User Manual
Table of Contents
SAFETY PRECAUTIONS ...................................................6
Storage, Carriage and Usage Conditions 6
Maintenance 7
RF Safety 9
Utilization 9
APPEARANCE ...................................................................11
TECHNICAL SPECIFICATIONS .....................................12
GETTING STARTED ........................................................13
Charging Battery 13
Power Management 14
Loading Files 15
Navigation 16
Working with On-Screen Keyboard 17
Connecting to Internet 19
Installing additional dictionaries 22
MAIN MENU ......................................................................23
Recent Events 25
Library 25
Notes 28
Applications 29
Calculator 29
Calendar & Clock 29
Chess 30
Dictionary 30
Klondike 31
Photo 31
Snake 31
Sudoku 31
News 32
Browser 33
Book Store 34
PocketBook Sync 35
Status Bar 37
READING BOOKS ............................................................38
Turning Pages 39
Following References 39
Changing Font Size 39
Reading Menu 40
Contents 40
Go to Page 41
Search 43
Bookmarks 43
Settings 43
Mode 44
Dictionary 45
Rotate 46
Making Notes 46
Closing a Book 47
SETTINGS..........................................................................48
Personalize 48
Network 49
Date/Time 50
Languages 51
Accounts and Synchronization 51
Advanced Settings 53
Saving Battery 57
Device Info 58
FIRMWARE UPDATE .......................................................59
TROUBLESHOOTING .....................................................62
CUSTOMER SUPPORT....................................................64
COMPLIANCE WITH INTERNATIONAL
STANDARTS ......................................................................65
Safety Precautions
Before start working with the Device, please, read this section
carefully. Following these instructions will help you ensure your
safety and extend service life of the Device.
Storage, Carriage and Usage Conditions
Device operating temperature range is 0°C to 40°C, so don’t ex-
pose the Device to excessively high or low temperatures. Never
leave cables near heat sources. Heated cables or their insulation
may become deformed or damaged, which could lead to fire or
electric shock.
Try to avoid next impacts:
• direct sunlight
• direct flame or smoke (cigarette, lighter, open fire etc.)
• exposure to liquids or damp (do not use the Device in the
rain, in the street at higher humidity, near bodies of water etc.)
• penetration of liquids or moisture
Safety Precautions 7
• exposure to strong electromagnetic fields, electrostatic
charges and artificial sources of UV electromagnetic radiation
• excessive mechanical pressure on the screen, connectors
and keys of the Device.
Do not leave the Device for a long time in poorly ventilated envi-
ronment, e.g. in a car or in closed tight boxes/packaging.
Neither drop nor try to bend the Device. Protect the screen from
objects that may scratch or damage it. To ensure adequate protec-
tion of the screen, we recommend storing the Device in a protec-
tive and/or hard cover.
Keep away from children.
Maintenance
Do not disassemble or modify the book reader.
Do not use the Device with a damaged battery or charger (broken
case, poor contact, broken feed cable). If the battery is damaged
Safety Precautions 8
(cracked case, leakage of electrolyte, off-shape etc.) it should be
replaced by the authorized personnel. Usage of home-made or
modified batteries may cause an explosion and/or damage the
Device.
Do not use organic or inorganic solvents (e.g. benzoyl etc.) to clean
the screen/case. Use a soft cloth to remove dust from the Device’s
surface. Apply a few drops of distilled water to remove dirt.
Up to five faulty pixels are acceptable in the screen and do not
constitute a warrantable defect of the screen.
By the end of product guarantee term, please contact the near-
est authorized service facility for examination on the subject of
security is maintained.
For detailed information about service centres in your region
please visit the official website of PocketBook International: http://
www.pocketbook-int.com.
Safety Precautions 9
RF Safety
The Device receives and transmits radio frequencies and may in-
terfere with radio communications and other electronic equip-
ment. If you use personal medical Devices (e.g. a pacemaker or
hearing aid) please contact your doctor or the manufacturer to
learn whether or not such medical devices are protected against
external RF signals.
Do not use wireless communication in places where it is prohib-
ited, e.g. onboard a plane and in hospitals — this may affect air-
borne avionics or medical equipment.
Utilization
Incorrect disposal of this Device may have adverse
impacts on the environment and public health. To
prevent such consequences follow the device-specific
disposal requirements. Recycling of these materials helps preserve
natural resources. For more information regarding recycling issues
please contact local municipal authorities, your domestic waste
Safety Precautions 10
collection service, store where you purchased the Device, or the
authorized service centre.
Disposal of electric and electronic components (the Directive is ap-
plicable to the EU and other European countries where separate
waste disposal systems exist). In other countries dispose batteries
accordingly to local laws.
Do not destroy the battery by burning it to avoid the danger of
explosion!
