Boot up to Dominate
M6S Plus 2.5 inch Series Solid State Drive
Still staring at your boot screen each morning?
Getting tired of your computer stuttering and
complaining when you open up certain programs?
Re-invigorate your system witha Plextor M6S Plus
upgrade and get ready for an entirely new experience!
SATA 6Gb/s
Feature
．Blazing Fast Random Read/
Write Speeds : Up to 94,000/
80,000 IOPS, utmost perfor-
mance for all read/write ope-
rations.
．Supports S.M.A.R.T. and
TRIM commands.
．Supports PlexTurbo, the exc-
lusive technology of acceler-
ation and writing operation
reduction (4GB Cache)
．Supports PlexCompressor,
the exclusive technology of
compression management
．Available in 128/256/512 GB
capacity
．Full 3-year warranty
Built for the Real World
The newest M6S Plus has a random read/write speed of up to 94,000/80,000 IOPS,
and a sequential read/write speed of up to 520/440 MB/s. The sequential
read/write speed is 4 times faster than that of the conventional HDDs typically
used by consumers. The performances of booting, executing software, gaming and
overall responsiveness of the system are all tremendously enhanced.
Plextor M6S Plus employs the new generation Marvell 88SS9188 dual-core
controller, increasing the speed while saving more energy. In the same operating
environment, compared with a 7200 rpm conventional HDD, M6S Plus extends the
battery life by 30 minutes!
Technological Revolution Gamer's Choice
Plextor introduced PlexTurbo, the latest generation of SSD memory caching
solution. Increasing the usage amount of system memory not only prolongs the life
span of M6S Plus SSD, but also vastly accelerates access performance of the SSD.
Best Choice for Workstation and Everyday Users
Compared to the conventional HDDs, speeds for booting, starting up applications,
and shutting down are greatly improved. Time is saved even when loading and
saving huge data files, and the overall efficiency is completely unaffected when
auto save is performed by the system.
M6S Plus comes with Plextor True Speed technology, and our firmware team
endeavors to provide a consistent performance design for compressible and
uncompressible data, sequential and random write, and throughout the entire life
span of our SSDs.
Plextor High Quality Standard
M6S plus has passed rigorous tests by the most advanced SSD testing equipments
in the world. Not a single error or failure is allowed (Zero Error), providing the
utmost product stability for end users. By simulating real-world read/write
conditions with various "Plextor Endurance Testing Mechanism", it is guaranteed
that M6S Plus has an astounding MTBF of 1.5 million hours, greatly raising
reliability after long use and ensuring safety for your valuable data.
M6S Plus 2.5 inch Series Solid State Drive
Specification
Performance (Under Windows NTFS)
Environment and Reliability
Compatibility
Form Factor and Connectors
Dimension and Weight
Package Content
Model PX- 128M6S+ PX- 256M6S+ PX- 512M6S+
Capacity 128 GB 256 GB 512 GB
Cache 256MB DDR3 512MB DDR3 768MB DDR3
Sequential Read Speed
(MB/s)*
Sequential W rite Speed
(MB/s)*
Random Read Speed
(4KB QD32 IOPS)*
Random W rite Speed
(4KB QD32 IOPS)*
Pow er Requirement
T emperature
Shock
Vibration
MT BF
Warranty
Operating System Supported
Agency Approval
Command Set Support
Interface
Firmware Upgrade
Up to 520 Up to 520 Up to 520
Up to 300 Up to 420 Up to 440
Up to 88,000 Up to 90,000 Up to 94,000
Up to 75,000 Up to 80,000 Up to 80,000
DC 5V 2.0A (Max.)
0°C ~ 70°C / 32°F ~ 158°F (Operating)
1500G (Max.) , at 1 msec hal f-sine
7 ~ 800Hz, 2.17Grms (Operating)
1,500,000 Hours
3 years
Microsoft Windows OS / Linux OS / Mac OS
UL, T UV, FCC, CE, BSMI, VCCI, RCM, KCC, EAC, ROHS, WHQL
T RIM, S.M.A.R.T ., NCQ, AT A/AT API-8
SAT A 6.0 Gb/s, compatibl e with SAT A 3.0/1.5Gb/s
Supported
Form Factor
Pow er Connector
15-pin SAT A connector for DC 5V input
Data Connector
Dimension (L/W/H)
100 x 69.85 x 6.8 mm / 3.94 x 2.75 x 0.27 inch
Weight
Drive
Documents
Specifications subject to change without notice.
* Test Platform
Motherboard: ASUS P8Z77-V PRO, CPU: Intel i5-3570 3.40Ghz, BIOS: ver.1504, AHCI driver: 12.5.0.1066, OS: Windows 8 x64.
Actual performance may vary based on hardware, software, and overall system configuration.
2.5 inch form factor
7-pin SAT A Connector
60g / 2.12oz (Max.)
128GB / 256GB / 512GB SSD
Quick Instal l ation Guide
For more information, please visit
www.PLEXTOR.com
Lite-On Technology Corporation
12F, 392, Ruey Kuang Road
Neihu Dist., Taipei 114
Taiwan, R.O.C
© 2015 Plextor.
Plextor branded products are developed and sold by Lite-On Technology Corporation.
