300Mbps 802.11n Wireless Broadband Router
M
M
6
-
6
-
6
-
a
a
2
2
2
n
n
7
7
7
u
u
a
a
l
l
Copyright
Copyright © 2011 by PLANET Technology Corp. All rights reserved. No part of this publication may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer
language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or
otherwise, without the prior written permission of PLANET.
PLANET makes no representations or warranties, either expressed or implied, with respect to the contents
hereof and specifically disclaims any warranties, merchantability or fitness for an y particular purpose. Any
software described in this manual is sold or licensed "as is". Should the programs prove defective following
their purchase, the buyer (and not this company, its distributor, or its dealer) assumes the entire cost of all
necessary servicing, repair, and any incidental or consequential damages resulting from any defect in the
software. Further, this company reserves the right to revise this publication and to make changes from time to
time in the contents hereof without obligation to notify any person of such revision or changes.
All brand and product names mentioned in this manual are trademarks and/or registered trademarks of their
respective holders.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radi o
frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
4. Consult the dealer or an experienced radio technician for help.
FCC Caution:
To assure continue d complia nc e, (example-u se only sh iel d ed interface c abl es when connecting to comp uter or
peripheral devices) any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the Following two conditions:
(1) This device may not cause harmful interference
(2) This Device must accept any interference received, including interference that may cause undesired
operation.
Any changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
I
Federal Communication Commission (FCC) Radiation Exposure Statement
This equipment complies with FCC radiation exposure set forth for an uncontrolled environment. In order to
avoid the possibility of exceeding the FCC radio frequenc y exposure limits, human proximity to the antenna
shall not be less than 20 cm (8 inches) during normal operation.
R&TTE Compliance Statement
This equipment complies with all the requirements of DIRECTIVE 1999/5/CE OF THE EUROPEAN
PARLIAMENT AND THE COUNCIL OF 9 March 1999 on radio equipment and telecommunication terminal
Equipment and the mutual recognition of their conformity (R&TTE).
The R&TTE Directive repeals and replaces in the directive 98/13/EEC (Telecommunications Terminal
Equipment and Satellite Earth Station Equipment) As of April 8, 2000.
Safety
This equipment is designed with the utmost care for the safety of those who install and use it. However, special
attention must be paid to the dangers of electric shock and static electricity when working with electrical
equipment. All guidelines of this and of the computer m anufacture must therefore be allowed at all times to
ensure the safe use of the equipment.
National Restrictions
This device is intended for home and office use in all EU countries (and other countries following the EU
directive 1999/5/EC) without any limitation except for the countries mentioned below:
Country Restriction Reason/remark
Bulgaria None
Outdoor use limited to 10
France
Italy None
Luxembourg None
Norway Implemented
Russian
Federation
mW e.i.r.p. within the band
2454-2483.5 MHz
None Only for indoor applications
General authorization required for outdoor use and
public service
Military Radiolocation use. Refarming of the 2.4 GHz
band has been ongoing in recent years to allow current
relaxed regulation. Full implementation planned 2012
If used outside of own premises, general authorization is
required
General authorization required for network and service
supply(not for spectrum)
This subsection does not apply for the geographical area
within a radius of 20 km from the centre of Ny-Ålesund
Note: Please don’t use the product outdoors in France
WEEE regulation
To avoid the p otential effects on the environment and human health as a result of the presence of
hazardous substances in electrical and electronic equipment, end users of electrical an d electronic
equipment should understand the meaning of the crossed-out wheeled bin symbol. Do not dispose of
WEEE as unsorted municipal waste and have to collect such WEEE separately.