Appearance
1. Backward – in reading
mode turns page backward; in navi-
gation mode – goes to the previous
menu or page of the list
2. Left
3. Down
4. Up
5. Ok — short press opens
an element (e.g. book or menu
item), continuous one – opens item’s
context menu (if available)
6. Right
7. Forward – turns page
forward
8. Micro-USB port – for con-
necting to computer or charger
9. On/Off (power) button – continuous pressing turns the Device
on/off, short one – locks keyboard.
NOTE You can congure key mapping to your own in Settings > Personalize > Key map-
ping. Navigation and page turning buttons mapping depends on screen orientation.
Technical Specications
Display
5” E Ink® 800×600,
200 dpi, B&W
CPU 1000 MHz
RAM 256MB
Storage 4 GB *
Operating system Linux®
Communications
Micro-USB
Wi-Fi (802.11 b/g/n)
Battery Li-Polymer, 3.7 V, 1000 mAh **
PDF, EPUB (including DRM-protected);
Book formats
TXT, FB2, FB2.zip, RTF, HTML, HTM, CHM,
DJVU, DOC, DOCX, TCR, PRC, TCR, MOBI,
ACSM
Image formats JPEG, BMP, PNG, TIFF
Dimensions 100.02×142.33×7.2 mm
Weight 131 g
* The actual available internal storage size may vary depending on the software
conguration of your device.
** Battery life and values mentioned above might vary depending on usage mode,
connectivity and settings.
Getting Started
In this chapter you will learn how to prepare the Device to
work and about its main control features.
CHARGING BATTERY
To extend battery lifetime, it is recommended to charge
the Device for the rst time from 8 to 12 hours in the off
state. You can charge the battery from PC using USB-cable
or from the power line using a charger (optional).
To charge the battery for the rst time, do the following:
• Connect the Device to a computer or charger with
USB-cable. Indicator will start glowing as soon, as the
charging starts
• When the battery is fully charged, indicator turns
off. Now you can disconnect the Device and turn it on for
the rst use.
Getting Started 14
If the Device is on when you connect the cable to PC, a dialogue window asking to select action – PC link or Charge
– will appear. Charging will start if corresponding mode is
selected only.
POWER MANAGEMENT
To turn on the Device, press and hold On/Off button for
a few seconds until startup logo will appear. When the
Device is ready to operate, an image will be changed to
Main menu or last opened book, depending on settings
(Settings > Personalize > At startup open).
To turn off the Device, press On/Off button continuously
until the Device goes off. If you will press power button
shortly, the keypad of the Device will be locked and the
lock sign will appear in a centre of the screen. To unlock
the keypad, press On/Off button again.
Getting Started 15
In addition, you can set automatic key lock or power off: go
to Settings > Advanced Settings > System > Lock device after
or Settings > Saving Power > Power off after respectively, and
set the idle time before locking keyboard or power off.
LOADING FILES
Connect the Device to the PC using micro-USB cable.
NOTE The Device should be kept on while transferring les.
You will be prompted to select USB mode: PC Link or
Charge either. Select PC Link. Operating system of com-
puter will detect Device’s storage as removable disk. Now
you can copy les to the Device using Explorer or other
le manager.
ATTENTION After copying les safely remove the Device before
disconnect the cable!
Getting Started 16
NAVIGATION
Use navigation buttons Up, Down, Left, Right to select required item (e.g. book or menu item).
ATTENTION! If you change screen orientation, navigation and
page turning keys mapping will be also changed accordingly to
the side you’ve changed orientation to.
Press OK button shortly to open selected item. Continuous OK press opens context menu of item, folder or application (if available). If a menu item contains several level,
you can go over them by Left/Right buttons.
Page turning buttons Backward/Forward are used to turn
list pages. Continuous Backward/Forward keys press turns
10 pages at once in lists and books. Short and continuous
Backward button press returns to the previous menu (or
Getting Started 17
list’s page), closes an application, a context menu and the
Library (If you are on the rst page).
Also you can congure key mapping to your own in Set-
tings > Key mapping section.
WORKING WITH ON-SCREEN KEYBOARD
The on-screen keyboard appears when it is necessary to
enter some text info, for example, Wi-Fi password, search
query or web-address.
To navigate through the keyboard use the navigation
keys and OK button. To speed up keyboard operations all
symbols are divided into 5 zones. The rst navigation key
press transfers cursor to the middle of the selected zone,
and then you can select the required symbol in this zone.
OK button press types selected symbol.
Getting Started 18
1 2 3
1. Change text case
2. Erase last entered symbol
3. Change input language. To add the language (up
to 3 layouts) to the onscreen keyboard layout go to Set-
tings > Languages > Keyboard Layouts.
