities
outlined on page 78.

46

INSTRUMENT CLUSTER

OVERVIEW

NOTICE

Features and telltales vary by model.

FEATURES AND CONTROLS

DISPLAY AREA FUNCTION

Gear Indicator

q

Display Area 2

w

Display Area 1

e

Fuel Gauge

r

H = High Gear
L = Low Gear
N = Neutral
R = Reverse Gear
P = Park
– = Gear Signal Error (or shifter between gears)

This area displays odometer, trip meter, trip meter 2,
voltage, engine temperature, engine hour meter,
programmable service hour interval, ground speed,
or engine RPM.

This area displays engine RPM, ground speed, or
coolant temperature.

The segments of the fuel gauge show the level of
fuel in the fuel tank. When the last segment clears, a
low fuel warning is activated. All segments including
the fuel icon will flash. Refuel immediately.

47

FEATURES AND CONTROLS

DISPLAY AREA FUNCTION

Service Indicator

t

Clock

y

Driveline Mode

u

Indicator

A flashing wrench symbol alerts the operator that the
preset service interval has been reached. Your
POLARIS dealer can provide scheduled
maintenance. See page 64 for more information.

The clock displays time in a 12-hour or 24-hour
format.

Segments of the indicator illuminate based on
driveline mode engaged.

INDICATOR LAMPS

INDICATOR ICON FUNCTION

Check Engine

This indicator appears if a fault occurs.
Do not operate the vehicle if this warning
appears. Serious engine damage could
result. Your authorized POLARIS dealer
can assist.

EPS Warning (if
equipped)

Engine Hot

Neutral

This indicator illuminates when a fault has
occurred in the EPS system. Your
authorized POLARIS dealer can assist.
EPS operation is possible with key on/
engine off for up to 5 minutes.

This lamp illuminates to indicate an
overheated engine. If the indicator
flashes, a severe overheating condition
exists.

This lamp illuminates when the
transmission is in neutral and the ignition
key is in the ON position.

Helmet/Seat
Belt

48

This lamp flashes for several seconds
when the key is turned to the ON position.
The lamp is a reminder to wear helmet
and seat belt (if equipped) before
operating.

FEATURES AND CONTROLS

INDICATOR ICON FUNCTION

High Beam

Brake Failure (if
equipped)

This lamp illuminates when the headlamp
switch is set to high beam.

Lamp illuminates when Brake System (if
Brake Failure Alarm is equipped) detects
low fluid level in brake hydraulic system.
Verify brake fluid in reservoir.

49

FEATURES AND CONTROLS

DISPLAY AREA 1

Pressing the MODE button
will change the information
displayed in Area 1q.

DISPLAY AREA 1 FUNCTION

Speed The vehicle’s speed will be displayed in mph, or km/h.

Engine
Temperature

RPM The vehicle’s RPM will be displayed.

The vehicle’s current engine temperature will be
displayed.

50

FEATURES AND CONTROLS

DISPLAY AREA 2

Toggle the Up/Down
buttons to change the
information displayed in
Area 2

DISPLAY AREA 2 FUNCTION

Odometer The vehicle’s odometer reading will be displayed.

w

.

Engine
Temperature

Trip 1 The vehicle Trip 1 mileage will be displayed.

Trip 2 The vehicle Trip 2 mileage will be displayed.

RPM The vehicle RPM will be displayed.

Voltage The vehicle’s current battery voltage will be displayed.

Speed The vehicle’s current speed will be displayed.

Engine Hours The vehicle’s engine hours will be displayed.

Service Hours The vehicle’s service hours will be displayed.

The vehicle Engine Temperature will be displayed.

51

FEATURES AND CONTROLS

OPTIONS MENU

From the options menu you
can view diagnostic codes,
access the advanced menu,
set the clock, and much more.
For a full list of available
options see below.

To enter the Options Menu,
press and hold the MODE
button.

OPTIONS MENU NOTES

Diagnostic Codes Only displays if fault codes are

present or stored

Advanced Menu (if equipped) Set maximum speed, and geofencing

settings.

Units - Distance Select MPH or KPH

Units - Temp Select between °F and °C

Clock (if equipped) Select between 12H or 24H, and set

time

Backlight Color Select between Blue or Red

Backlight Level Set backlight brightness level

Service Hours View/Set Service hours

Exit Menu Exit

52

FEATURES AND CONTROLS

DIAGNOSTIC CODE

Diagnostic Code Screen will show available MIL that has come on during that
ignition cycle.

To access the Diagnostic Code
Screen, do the following:

1. Press and hold the MODE
button to enter the Options
Menu. “OPTIONS” will
display on the screen for 3
seconds before showing
first menu item.

2. Select “Diagnostic Codes” from the Options Menu by pressing the MODE
button.

Toggle the Up/Down Buttons to cycle through Code(s).

NOTICE

This option will only be available if a fault code was set or is active during the

current ignition key 'on' cycle. Turning off the ignition will clear any save fault

codes from the gauge.

Display area 1 will show FMI

q

Display area 2 will show SPN

w

Clock Area will show Count.

e

53

FEATURES AND CONTROLS

NOTICE

When the gauge is displaying a fault code, the warning telltale (check engine

or EPS) will blink to indicate which controller set the fault code.

3. To exit the Options Menu the user can select Exit Menu function from
Options Menu, can hold Mode Button and exit out of Options Menu, or not
press any button for 10 seconds, which will exit out of the Options Menu.

DIAGNOSTIC DISPLAY CODE DEFINITIONS

Open Load:There is a break in the wires that lead to the item listed in the chart
(injector, fuel pump, etc.), or the item has failed.

Short-to-Ground:The wire is shorted to ground between the electronic control
unit and the item listed in the chart.

Shorted Load:The wires leading to the item listed in the chart are shorted
together, or the item has shorted internally.

Short-to-Battery:The wire leading from the item listed in the chart to the
electronic control unit is shorted to a wire at battery voltage.

DIAGNOSTIC CODES

COMPONENT CONDITION SPN FMI

Throttle Position
Sensor

Engine Temperature
Sensor

Intake Air
Temperature Sensor

Voltage Too High

Voltage Too Low

Voltage Too High

Voltage Too Low

Temperature Too High

Engine Overheat
Shutdown

Voltage Too High

Voltage Too Low

51 3

51 4

110 3

110 4

110 16

110 0

105 3

105 4

Manifold Absolute
Pressure Sensor

Crankshaft Position
Sensor

54

Voltage Too High

Voltage Too Low

Signal Out of Range

Circuit Fault

Plausibility Fault

102 3

102 4

102 2

636 8

636 2

FEATURES AND CONTROLS

DIAGNOSTIC CODES

COMPONENT CONDITION SPN FMI

Vehicle Speed Signal Speed Too High

Plausibility Fault

Gear Sensor Signal Voltage Too Low

Voltage Too High

Signal Fault

Injector 1 (MAG) (SDI
Part Load)

Injector 2 (PTO) (SDI
Part Load)