II
Revision
User’s Manual for PLANET 802.11n Wireless Broadband Router
Model: WNRT-627
Rev: 1.0 (FEBRUARY. 2011)
III
CONTENTS
Chapter 1. Product Introduction...........................................................................................................1
1.1 Package Contents.................................................................................................................1
1.2 Product Description...............................................................................................................1
1.3 Product Features...................................................................................................................2
1.4 Product Specification.............................................................................................................3
Chapter 2. Hardware Installation .......................................................................................................... 6
2.1 Hardware Description............................................................................................................6
2.1.1 The Front Panel........................................................................................................6
2.1.2 LED Indications.........................................................................................................7
2.1.3 The Rear Panel.........................................................................................................8
Chapter 3. Connecting the Router........................................................................................................ 9
3.1 System Requirements...........................................................................................................9
3.2 Installing the Router..............................................................................................................9
Chapter 4. Quick Installation Guide ...................................................................................................12
4.1 Manual Network Setup - TCP/IP Configuration..................................................................12
4.1.1 Obtain an IP Address Automatically........................................................................12
4.1.2 Configure the IP Address Manually........................................................................14
4.2 Starting Setup in Web UI.....................................................................................................19
4.3 PLANET Smart Setup! Utility ..............................................................................................25
Chapter 5. Configuring the Router ..................................................................................................... 27
5.1 Login....................................................................................................................................27
5.2 Status..................................................................................................................................27
5.3 Quick Setup.........................................................................................................................28
5.4 WPS....................................................................................................................................29
5.5 Network...............................................................................................................................33
5.5.1 WAN........................................................................................................................33
5.5.2 LAN.........................................................................................................................45
5.5.3 MAC Clone .............................................................................................................46
5.6 Wireless...............................................................................................................................47
5.6.1 Wireless Settings....................................................................................................47
5.6.2 Wireless Security....................................................................................................50
5.6.3 Wireless MAC Filtering...........................................................................................55
5.6.4 Wireless Advanced.................................................................................................58
5.6.5 Wireless Statistics...................................................................................................60
IV
5.7 DHCP..................................................................................................................................61
5.7.1 DHCP Settings........................................................................................................61
5.7.2 DHCP Clients List...................................................................................................62
5.7.3 Address Reservation ..............................................................................................63
5.8 Forwarding..........................................................................................................................65
5.8.1 Virtual Servers ........................................................................................................66
5.8.2 Port Triggering........................................................................................................69
5.8.3 DMZ........................................................................................................................71
5.8.4 UPnP.......................................................................................................................72
5.9 Security ...............................................................................................................................73
5.9.1 Basic Security.........................................................................................................73
5.9.2 Advanced Security..................................................................................................75
5.9.3 Local Management.................................................................................................77
5.9.4 Remote Management.............................................................................................79
5.10 Parental Control..................................................................................................................80
5.11 Access Control....................................................................................................................84
5.11.1 Rule.........................................................................................................................84
5.11.2 Host.........................................................................................................................88
5.11.3 Target......................................................................................................................90
5.11.4 Schedule.................................................................................................................93
5.12 Advanced Routing...............................................................................................................96
5.12.1 Static Routing List...................................................................................................96
5.12.2 System Routing Table.............................................................................................98
5.13 Bandwidth Control...............................................................................................................98
5.13.1 Control Settings......................................................................................................99
5.13.2 Rules List................................................................................................................99
5.14 IP & MAC Binding .............................................................................................................101
5.14.1 Binding Settings....................................................................................................101
5.14.2 ARP List................................................................................................................104
5.15 Dynamic DNS....................................................................................................................106
5.15.1 Comexe.cn DDNS ................................................................................................106
5.15.2 Dyndns.org DDNS................................................................................................107
5.15.3 No-ip.com DDNS..................................................................................................108
5.16 System Tools.....................................................................................................................109
5.16.1 Time Settings........................................................................................................109
5.16.2 Diagnostic............................................................................................................. 111
5.16.3 Firmware Upgrade................................................................................................113
V
5.16.4 Factory Defaults.................................................................................................... 114
5.16.5 Backup & Restore.................................................................................................115
5.16.6 Reboot ..................................................................................................................115
5.16.7 Password..............................................................................................................116
5.16.8 System Log...........................................................................................................117
5.16.9 Statistics................................................................................................................121
Chapter 6. Quick Connect to a Wireless Network ..........................................................................123
6.1 Windows XP (Wireless Zero Configuration)......................................................................123
6.2 Windows 7 (WLAN AutoConfig)........................................................................................125
6.3 Mac OS X 10.x..................................................................................................................128
6.4 iPhone / iPod Touch / iPad................................................................................................130
Appendix A: FAQ..................................................................................................................................133
Appendix B: Configuring the PCs ......................................................................................................140
Appendix C: Specifications.................................................................................................................144
Appendix D: Glossary..........................................................................................................................147
VI
User’s Manual of WNRT-627
Chapter 1. Product Introduction
1.1 Package Contents
The following items should be contained in the package:
WNRT-627 Wireless Broadband Router
Power Adapter
Ethernet Cable
Quick Installation Guide
CD-ROM (User’s Manual included)
If there is any item missed or damaged, please contact the seller immediately.
