START TO CLEAN IN 30 SECONDS FLAT!

SSH SERIES - Technical Outline

AUTOMATIC SELF CLEANING BURNERS

With the push of a button, once a day, our

matchless ignition system ignites a standing

pilot. This begins a 30 second automatic self

cleaning burner procedure, which ensures

optimal burner efficiency.

(PATENT PENDING)

This procedure ensures that the

burners stay clean and efficient all

SSH Series

SSH75 with Optional

I-12 Computer, BL, Casters

Standard SSH55 SSH55T SSH75

Specifications

BTU / Hr 80,000 40,000* 105,000 Oil Capacity (lbs) 40-50 20-25* 75 Frying Area 14 x 14” 7 x 14”* 18 x 18” Frying Depth 3-1/4 – 5” 3-1/4 – 5” 3-1/4 – 5” Model Width 15 – 5/8” 15 – 5/8” 19 – 5/8” Model Height 46 – 1/8” 46 – 1/8” 46 – 1/8” Model Depth 34 – 15/32” 34 – 15/32” 34 – 15/32” Hourly Fries (Frozen) 80 Lbs. 80 Lbs. 105 Lbs.

KEY STANDARD FEATURES

Solstice Supreme high efficiency technology

Energy $$ savings - lower gas usage

Lower flue temperatures

Gas company rebate $$ program eligible

High frying production capacity

Lower maintenance and repair cost

SCB Self Clean Burner (patent pending)

DDP Downdraft Protection (patent pending)

No complex power blower

No fragile ceramics to break

Common parts and front accessible

Simple, safe, flexible controls

Matchless ignition for simple easy lighting

DVI Drain Valve Interlock for safe operation

Solid State thermostat w/melt and boil out modes

Flexible options: Add digital or computer controls, or basket lifts at factory or in the field.

(*per side)

Solo Filter

Solo Filter SFSH55 Features

Space-saving design

3” swivel downspout

Add a Solo Filter in the field

FROM START TO CLEAN IN 30 SECONDS FLAT!

day, every day... PERIOD!

MIX & MATCH CABINET

COMBINATIONS

You now have the flexibility to mix and match any

Supreme Fryer and create your own custom design. Combine any

SSH55, SSH55T, or SSH75 to create the perfect combination for your

individual needs. (Combine up to (6) six combinations)

Filter Drawer System

SSH55T / Filter / 75 / BNB / 55

PO Box 501, Concord, New Hampshire 03302-0501 .509 Route 3A, Bow, New Hampshire, USA

800-258-3708

www.pitco.com

FILTER DRAWER KEY FEATURE

Easy two-step filtrationEasy 2 Step Filtration

Fast 8 gpm (gallons per minute) pump

Built-in pickup strainer prevents clogs

Mix and match any SSH fryer and BNB

Up to six units in a battery

Filter drawer in any location, default is left

All fryer drains at the same height

Filter pan on easy tow casters

Optional : Paperless filter, flush hose, crumb basket, heater

L12-242 Rev 1 (04/06)

PO Box 501, Concord, New Hampshire 03302-0501 .509 Route 3A, Bow, New Hampshire, USA

800-258-3708 .www.pitco.com

L12-241 Rev 1 (04/06)

Pitco’s newest series of

fryers, the “Solstice Supreme”,

are a major breakthrough in

fryer design and efficiency.

Our engineers have designed a

THE BEST FRYER IN THE WORLD - PERIOD

NEW TECHNOLOGY Pitco’s non-Blower System

NON-BLOWER SYSTEM

The smart simple design eliminates all of the failure prone

moving parts found in old technology high efficiency fryers.

Pitco’s new burner and baffle squeeze more heat out of

your dollar by causing a “scrubbing action” of the flame.

system that has the highest

gas efficiency rating,

combined with the lowest

cost of ownership in

the industry.

HIGHEST

EFFICIENCY RATING

Pitco’s Solstice Supreme fryer category has more gas

models than any manufacturer (25 lb., 50 lb., etc.)

that achieve the Energy Star Rating.

OLD TECHNOLOGY

Blower

This new baffle becomes radiant

much faster, leading to quicker recovery times and

higher cooking efficiency, while still maintaining it’s

high efficient combustion.

Fragile Ceramic Burner

LOWEST COST OF OWNERSHIP

Less moving parts and no fragile

ceramic burners to crack or blowers to clean means greater reliability, less

required maintenance and longer life.
