Planet IGT-x205AT Installation Manual

1. Package Contents

Thank you for purchasing PLANET industrial Gigabit Media Converter,
IGT-1205AT or IGT-2205AT. In the following sections, the term
“Industrial Gigabit Media Converter” mentioned in this user’s
manual also means the IGT-x205AT.

Open the box of the Industrial Gigabit Media Converter and carefully
unpack it. The box should contain the following items:

Industrial Gigabit Media

Converterx 1

DIN-rail Kit x 1 Wall-mount Kit x 1 RJ45 Dust Cap

If any of these are missing or damaged, please contact your dealer
immediately; if possible, retain the carton including the original packing
material, and use them again to repack the product in case there is a
need to return it to us for repair.

User’s Manual x 1 SFP Dust Cap x 2

IGT-1205AT x 1
IGT-2205AT x 2

- 1 -

2.2 LED Indicators

 System

LED Color Function

P1 Green Lit: Indicates power 1 has power.

P2 Green Lit: Indicates power 2 has power.

Alarm Red

 Alarm LED denition

PWR1 PWR2 DIP

NO NO - - - NO

YES YES Switch - O Normal Close

YES NO Switch - On Fault Open

NO YES Switch - On Fault Open

YES YES Redundant Primary ON O Normal Close

YES YES Redundant

YES NO Redundant

NO YES Redundant

YES NO Redundant Primary ON On Fault Open

NO YES Redundant Primary ON On Fault Open

Lit: Indicates one or more of the following events

are triggering the alarm (LED).

Fiber Port

Link Status

Primary

DOWN

Primary

DOWN

Primary

DOWN

Alarm LED

Slow blink

for 2 seconds

Blink rapidly Fault Open

Blink rapidly Fault Open

FAULT Alarm

OUTPUT

Fault Open

- 3 -

Although 2.5G LED is a bi-color light, the actual color is

Caution

close to Amber.

2.3 Converter Upper Panel

The upper panels of the IGT-x205AT consist of one terminal block
connector within two DC power inputs, and the IGT-x205AT also

provides one DIP switch for ber redundant function. Figure 2-3 shows

the upper panel of the IGT-x205AT.

Max. Fault Alarm Loading: 24V, 1A

1 2 3 4 5 6

V1+

PWR1

Figure 2-3: IGT-x205AT Upper Panel

The DIP switch settings and descriptions of the IGT-x205AT

Fiber

Mode

Redundant
Switch

Note

DIP Position Function

Fiber Mode

ON Fiber Redundancy

OFF (default) Switch Mode

1. If using the Switch mode, the IGT-x205AT can use 3
or 4 ports.

2. If using the Redundant mode, one of the two Fiber
ports will be redundant while the other 1 or 2 copper
ports are in operation.

V2+

PWR2Alarm

- 5 -

DC Input: 12-48V
AC Input: 24V

Fiber
Mode

Redundant
Switch

, 0.6A

, 0.6A

2.5 Wiring the Fault Alarm Contact

The fault alarm contacts are in the middle of the terminal block
connector as the picture shows below. When inserting the wires, the
Industrial Gigabit Media Converter will detect the fault status of the
power failure and then forms an open circuit. The following illustration
shows an application example for wiring the fault alarm contacts.

1 2 3 4 5 6

The Fault Alarm Contacts are
energized (CLOSE) for normal

Fault Alarm Contacts

Note

Alarm

Insert the wires into the fault alarm contacts

1. The wire gauge for the terminal block should be in the
range between 12 and 24 AWG

2. Alarm relay circuit accepts up to 24V DC, max. 1A
currents.

operation and will OPEN when
failure occurs

- 7 -

2. Hardware Introduction

2.1 Converter Front Panel

Figures 2-1 and 2-2 show the front panels of the Industrial Gigabit
Media Converters.