Getting Started 19
CONNECTING TO INTERNET
The Device can be connected to the Internet using Wi-
Fi networks. If you open an application, which requires
Internet access (e.g. Browser, PocketNews), the Device
displays a list of available Wi-Fi connections. If the
network you select is protected, you will be suggested to
enter network key using the on-screen keyboard.
You can pre-congure a connection and set an automatic
connection. To proceed, follow these steps:
1. Go to Settings > Network > Network Access
2. Select On for the Network access checkbox and then
further settings appear: Automatic connection, Connection
to a hidden network, and a list of available Wi-Fi networks.
NOTE If there are no available networks or the signal strength is
week, Available networks aren’t displayed and instead replaced by
Scanning — searching for available networks
Getting Started 20
3. To set up connection with a hidden network, open
Connection to a hidden network and enter its SSID from
the on-screen keyboard in the Network name (SSID) eld.
4. Select the security type in the corresponding list:
• None – for an open network
• Simple (WEP) – after you select this option, you
will need to specify WEP Authentication type – Open
System or Shared Key. The Device cannot recognize
the type of authentication automatically
• WPA/WPA2 Enterprise – you will need to specify
username, password and domain (if necessary)
• WPA/WPA2 PSK – you will need to enter a
network key (up to 64 symbols)
5. Open Advanced settings. Select the idle time
before disconnection in the corresponding section
6. If it is needed to congure network settings
manually, go to Advanced settings, and change IP address
conguration:
Getting Started 21
• DHCP — get IP address automatically (if DHCP
server is congured)
• Manual (for skilled users) — enter networks
parameters manually from the on-screen keyboard
7. If the network you need to connect to has a
proxy server, you can specify its parameters in the Proxy
conguration section
8. To check network conguration and connect
to network, return to the Connection to hidden network
section and press Connect.
NOTE Wi-Fi connection can be used for connecting to an Inter-
net network. Transferring data via Wi-Fi connection is unavailable.
The Device can be connected to a Wi-Fi access point with MAC
address ltration applied.
Getting Started 22
INSTALLING ADDITIONAL DICTIONARIES
You can install additional dictionaries (you can purchase
dictionaries in Book Store (http://www.bookland.com).
1. Copy le with .pbi extension to the Device inter-
nal memory
2. Disconnect the Device from PC
3. Loaded le will appear in Last Events
4. Press OK on the copied extension le and it will
be launched as an application.
5. Conrm proposed installation.
Main Menu
IN THIS CHAPTER...
You will learn about basic elements of user interface of
the Device. After turning on the Device Main menu will be
displayed on the screen (if Settings > Personalize > Open
at startup corresponding option was set). To return to the
Main menu from any application, press key Backward.
Main menu consists of Recent Events section and applica-
tion panel.
Main Menu 24
Main Menu
Last opened
Last
downloaded
Application
panel
Last Events — list of last opened and down-
loaded books
Main Menu 25
RECENT EVENTS
This section displays last actions on the Device, namely
last opened and recently loaded books.
After you press OK on recently opened book title, it will be
opened on a page you’ve nished reading before.
After pressing OK on a message about recently added
books, Library will be opened displaying added books.
Books will be grouped by creation date.
LIBRARY
Library is e-books le manager. To open a book, press
OK on its title. Library menu allows to lter, group, sort,
change appearance of the section and perform search.
Context menu, evoked by continuous pressing OK on the
book title, allows performing the following operations:
Main Menu 26
Open (if item can be opened with alternative reader pro-
gram – Open with…)
File – le operations:
• Rename
• Move to folder
• Delete
Add to/Remove from Favorites
Mark as read/unread
Information – brief information about book/folder.
Filter:
• All Books – all books are displayed
Main Menu 27
• Now reading – books were opened and read more
than one page
• Favourites.
Group by – depending on selected grouping next param-
eters are displayed as folders’ titles:
• Folder – real folder name
• Author – an alphabet is added at the top of the screen
• Series
• Genre
• Format
• Date Added.
Sort – performed by following parameters:
• File names
• Book titles
• Last opened
• Creation date
• Series
• Author.
View – the list of books has two viewing modes:
Main Menu 28
• Simple – in this mode next information is dis-
played: folder or le format icon; book title and author
name (if known); read percentage.
• Detailed – in this mode there are displayed also
book thubnails, information about format and le size
and status icons: — Read, — Favorite.
Search – allows quick books search by following criteria:
• By an author or a name;
• All books of the author;
• All books of the series.
Exit – to leave a library.
NOTES
In this section you can view notes made during reading.
After selecting a book, where you made a note, the book
contents with all the notes will be displayed. Select a
note, and a reader will open a book at the place the note
was made.
Main Menu 29
Notes are saved in \system\cong\Active Contents\ folder
of the Device’s internal storage.
APPLICATIONS
This section contains games and additional software.
Press Backward key to exit an application.