1.2 Product Description
The WNRT-627 in te gr at es 4 - p o r t S w i t c h, F ir ew al l, NAT-Rout er an d W ir el es s A P. The 300Mbps Wireless
Broadband Router delivers exceptional range and speed, which can fully meet the need of Small
Office/Home Office (SOHO) networks and the users demanding higher networking perfo rmance.
Easy Installation
The WNRT-627 provides a total solution for the home and the SOHO users. With the MIMO 11n
wireless technology, it’s easy to combine the wireless devices with existing wired network.
Multiple Wireless Network Technologies for Greater Access
PLANET Wireless Broadband Router, WNRT-627 features 802.11n radio with 2T2R antenna
technology compliant with 802.11b/g standards. Compared with general wireless routers, the
WNRT-627 offers more powerful and flexible capability for LAN clients to access the Internet with
management functions.
Incredibly High Speed
The WNRT-627 Wireless Broadband Router provides speed of up to 300Mbps which is 6x of the
traditional 11g products, and the use of high bandwid th-consuming applications such as HD Videos.
Wide Range of Wireless Security Support
The WNRT-627 supports one WAN port for wired cable or DSL service connection. To secure the
wireless communication, the WNRT-627 supports up-to-date encryption, WPA-PSK/WPA2-PSK with
TKIP/AES. In order to simplify the security settings, the WNRT-627 supports Wi-Fi Protected Setup
-1-
User’s Manual of WNRT-627
(WPS) configuration with PBC/PIN method. By just clicking the options, the secure connection
between AP and wireless client will be built immediately.
Advanced Firewall Security
The WNRT-627 supports NAT function to allow multiple users to access the Internet via a single legal
IP. It also provides Virtual Server for LAN PC to act as an application server and offer certain service
to the clients on Internet. Furthermore, the SPI (Stateful Packet Inspection) firewall protects your
Intranet PCs from unauthorized accesses and many kinds of DoS attacks from the Internet. In the
aspect of firewall, the WNRT-627 supplies IP-based and MAC-based access control, and prevent
possible hackers attack.
1.3 Product Features
¾ Industrial Compliant Wireless LAN & LAN
Compliant with IEEE 802.11n wireless technology capable of up to 300Mbps data rate
Backward compatible with 802.11b/g sta ndard
Equipped with four LAN ports (10/100Mbps) and one WAN port (10/100Mbps), Auto
MDI/MDI-X supported
¾ Fixed-network Broadband Router
Supported connection types: Dynamic IP/ Static IP / PPPoE / Telstra Big Pond / L2TP /
PPTP
Support Static Routing, WDS, UPnP, Dynamic DNS
¾ Secure Network Connection
Support Wi-Fi Protected Setup (WPS)
Advanced security: 64/128/152-bit WEP, WPA/WPA2 and
WPA-PSK/WPA2-PSK(TKIP/AES encryption), 802.1x
Support NAT firewall featur es, with SPI function to protect against DoS attacks.
