Contents |
|
|
Contents.................................................................................................................................. |
1 |
|
General notices for use ......................................................................................................... |
2 |
|
Disclaimer ............................................................................................................................... |
2 |
|
Box Contents .......................................................................................................................... |
2 |
|
1.0 Product basics.................................................................................................................. |
3 |
|
1.1 |
Buttons and connections ................................................................................................ |
3 |
1.2 |
Start up and shut down................................................................................................... |
3 |
2.0 Introduction to Google Android 4.0................................................................................ |
4 |
|
2.1 |
The Desktop ................................................................................................................... |
4 |
2.2 |
The App drawer – right top corner .................................................................................. |
5 |
2.3 |
Google Search / Voice search – left top corner .............................................................. |
5 |
2.4 |
Navigation icons – bottom left of the screen................................................................... |
6 |
2.5 |
Status information area – right bottom of the screen...................................................... |
6 |
3.0 General operation............................................................................................................. |
7 |
|
3.1 |
Battery status / Charging your tablet .............................................................................. |
7 |
3.2 |
Installing Apps ................................................................................................................ |
7 |
3.3 |
Administer / remove apps ............................................................................................... |
7 |
3.4 |
Add an account............................................................................................................... |
8 |
4.0 Basic setup ....................................................................................................................... |
9 |
|
4.1 |
Changing operating language......................................................................................... |
9 |
4.2 |
WiFi settings ................................................................................................................... |
9 |
4.3 |
Connecting the tablet to your PC.................................................................................. |
10 |
5.0 Frequently Asked Questions......................................................................................... |
11 |
|
English |
Point of View PlayTab pro - Android 4.0 Tablet PC |
General notices for use
This product is a highly advanced electronics device, disassembly, customization or repairs without the appropriate knowledge and pre-cautions can lead to dangerous situations with chance on damaging the product and serious injuries.
Avoid use in extreme conditions such as high and low temperatures, high humidity or moist environments and around magnetic fields. Also avoid long-time exposure to sunlight.
Only use by the manufacturer permitted accessories to avoid damages to the product with possibly warranty loss.
Please follow the relevant local environmental regulations to deal with obsolete machines and accessories.
Use a protective folder to avoid extreme physical shocks to the device (i.e. of dropping).
Disclaimer
The screenshots are for Android reference only. They may be made on a device with a different resolution or hardware configuration than yours and therefore can be slightly different that the final product.
The manufacturer takes no responsibility for loss of information or data caused by hardware or software failure. The user is responsible for performing timely backups of important data.
All information and images used in this user manual are provided ‘as is’ and are subject to change without notice.
The manufacturer accepts no liability for the information offered in this document.
Box Contents
Android Tablet PC
Device charger (DC / 5V – 2A)
Instruction manual
USB Cable
Headphone (optional)
MicroSD Card (optional)
2
Point of View PlayTab Pro - Android 4.0 Tablet PC |
English |
1.0Product basics
1.1Buttons and connections
1 |
2 |
3 |
4 |
5 |
6 |
|
|
|
|
|
|
7 |
8 |
9 |
10 |
11 |
12 |
|
|
|
|
|
|
|
|
|
|
1 |
Webcam |
|
|
|
|
2 |
Microphone |
3 |
Reset |
|
|
|
|
4 |
Power |
5 |
Menu button |
|
|
|
6 |
Back button |
|
7 |
USB 2.0 Host |
|
|
|
8 |
Mini USB |
|
9 |
Power jack |
|
|
|
|
10 |
Headphone |
11 |
Mini HDMI |
|
|
|
|
12 |
Micro SD card reader |
1.2 Start up and shut down
To start your device, press and hold the ‘Power button’ until the screen lights up.
To shut down your device, press and hold the ‘Power button’ until the following dialog popup appears.
3
English |
Point of View PlayTab pro - Android 4.0 Tablet PC |
2.0 Introduction to Google Android 4.0
2.1 The Desktop
The main area of interest will be the desktop itself. Here you will place shortcuts to Apps or widgets – a visual application that can display real-time information. There may be some preinstalled icons and widgets on your tablet.
To change the desktop background image of your tablet return to your desktop by pressing the ‘HOME’
icon. Press and hold an open space on the desktop (don’t press an icon) - until a popup appears named ‘Select wallpaper from’. In the list may appear multiple options to select an image or animated image of choice. The option ‘Live Wallpapers’ will show the pre-installed animated desktop images. Other options such as a ‘Super-HD Player’, ‘Gallery’ or ‘Wallpapers’ allow you to select (widescreen) photos, downloaded images or other images; depending on the features of that specific application.
To place a widget or app shortcut on the desktop, touch and hold the icon until the App drawer fades and the desktop appears. Move your finger to the location where you want to place the icon and release your touch to place the icon.
To move or delete icons and widgets from your desktop, touch and hold the icon until a grid appears. Move the icon to the new location or drag it to the ‘Remove’ bar on the top of the screen to remove it. Releasing the touch screen will confirm your action.
4