Calculator
Engineering calculator supports a wide range of mathematical operations, such as different numeric systems,
trigonometric, logarithm, power and logical operations.
Calendar & Clock
Opens current month calendar and clock. Navigation /
allows turning over a calendar. The button returns you
to the current month. Read about date and time setting in
Date/Time manual’s chapter.
Main Menu 30
Chess
You can play versus your friend or the Device. If you are
playing against the Device, you can select 10 difculty
levels. Use the navigation keys to move cursor over the
gaming board and OK to pick and put a piece.
Dictionary
After your start this application, the on-screen keyboard
will appear. Type the word you’d like to nd, and application will nd its entry in the dictionary. To change diction-
aries, press Forward button (press Forward button twice, if
the on-screen keyboard is displayed), select the dictionary
you need from the list and press OK.
After you close the on-screen keyboard (by pressing its
keys OK or Cancel), you will be able to view dictionary
page-by-page. To turn pages, use Left/Right keys. To bring
up the on-screen keyboard again, press OK. To exit dictionary, press Backward button.
Main Menu 31
Klondike
Classic solitaire.
This section opens Library in the mode of photo viewing
(all photos must be downloaded to the Photo folder). You
can look through images in JPG, BMP, PNG and TIFF formats.
Snake
The game. Use navigation keys to move the snake and col-
lect bugs. Beware of the walls and other snake!
Sudoku Popular Japanese puzzle. After pressing OK on an empty
eld, selection window will appear. You can select a digit
you think should stand in the cell or set labels – digits,
you suggest may stand in the cell.
Main Menu 32
News
PocketNews is an application for adding and reading RSS
feeds.
To add RSS news feeds, open RSS setup. Select Add RSS
feed option. Enter the feed address using the on-screen
keyboard.
To delete the feed, select it, open the context menu (by
continuous OK button press) and select Delete command.
To edit the feed, select it, open the context menu (by con-
tinuous OK button press) and select Edit command. Edit
the feed address using the on-screen keyboard.
To update feed, select Update in the application menu. Up-
dated content is added to the le with .hrss extension and
will be accessible for reading after updating. The news
downloading status is displayed while updating. After
Main Menu 33
updating the le is available for reading off-line in the
browser.
To read latest feeds, select Read the latest news option in
the application’s menu. The latest downloaded RSS feed
updates can be opened in browser.
You can open the previously stored RSS feeds for reading
by choosing the News Archive option.
Browser
You can navigate by using the following buttons:
• Up/Down/Left/Right buttons:
• short press — to scroll the window content
horizontally and vertically, to switch between
active elements on the page (references, text elds,
etc.);
• long press — to scroll the window content hor-
izontally and vertically with acceleration;
Main Menu 34
• Backward/Forward buttons — to go to the previ-
ous page or next page
• OK button:
• short press – to follow links and activate text
boxes; to display/hide a context menu; to open the
on-screen keyboard for entering a website address
• long press – to activate an address bar.
The browser supports le downloading from the Internet.
Downloaded les are saved to the root folder of the De-
vice’s internal storage.
To exit the browser, press the corresponding menu item.
Book Store
Book Store application provides quick and convenient licensed content download from Book Store portal to your
Device. The internet connection must be active.
Main Menu 35
PocketBook Sync
To download content using PocketBook Sync:
1. Go to the Book Store website (http://www.book-
land.com) using a browser on a PC or your Device.
• Enter the system by inputting your account data
at Book Store.
• Select content to be downloaded in the list of already bought Goods and press the Sync with devices button.
After this the selected le is moved to download queue.
NOTE If the is no Sync with devices button, go to PocketBook Devices and
set check in box Auto sync opposite the Device’s serial number.
2. Connect Your Device to wireless network.
3. Press the PocketBook Sync icon (arrow at the
bottom of the page on a status bar) or get PocketBook
Sync from Applications (if Wi-Fi connection has not been
activated, the Device will either do this automatically or
generate a connection request, depending on PocketBook
Main Menu 36
Sync settings). Authorize by inputting your account data
at Book Store
• Press the Update button in the PocketBook Sync
widget. A list of links to les prepared for download to
the Device will be displayed. They need user processing:
choose one, several or all items of a list. Then the con-
rmed les can be downloaded.
• The content will be downloaded to the Device
automatically or after pressing Download button in the
PocketBook Synс widget, depending on PocketBook Sync
settings
4. Downloaded le is moved to the folder Library >
Downloads (by default, you can choose another Download
folder in PocketBook Sync settings). The downloaded le
is displayed on the wall of Last events of the Main Menu.
Main Menu 37
STATUS BAR
Status bar is located at the bottom of the screen and dis-
plays next service information:
• Date and time
• Battery charge
• PocketBook Sync status.
