Plantronics 83757-01 User manual

MDA200

Audio Switcher

User Guide

™

ContentsContentsContents

Welcome 3

What’s in the Box 4

MDA200 Basics 5

Accessories 6

Connect Your Headset 7

Desk Phone: Connect and Call 8

Desk Phone (standard) 8
Desk Phone Plus HL10 lifter and Power Supply (sold separately) 10
Desk Phone Plus EHS Cable 12

Computer: Connect and Call 13

Connect Your Computer and Place a Call 13

MDA200 LED Indicators 14

Daily Use 15

Answer an Incoming Call 15
Place an Outgoing Call 15
Switch Calls 15

Troubleshooting 16

Desk Phone 16
Softphone 17

2

Welcome

Congratulations on purchasing your new Plantronics product. This guide contains instructions

for setting up and using your MDA200 audio switcher.

Please refer to the separate safety instructions for important product safety information prior
to installation or use of the product.

3

What’s in the Box

Telephone Interface Cable

MDA200 Audio Switcher

4

MDA200 Basics

FRONT/TOP

1

2

3

1 Computer talk button
2 Desk phone talk button

3 USB headset/USB wireless adapter port

(headset and adapter not included)

4 USB cable (connect to computer)
5 Handset lifter/EHS cable jack
6 Telephone interface cable jack
7 Power jack
8 Configuration slide switch
9 Listening volume dial
10 Speaking volume dial

8

BACK

4

BOTTOM

5

6

7

9

10

4

5

Accessories

2

3 4

1 Electronic Hookswitch Cable Electronically and automatically takes your desk phone handset

off hook. Enables remote call answer/end with your headset.

2 On Line Indicator (OLI) A light that flashes once a call is activated. It allows others to know

when you are on a call.

3 HL10™ Lifter Automatically lifts handset and returns it to the cradle. Enables remote call

answer/end with your headset.

4 AC Power Supply Required when using the HL10 lifter.

5 USB Extension Cable Extends the length of the USB cable between the MDA200 and

computer.

21

5

See plantronics.com/accessories for more information on all accessories.

6