Support IP / Protocol-based access control and MAC Filtering
¾ Advanced Networking function for Specific Application
Support multiple sessions IPSec, L2TP and PPTP VPN pass-through
Support Virtual Server, ALG, DMZ and UPnP for various networking applications
Support DHCP Server
¾ Easy Installation & Management
Web-based UI for and Quick setup for easy configuration
Remote Management allows configuration from a remote site
System status monitoring includes DHCP Client, System Log
-2-
1.4 Product Specification
User’s Manual of WNRT-627
Product
Hardware Specification
Interface
Antenna
Power Button Power On/Off button at rear panel
WPS / Reset Button
LED Indicators PWR, SYS, WLAN, LAN x 4, WAN, WPS with green light
Material Plastic
Wireless Interface Specification
Standard Compliance with IEEE 802.11b/g/n
Frequency Band
Extend Frequency
Modulation Type
WNRT-627
300Mbps 802.11n Wireless Broadband Router
WAN Port: 1 x 10/100Mbps Auto MDI/MDI-X RJ45 port
LAN Port: 4 x 10/100Mbps Auto MDI/MDI-X RJ45 ports
Gain: 2 x Fixed 5dBi Antenna
Orientation: Omni-directional
WPS / Reset button at front panel
Push for above 5 seconds to reset to factory default setting
2.4~2.4835GHz
DSSS
DBPSK, DQPSK, QPSK, CCK and OFDM (BPSK/QPSK/16-QAM/ 64-QAM)
11n: 135/121.5/108/81/54/40.5/27/13.5Mbps
Data Transmission
Rates
Transmission
Distance
Channel
RF Power
Receive Sensitivity
130/117/104/78/52/39/26/13Mbps
65/58.5/52/39/26/19.5/13/6.5Mbps (Dynamic)
11g: 54/48/36/24/18/12/9/6Mbps (Dynamic)
11b: 11/5.5/2/1Mbps (Dynamic)
Indoor up to 100m
Outdoor up to 300m (it is limited to the environment)
America/ FCC: 2.414~2.462GHz (11 Channels)
Europe/ ETSI: 2.412~2.472GHz (13 Channels)
Japan/ TELEC: 2.412~2.484GHz (14 Channels)
High: 18 dBm (max)
Middle: 15 dBm
Low: 12 dBm
130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER
Wireless Management Features
Wireless Operation
Mode
Encryption Security
AP, WDS (AP+Bridge)
WEP (64/128/152-bit) encryption security
-3-
User’s Manual of WNRT-627
WPA-PSK / WPA2-PSK (TKIP/AES)
WPA / WPA2 (TKIP/AES)
WPA / WPA2 enterprise mode (802.1x authentication)
Provide wireless LAN ACL (Access Control List) filtering
Wireless Security
Wireless Advanced
Router Features
Internet Connection
Typ e
Firewall
Wireless MAC address filtering
Support WPS(WIFI Protected Setup )
Enable/Disable SSID Broadcast
Support 802.11e WMM (Wi-Fi Multimedia)
Support Wireless Roaming
Provide Wireless Statistics
Shares data and Internet access for users, supporting following internet access:
PPPoE / Russia PPPoE
Dynamic IP
Static IP
Telstra Big Pond
PPTP / Russia PPTP
L2TP / Russia L2TP
NAT firewall with SPI (Stateful Packet Inspection)
NAT with ALG (Application Layer Gateway)
Built-in NAT server supporting Virtual Server, and DMZ
Built-in firewall with IP address filtering, Domain Name filtering, and MAC address filtering
Support ICMP-FLOOD, UDP-FLOOD, TCP-SYN-FLOOD filter, DoS protection
Routing Protocol
Static Routing
VPN Pass-through PPTP, L2TP, IPSec
Built-in DHCP server supporting static IP address distributing
Support UPnP, Dynamic DNS
Support Flow Statistics
LAN
IP & MAC Binding
IP / Protocol-based Bandwidth Control
Session Number: Max 5210
Web-based (HTTP) management interface
Remote management
System Management
SNTP time synchronize
Easy firmware upgrade
System Log supports auto mail and save to local host
Windows 7(32-bit/64-bit)
OS Compatibility
Windows Vista (32-bit/64-bit)
Windows XP
Mac OS X 10.4 and higher
-4-
Standards Conformance
IEEE Standards
Others Protocols and
Standards
User’s Manual of WNRT-627
IEEE 802.11n (1T1R, up to 150Mbps)
IEEE 802.11g
IEEE 802.11b
IEEE 802.11i
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
IEEE 802.3x Flow Control
CSMA/CA, CSMA/CD, TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP
-5-
User’s Manual of WNRT-627
Chapter 2. Hardware Installation
Please follow the instruction below to build the wireless network connection between WNRT-627 and your
computers.
2.1 Hardware Description
2.1.1 The Front Panel
The front panel provides a simple interface monitoring the router. Figure 2-1 shows the front panel of
WNRT-627.
