Revision
PLANET Long Reach PoE over Coaxial / UTP Extender User’s Manual
MODELS: LRP-101CE / LRP-101UE
REVISION: 1.0 (January 2015)
Part No: EM-LRP-101x_v1.0 (2350-AN0010-000)
Long Reach PoE over Coaxial Extender
LRP-101CE
User’s Manual
1. Package Contents
Power over Coaxial
PoE IP Camera
802.3at PoE+
Thank you for purchasing PLANET Long Reach PoE over Coaxial Extender,
the LRP-101CE. “Long Reach PoE over Coaxial Extender” mentioned in
this manual refers to the LRP-101CE.
Open the box of the Long Reach PoE over Coaxial Extender and carefully
unpack it. The box should contain the following items:
LRP-101CE User’s Manual
If there is any item missing or damaged, please contact the
Note
seller immediately.
2. Application Diagram
Point to Point
PoE+ Switch
802.3at
PoE
PoE+
LRP-101CH
Long Reach PoE Injector
Long Reach Power over Ethernet
Coaxial
Up to 1km
LRP-101CE
Long Reach PoE Extender
UTP
Long Reach Power over Ethernet
100m
1-1
Single Chain, Multi-point
PoE IP Camera
PoE IP Camera
IP Camera
Power over Coaxial
802.3at PoE+
PoE IP Camera
AC-to-DC Adapter
48-56V DC Out
Long Reach Power over Ethernet
Ethernet Switch
Point to Multi-point
Coaxial
400m
100m
Long Reach Power over Ethernet
UTP
Coaxial
400m
LRP-101CE
Long Reach PoE Extender
UTP
Long Reach Power over Ethernet
100m
Note
PoE
Coaxial
400m
Coaxial
Up to 1km
Coaxial
Up to 1km
Coaxial
Up to 1km
Long Reach Power over Ethernet
100m
Coaxial
400m
UTP
LRP-101CELRP-822CS
LRP-101CE
Long Reach Power over Ethernet
Long Reach Power over Ethernet
Long Reach Power over Ethernet
Long Reach Power over Ethernet
UTP
100m
UTP
100m
UTP
100m
UTP
100m
It is recommended to use PLANET Long Reach Ethernet
coaxial extenders on the LRP Managed Switch-LRP-822CS. If
you insert a coaxial extender that is not supported, the LRP
Managed Switch may damage it.
1-2
3. Physical Introduction
Rear Panel
Front Panel
LRP-101CE Physical Dimensions
Dimensions (W x D x H): 94 x 70.3 x 26 mm
LNK/ACTPoE In-use
PoE OUT
10/100BASE-TX
Top Panel
Long Reach Power over Ethernet
Bottom
LRP-101CE
Long Reach PoE Extender - Coax
LRP IN
Extender
LNK
PWR
1-3
LED Descriptions
LRP-101CE
Long Reach PoE Extender - Coax
LRP IN
LNK
PWR
Extender
System & LRP Coax Interface
LED Color Function
PWR Green Light: indicates the power is on.
LNK Green
Light: indicates that the coaxial link is established.
Off: indicates that the coaxial link is down.
LNK/ACTPoE In-use
PoE OUT
10/100BASE-TX
RJ45 10/100BASE-TX Interface
LED Color Function
PoE In-Use Amber
LNK/ACT Green
Light: indicates the RJ45 port is providing PoE
power
Blink: indicates the extender is actively sending or
receiving data over that port.
1-4
4.HardwareSpecications
Model LRP-101CE
Functions Long Reach PoE Extender
HardwareSpecications
10/100BASE-TX RJ45
Auto-negotiation / Auto-MDI/MDI-X
IEEE 802.3at/af PoE PSE
(Power Source Equipment)
100m
1522bytes
1 x BNC female
Long Reach PoE over coaxial PD (Powered
Device)
BNC center pole : DC+
BNC shield : DC -
Coaxial cable: 75 ohm
RG-6/Ucable,lessthan12Ω/1000ft
RG-59/Ucable,lessthan30Ω/1000ft.
Max. 200m with PoE+ output (1,640 ft.)
Max. 600m with PoE output (2,624 ft.)
Max. 1200m without PoE output (3,937ft.)
IEEE 1901
Ethernet
Interface
Long
Reach
PoE
Interface
Copper
Power over
Ethernet
Standard
PoE Output 48~56V DC, 600mA max.