In reading mode current page number and total page
count is also displayed.
Reading Books
In this chapter you will learn how to read e-books and
congure reader software for the most comfortable
reading.
The Device supports next book formats: PDF, EPUB (including DRM-protected); FB2, FB2.zip, TXT, RTF, HTML,
HTM, CHM, DJVU, DOC, DOCX, TCR, PRC, MOBI, ACSM.
To open a book, press OK on its title in Last events or
Library section. If you opened a book before, it will be
opened at the page you’ve nished reading.
In some book formats (e.g. FB2 or ePub, opened by FBreader) after opening a book reader application will count
pages – this is indicated with ‘…’ sign instead of a page
count in a status bar. During page calculation some features will not be available.
Reading Books 39
TURNING PAGES
Use Backward/Forward or Left/Right keys to turn pages.
Continuous Backward/Forward keys press turns 10 pages
at once.
FOLLOWING REFERENCES
If a page contains footnotes, internal or external references, you can enter links mode on continuous OK button
press (otherwise you’ll get a message informing that a
page contains no links to follow). A cursor will appear, and
you will be able to select a link using Down/Up keys and
press OK to follow. If a link follows to a web-site, it will be
opened with Device built-in browser.
CHANGING FONT SIZE
In text format books (ePub, FB2 etc., excluding PDF and
DjVu) you can change font size with Up/Down keys. When
Reading Books 40
you will reach the largest/smallest one, text will change
to smallest/largest.
READING MENU
To access reader application menu press OK button.
Reading menu for books in FB2, Epub,
TXT, RTF, HTML, PRC, CHM formats
Reading menu for books
in PDF, Djvu formats
Contents
Opens a content of the book if it is present, otherwise
you get a message about missing table of contents. Active
contents display table of contents, bookmarks and notes
you’ve made during reading. If table of contents has more
Reading Books 41
than one level, higher level entry is marked with ‘+’ sign.
Expanded item is displayed with a sign ‘-‘. Buttons Left/
Right collapse/expand selected subsection branch.
Use navigation keys to move across the table, OK button
opens a selected book chapter, continuous press of OK
button opens the context menu.
Using this menu you can open contents entry, edit or delete notes and bookmarks, expands/collapses selected
subsection branch. Under Settings section of the context
menu you can congure which elements to display:
• Contents
• Notes
• Bookmarks.
Go to Page
To select a page, move the slider left or right by Left/Right
buttons. Press OK to go to a chosen page. If you want to
open the exact page press Enter page number, after typing
Reading Books 42
a page number exactly from on-screen keyboard press OK.
As you set a slider or enter a page number, a page preview
will be opened on a background. If you will exit the menu
by pressing Backward, you will stay on a page you was
before.
Chapter name is displayed under the scroll bar.
NOTE Only the highest level chapters are marked on a scroll bar
In Last Opened sections thumbnails of last four opened
pages are displayed.
Reading Books 43
Search
Search mode works only in books containing text layer. To
search text through the book enter it using the on-screen
keyboard. Found text would be highlighted, and you can
switch between found instances using Left/Right naviga-
tion keys. To exit search mode press OK.
NOTE Search mode is not available for DJVU books, where there
is no text layers.
Bookmarks
Adds current page to bookmarks. After adding a page to
bookmarks in a right top corner a bookmark will appear.
All the bookmarks will be displayed in contents. To delete
bookmark, select the correspondent menu item again.
Settings
For FB2, TXT, RTF, HTML, PRC and CHM books you can
set up the most convenient reading settings: font, font
Reading Books 44
size (you can adjust font size with Up/Down navigation
keys), line spacing, page margins width or encoding (for
TXT and HTML books). FB2 books has two refresh modes:
Best Quality (default) or High Speed.
You can select left to right (by default) or right to left (e.g.
for Arabic or Hebrew texts) text direction.
Mode
PDF and DjVu books has Mode menu item instead of Set-
tings. Select viewing mode using Left/Right keys. Follow-
ing modes are available:
• Margins cropping – allows to decrease margins
width or height. Dene a border, you want to crop by a
joystick and press OK. Move arrow buttons by a joystick
to set margins width and height. After selecting cropping
area choose Accept. Then dene cropping settings: whole
document, odd pages, even pages or current page only.
Conrm your choice by clicking Accept.
Reading Books 45
• Zoom — zoom in or zoom out a page from 75%
to 400%
• Fit width – scaling page to the screen width
• The whole page – one page scaling
• Columns – for reading books with columns. To
navigate the page use navigation buttons. A page will be
turned after bottom edge of the sheet reached
• Reow – in this mode text is formatted to display
completely on a page. You can change font size with Up
and Down keys. Some images and tables may not display
in this mode. Reow mode is supported for PDF books
only. Some tables and pictures cannot be displayed in the
Reow mode.