Front Panel
WPS/Reset Button
ACTIVE TIME
WPS
Reset Press and hold the button more than 8 seconds to the factory default setting
Figure 2-1 WNRT-627 Front Panel
Press and hold the button less than 5 seconds for WPS configuration
-6-
User’s Manual of WNRT-627
2.1.2 LED Indications
The front panel LEDs indicates instant status of port links, wireless data activity and system power;
and helps monitor and troubleshoot when needed. Figure 2-2 and Table 2-1 show the LED indications
of the Wireless Router.
LED Definition
Figure 2-2 WNRT-627 Front Panel
LED Status Function
PWR
SYS
WLAN
LAN1-4
WAN
WPS
On Power is on.
Off Power is off.
On The Router is initializing.
Flashing The Router is working properly.
Off The Router has a system error.
Flashing The Wireless function is enabled.
Off The Wireless function is disabled.
On A device is linked to the corresponding port but there is no activity.
Flashing An active device is linked to the corresponding port.
Off No device is linked to the corresponding port.
On A device is linked to the corresponding port but there is no activity.
Flashing An active device is linked to the corresponding port.
Off No device is linked to the WAN port.
Slow Flashing
On
Quick
Flashing
A wireless device is connecting to the network by WPS function. This
process will last for about 2 minutes.
A wireless de vice has been succe ssfully added to the network by WPS
function. The LED will keep on for about 5 minutes.
A wireless device has failed to be added to the network by WPS
function.
Table 2-1 The LEDs indication
1. When a device has been successfully added to the network by WPS function, the
WPS LED will keep on for about 5 minutes and then turn off.
2. When pressing and holding the WPS/Reset Button for more than 5 seconds, you
will reset the router.
-7-
2.1.3 The Rear Panel
User’s Manual of WNRT-627
Figure 2-3 Rear Panel
Interface Function
POWER
The Power socket is where you will connect the power adapter.
Please use the power adapter provided with WNRT-627.
ON/OFF The button of the power.
WAN Connect to the DSL/cable Modem, or Ethernet
1,2,3,4 (LAN) Connect to the user’s PC or network devices
Table 2-2 The Interface indication
-8-
User’s Manual of WNRT-627
Chapter 3. Connecting the Router
3.1 System Requirements
Broadband Internet Access Service (DSL/Cable/Ethernet connection)
One DSL/Cable Modem that has an RJ-45 connector (not necessary if the Router is
connected directly to the Ethernet.)
PCs with a working Ethernet Adapter and an Ethernet cable with RJ-45 connectors
PC of subscribers running Windows 98/ME, NT4.0, 2000/XP, Windows Vista / Win 7, MAC
OS 9 or later, Linux, UNIX or other platform compatible with TCP/IP protocols
Above PC installed with WEB Browser
It is recommended to use Internet Explore 7.0 or above to access the Router.
3.2 Installing the Router
Before installing the Router, make sure your PC is connected to the Internet through the broadband
service successfully at this moment. If there is any problem, please contact your local ISP. After that,
please install the Router according to the following steps. Don't forget to pull out the power plug and
keep your hands dry.
Step 1. Power off your PC, Cable/DSL Modem, and the Router.
Step 2. Locate an optimum location for the Router. The best place is usually at the center of your
wireless network.
Step 3. Adjust the direction of the antenna. Normally, upright is a good direction.
-9-
User’s Manual of WNRT-627
Figure 3-1 Adjust the direction of the antenna
Step 4. Connect the PC or Switch/Hub in your LAN to the LAN Ports (Y ello w port s) of the Router with
Ethernet cable, shown in Figure 3-2.
Figure 3-2 Hardware Installation of the WNRT-627 Wireless Router
Step 5. Connect the power adapter to the power socket on the Router, and the other end into an
electrical outlet. Then power on the Router.
-10-
Step 6. Power on your PC and Cable/DSL Modem.
User’s Manual of WNRT-627
-11-
User’s Manual of WNRT-627
Chapter 4. Quick Installation Guide
This chapter will show you how to configure the basic functions of your Wireless 3G Router using
Quick Setup within minutes.
A computer with wired Ethernet connection to the Wireless Router is required for the
first-time configuration.