PoE Budget Up to 25 watts
PoE Mode End-span, RJ45 Pin 1/2(+), 3/6(-)
Data Rate 100/100Mbps
Cabling Cat5e or above
Maximum
Distance
Maximum
Frame sizes
Connectivity
Power Iutput 44~56V DC
Cabling
Maximum
Distance
Long Reach
Ethernet
Standard
1-5
Modulation
Type
Security 128-bit AES encryption
Frequency
Band
Long
Reach
PoE
Interface
LED Indicators
ESD Protection 2KV DC
Enclosure Metal case
Installation Wall mount or DIN rail with optional kit
Dimensions (W x D x H) 94 x 70 x 26 mm
Weight 375g
Performance
LRP
Compatibility
Wavelet-OFDM
2 ~ 28 MHz
LRP-101CE 802.3af/at
Data Rate*
Distance
200m
400m
600m
800m
1000m
With power over coaxial input
LRP-101CH – 1-Port LRP Injector
LRP-822CS – 8-Port LRP over Coax Switch
LRP-1622CS – 16-Port LRP over Coax Switch
PWR
LRP LNK
PoE In-use
LNK/ACT
(Upload /
Download)
93 / 93
Mbps
93 / 93
Mbps
87 / 91
Mbps
75 / 83
Mbps
55 / 73
Mbps
PoE Output Capability**
LRP-101CH
W/56V DC
IN
29W 16W
22W 14W
13W 10W
10W 8W
8W 7W
LRP-101CH
W/30W
PoE+ IN
1-6
Power Requirements BNC Power over Coaxial Input: 44~56V DC
Standards Conformance
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
Standards Compliance
IEEE 802.3af Power over Ethernet (802.3at
Type 1)
IEEE 802.3at Power over Ethernet (802.3at
Type 2)
Regulation Compliance FCC Part 15 Class A, CE
Environment
Temperature
Humidity
* 1. Upload: LRP-101CE to LRP-101CH. Download: LRP-101CH to LRP-
101CE.
2. As there are various resistance values in the category of RG-59/U
or RG-6/U cable, the actual data rate will vary on the quality of the
copper wire and environment factors.
** Depending on what the DC/PoE Power Input and the length of coaxial
cable are.
Operating: -20~70 degrees C
Storage: -40~75 degrees C
Operating: 5~95% (non-condensing)
Storage: 5~95% (non-condensing)
1-7
Long Reach PoE over UTP Extender
LRP-101UE
User’s Manual
5. Package Contents
Thank you for purchasing PLANET Long Reach PoE over UTP Extender, the
LRP-101UE. “Long Reach PoE over UTP Extender” mentioned in this
manual refers to the LRP-101UE.
Open the box of the Long Reach PoE over UTP Extender and carefully
unpack it. The box should contain the following items:
LRP-101UE User’s Manual
2-1
6. Application Diagram
802.3at
PoE+ Switch
PoE IP Camera
Power over UTP
802.3at PoE+
Point to Point
PoE
PoE+
LRP-101UH
Long Reach PoE Injector
Long Reach Power over Ethernet
500m
Long UTP
Long Reach Power over Ethernet
LRP-101UE
Long Reach PoE Extender
UTP
100m
2-2
7. Physical Introduction
Rear Panel
Front Panel
LRP-101UE Physical Dimensions
Dimensions (W x D x H): 94 x 70.3 x 26 mm
LNK/ACTPoE In-use
PoE OUT
10/100BASE-TX
LRP-101UE
Extender
Long Reach PoE Extender - UTP
Top Panel
Long Reach Power over Ethernet
LRP IN
LNK
PWR
Bottom
2-3
LED Descriptions
LRP-101UE
Extender
Long Reach PoE Extender - UTP
LNK
PWR
LRP IN
System & LRP UTP Interface
LED Color Function
PWR Green Light: indicates the power is on.
LNK Green
Light: indicates that the UTP link is established.
Off: indicates that the UTP link is down.
LNK/ACTPoE In-use
PoE OUT
10/100BASE-TX
RJ45 10/100BASE-TX Interface
LED Color Function
PoE In-Use Amber
LNK/ACT Green
Light: indicates the RJ45 Port is providing PoE
power
Blink: indicates the extender is actively sending or
receiving data over that port.
2-4
8.HardwareSpecications
Model LRP-101UE
HardwareSpecications
10/100BASE-TX RJ45
Auto-negotiation / Auto-MDI/MDI-X
IEEE 802.3at/af PoE PSE
(Power Source Equipment)
100m
1522bytes
1 x RJ45 connector
Long Reach PoE over UTP PD (Powered Device)
PIN 1,3,5,7: VCC+
PIN 2,4,6,8: VCC-
Max. 200m with PoE+ output (1,640 ft.)
Max. 600m with PoE output (2,624 ft.)
Max. 1200m without PoE output (3,937ft.)