Driver Circuit Open/
Grounded

Driver Circuit Short to
B+

Driver Circuit
Grounded

Driver Circuit Open/
Grounded

Driver Circuit Short to
B+

84 8

84 2

523 4

523 3

523 2

651 5

651 3

651 4

652 5

652 3

Ignition Coil Primary
Driver 1 (MAG)

Ignition Coil Primary
Driver 2 (PTO)

Fuel Pump Driver
Circuit

Fan Relay Driver
Circuit

Driver Circuit
Grounded

Driver Circuit Short to
B+

Driver Circuit Short to
B+

Driver Circuit Open/
Grounded

Driver Circuit Short to
B+

Driver Circuit
Grounded

Driver Circuit Open/
Grounded

Driver Circuit Short to
B+

652 4

1268 3

1269 3

1347 5

1347 3

1347 4

1071 5

1071 3

Driver Circuit
Grounded

Idle Air Control Driver Circuit Open/

Grounded

1071 4

634 5

55

FEATURES AND CONTROLS

DIAGNOSTIC CODES

COMPONENT CONDITION SPN FMI

Driver Circuit Short to
B+

Driver Circuit
Grounded

Position Out of Range

Starter Enable Circuit Driver Circuit Open/

Grounded

Driver Circuit Short to
B+

Driver Circuit
Grounded

Chassis Relay Driver Circuit Open/

Grounded

Driver Circuit Short to
B+

Driver Circuit
Grounded

634 3

634 4

634 7

1321 5

1321 3

1321 4

520208 5

520208 3

520208 4

All Wheel Drive
Control

System Power Voltage Too High

Throttle Safety Signal Voltage Too High

Active Descent
Control System

Driver Circuit Open/
Grounded

Driver Circuit Short to
B+

Driver Circuit
Grounded

Voltage Too Low

Voltage Too Low

Signal Out of Range

Throttle Stuck

Driver Circuit Open/
Grounded

520207 5

520207 3

520207 4

168 3

168 4

520194 3

520194 4

520194 2

520194 7

520203 5

56

Driver Circuit Short to
B+

520203 3

FEATURES AND CONTROLS

DIAGNOSTIC CODES

COMPONENT CONDITION SPN FMI

Driver Circuit
Grounded

Idle Speed Speed Too High

Speed Too Low

Right Hand Control Momentary Driveline

Mode Switch Press

DIAGNOSTIC CODES

COMPONENT CONDITION SPN FMI

EPS MODELS ONLY

Vehicle Speed Sensor Data Valid But Above

Normal Operational
Range - Most Severe
Level

Data Erratic,
Intermittent Or
Incorrect

520203 4

520211 3

520211 4

520468 31

84 0

84 2

Abnormal Rate Of
Change

Received Network
Data In Error

System Power Data Valid But Above

Normal Operational
Range - Most Severe
Level

Voltage Above
Normal, Or Shorted To
High Source

Voltage Below
Normal, Or Shorted To
Low Source

Engine Speed Data Valid But Above

Normal Operational
Range - Most Severe
Level

Data Erratic,
Intermittent Or
Incorrect

84 10

84 19

168 0

168 3

168 4

190 0

190 2

57

FEATURES AND CONTROLS

DIAGNOSTIC CODES

COMPONENT CONDITION SPN FMI

EPS MODELS ONLY

Received Network
Data In Error

ECU Memory Bad Intelligent Device

Or Component

Out Of Calibration

Calibration Out Of Calibration

Steering Over Current
Shut Down

Steering Excessive
Current Error

Steering Torque
Partial Failure

Steering Torque Full
Failure

EPAS Inverter
Temperature

Current Above Normal
Or Grounded Circuit

Current Above Normal
Or Grounded Circuit

Condition Exists

Condition Exists

Data Valid But Above
Normal Operational
Range - Most Severe
Level

190 19

628 12

628 13

630 13

520221 6

520222 6

520223 31

520224 31

520225 0

Data Valid But Above
Normal Operating
Range - Moderately
Severe Level

EPAS
Communications
Receive Data Error

Position Encoder
Error

EPAS Software Error Bad Intelligent Device

Data Erratic,
Intermittent Or
Incorrect

Condition Exists

Root Cause Not
Known

Bad Intelligent Device
Or Component

Condition Exists

Or Component

Condition Exists

520225 16

520226 2

520226 31

520228 11

520228 12

520228 31

520229 12

520229 31

EPAS Power Save
Condition

58

Condition Exists

520231 31

FEATURES AND CONTROLS

DIAGNOSTIC CODES

COMPONENT CONDITION SPN FMI

EPS MODELS ONLY

EPS SEPIC Voltage
Error

Voltage Above
Normal, Or Shorted To
High Source

Voltage Below
Normal, Or Shorted To
Low Source

524086 3

524086 4

UNIT SELECTION DISTANCE

1. Press and hold the MODE button to enter the Options Menu.

NOTICE

“OPTIONS” will display on the screen for 3 seconds before showing first menu

item.

2. Select “Units-Distance” from the Options Menu by pressing the MODE
button.

Reference the image shown above:

Press the MODE button.

q

Toggle the Up/Down Buttons to change the units (MPH or KPH)

w

With the correct unit displayed, Press the mode button which will set

e

the unit and return to the Options Menu.

3. To exit the Options Menu the user can select Exit Menu function from
Options Menu, can hold Mode Button and exit out of Options Menu, or not
press any button for 10 seconds, which will exit out of the Options Menu.

59

FEATURES AND CONTROLS

UNIT SELECTION TEMPERATURE

1. Press and hold the MODE button to enter the Options Menu.

NOTICE

“OPTIONS” will display on the screen for 3 seconds before showing first menu

item.

2. Select “Units - Temp” from the Options Menu by pressing the MODE button.

Reference the image shown above:

Press the MODE button.

q

Toggle the Up/Down Buttons to change the units (°F or °C)

w

With the correct unit displayed, Press the mode button which will set

e

the unit and return to the Options Menu.

3. To exit the Options Menu the user can select Exit Menu function from
Options Menu, can hold Mode Button and exit out of Options Menu, or not
press any button for 10 seconds, which will exit out of the Options Menu.

60

FEATURES AND CONTROLS

CLOCK

1. Press and hold the MODE button to enter the Options Menu.

NOTICE

“OPTIONS” will display on the screen for 3 seconds before showing first menu

item.

2. Select “Clock” from the Options Menu by pressing the MODE button.

Reference the image shown above:

Press the MODE button.

q

Toggle the Up/Down Buttons to change the units (12H or 24H)

w

With the correct unit displayed, Press the mode button which will set the

e

unit.

Toggle the Up/Down Buttons to change the units (Cycles Hours)

r

With the correct unit displayed, Press the mode button which will set the

t

unit.

Toggle the Up/Down Buttons to change the units (Cycles 10s of Minutes)

y

With the correct unit displayed, Press the mode button which will set the

u

unit.

Toggle the Up/Down Buttons to change the units (Cycles 1s of Minutes)

i

With the correct unit displayed. Press the mode button which will set the

o

unit and return to the Options menu.