P1 P2 Alarm

100/1G/2.5G

SFP

LNK /
ACT

2.5G
1000
100

100/1G/2.5G

SFP

LNK /
ACT

10/100/1000T

LNK/ACT

10/100
1000

LNK/ACT

IGT-1205AT

Figure 2-1:

IGT-1205AT

Front Panel

1

2

3

P1 P2 Alarm

100/1G/2.5G

SFP

LNK /
ACT

2.5G
1000
100

100/1G/2.5G

SFP

LNK /
ACT

10/100/1000T

LNK/ACT

10/100

LNK/ACT

1000

IGT-2205AT

Figure 2-2:

IGT-2205AT

Front Panel

1

 SFP Port

100/1000/2500BASE-X SFP port
for transceiver module, enables
to have a networking distance of

2

300 meters to 2km (multi-mode
ber) and 10/20/40/60/80/120
kilometers (single-mode ber)

3

 Gigabit TP Interface

10/100/1000BASE-T copper RJ45
twisted-pair with up to 100 meters
in distance.

4

 Per 10/100/1000T Port

LED Color Function

Lit: Indicates the link through that port
is successfully established at 10Mbps or
100Mbps.

Blinking: Indicates that the Media
Converter is actively sending or receiving
data over that port.

Lit: Indicates the link through that port
is successfully established at 1000Mbps.

Blinking: Indicates that the Media
Converter is actively sending or receiving

10/100/1000T

10/100
1000

LNK/ACT
LNK/ACT

3

10/100

LNK/

ACT

1000
LNK/

ACT

Amber

Green

data over that port.

 Per 100/1000/2500X SFP Port

LED Color Function

Lit: Indicates the link through that port is

100

LNK/

Amber

ACT

100/1G/2.5G

SFP

1

LNK /
ACT

100/1G/2.5G

SFP

LNK /
ACT

1000

2.5G
1000

LNK/

100

Green

ACT

2

Amber

2500
LNK/

Green

ACT

successfully established at 100Mbps.

Blinking: Indicates that the Media
Converter is actively sending or receiving
data over that port.

Lit: Indicates the link through that port is
successfully established at 1000Mbps.

Blinking: Indicates that the Media
Converter is actively sending or receiving
data over that port.

Lit: Indicates the link through that port is
successfully established at 2500Mbps.

+

Blinking: Indicates that the Media
Converter is actively sending or receiving
data over that port.

2.4 Wiring the Power Inputs

The 6-contact terminal block connector on the top panel of Industrial

Gigabit Media Converter is used for two DC redundant power inputs.
Please follow the steps below to insert the power wire.

1. Insert positive / negative DC power wires into contacts 1 and 2 for

POWER 1, or 5 and 6 for POWER 2.

Max. Fault Alarm Loading: 24V, 1A

1 2 3 4 5 6

V1+

PWR1

2. Tighten the wire-clamp screws for preventing the wires from loos­ening.

1 2 3 4 5 6

Power 1 Alarm Power 2

+ - + -

1. The wire gauge for the terminal block should be in the
range between 12 and 24 AWG.

2. The DC power input range is 12V ~ 48V DC and

Note

supports 24V AC.

3. Use one power input when using 24V AC.

V2+

PWR2Alarm

DC Input: 12-48V
AC Input: 24V

Fiber
Mode

Redundant
Switch

, 0.6A

, 0.6A

2.6 Grounding the Device

Users MUST complete grounding wired with the device; otherwise, a
sudden lightning could cause fatal damage to the device.

Max. Fault Alarm Loading: 24V, 1A

1 2 3 4 5 6

V1+

PWR1

V2+

PWR2Alarm

DC Input: 12-48V
AC Input: 24V

Fiber
Mode

Redundant
Switch

, 0.6A

, 0.6A

Earth Ground

EMD (Lightning) DAMAGE IS NOT CONVERED UNDER

Note

WARRANTY.

3. Installation

This section describes the functionalities of the Industrial Gigabit Media
Converter’s components and guides how to install it on the DIN-rail
and wall. Basic knowledge of networking is assumed. Please read this
chapter completely before continuing.

This following pictures show the user how to install the

Note

device, and the device is not IGT-x205AT.

- 2 -

- 4 -

- 6 -

- 8 -

3.1 DIN-rail Mounting Installation

1

2

PLANET Industrial Gigabit Media Converter supports 100/1000/2500X
with both single mode and multi-mode SFP transceivers. Before we
connect Industrial Gigabit Media Converter to the other network device,
please do the following:

1. Set the DIP Switch of SFP Port 1 or Port 2 to the “OFF” position

with ber speed auto detection.