Dictionary
Single-word translation. By default cursor highlights the
word to translate and dictionary looks for translation
automatically. Pressing OK button switches to a toolbar.
Reading Books 46
On-screen
Toggle to text
for choosing
a word
keyboard to type
word to translate
Change
dictionary
Rotate
Fixes the screen orientation: select the suitable one with
navigation keys.
Making Notes
You can enter notes mode by pressing Down button con-
tinuously or by pressing the corresponding menu option.
Reading Books 47
On the top of the display separate area will appear. Use
the buttons Up, Down to choose the place where your
note will begin and press OK to set up the top margin
of the note. Use navigation buttons to highlight a text
fragment and press OK to set the bottom margin of the
note. The menu, that will appear, suggests you to save
selected fragment as image or text (if available) or cancel
creating note.
You can look through the notes by choosing Notes section
in the main menu. By pressing OK button on the note, you
can switch to the initial page, where it was created.
CLOSING A BOOK
To close a book, select the corresponding reading menu
item.
Settings
In this chapter you will learn how congure the interface
and software features of the Device for the most
comfortable usage. Select Settings Main menu section
to congure the Device. All changes will be applied after
exiting the section.
If you will encounter any problems with new settings, you
will be able to start the Device in safe mode with factory
defaults. To start in a safe mode, press and hold Backward
key during the Device boot.
PERSONALIZE
Open at Startup last opened book or main menu.
Power-off Logo — the image will be displayed when the
Device is off. You can set a cover of the last opened book
by setting book cover.
Settings 49
NOTE You can also set your own picture as a logo from the Photo
application. Read about it in the Photo section.
Font. If you’d like to use your own font, copy its les to the
system/fonts internal storage folder
ATTENTION! System folder is hidden by default. Please, change
its parameters on your computer to make it visible.
Theme is set by default. If you want to use another theme,
download a le in .pbt format to the folder system/themes;
Key Mapping. In this section you can remap hardware keys.
To change key action, select it from the list and select
action from the list.
NETWORK
In this section you can set parameters needed for network
connection.
Settings 50
Network access — on or off. After network access activation,
the following settings appear:
• Auto connection on or off.
• Connection to hidden networks — Read more in the
Connecting to Internet section of this manual
• Available Networks — a list of available networks.
Choose one of them and you’ll see parameters of this
connection: Network name (SSID), signal strength,
security, IP-address, network mask, main gateway, DNS.
NOTE If Scanning is displayed instead of Available Networks, it
means that Device is searching for available networks.
DATE/TIME
In this section you will be able to set date, time, time zone
and clock format. You can also Synchronize Time or set
Auto Time Sync to use the network time/date.
Settings 51
LANGUAGES
Language Select the Device’s interface language.
Keyboard Layouts Under this section you can add up to 3
keyboard layouts.
Congure Dictionaries. Under this section you can uncheck dictionaries you don’t want to be displayed in the
list during the translation or in Dictionary application;
ACCOUNTS AND SYNCHRONIZATION
PocketBook Sync — There are the following settings for
the PocketBook Sync service:
• PocketBook Sync Status: On or off. The service is
turned on automatically at the autorization. If you are not
going to use the service for a long period, you can turn off
to optimize the Device productivity.
Settings 52
• Establishing Connection: Automatically (connection
will be established automatically every half an hour to
check for new links (if the Device is not powered off/ not
in sleeping mode)) or Manually (the connection is established at updating list of downloads or at choosing network connection).
• Downloading via Wi-Fi: On demand (you need to
process the list before download) or Automatically (all
new les are dowloaded automatically).
• Download folder: location of les. The Downloads
folder is set by default. You can choose another folder or
create a new one in the internal Device storage.
• Login/Exit: if you are not authorized in the appli-
cation, the page with a list of book stores will appear for
choosing and authorization. If you are authorized, then
you can logout PocketBook Sync.
Adobe DRM — to authorize, input your Login (e-mail
address) and Password. When you are authorized, your
login and Remove Adobe DRM Authorization item are
Settings 53
displayed. After removing all protected DRM documents
will be unavailable.
ADVANCED SETTINGS
UserProles
Here you can congure up to 5 user proles. Each
prole stores individual books’ status, last opened books,
bookmarks, notes, favorites and pre-congured network
connections.
To add new prole, open the corresponding item and enter
the name from on-screen keyboard. After this current
above-mentioned parameters will be stored at this prole.
To activate prole open the one you need. In prole
context menu you can change avatar, duplicate prole to
a new one, rename or delete prole.
Settings 54
System
Format Internal Memory – this action will erase all data,
except system les;
CAUTION! If you need to erase all data on the Device, use this
feature only, don’t try to format the Device internal memory via PC.