3. To exit the Options Menu the user can select Exit Menu function from
Options Menu, can hold Mode Button and exit out of Options Menu, or not
press any button for 10 seconds, which will exit out of the Options Menu.

61

FEATURES AND CONTROLS

BACK LIGHT COLOR

1. Press and hold the MODE button to enter the Options Menu.

NOTICE

“OPTIONS” will display on the screen for 3 seconds before showing first menu

item.

2. Select “Backlight Color” from the Options Menu by pressing the MODE
button.

Reference the image shown above:

Press the MODE button.

q

Toggle the Up/Down Buttons to change the units (Blue or Red)

w

With the correct unit displayed, Press the mode button which will set

e

the unit and return to the Options Menu.

3. To exit the Options Menu the user can select Exit Menu function from

Options Menu, can hold Mode Button and exit out of Options Menu, or not
press any button for 10 seconds, which will exit out of the Options Menu.

62

FEATURES AND CONTROLS

BACK LIGHT LEVEL

1. Press and hold the MODE button to enter the Options Menu.

NOTICE

“OPTIONS” will display on the screen for 3 seconds before showing first menu

item.

2. Select “Backlight Level” from the Options Menu by pressing the MODE
button.

Reference the image shown above:

Press the MODE button.

q

Toggle the Up/Down Buttons to change the units (Increase or De-

w

crease Level)

With the correct unit displayed, Press the mode button which will set

e

the unit and return to the Options Menu.

3. To exit the Options Menu the user can select Exit Menu function from
Options Menu, can hold Mode Button and exit out of Options Menu, or not
press any button for 10 seconds, which will exit out of the Options Menu.

63

FEATURES AND CONTROLS

SERVICE HOURS

1. Press and hold the MODE button to enter the Options Menu.

NOTICE

“OPTIONS” will display on the screen for 3 seconds before showing first menu

item.

2. Select “Service Hours” from the Options Menu by pressing the MODE button.

Reference the image shown above:

Press the MODE button.

q

Toggle the Up/Down Buttons to change the units (0, 5, 10 - 95, 100)

w

With the correct unit displayed, press the MODE button, which will set

e

the unit and return you to the Options Menu.

NOTICE

To reset service hours after they have counted down to "0.0", reselect the

existing setpoint or select a new service hour value.

3. To exit the Options Menu the user can select Exit Menu function from
Options Menu, can hold Mode Button and exit out of Options Menu, or not
press any button for 10 seconds, which will exit out of the Options Menu.

PIN ACTIVATED SECURITY SYSTEM (P.A.S.S.) (IF
EQUIPPED) — INSTRUMENT CLUSTER

The optional PIN Activated Security System (P.A.S.S.) is to prevent
unauthorized use. When enabled, the vehicle cannot be operated until a valid
passcode has been entered using the Instrument Cluster.

To enable/disable P.A.S.S. using the Instrument Cluster, follow the procedures
below.

64

FEATURES AND CONTROLS

ENABLE P.A.S.S.

NOTICE

After activating P.A.S.S. for the first time you must power down the vehicle and

allow the electronic control module (ECM) to fully shutdown before restarting.

This may take up to three minutes.

Once a new passcode has been enabled, it cannot be changed unless you first

disable the system. Then you can re-follow the steps outlined in the ENABLE

P.A.S.S. section to enter a new passcode.

1. Press and hold the MODE button to enter the “OPTIONS” menu.

2. Use the UP/DOWN toggle buttons to cycle through options until “REQUIRE
PIN TO START” appears. Press the MODE button to select.

3. If required, “ENTER NEW PIN” will appear. Use the UP/DOWN toggle
buttons to cycle to your desired first digit. Press the MODE button to select
the digit.

4. Continue until all four digits of your desired passcode have been selected.
Once finished, “NEW PIN SET” will flash momentarily and then revert back to
the “REQUIRE PIN TO START” screen.

Please record your passcode.

5. To enable your new passcode, use the UP/DOWN toggle buttons to change
the flashing “OFF” at bottom of screen to “ON”. If this step is skipped, P.A.

S.S. will not be enabled.

6. Press the MODE button to re-enter the “OPTIONS” menu. The vehicle will
now require passcode entry before next startup.

You can exit the “OPTIONS” menu three different ways.

• Toggle to “EXIT” and press the MODE button.

• Hold the MODE button for a few seconds.

• Do nothing, allowing the system to automatically revert back to the main

screen.

NOTICE

If the battery becomes low while the P.A.S.S. system is enabled, the gauge

may show “New Vehicle Detected” after the battery has been recharged/

replaced. Leave the key in the ON position to allow system reconfirmation.

65

FEATURES AND CONTROLS

DISABLE P.A.S.S.

1. Press and hold the MODE button to enter the “OPTIONS” menu.

2. Use the UP/DOWN toggle buttons to cycle through options until “REQUIRE
PIN TO START” appears. Press the MODE button to select.

3. Enter current passcode.

4. Use the UP/DOWN toggle buttons to change the flashing “ON” at bottom of
screen to “OFF”.

5. Press the MODE button to re-enter the “OPTIONS” menu. P.A.S.S. is now
disabled.

You can exit the “OPTIONS” menu three different ways.

• Toggle to “EXIT” and press the MODE button.

• Hold the MODE button for a few seconds.

• Do nothing, allowing the system to automatically revert back to the main

screen.

66

OPERATION

OPERATION

IMPORTANT INFORMATION

WARNING

Failure to operate the vehicle properly can result in a collision, loss of control,

accident or rollover, which may result in serious injury or death. Read and

understand all safety warnings outlined in the safety section of this owner’s

manual.

VEHICLE BREAK-IN PERIOD

The break-in period for your new RANGER is the first 25 hours of operation, or
the time it takes to use the first two tanks full of fuel. No single action on your
part is as important as a proper break-in period. Careful treatment of a new
engine will result in more efficient performance and longer life for the engine.
Perform the following procedures carefully.

NOTICE

Excessive heat build-up during the first 3 hours of operation will damage close-

fitted engine parts and drive components. Do not operate at full throttle or high

speeds during the first 3 hours of use.

67

OPERATION

ENGINE AND DRIVETRAIN BREAK-IN

1. Fill the fuel tank with clean, fresh fuel.

2. Check the oil level. Add the recommended oil as needed to maintain the oil
level in the normal (safe) operating range.

3. Drive slowly at first. Select an open area that allows room to familiarize
yourself with vehicle operation and handling.

4. Vary throttle positions. Do not operate at sustained idle.

5. Perform regular checks on fluid levels, controls and areas outlined on the
daily pre-ride inspection checklist.

6. During the break-in period, change both the oil and the filter at 25 hours.

7. Check fluid levels of transmission and all gearcases after the first 25 hours of
operation and every 100 hours thereafter.

8. Pull only light loads.

PVT BREAK-IN (CLUTCHES/BELT)

Always break in the clutches and drive belt of new vehicles, as well as after a
belt replacement.