DIP Position Function

Fiber Mode

ON Fiber Redundancy

OFF (default) Switch Mode

3.2 Wall-mount Plate Mounting

3.3 Side Wall-mount Plate Mounting

You must use the screws supplied with the wall­mounting brackets. Damage caused to the parts by

Caution

using incorrect screws would invalidate your warranty.

- 9 -

2. Make sure both sides of the SFP transceivers are with the same
media type, for example, 1000BASE-SX to 1000BASE-SX, and
1000BASE-LX to 1000BASE-LX.

Never pull out the module without pulling the lever or
the push bolts on the module. Directly pulling out the

Note

module with force could damage the module and the
SFP port of the Industrial Gigabit Media Converter.

- 11 -

3.3 Installing the SFP Transceiver

The sections describe how to insert an SFP transceiver into an SFP
port.

The SFP transceivers are hot-pluggable and hot-swappable. You can
plug in and out the transceiver to/from any SFP port without having

to power down the Industrial Gigabit Media Converter as Figure 3-1

shows.

MGB / MFB

Series Module

Figure 3-1: Inserting the SFP Transceiver

It is recommended to use PLANET SFP transceiver on
the Industrial Gigabit Media Converter. If you insert an

Note

SFP transceiver that is not supported, the Industrial
Gigabit Media Converter will not recognize it.

- 10 -

4. Product Specications

Model IGT-1205AT IGT-2205AT

Hardware Specications

Copper Interface

Fiber Optic
Interfaces

Connector

DIP Switch

Alarm

Power
Requirements

Power
Consumption /
Dissipation

Dimensions
(W x D x H)

Weight 412g 419g

Enclosure IP30 type metal case

Installation DIN-rail kit and wall mount ear

1 x 10/100/1000BASE-T
RJ45

2 x 100/1G/2.5GBASE-X SFP interfaces
(Port-1 and Port-2)
Supports auto detection

Removable 6-pin terminal block

Pin 1/2 for Power 1;

Pin 3/4 for fault alarm;
Pin 5/6 for Power 2

DIP Position Function

Fiber
Mode

Provides one relay output for power failure
Alarm Relay current carry ability: 1A @ DC 24V

DC 12~48V or AC 24V

Redundant power with reverse polarity protection

4.8 watts/16BTU 4.92 watts/16.9BTU

32 x 87 x 135mm 32 x 87 x 135mm

ON Fiber Redundancy

OFF (default) Switch Mode

- 12 - - 13 - - 14 -

2 x 10/100/1000BASE-T
RJ45

ESD Protection 6KV DC

Converter Specications

Processing
Scheme

Fabric 12Gbps 14Gbps

Throughput
(packet per
second)

Flow Control

Address Table 4K entries

Jumbo Frame 9216bytes

Standards Conformance

Standards
Compliance

Regulatory
Compliance

Stability Testing

Environment

Temperature

Humidity

Store-and-Forward

8.93Mpps@64bytes 10.42Mpps@64bytes

Back pressure for half duplex.

IEEE 802.3x pause frame for full duplex

IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3ab Gigabit Ethernet
IEEE 802.3z Gigabit Ethernet 1000BASE-SX/LX
IEEE 802.3x Full-Duplex Flow Control
IEEE 802.1p Class of Service

FCC Part 15 Class A, CE

IEC60068-2-32 (free fall)
IEC60068-2-27 (shock)
IEC60068-2-6 (vibration)

Operating: -40~75 degrees C
Storage: -40~75 degrees C

Operating: 5~95% (non-condensing)
Storage: 5~95% (non-condensing)

5. Customer Support

Thank you for purchasing PLANET products. You can browse our online

FAQ resource on PLANET web site rst to check if it could solve your

issue. If you need more support information, please contact PLANET
switch support team.

PLANET online FAQs:
http://www.planet.com.tw/en/support/faq

Switch support team mail address:
[e-mail]

Copyright © PLANET Technology Corp. 2021.
Contents are subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp.
All other trademarks belong to their respective owners.