Backup & Recovery
• Factory Reset – the Device state will be reset to
factory default settings, erasing user settings. Other data
(e.g. books, photos) won’t be lost;
Library
This section is intended for optimization of Library
database.
• Library Data Update – set the parameters for
Library database update:
• Off – database won’t be updated;
Settings 55
• Once – database will be updated after exit
from Conguration section, the parameter will be
set to Off after update;
• Automatically – database would be update
after each Library opening and copying/removal of
books.
• Optimise Database – remove old database
entries. To run optimization set the parameter to Once
and exit Settings. The parameter will be set to Off after
optimization.
Lock Device after — set time of idleness, after which the
Device is locked: off, 5 min, 10 min.
Removing Packages – remove dictionaries. Check items to
uninstall, press Backward to exit the section and conrm
removal in dialog window.
USB Mode — set how the Device handles USB connection
by default: PC link, charge or ask user
Settings 56
Privacy
Protect Congurations by Password — in this section you
can protect your setting by password. Select Set Password
section and type the password from on-screen keyboard.
Now each time you try to enter Settings section, you will
be asked to enter the password. You can remove or change
password by selecting the corresponding item. To proceed,
you will be asked to enter the password once more.
Diagnostic and Usage — software provides data to
PocketBook about certain actions, performed by a user
on the Device, for further improvement of the Device
and services to users. The serial number and any other
information for identifying a user is not saved. You can
disable this statistics gathering option in the Diagnostic
and Usage section.
Text Rendering
good quality or high speed.
Settings 57
Complete Page Refresh
select the amount of page turned before the screen will
be updated completely. Always item provides the best
quality, but consumes the most power. Less frequency may
cause some artifacts from previous pages on a screen.
Large File Warning
If this setting is on, the Device will show a notication
when you try to open le larger than 25 MB.
Demo mode
switching demo mode for the Device. To activate demonstration mode check On in the Demo mode item.
SAVING BATTERY
Here you can set parameters, which help to save battery
charge:
• LED Indication – you may disable LED indication
by selecting Off in this section.
Settings 58
• Power off after — set time of idleness, after which
the Device power off: 10, 20, 30 or 60 minutes.
DEVICE INFO
The following information about Device will be displayed:
Device Model (model, serial number, hardware platform,
Wi-Fi MAC address),
Battery level,
Memory (operative memory, total and available internal
memory),
Software
• Firmware Version,
• Software Update – the Device will search for
updates in the following order: internal storage and
Internet;
• Auto Update – turn on/off automatic check for
updates.
Legal Information — license and information about third-
party applications, used on the Device.
Firmware Update
WARNING! Firmware Update is a responsible operation, during
which management software of the Device will be changed. In
case of improper execution control program may be damaged and
will require treatment in the service centre. Please perform the
upgrade procedure in accordance with the instructions below.
There are two ways to update the rmware.
Automatic Update
To start automatic software update select Settings > About
Device > Software > Software Update.
The Device will begin to check available update sources
in the following order:
• internal memory
• Internet.
Firmware Update 60
If default Internet connection is not set, the Device will
ask to connect to one of available wireless networks.
Also you can activate the automatic updates check (Set-
tings > About Device > Software > Auto Update). In this case,
the Device will use Wi-Fi connection only.
Manual Update
1. Open site www.pocketbook-int.com. Select your
country.
2. Click the Support button on top menu. Select
hardware model of your Device.
3. Download the Firmware to your PC.
4. Unpack the content of the archive, le SWUPDATE.
BIN, and copy it to the root folder of internal Device storage.
5. Switch off the Device by pressing button On/Off.
6. Press and hold both Backward and Forward buttons.
7. Switch on the Device by pressing On/Off. Hold
both Backward and Forward buttons until the message
Firmware update… is displayed on the screen.
Firmware Update 61
8. Follow the on-screen instructions with pictures:
connect USB cable to the Device and Press central Key
NOTE: You can check your Firmware version in Main menu > Set-
tings > About device > Software
Troubleshooting
Error Message Reason Correction Method
Delete some les from
the Device and copy
SWUPDATE.BIN le on it
one more time. Repeat
the download from www.
pocketbook-int.com.
Delete some les from
the Device and copy
SWUPDATE.BIN le on it
one more time. Repeat
the download from www.
pocketbook-int.com.
Delete the old version
of the rmware le from
the Device’s internal
memory root folder
No upgrade image
found
Upgrade image is
corrupted or Image is
empty
Error. A different
rmware version is
installed on the device
File SWUPDATE.BIN
cannot be found. Make
sure the le is in the
root folder.
SWUPDATE.BIN le is
damaged or there is no
space available.
A rmware le of an
older version is stored
in the device internal
memory.