A proper break-in of the clutches and drive belt will ensure a longer life and
better performance. Break in the clutches and belt by operating at slower
speeds during the break-in period as recommended. Pull only light loads. Avoid
aggressive acceleration and high speed operation during the break-in period.

If a belt fails, always clean any debris from the PVT intake and outlet duct and
from the clutch and engine compartments when replacing the belt.

PRE-RIDE INSPECTION

Failure to inspect and verify that the vehicle is in safe operating condition before
operating increases the risk of an accident. Always inspect the vehicle before
each use to make sure it's in safe operating condition.

ITEM REMARKS REF.

Brake system/pedal travel Ensure proper operation page 41

page 128

Brake fluid Ensure proper level page 128

Front suspension Inspect page 130

Rear suspension Inspect page 130

Steering Ensure free operation page 130

68

OPERATION

ITEM REMARKS REF.

Tires Inspect condition and pressure page 131

Wheels/fasteners Inspect, ensure fastener tightness page 131

Frame nuts, bolts,
fasteners

Fuel and oil Ensure proper levels page 47

Coolant level Ensure proper level page 120

Coolant hoses Inspect for leaks

Throttle Ensure proper operation

Indicator lights/switches Ensure proper operation page 39

Intake pre-filters Inspect, clean page 126

Headlamps Check operation, apply POLARIS

Brake light/tail lamps Check operation

Seat Latch Push down on the seat back to ensure the

Inspect, ensure tightness

dielectric grease when lamp is replaced

latch is secure

–

page 104

–

–

page 136

–

page 43

Seat Belt Check length of belt for damage, check

latches for proper operation

Cab Doors (If equipped) Check doors and latches for wear or

damage.

Riding Gear Wear approved helmet, goggles, and

protective clothing

page 43

page 45

STARTING THE ENGINE

1. Position the vehicle on a level surface outdoors or in a well ventilated area.

2. Sit in the driver's seat and fasten the seat belt. Secure the cab nets.

3. Place the transmission in PARK and apply the PARKING BRAKE (if
equipped).

4. Apply the brakes. Do not press the throttle pedal while starting the engine.

5. Turn the ignition key past the ON/RUN position to START. Engage the starter
for a maximum of five seconds. Release the key when the engine starts.

69

OPERATION

6. If the engine does not start within five seconds, return the ignition switch to
the OFF position and wait five seconds. Repeat steps 5 and 6 until the
engine starts.

7. Vary the engine RPM slightly with the throttle to aid in warm up until the
engine idles smoothly.

NOTICE

Operating the vehicle immediately after starting could cause engine damage.

Allow the engine to warm up for several minutes before operating the vehicle.

STOPPING THE ENGINE

1. Release the throttle pedal completely and brake to a complete stop.

2. Place the transmission in PARK.

3. Engage the PARKING BRAKE (if equipped).

4. Slowly release the brake pedal and make sure the transmission is in PARK
before exiting the vehicle.

5. Turn the engine off.

WARNING

A rolling vehicle can cause serious injury. Always place the transmission in

PARK and engage the PARKING BRAKE (if equipped) when stopping the

engine.

70

OPERATION

BRAKING

1. Release the throttle pedal completely.

TIP

When the throttle pedal is released completely and the engine speed drops

near an idle, the vehicle has no engine braking.

2. Press on the brake pedal evenly and firmly.

TIP

If the throttle pedal and brake pedal are applied simultaneously, engine power

may be limited.

3. Practice starting and stopping (using the brakes) until you’re familiar with the
controls.

DRIVING PROCEDURES

1. Wear a helmet, eye protection, gloves, long-sleeve shirt, long pants and
over-the-ankle boots.

2. Perform the pre-ride inspection.

3. Sit in the driver's seat and fasten the seat belt.

4. Always use the cab nets (or doors) while riding in this vehicle.

5. Place the transmission in PARK.

6. Start the engine.

7. Apply the service brakes and shift the transmission into gear.

8. Check your surroundings and determine your path of travel.

9. Release the park brake.

10.Keeping both hands on the steering wheel, slowly release the brakes and
slowly depress the throttle with your right foot to begin driving.

11. Drive slowly. Practice maneuvering and using the throttle and brakes on level
surfaces.

12.Do not carry a passenger until you have at least two hours of driving
experience with this vehicle.

71

OPERATION

DRIVING WITH A PASSENGER

• Perform the pre-ride inspection.

• Make sure all passengers are at least 12 years of age and tall enough to
comfortably and safely sit in a passenger seat with the seat belt secured, put
both feet on the floor and grasp the hand hold.

• Make sure all passengers are wearing helmets, eye protection, gloves, long­sleeve shirt, long pants and over-the-ankle boots.

• Make sure all cab nets or doors (if equipped) are properly secured.

• Do not carry more than the recommended number of passengers for your
vehicle.

• Allow a passenger to ride only in a passenger seat.

• Slow down. Always travel at a speed appropriate for your skills, your
passengers’ skills, and operating conditions. Avoid unexpected or aggressive
maneuvers that could cause discomfort or injury to a passenger.

• Vehicle handling may change with a passenger and/or cargo on board. Allow
more time and distance for braking.

• Always follow all operating guidelines as outlined on safety labels and in this
manual.

72

OPERATION

DRIVING ON SLIPPERY SURFACES

WARNING

Skidding or sliding can cause loss of control or rollover (if tires regain traction

unexpectedly). When operating on slippery surfaces such as ice or loose

gravel, reduce speed and use extra caution to reduce the chance of skidding or

sliding out of control. Do not operate on excessively slippery surfaces.

When driving on slippery surfaces such as wet trails, loose gravel, or ice, be
alert for the possibility of skidding and sliding. Follow these precautions when
encountering slippery conditions:

• Do not operate on excessively rough, slippery or loose terrain.

• Slow down before entering slippery areas.

• Maintain a high level of alertness, reading the trail and avoiding quick, sharp
turns, which can cause skids.

• Engage all-wheel drive before wheels begin to lose traction.

NOTICE

Severe damage to the drive train may occur if the AWD is engaged while the

wheels are spinning. Always allow the wheels to stop spinning before engaging

AWD.

• Correct a skid by turning the steering wheel in the direction of the skid. Never

apply the brakes during a skid.

73

OPERATION

DRIVING UPHILL

Whenever traveling uphill, follow these precautions:

1. Avoid excessively steep hills.

2. Always travel straight uphill.

3. Keep both feet on the floor.

4. Always check the terrain carefully before ascending any hill. Never climb hills
with excessively slippery or loose surfaces.

5. Proceed at a steady rate of speed and throttle opening. Never open the
throttle suddenly.

6. Never go over the crest of a hill at high speed. An obstacle, a sharp drop, or
another vehicle or person could be on the other side of the hill.

DRIVING ON A SIDEHILL (SIDEHILLING)

Driving on a sidehill is not recommended. Improper procedure could cause loss
of control or rollover. Avoid crossing the side of any hill unless absolutely
necessary.