4.1 Manual Network Setup - TCP/IP Configuration
The default IP address of the WNRT-627 is 192.168.1.1. And the default Subnet Mask is
255.255.255.0. These values can be changed as you desire. In this guide, we use all the default
values for description.
Connect the local PC to the LAN ports of the Router. And then you can configure the IP address for
your PC in the following two ways.
Obtain an IP address automatically
Configure the IP address manually
In the following sections, we’ll introduce how to install and configure the TCP/IP correctly in Windows
XP. First, make sure your Ethernet Adapter is working, and refer to the Ethernet adapter’s manual if
needed.
4.1.1 Obtain an IP Address Automatically
Summary:
Set up the TCP/IP Protocol in "Obtain an IP address automatically" mode on your PC.
Then the WNRT-627 built-in DHCP serv er will a ssign IP address to the PC automatically.
1. Install TCP/IP component
1) On the Windows taskbar, click the Start button, point to Settings, and then click Control
Panel.
2) Click the Network and Internet Connections icon, and then click on the Network
Connections tab in the appearing window.
3) Right click the icon shown below, select Properties on the prompt window.
-12-
Figure 4-1
User’s Manual of WNRT-627
4) In the prompt window shown below, double click on the Internet Protocol (TCP/IP).
Figure 4-2
5) The following TCP/IP Properties window will display and the IP Address tab is open on this
window by default.
-13-
User’s Manual of WNRT-627
2. Setting IP address automatically
Select Obtain an IP address automatically, Choose Obtain DNS server automatically, as shown in
the Figure below:
Figure 4-3
Now click OK to save your settings.
4.1.2 Configure the IP Address Manually
Summary:
Set up the TCP/IP Protocol for your PC.
Configure the network parameters. The IP address is 192.168.1.xxx ("xxx" is any number
from 2 to 254), Subnet Mask is 255.255.255.0, and Gateway is 192.168.1.1 (The Router's
default IP address)
1 Select Use the following IP address radio button.
2 If the Router's LAN IP address is 192.168.1.1, enter IP address 192.168.1.x (x is from 2 to 254),
and Subnet mask 255.255.255.0.
-14-
User’s Manual of WNRT-627
3 Enter the Router’s LAN IP address (the default IP is 192.168.1.1) into the Default gateway field.
4 Select Use the following DNS server addresses radio button. In the Preferred DNS Server
field, you can enter the DNS server IP address which has been provided by your ISP
Figure 4-4
Now click OK to save your settings.
Now, you can run the Ping command in the command prompt to verify the network connection
between your PC and the Router. The following example is in Windows XP OS. Please follow the
steps below:
1. Click on Start > Run.
-15-
User’s Manual of WNRT-627
Figure 4-5
2. In the run box type “cmd” and click OK. (Windows Vista users type cmd in the Start .Search
box.)At the prompt.
Figure 4-6
Open a command prompt, and type ping 192.168.1.1, and then press Enter.
If the result displayed is similar to Figure 4-7, it means the connection between your PC and
the Router has been established well.
-16-
User’s Manual of WNRT-627
Figure 4-7 Success result of Ping command
If the result displayed is similar to Figure 4-8, it means the connection between your PC and
the Router has failed.
Figure 4-8 Failure result of Ping command
If the address is 0.0.0.0, check your adapter installation, security settings, and the settings on your
router. Some firewall software programs may block a DHCP request on newly installed adapters.
-17-
User’s Manual of WNRT-627
1. The 1/2/3/4 LEDs of LAN ports which you link to on the Router and LEDs on your
PC's adapter should be lit.
2. If the Router's IP address is 192.168.1.1, your PC's IP address must be within the
range of 192.168.1.2 ~ 192.168.1.254.
-18-
User’s Manual of WNRT-627
4.2 Starting Setup in Web UI
It is easy to configure and manage the WNRT-627 with web browser.
Step 1. To access the configuration utility, open a web-browser and enter the default IP address
http://192.168.1.1 in the address field of the browser.
Figure 4-9 Login the Router
After a moment, a login window will appear. Enter admin for the User Name and Password, both in
lower case letters. Then click the OK button or press the Enter key.
Default User name: admin
Default Password: admin
Figure 4-10 Login Window
-19-
Loading...
