Point Source CO-8WS-XSE-BE Product Guide
RETAIL • MARCH 2016 • NEW ITEMS
SERIES8
Award-winning headset,
earworn and lavalier mics
NEW!
EMBRACE™
Build custom-fit actor
microphones in seconds
CM-i3
World’s first modular
in-ear comms headset
INTRODUCTION TO POINT SOURCE AUDIO
About Us...
Point Source Audio is a solution based design,
engineering, and manufacturing company in the audio industry.
With over 60 years of combined professional audio industry
experience, the PSA product designers approach every product
detail with a depth of understanding that results in ease,
convenience, and efficiency in design. Since 2002 Point Source
Audio has developed, engineered and manufactured transducer
products for companies under a variety of brands. While
continuing to do this we are also focused on developing products
under the Point Source Audio brand affording our customers a
streamlined path for purchasing high value products.
We sell our products exclusively through a network of high
caliber resellers, contractors and distributors throughout the
world. It is our goal to provide performance based products at
great prices with the very best customer service and support.
Customers are increasingly choosing Point Source Audio
for its product innovation, performance, and committed
customer support. Here is just a short list of them:
San Francisco Opera Berklee College of Music
New York Philharmonic SUNY Oswego
Belgian Movie Awards Southeast Missouri State
Naonal Theatere in Oslo Interlochen Center for the Arts
Shiki Theater Company, Tokyo Princeton University
Universal Studios "Harry Poer
Show" Orlando
University of Alabama School
of Theatre & Dance
Théâtre du Châtelet, Paris Philadelphia POPS
Chicago Shakespeare Theater Utah Shakespeare Fesval
City of Albuquerque Performing
Arts Center
David Saxe Producons,
Planet Hollywood, Las Vegas
University of Arizona School of
Theater Arts
Long Beach Center for the
Performing Arts
s a l e s @ p o i n t - s o u r c e a u d i o . c o m 2
© 2 0 1 6 Point S ource Audi o
CONTENTS
NEW! EMBRACE Actor Microphones
4
SERIES8 Performance Microphones
6
CO-5/6 Speech Microphones
8
10
11
12
13
14
CO-3 Basic Voice Microphones
Microphone Comparison Chart
NEW! Slider Microphone Clips
Microphone Accessories
CM-i3 Intercom Headset
EMBRACE
Microphones
Page 4
s a l e s @ p o i n t - s o u r c e a u d i o . c o m 3
© 2 0 1 6 Point S ource Audi o
EO-8 OMNIDIRECTIONAL
Patent-pending
EMBRACE Fitted Microphone
ITEM: EO-8WL-XXX-XX
DESCR I P TION
EMBRACE Microphones are custom-fit ear mounted microphone solutions for theatre, television
and other applications where the microphone must be completely camouflaged yet still maintain
consistent placement from the mouth even with head movement. EMBRACE lets you bend, shape
and trim for a precise custom-fitted microphone in seconds—without all the time, hassle, and
expense of outdated ear rigs. EMBRACE Microphones come complete with our acclaimed
SERIES8 lavalier microphone, a color matched left and right Earmount, and a assortment of cable
clips. For extreme camouflaging, the EMBRACE Earmounts also accept theatrical color
markers of almost any color.
148dB max SPL Water, Sweat, Makeup Proof Interchangeable X-Connector
-XXX C O NNEC T O R OP T I O NS
-XAK AKG, Audix -XLEw Lectrosonics-waterproof -XSH Shure, Line 6
-XAT Audio-Technica -XMP MiPro -XSK Sennheiser SK, Zaxcom
-XBY Beyerdynamic -XSD Sony DWT-B01 -XTX Telex
-XLE Lectrosonics -XSE Sennheiser
-XX C O L OR O P T IONS
Bendable and trimmable
mounts for a custom-fit
EMBRACE Earmounts (L/R)
ITEM: EMB-6 / 12 / 24
-BE Beige
-BR Brown
-BL Black
MICRO P H ONE S P ECIFI C ATIO N S
Element: Back Electret Condenser
Pattern: Omnidirectional
Frequency: 20Hz ~ 20kHz
Sensitivity: -43dB 1V/Pa (Nominal Sensitivity ± 3dB at 1kHz)
Maximum SPL: 148dB SPL
Output Impedance: 1400Ω ± 30% (at 1kHz)
Operating Voltage: 1 ~ 10 V
Cable Length: 4ft. 077in. + connector
Net Weight: 0.6 oz
Colors: Beige, Brown, or Black
Connector Types: TA3F, TA4F, TA5F, lockable 3.5mm, Hirose, Lemo-style
Ear Placement: Left and Right Earmounts with finishing caps included
Included Accessories: 2 Earmounts, windscreen, cable clip, 2 slider clips, storage box
s a l e s @ p o i n t - s o u r c e a u d i o . c o m 5
© 2 0 1 6 Point S ource Audi o
SERIES8 PERFORMANCE VOCALS
DESCR I P TION
The SERIES8 cardioid collection is offered in 3 popular styles: headset, earworn, and lavalier. The
cardioid pick up pattern is ideal in applications when there is more than one mic being used, in
live performances, and in some recording situations. A unique benefit of the SERIES8 cardioid
headset and earworn microphones is that the capsule is especially miniaturized and there is no
need to force the mic directly in front of the mouth as with other cardioid microphones. The boom
of the microphone can sit comfortably at the corner of the mouth so an unobtrusive appearance is
easily achieved. Both the headset and earworn mics feature a boom bendable beyond 360°. Each
microphone includes one Interchangeable X-Connector for termination to your wireless system.
Boom Bends 360˚ 135dB max SPL Interchangeable X-Connector
CR-8 CARDIOID
CR-8D Headset
ITEM: CR-8D-XXX-XX
CR-8S Earworn
ITEM: CR-8S-XXX-XX
CR-8L Lavalier
ITEM: CR-8L-XXX-XX
-XXX C O NNEC T O R OP T I O NS
-XAK AKG, Audix -XLEw Lectrosonics-waterproof -XSH Shure, Line 6
-XAT Audio-Technica -XMP MiPro -XSK Sennheiser SK, Zaxcom
-XBY Beyerdynamic -XSD Sony DWT-B01 -XTX Telex
-XLE Lectrosonics -XSE Sennheiser
-XX C O L OR O P T IONS
-WH White (lav)
-BE Beige
-BR Brown
-BL Black
SPECI F I CATI O N S
Element: Back Electret Condenser
Pattern: Unidirectional, Cardioid
Frequency: 160Hz ~ 14kHz
Sensitivity: -50dB 1V/Pa (Nominal Sensitivity ± 3dB at 1kHz)
Maximum SPL: 135dB SPL
Output Impedance: 5000 Ω ± 30% (at 1kHz)
Operating Voltage: 1 ~ 10 V
Cable Length: 4ft .077in. + connector
Net Weight: 0.6 oz
Colors: White, Beige, Brown, or Black
Connector Types: TA3F, TA4F, TA5F, Lockable 3.5mm, Hirose, Lemo-style
Boom Flexibility: Bendable to 360°
Ear Placement: Left/Right
Included Accessories: Windscreen, cable clip, storage box
s a l e s @ p o i n t - s o u r c e a u d i o . c o m 6
© 2 0 1 6 Point S ource Audi o