If crossing a sidehill is unavoidable, follow these precautions:

1. Slow down.

2. Exercise extreme caution.

3. Avoid crossing the side of a steep hill.

DRIVING DOWNHILL

When driving downhill, follow these precautions:

1. Avoid excessively steep hills.

2. Always descend a hill with the direction selector switch on forward. Never
descend a hill with the switch on neutral.

3. Drive straight downhill. Avoid descending a hill at an angle, which would
cause the vehicle to lean sharply to one side. Travel straight downhill when
possible.

4. Slow down.

5. Apply the brakes slightly to aid in slowing.

DRIVING THROUGH WATER

Your vehicle can operate through water up to a maximum recommended depth
equal to the floorboards.

74

OPERATION

NOTICE

If your vehicle becomes immersed or is operated in water that exceeds the

seat base level, service is required before starting the engine. Your dealer can

provide this service. If it's impossible to bring the vehicle in before starting the

engine, perform the service outlined in the Spark Arrester section, and take the

vehicle in for service at the first opportunity.

Follow these procedures when operating through water:

1. Determine water depths and current before entering water.

2. Choose a crossing where both banks have gradual inclines.

3. Proceed slowly, avoiding rocks and obstacles.

4. Avoid operating through deep or fast-flowing water.

WARNING

The large tires on your vehicle may cause the vehicle to float in deep or fast-

flowing water, which could result in loss of control and lead to serious injury or

death. Never cross deep or fast-flowing water with your vehicle

5. After leaving water, always dry the brakes by applying light pressure to the
pedal repeatedly until braking action is normal.

NOTICE

After running your vehicle in water, it's critical that you perform the services

outlined in the Polaris Maintenance Schedule. Give special attention to engine

oil, transmission oil, front and rear gearcases (if equipped), and all grease

fittings.

DRIVING IN REVERSE

Follow these precautions when operating in reverse:

• Always check for obstacles or people behind the vehicle. Always inspect left

and right fields of vision before backing.

• Always avoid backing downhill.

• Back slowly.

• Apply the brakes lightly for stopping.

• Avoid turning at sharp angles.

• Never open the throttle suddenly.

75

OPERATION

DRIVING OVER OBSTACLES

Follow these precautions when operating over obstacles:

• Always check for obstacles before operating in a new area.

• Look ahead and learn to read the terrain. Be constantly alert for hazards such
as logs, rocks and low hanging branches.

• Travel slowly and use extra caution when operating on unfamiliar terrain. Not
all obstacles are immediately visible.

• Move the gear selector to Low Gear, if needed.

• Avoid operating over large obstacles such as large rocks and fallen trees. If
unavoidable, use extreme caution and operate slowly.

• Always have all passengers dismount and move away from the vehicle before
operating over an obstacle that could cause a rollover.

PARKING THE VEHICLE

To park the vehicle, do the following:

1. Apply the brakes. Stop the vehicle on a level surface.

2. When parking inside a garage or other structure, be sure that the structure is

well ventilated and that the vehicle is not close to any source of flame or
sparks, including any appliance with pilot lights.

3. Place the transmission in PARK.

4. Turn the engine off.

5. Engage the PARKING BRAKE (if equipped).

6. Slowly release the brake pedal and make sure the transmission is in PARK

before exiting the vehicle.

7. Remove the ignition switch key to prevent unauthorized use.

PARKING ON AN INCLINE

Avoid parking on an incline if possible. If it's unavoidable, follow these
precautions:

1. Apply the brakes.

2. Place the transmission in PARK.

3. Engage the PARKING BRAKE (if equipped).

4. Turn the engine off.

5. Slowly release the brake pedal and make sure the transmission is in PARK

before exiting the vehicle.

6. Block the rear wheels on the downhill side.

76

OPERATION

HAULING CARGO

WARNING

Hauling cargo improperly can alter vehicle handling and may cause loss of

control or brake instability, which can result in serious injury or death. Always

follow these precautions when hauling cargo:

Never exceed the maximum weight capacity of the vehicle. When determining

the weight you are adding to the vehicle, include the weight of the operator,

passengers, non-factory installed accessories, loads in the rack or box and the

load on the trailer tongue. The combined weight of these items must not

exceed the maximum weight capacity.

REDUCE SPEED AND ALLOW GREATER DISTANCES FOR BRAKING

WHEN HAULING CARGO.

Always load the cargo box with the load as far forward and as low as possible.

When operating over rough or hilly terrain, reduce speed and cargo to maintain

stable driving conditions.

Always operate the vehicle with extreme care when hauling or towing loads.

Slow down and drive in the lowest gear available. Always use LOW gear when

towing or hauling heavy loads.

SECURE ALL LOADS BEFORE OPERATING. Unsecured loads can create

unstable operating conditions, which could result in loss of control of the

vehicle.

OPERATE ONLY WITH STABLE AND SAFELY ARRANGED LOADS. When

handling off-centered loads that cannot be centered, securely fasten the load

and operate with extra caution. Always attach the tow load to the hitch point

designated for your vehicle.

HEAVY LOADS CAN CAUSE BRAKING AND CONTROL PROBLEMS. Use

extreme caution when applying brakes with a loaded vehicle. Avoid terrain or

situations that may require backing downhill.

USE EXTREME CAUTION when operating with loads that extend over the

rack sides. Stability and maneuverability may be adversely affected, causing a

rollover.

DO NOT TRAVEL FASTER THAN THE RECOMMENDED SPEEDS. Vehicle

should never exceed 16 km/h (10 MPH) while towing a load on a level grass

surface. Vehicle speed should never exceed 8 km/h (5 MPH) when towing

loads in rough terrain, while cornering, or while ascending or descending a hill.

77

OPERATION

LOAD CAPACITY

Your vehicle has been designed to carry or tow specific capacities. Always read
and understand the load distribution warnings listed on the warning labels. The
total load (operator, passengers, non-factory installed accessories, cargo and
weight on hitch) must not exceed the maximum weight capacity of the vehicle.
Never exceed the following capacities:

MAXIMUM

MODEL

CAPACITIES

(LEVEL GROUND)

CARGO BOX

RANGER 570 454 kg

(1000 lbs.)

RANGER CREW 570 547 kg

(1225 lbs)

WARNING

Driving with passengers in the cargo box can result in severe injury or death.

Never allow passengers to ride in the cargo box. Passengers must always ride

in the cab with seat belts fastened securely.

226 kg

(500 lbs.)

226 kg

(500 lbs.)

TOWING A RANGER

Towing this vehicle is not recommended. Always transport the vehicle on a
trailer or flatbed with all four wheels off the ground.

If towing a disabled vehicle is unavoidable, place the disabled vehicle’s
transmission in neutral. Tow the shortest distance possible. Do not operate
faster than 16 km/h (10 MPH).

TOWING LOADS

WARNING

Towing improperly can alter vehicle handling and may cause loss of control or

brake instability.

