Savi™ Talk WT100/T

Professional wireless headset system

(WT1/T base + WH100/T headset)

with optional HL10 lifter

User Guide

Welcome

Congratulations on purchasing your new Plantronics product. This guide contains instructions for
setting up and using your Savi Talk professional wireless headset system.

Plantronics Savi User Guide

Contents

1 Package contents and features .................................. 4

1.1 Base ......................................................................... 4

1.2 Savi WH100/T headset ............................................ 5

1.3 HL10 lifter and features (optional) ............................ 6

2 Base set-up ................................................................ 7

2.1 Attaching charging cradle to base ........................... 7

2.2 Connecting base to desk phone .............................. 7

2.3 Connecting power supply to base ........................... 7

2.4 Positioning base ..................................................... 7

3 Headset set-up ........................................................... 8

3.1 Fitting headset ......................................................... 8

3.2 Docking and charging the headset .......................... 8

4 Configuration and test call ......................................... 9

4.1 Checking configuration ............................................ 9

4.2 Making a test call ..................................................... 9

5 Lifter set-up (optional) .............................................. 10

5.1 Installing lifter ........................................................ 10

5.2 If you do not hear a dial tone ................................ 10

5.3 Additional parts (if required) .................................. 11

6 Using your Savi Talk professional wireless headset

system ..................................................................... 12

Powering headset on/off .............................................. 12

Placing, answering and

ending calls with desk phone ..................................... 12

Muting a call ................................................................ 13

Base indicator lights .................................................. 13

Headset indicator lights and tones .............................. 13

Subscription ................................................................. 14

7 Troubleshooting and common questions ................. 15

Plantronics Savi User Guide

1 Package contents and features

1.1 Base

Telephone

interface cable

Base

Base power supply

Savi WT1/T base features

Talk indicator light

Master
speaking
volume

Configuration
switch

Master
listening
volume

Subscription
button and
indicator light

Power
indicator
light

Power jack

Telephone interface
cable jack

Handset
lifter jack

Plantronics Savi User Guide 4

1.2 Savi WH100/T headset

Headset with pre-installed ear loop

Headband

Charging cradle

Savi WH100/T headset features

Ear loop

Indicator light

Call control button (also controls
volume and mute functions)

Microphone

Plantronics Savi User Guide 5
