Plinius P-10 Brochure

THE HEART OF MUSIC

P10

POWER
AMPLIFIER

P10

POWER
AMPLIFIER

Although our entry-level amplifier, the P10 has a level of
sophistication rarely found in such a cost-effective product.
The PLINIUS Odeon development has had a dramatic effect
on the design and implementation of this very desirable
amplifier. The Odeon power supply has been mirrored in
a smaller more cost effective way and the new circuit uses
faster driver devices with separate input and driver stage
power supply regulation. This has delivered an amplifier
capable of true high-end performance.

The large toroidal transformer will allow the P10 to deliver
power levels in excess of 200 watts per channel into
8 Ohms. Difficult speaker loads are driven with ease to the
most satisfying levels, while maintaining control and finesse.

The ideal partner for the P10 is the PLINIUS M8 Preamplifier.
The stable mates will combine to perform at the highest
level. The P10 is also highly suited to multiple custom
installation use.

The chassis has been fashioned from robust materials
including a forged and anodised fascia of gratifying
solidity. The fascia and accents are available in either
silver or black to match with other ancillary equipment.

Specifications For PLINIUS P10

Power:

200-Watts RMS per channel into 8 Ohms
Both channels driven from 20Hz to 20kHz

at less than 0.2% total harmonic distortion

Frequency Response:

20Hz to 20kHz +/–2dB
–3dB at 5Hz and –3dB at 70kHz

Distortion:

Typically <0.05% THD at rated power

0.2% THD and IM worst case prior
to clipping

4 Ohm Power:

300 Watts per channel or greater

Current Output:

40A short duration peak per channel
Fuse protected

Slewing: 50V/us

Hum & Noise:

90dB below rated output 20Hz to
20kHz unweighted

Gain on RCA Inputs:

32dB

Gain on XLR Inputs:

38dB

Input Impedance:

47k Ohms

Dimensions:

Height: 120mm (4 3/4”)
Width: 450mm (17 3/4”)
Depth: 400mm (15 3 1/4 4”)
Weight: 14kg (30lbs)