Always follow these precautions when towing:

1. Never load more than 68.1 kg (150 lbs.) tongue weight on the towing bracket.

2. Always shift to low gear for towing.

3. When towing a disabled RANGER vehicle, place the disabled vehicle’s
transmission in neutral. Do not operate the vehicle faster than 16 km/h (10
MPH) when towing.

78

OPERATION

4. Towing a trailer increases braking distance. Do not operate the vehicle faster
than 16 km/h (10 MPH) when towing. Towing a trailer increases braking
distance.

5. Do not tow more than the recommended weight for the vehicle. See the
towing capacity chart below and the specifications in the Specifications
chapter.

6. Attach a trailer to the trailer hitch bracket only. Do not attach a trailer to any
other location or you may lose control of the vehicle.

7. Never tow a trailer on a grade steeper than 15°.

8. Always be mindful of the trailer’s reaction to vehicle movements when driving
off-road.

MODEL

RANGER

570

TOTAL

TOWED

LOAD

WEIGHT

(LEVEL

GROUND)

680.4 kg

(1500 lbs.)

TOTAL

TOWED

LOAD

WEIGHT (15°

GRADE)

386 kg

(850 lbs.)

TOTAL

HITCH

VERTICAL

WEIGHT

68.1 kg

(150 lbs.)

MAXIMUM

TOWING

SPEED

16 km/h

(10 MPH)

BELT LIFE

To extend belt life, use low gear when hauling or towing heavy cargo. Using high
gear for heavy loads, hilly terrain or in wet, muddy conditions will increase the
chance of drive belt burning.

DUMPING THE CARGO BOX

To dump the cargo box, do the following:

1. Select a level site to dump the cargo box. Do not attempt to dump or unload
the vehicle while parked on an incline.

2. Apply the brakes. Place the transmission in PARK.

3. Engage the PARKING BRAKE (if equipped).

4. Ensure that the cargo is positioned evenly or toward the front of the cargo
box.

79

OPERATION

5. Release the tailgate by pulling up on the tailgate latch.

WARNING

If the weight distribution on the box is located toward the rear of the box when

the release lever is pulled forward, the box may dump unexpectedly and cause

serious injury to the operator or bystanders. Never operate the Release Lever

dump lever without ensuring that the load is positioned evenly or at the front of

the box.

6. Stand clear and pull up on the cargo box release lever
cargo box to dump the cargo.

. Lift the front of the

q

7. Lower the cargo box and push down securely to latch.

WARNING

Operating the vehicle while the cargo box is raised could result in severe injury.

The box could close unexpectedly and cause injury to the driver or passenger.

The rear tires could also catch the rear of a raised box, damaging the vehicle

and creating hazardous driving conditions. Never operate this vehicle with the

cargo box in the raised position.

80

OPERATION

ALL WHEEL DRIVE/REAR DIFFERENTIAL
SYSTEM

If your model is equipped with a lockable differential, you can choose to operate
with an open differential or a closed differential.

ENGAGING AWD

NOTICE

Switching to AWD while the rear wheels are spinning may cause severe drive

shaft and clutch damage. Always switch to AWD while the rear wheels have

traction or are at rest.

All-Wheel Drive (AWD)

q

Differential Lock (2WD)

w

Differential Unlock (TURF Mode)

e

Press the top of the driveline mode switch to engage All Wheel Drive (AWD).
The 4X4 indicator illuminates in the rider information center to indicate that the
vehicle is in AWD. When the AWD switch is on, the front gearcase will
automatically engage any time the rear wheels lose traction. When the rear
wheels regain traction, the front gearcase will automatically disengage. There is
no limit to the length of time the vehicle may remain in AWD. Initially, the
vehicle's electronic system will not enable the AWD until the engine RPM is
below 3100. Once enabled, the AWD remains enabled until the switch is turned
off. If the switch is turned off while the front gearcase is moving, it will not
disengage until the rear wheels regain traction.

Engage the AWD before getting into conditions where front wheel drive may be
needed. If the rear wheels are spinning, release the throttle before switching to
AWD.

81

OPERATION

DISENGAGING AWD

Move the driveline mode switch to the center or bottom position to disengage
AWD. If the switch is turned off while the front hubs are driving, they will not
release until the rear wheels regain traction.

In some situations, the front gearcase may remain locked after turning the AWD
switch off. If this occurs, you may notice increased steering effort and some
vehicle speed restriction. Perform the following procedure to unlock the front
gearcase.

To disengage AWD, do the following:

1. Stop the vehicle.

2. Operate in reverse for at least 3 m.

3. Stop completely.

4. Shift into low gear and drive forward.

5. If the front gearcase remains locked after following these instructions, see
your dealer or other qualified service person for service.

LOCKING THE DIFFERENTIAL

Move the switch to the center position to lock the differential and operate in two
wheel drive (2WD). Locking the differential in slippery or low traction conditions
helps improve traction. When the rear differential is locked, both rear wheels
rotate at the same speed.

UNLOCKING THE DIFFERENTIAL (TURF MODE)

When operating in TURF mode, the inside rear wheel will rotate independently
from the outside wheel during turns. Operate in TURF mode only as needed to
protect smooth, level surfaces from tire damage. DO NOT operate in TURF
mode when climbing or descending hills, when sidehilling, or when operating on
uneven, loose, or slippery terrain such as sand, gravel, ice, snow, obstacles, and
water crossings. Always operate in AWD on these types of terrain.

WARNING

Operating in TURF mode (if equipped) when on sloped, uneven, or loose

terrain could cause loss of control and result in serious injury or death. One

rear wheel may slip and lose traction or may lift up and grab when it touches

the ground again.

Press the bottom of the switch to unlock the differential and allow the rear drive
wheels to operate independently (1WD). When the rear differential is unlocked,
the rear wheels can rotate at different speeds. Unlock the differential to make
maneuvering easier and minimize damage to turf.

82

OPERATION

NOTICE

Damage to the differential can occur if it is engaged while the vehicle is

traveling at high speeds or while the rear wheels are spinning. Slow the vehicle

to nearly stopped before engaging the differential.

WARNING

Never operate in TURF mode (if equipped) while operating on a hill or other

irregular terrain. Always move the switch to AWD before ascending or

descending a hill.

83

84

WINCH GUIDE

WINCH GUIDE

WINCH SAFETY

These safety warnings and instructions apply if your vehicle came equipped with
a winch or if you choose to add an accessory winch to your vehicle.

WARNING

Improper winch use can result in SEVERE INJURY or DEATH. Always follow

all winch instructions and warnings in this manual.

Your winch may have a cable made of either wire rope or specially designed
synthetic rope. The term “winch cable” will be used for either unless noted
otherwise.

WINCH SAFETY PRECAUTIONS

1. Read all sections of this manual.

2. Never use alcohol or drugs before or while operating the winch.

3. Never allow children under 16 years of age to operate the winch.

4. Always wear eye protection and heavy gloves when operating the winch.

5. Always keep body, hair, clothing and jewelry clear of the winch cable, fairlead
and hook when operating winch.

6. Never attempt to “jerk” a load attached to the winch with a moving vehicle.
See the Shock Loading section on page 94.

7. Always keep the area around the vehicle, winch, winch cable, and load clear
of people (especially children) and distractions while operating the winch.