IEEE 1901
Wavelet-OFDM
Ethernet
Interface
Long
Reach
PoE
Interface
Copper
PoE Standard
PoE Output 48~56V DC, 600mA max.
PoE Budget Up to 25 watts
PoE Mode End-span, RJ45 Pin 1/2(+), 3/6(-)
Data Rate 100/100Mbps
Cabling Cat5e or above
Maximum
Distance
Maximum
Frame Size
Connectivity
Pin
Assignment
Power Iutput 44~56V DC
Cabling 2-wire UTP / 4-wire UTP / 8-wire UTP
Maximum
Distance
Long Reach
Ethernet
Standard
Modulation
Type
Security 128-bit AES encryption
2-5
Frequency
Band
Long
Reach
PoE
Interface
LED Indicators
ESD Protection 2KV DC
Enclosure Metal case
Installation Wall mount or DIN rail with optional kit
Dimensions (W x D x H) 94 x 70 x 26 mm
Weight 190g
Power Requirements Power over RJ45 Input: 44~56V DC
Performance
LRP
Compatibility
2 ~ 28 MHz
LRP-101UE 802.3af/at
Data Rate*
Distance
100m
200m
300m
400m
500m
With power over UTP input
LRP-101UH – 1-Port LRP Injector
PWR
LRP LNK
PoE In-use
LNK/ACT
(Upload /
Download)
94 / 94
Mbps
82 / 82
Mbps
63 / 67
Mbps
44 / 48
Mbps
30 / 30
Mbps
PoE Output Capability**
LRP-101UH
W/56V DC
IN
30W 19W
30W 18W
30W 17W
22W 14W
18W 12W
LRP-101UH
W/30W
PoE+ IN
2-6
Standards Conformance
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
Standards Compliance
IEEE 802.3af Power over Ethernet (802.3at
Type 1)
IEEE 802.3at Power over Ethernet (802.3at
Type 2)
Regulation Compliance FCC Part 15 Class A, CE
Environment
Temperature
Humidity
* 1. Upload: LRP-101UE to LRP-101UH. Download: LRP-101UH to LRP-
101UE.
2. As there are various resistance values in the category of 5/5e cable,
the actual data rate will vary on the quality of the copper wire and
environment factors.
** Depending on what the DC/PoE Power Input and the length of UTP
cable are.
Operating: -20~70 degrees C
Storage: -40~75 degrees C
Operating: 5~95% (non-condensing)
Storage: 5~95% (non-condensing)
2-7
EC Declaration of Conformity
For the following equipment:
*Type of Product: 1-Port 10/100TX PoE PD + 1-Port Coax Long Reach PoE Injector
*Model Number: LRP-101CH, LRP-101CE
* Produced by:
Manufacturer’s Name : Planet Technology Corp.
Manufacturer’s Address: 10F., No.96, Minquan Rd., Xindian Dist.
We hereby confirmed that the products mentioned comply with the requirements set out in
the Council Directive on the Approximation of the Laws of the Member States relating to
Electromagnetic Compatibility (2004/108/EC).
For the evaluation regarding the EMC, the following standards were applied:
Responsible for marking this declaration if the:
Manufacturer Authorized representative established within the EU
Authorized representative established within the EU (if applicable):
Company Name: Planet Technology Corp.
Company Address: 10F., No.96, Minquan Rd., Xindian Dist., New Taipei City 231, Taiwan
Person responsible for making this declaration
Name, Surname Kent Kang
Position / Title : Product Manager
1-Port 10/100TX PoE PSE + 1-Port Coax Long Reach PoE Extender
1-Port 10/100TX PoE PD + 1-Port UTP Long Reach PoE Injector
1-Port 10/100TX PoE PSE + 1-Port UTP Long Reach PoE Extender
LRP-101UH, LRP-101UE
New Taipei City 231, Taiwan (R.O.C.).
EN55022 (2010)
EN 61000-3-2 (2006 + A1:2009 + A2:2009)
EN 61000-3-3 (2008)
EN55024 (2010)
IEC 61000-4-2 (2008)
IEC 61000-4-3 (2006 + A1: 2007 + A2: 2010)
IEC 61000-4-4 (2012)
IEC 61000-4-5 (2005)
IEC 61000-4-6 (2008)
IEC 61000-4-11 (2004)
IEC 61000-4-8 (2009)
(R.O.C.)
Taiwan 31st March, 2015
Place Date Legal Signature
PLANET TECHNOLOGY CORPORATION
10F., No.96, Minquan Rd., Xindian Dist., New Taipei City, Taiwan, R.O.C. Tel:886-2-2219-9518 Fax:886-2-2219-9528
e-mail: sales@planet.com.tw http://www.planet.com.tw
Loading...
