Plantronics PLUG PRONG ADAPTERS User Manual

welcome

to hands-free
communications from

Plantronics

With a Plantronics headset, you will experience
a level of comfort and on-the-job freedom you
may have never felt before. To obtain maximum
performance, please read the adapter installation
and usage information contained in this manual.
For information on headset operation, please refer
to your headset manual.

If you have any questions, please call Plantronics:
1(800) 544-4660

for units with a push-to-talk button

Your headset is equipped with a push-to-talk
button that can be adjusted with a screwdriver to
be either lockable or nonlockable. When the button
is depressed or locked in the ON position, the
microphone is
turned on and
will transmit
your voice.

how to select

Installation

the lockable
or nonlockable
switch position

lockable position

Note that the selec­tor slot is aligned verti­cally. The push-to-talk
button can be depressed
momentarily or locked in
the ON position by first
depressing then sliding
the button until it locks.

plug prong adapters

Simply plug into the
appropriate jack in your
station or jackset.
The adapters are
universal and may
be positioned so that
either side is visible.

nonlockable position

Turn the selector
horizon-tally. The push­to-talk button can be
depressed momentarily
when you wish to speak.

How to Obtain Warranty Repairs

To obtain warranty repairs, return the unit(s), shipping
prepaid, to:

Plantronics Service Center Operations
345 Encinal Street
Santa Cruz, CA 95061-0635

Please use the original container, or pack the unit(s) in a sturdy
carton with sufficient packing material to prevent damage.

Include the following information:

1. A proof-of-purchase indicating model number
date of purchase

2. Bill-to address

3. Ship-to address

4. Number and description of units shipped

and warranty repairs

5. Name and telephone number of person to call,
should contact be necessary

Service

6. Reason for return and description of your problem

Return shipping charges to the customer are paid by Plantronics
only for in-warranty equipment not requiring chargeable repairs.
For out-of-warranty equipment, and for in-warranty equipment
requiring chargeable repairs, shipping charges are prepaid by
Plantronics and billed to the customer. Damage occurring during
shipment is deemed the responsibility of the carrier, and claims
should be made directly with such carrier.

Plantronics reserves the right to refuse to service any headset if it
has been altered, modified, or serviced by someone other than
Plantronics Service Center Operations.

How to Obtain Out-of-Warranty Repairs

To obtain out-of-warranty repairs, please contact Plantronics
Service Center Operations:

phone [phone], fax [phone].
For more information: www.plantronics.com