8. Always turn the vehicle ignition power OFF when it and the winch are not
being used.

9. Always be sure that at least five (5) full turns of winch cable are wrapped
around the winch drum at all times. The friction provided by this wrapped
cable allows the drum to pull on the winch cable and move the load.

10.Always apply your vehicle’s park brake and/or park mechanism to hold the
vehicle in place during winching. Use wheel chocks if needed.

11. Always align the vehicle and winch with the load directly in front of the
vehicle as much as possible. Avoid winching with the winch cable at an angle
to the winching vehicle’s centerline whenever possible.

85

WINCH GUIDE

12.If winching at an angle is unavoidable, follow these precautions:

a. Look at the winch drum occasionally. Never let the winch cable “stack” or

accumulate at one end of the winch drum. Too much winch cable at one
end of the winch drum can damage the winch and the winch cable.

b. If stacking occurs, stop winching. Follow step 15 of Winch Operation to

feed and rewind the cable evenly before continuing the winch operation.

13.Never winch up or down at sharp angles. This can destabilize the winching
vehicle and possibly cause it to move without warning.

14.Never attempt to winch loads that weigh more than the winch’s rated
capacity.

15.The winch motor may become hot during winch use. If you winch for more
than 45 seconds, or if the winch stalls during operation, stop winching and
permit the winch to cool down for 10 minutes before using it again.

16.Never touch, push, pull or straddle the winch cable while winching a load.

17.Never let the winch cable run through your hands, even if wearing heavy
gloves.

18.Never release the clutch on the winch when the winch cable is under load.

19.Never use the winch for lifting or transporting people.

20.Never use the winch to hoist or suspend a vertical load.

21.Always inspect your winch and winch cable before each use.

86

WINCH GUIDE

22.Never winch the hook fully into the winch. This can cause damage to winch
components.

23.Unplug the remote control from the vehicle when the winch is not in use to
prevent inadvertent activation and use by unauthorized persons.

24.Never grease or oil the winch cable. This will cause the winch cable to collect
debris that will shorten the life of the cable.

87

WINCH GUIDE

WINCH OPERATION

Read the Winch Safety Precautions in the preceding pages before using your
winch.

TIP

Consider practicing the operation and use of your winch before you actually

need to use it in the field.

WARNING

Improper winch use can result in SEVERE INJURY or DEATH. Always follow

all winch instructions and warnings in this manual.

Each winching situation is unique.

• Take your time to think through the winching you are about to do.

• Proceed slowly and deliberately.

• Never hurry or rush during winching.

• Always pay attention to your surroundings.

• You may need to change your winching strategy if it is not working.

• Always remember that your winch is very powerful.

• There are simply some situations that you and your winch will not be able to

deal with. Do not be afraid to ask others to help when this happens.

1. Always inspect the vehicle, winch, winch cable and winch controls for any
signs of damage or parts in need of repair or replacement before each use.

Pay particular attention to the first 3 ft (1 m) of winch cable if the winch is
being used (or has been used) for lifting an accessory plow assembly.

Promptly replace any worn or damaged cable.

2. Never operate a winch or a vehicle in need of repair or service.

3. Always apply your vehicle’s park brake and/ or park mechanism to hold the
vehicle in place during winching. Use wheel chocks if needed.

88

4. Always use the hook strap when handling the hook.

WINCH GUIDE

WARNING

Never put your fingers into the hook. This could lead to SEVERE INJURY.

• Attach the hook itself onto the load or use a tow strap or chain to secure
the load to the winch cable.

TIP

A “tow strap” is NOT intended to stretch. A “recovery strap” is designed to

stretch.

89

WINCH GUIDE

WARNING

Never use a recovery strap when winching due to the excessive energy that

can be released if the winch cable breaks. This can result in SEVERE INJURY

or DEATH. See the Shock Loading section on page 94.

• Never hook the winch cable back onto itself. This will damage the winch
cable and may result in winch cable failure.

WARNING

Replace the winch cable at the first sign of damage to prevent SEVERE

INJURY or DEATH in the event of failure. For your safety, always replace

POLARIS winch parts (including the cable) with genuine POLARIS

replacement parts available at your authorized POLARIS dealer, or other

qualified dealer.

• If possible, keep the winch cable aligned with the centerline of the
winching vehicle. This will help the spooling of the winch cable and reduce
the load on the fairlead.

• If freeing a stuck vehicle by attaching to a tree, use an item such as a tow
strap to avoid damaging the tree during winch operation. Sharp cables and
chains can damage and even kill trees. Please remember to Tread
Lightly® (treadlightly.org).

• Before operating the winch, be sure that the safety latch on the winch
cable hook is fully seated when the load is attached.

• Never operate your winch with a damaged hook or latch. Always replace
damaged parts before using the winch.

5. Never remove the hook strap from the hook.

6. Release the winch clutch and pull out the winch cable.

7. Pulling out as much cable as possible maximizes the winch’s pulling
capacity. Always be sure that at least five (5) full turns of winch cable are
wrapped around the winch drum at all times. The friction provided by this
wrapped cable allows the drum to pull on the winch cable and move the load.

90

WINCH GUIDE

8. Read and adhere to the following information for winch damping to ensure
safe winch use.

a. In order to absorb energy that could be released by a winch cable failure,

always place a “damper” on the winch cable. A damper can be heavy
jacket, tarp, or other soft, dense object. A damper can absorb much of the
energy released if a winch cable breaks when winching. Even a tree limb
can help as a damper if no other items are available to you.

b. Lay the damper on top of the mid-point of the winch cable length that is

spooled out.

c. On a long pull, it may be necessary to stop winching so that the damper

can be repositioned to the new mid-point of the winch cable. Always
release the tension on the winch cable before repositioning the damper.

d. Avoid being directly in line with the winch cable whenever possible. Also,

never permit others to stand near or in line with the winch cable during
winch operation.

9. Never hook the winch cable back onto itself. This will damage the winch
cable and may result in winch cable failure.

10.Never use straps, chains or other rigging items that are damaged or worn.

11. The ONLY time a winch-equipped vehicle should be moving when using the
winch is when that vehicle itself is stuck. The winch equipped vehicle should
NEVER be in motion to “shock” load the winch cable in an attempt to move a
second stuck vehicle. See the Shock Loading section on page 94. For your
safety, always follow these guidelines when winching a vehicle free:

a. Release the winch clutch and spool out the necessary length of winch

cable.

b. Align the winch cable as close as possible to the winching vehicle’s

centerline.

c. Attach the winch cable hook to the anchor point or the stuck vehicle’s

frame following instructions in this manual.

d. Re-engage the clutch on the winch.

e. Slowly winch in the slack in the winch cable.

f. Select the proper vehicle gear to propel the stuck vehicle in the direction

of winching.

g. Shift to the lowest gear available on the stuck vehicle.

h. Slowly and carefully apply vehicle throttle and winch together to free the

vehicle.

i. Stop winching as soon as the stuck vehicle is able to propel itself without

the help of the winch.