Troubleshooting
Malfunciton Possible Reason Solution
Device does not turn on
or turns on but only the
logo is loaded
A book does not open
- the message Book is
probably damaged or
protected appears, or
nothing happens at all
Html book opens but is
displayed incorrectly.
For example, there are
empty pages, some part
of the text is missing etc.
Book opens but various
symbols, question marks
etc. are displayed instead
of letters
No response when you
press any key
Battery is low Charge the battery
If the book was downloaded from the online
store try to re-load it
The book is damaged
HTML-files contain
non-text elements
(frames, JAVA-scripts,
flash-elements)
Incorrect encoding
Sometimes (e.g., when
downloading damaged
or too large books) the
Device may freeze
again. If the file opens
on your PC, but does
not open on the Device,
save the book in another
format (TXT, DOC, PDF).
Save the page in TXT
format
Switch to reading mode,
select Settings and
change encoding
Close the frozen application by pressing the
Home key for 1–2 sec.
Troubleshooting 63
Malfunciton Possible Reason Solution
Check USB mode in
Settings Main Menu item.
Set Connection to PC or
Ask at Connection
Check USB cable condition and its proper connection to connector. Try
to connect the USB-cable
to another port
Connect the device to
a PC and check disks.
To proceed, open My
Computer, right-click on
the selected disk and
select Properties >Service
> Check Disk
Delete books, images
and/or music files that
you do not need
Settings > Date/Time
in Main Menu. Select
automatic turn off time in
Auto Turn Off in… item
After connection to PC
disks are not displayed in
Explorer
Bookmarks, settings and
current position in file
cannot be saved
Battery discharges
too fast
Your Device is in the battery charging mode.
No signal in connection
cable
File system damaged
Internal memory is full
Disabled automatic
turning off
Customer Support
For detailed information about service centers in your
country please use contacts below:
Česko 800-701-307
Deutschland 0-800-187-30-03
France 0805-080277
Polska 0-0-800-141-0112
Slovensko 0-800-606-676
USA/Canada 1-877-910-1520
Россия 8-800-100-6990
Україна 0-800-304-800
Казахстан 8-800-333-35-13
Беларусь 8-820-0011-02-62
საქართველო 995-706-777-360
www.pocketbook-int.com/support/
help@pocketbook-int.com
Compliance with International Standarts
Product name: PocketBook Mini
Model number: PocketBook 515w
The EUT should be supplied by USB port from complied Limited
Power Source of personal computer or notebook.
The EUT should be suppled by Adapter from complied Limited
Power Source.
Rated output voltage: DC 5V 1A
This equipment is marked with the 0678 symbol and can be used
throughout the European community.
This indicates compliance with the R&TTE Directive 1999/5/EC.
France – 2.4GHz for Metropolitan France.
Compliance with International Standarts 66
In all Metropolitan departments, wireless LAN frequencies can
be used under the following conditions, either for public or
private use:
• Indoor use: maximum power (EIRP*) of 100 mW for the
entire 2400-2483.5 MHz frequency band
• Outdoor use: maximum power (EIRP*) of 100 mW for
the 2400-2454 MHz band and with maximum power (EIRP*) of
10 mW for the 2454-2483 MHz band.
IMPORTANT: Changes or modications to this product not authorized
could void the EMC and wireless compliance and negate your authority to
operate the product. This product has demonstrated EMC compliance under
conditions that included the use of compliant peripheral devices and shielded
cables between system components. It is important that you use compliant
peripheral devices and shielded cables between system components to
reduce the possibility of causing interference to radios, televisions, and other
electronic devices.
Compliance with International Standarts 67
Certicationinformation(SAR)
The device meets guidelines for exposure to radio waves.
Your device is a radio transmitter and receiver. It is designed not
to exceed the limits for exposure to radio waves recommended
by international guidelines. These guidelines were developed
by the independent scientic organization ICNIRP and include
safety margins designed to assure the protection of all persons,
regardless of age and health.
The exposure guidelines for devices employ a unit of
measurement known as the Specic Absorption Rate or SAR. The
SAR limit stated in the ICNIRP guidelines is 2.0 watts/kilogram
(W/kg) averaged over 10 grams of tissue. Tests for SAR are
conducted using standard operating positions with the device
transmitting at its highest certied power level in all tested
frequency bands. The actual SAR level of an operating device can
be below the maximum value because the device is designed to
use only the power required to reach the network.
Compliance with International Standarts 68
This equipment complies with the European Council
Recommendation of 12 July 1999 on the Limitation of Exposure
of the General Public to Electromagnetic Fields [1999/519/EC].
PocketBook International S.A.
Crocicchio Cortogna, 6, 6900, Lugano, Switzerland
Te l . 0800-187-3003
Designed by Obreey Products. Assembled in PRC
Contains Reader® Mobile technology by Adobe Systems
Incorporated
Loading...