91

WINCH GUIDE

j. Detach the winch cable hook.

k. Rewind the winch cable evenly back onto the winch drum following the

instructions in this manual.

12.Never attempt to winch another stuck vehicle by attaching the winch cable to
a suspension component, brush guard, bumper or cargo rack. Vehicle
damage may result. Instead, attach the winch to a strong portion of the
vehicle frame or hitch.

13.Extensive winching will run down the battery on the winching vehicle. Let the
winching vehicle’s engine run while operating the winch to prevent the
battery from running low if winching for long periods.

14.The winch motor may become hot during winch use. If you winch for more
than 45 seconds, or if the winch stalls during operation, stop winching and
permit the winch to cool down for 10 minutes before using it again.

15.After winching is complete, especially if winching at an angle, it may be
necessary to re-distribute the winch cable across the winch drum. You will
need an assistant to perform this task.

a. Release the clutch on the winch.

b. Feed out the winch cable that is unevenly bunched up in one area.

c. Re-engage the winch clutch.

d. Have an assistant pull the winch cable tightly with about 100 lb (45 kg) of

tension using the hook strap.

e. Slowly winch the cable in while your assistant moves the end of the winch

cable back and forth horizontally to evenly distribute the winch cable on
the drum.

f. Doing this reduces the chances of the winch cable “wedging” itself

between lower layers of winch cable.

92

WINCH GUIDE

WINCH CABLE CARE

WARNING

Use of worn or damaged cable could lead to sudden failure and SEVERE

INJURY.

For your safety, always replace POLARIS winch parts (including the cable) with
genuine POLARIS replacement parts available at your authorized POLARIS
dealer, or other qualified person.

1. Always inspect your winch before each use. Inspect for worn or loose parts
including mounting hardware. Never use the winch if any part needs repair or
replacement.

2. Always inspect your winch cable before each use. Inspect for worn or kinked
winch cable.

A kinked winch cable made of wire rope
is shown at right. Even after being
“straightened out,” this cable has
already been permanently and severely
damaged. Promptly discontinue use of
a winch cable in this condition.

A kinked winch cable made of wire rope
that has been “straightened out” is
shown at right. Even though it may look
usable, the cable has been permanently
and severely damaged. It can no longer
transmit the load that it could prior to
kinking. Promptly discontinue use of a
winch cable in this condition.

A winch cable made of synthetic rope
should be inspected for signs of fraying.
Replace the cable if fraying is observed
(shown below). Promptly discontinue
use of a winch cable in this condition.
Also replace the winch cable if there are
fused or melted fibers. Such an area of
the synthetic rope will be stiff and
appear smooth or glazed. Promptly
discontinue use of a winch cable in this
condition.

93

WINCH GUIDE

SHOCK LOADING

WARNING

Your winch cable is very strong but it is NOT designed for dynamic, or “shock”

loading. Shock loading may tension a winch cable beyond its strength and

cause the cable to break. The end of a broken winch cable under such high

loading can cause SEVERE INJURY or DEATH to you and other bystanders.

Winch cables are designed to NOT absorb energy. This is true of both wire-rope
and synthetic-rope winch cables.

1. Never attempt to “jerk” a load with the winch. For example, never take up
slack in the winch cable by moving the winching vehicle in an attempt to
move an object. This is a dangerous practice. It generates high winch cable
loads that may exceed the strength of the cable. Even a slowly moving
vehicle can create large shock loads in a winch cable.

WARNING

SEVERE INJURY or DEATH can result from a broken winch cable.

2. Never quickly turn the winch ON and OFF repeatedly (“jogging”). This puts
extra load on the winch, winch cable, and generates excessive heat from the
motor. This is a form of shock loading.

3. Never tow a vehicle or other object with your winch. Towing an object with a
winch produces shock loading of the cable even when towing at slow
speeds. Towing from a winch also positions the towing force high on the
vehicle. This can cause instability of the vehicle and possibly lead to an
accident.

4. Never use recovery straps with your winch. Recovery straps are designed to
stretch and can store energy. This stored energy in the recovery strap is
released if a winch cable fails making the event even more hazardous.
Similarly, never use elastic “bungie” cords for winching.

5. Never use the winch to tie down a vehicle to a trailer or other transportation
vehicle. This type of use also causes shock loading that can cause damage
to the winch, winch cable, or vehicles used.

Your winch cable is designed and tested to withstand the loads produced
by the winch motor when operated from a stationary vehicle. Always
remember that the winch and winch cable are NOT designed for shock
loading.

94

WINCH GUIDE

WINCH MAINTENANCE AND SERVICE SAFETY

WARNING

Improper or lack of winch maintenance and service could lead to SEVERE

INJURY or DEATH. Always follow all winch instructions and warnings in this

manual.

1. Always inspect your winch before each use. Inspect for worn or kinked winch
cable. Also inspect for worn or loose parts including mounting hardware.

2. Permit your winch motor to cool down prior to servicing your winch.

3. Never work on your winch without first disconnecting the battery connections
to prevent accidental activation of the winch.

4. For your safety, always replace POLARIS winch parts (including the cable)
with genuine POLARIS replacement parts available at your authorized
POLARIS dealer, or other qualified person.

5. Some winch models use wire rope as the winch cable. Other winches use a
specially designed synthetic rope as the winch cable.

6. Never replace a synthetic-rope winch cable with a consumer-grade polymer
rope such as can be purchased in a hardware store. Although they may look
similar, they are NOT alike. A polymer rope not designed for winch use will
stretch and store excessive energy when winching.

WARNING

Failure of a stretched rope under winching conditions will release all of the

stored energy. This will increase the chances of SEVERE INJURY or DEATH.

95

96

EMISSION CONTROL SYSTEMS

EMISSION CONTROL SYSTEMS

NOISE EMISSION CONTROL SYSTEM

Do not modify the engine, intake or exhaust components, as doing so may affect
compliance with governmental noise level requirements.

SPARK ARRESTER

Your POLARIS vehicle has a spark arrester that was designed for on-road and
off-road operation. It is required that this spark arrester remain installed and
functional when the vehicle is operated.

EXHAUST EMISSION CONTROL SYSTEM

Exhaust emissions are controlled by engine design. An electronic fuel injection
(EFI) system controls fuel delivery. The engine and EFI components are set at
the factory for optimal performance and are not adjustable.

The emissions label is located on the inside of the lower left frame tube (below
driver’s foot area).

ELECTROMAGNETIC INTERFERENCE

This vehicle complies with the EMC requirements of UN ECE Regulation 10.

Non-ionizing Radiation: This vehicle emits some electromagnetic energy.
People with active or non-active implantable medical devices (such as heart
monitoring or controlling devices) should review the limitations of their device
and the applicable electromagnetic standards and directives that apply to this
vehicle.
