PiPO Pad-P1 User Manual

User Manual

２

３

Contents

Welcome

Important Notices

Keys and Functions

I. Getting Started

1.1 Turn on/off

1.1.1 Turn on

1.1.2 Turn off

....................................................................................................................

.................................................................................................

...............................................................................................

..................................................................................................

......................................................................................................

.........................................................................................................

1.2 Lock/unlock the screen (sleep mode)

1.3 Connect to computer

II. Your Home Screen

..................................................................................

...........................................................................................

....................................................

３

４

５

６

2.1 Change wallpaper:

........................................................................................

2.2 Add/delete applications on home screen:

2.3 Add widgets to home screen:

III. Network Connection

3.1 Wi-Fi

..................................................................................................................

3.1.1 Turn on Wi-Fi

3.1.2 Turn off Wi-Fi

3.1.3 Add a Wi-Fi network

3.2 Bluetooth

..........................................................................................................

......................................................................................

............................................................................................

..............................................................................

3.2.1 Make device discoverable

...................................................................

........................................................................

...........................................

７

８

９

3.2.2 Scan for devices

.........................................................................................

９

４

3.2.3 Pair with the Bluetooth device

............................................................

９

3.3 3G Network

3.3.1 External 3G Network

....................................................................................................

..............................................................................

3.3.2 Internal 3G support (optional)

IV. Internet Browsing

4.1 Internet Browsing

V. Install and Manage Apps

5.1 Install Apps

..................................................................................................

5.2 Manage Apps

VI. Multi-media Functions

6.1 Music

..............................................................................................................

......................................................................................

.....................................................................................

..........................................................................

..............................................................................................

.............................................................................

........................................................

９

１０

１１

１２

6.2 Video

6.2.1 HDMI output

6.3 Gallery

6.4 Camera

6.5 E-book reader

6.6 Sign function

VII. Settings

VIII. Battery

..............................................................................................................

...........................................................................................

...........................................................................................................

..........................................................................................................

............................................................................................

...............................................................................................

..........................................................................................................

.........................................................................................................

IX .Firmware Upgrading Procedures

Troubleshooting

..................................................................................................

.........................................................

１３

１４

１５

１６

１７

２１

２２

２６

５

Welcome

Thank you for purchasing this tablet.

It brings you much convenience for your business (supports Word,

Excel, send & receive e-mails...) and entertainment (supports 3D

game, chatting, movie playback, eBooks.....).

Running on Android 4.4, with a 1.8GHz processor and highly

responsive capacitive touch screen, it brings you wonderful user

experience.

Before beginning, please refer to this user manual carefully.

Important Notices

⊙ While using the earphone, if the volume is excessively high it may

cause hearing damage. So please adjust the volume of the player

to a moderate level and balance the time of using.

⊙ Do not disconnect the tablet suddenly when formatting or

uploading and downloading, which can lead to program errors.

⊙ Do not dismantle the tablet by yourself, and do not use alcohol,

thinner or benzene to clean its surface.

６

⊙ The tablet dose not support USB charge. If you want to charge the

1. Esc key

2. Menu key

Tap to view the option menu. When you Tap the Menu

tablet, please use the AC adaptor supplied. Please use the original

accessories.

⊙ Read this User Manual carefully, Make sure you know how to

upgrade the tablet, other wise do not upgrade it by yourself.

Keys and Functions

Tap to return to home screen

７

key from within an application, you will see the

sub-menus for the application.

3. Power jack(DC

input)

Connect to a 9V2.5A output adaptor as included in

the accessories

4. HDMI

5. USB slot

Connect to a computer via a USB cable to transfer data

6. Host

7. MIC

8. TF card slot

9. SIM card slot

To insert your 3G card (optional, only 3G version with

this)

10. Power and lock

key

11. Earphone Jack

12. Front camera

13. Rear camera

14. Reset

Press to reset the tablet if it freezes or behaves

abnormal

15. Speakers

16. light sensor

Sensor will make the display will adjust the brightness

automatically

17. Flash light

Connect to TV output via a HDMI cable

Connect to Flash drive, 3G dongle. ect

MIC, microphone for for recording invoice.

To insert your TF card

Hold and press to turn on or turn off the unit.

Briefly press to turn on or turn off the screen.

To connect your earphone

2M pixel Front camera

5M pixel rear camera.

Speakers

Flash while taking picture under dark condition

８

I. Getting Started

→

1.1 Turn on/off

1.1.1 Turn on

To start your tablet, press and hold the power key at the right side of

your tablet for a while. Tap and drag the lock out of the circle to

unlock.

Tap and drag the lock out of the circle to unlock.

Drag the lock to right: you will go to the home screen.

Drag the lock to left: you will go to camera directly.

1.1.2 Turn off

To power off your tablet, press and hold the power button until the

“Would you like to shut down?” dialog appears and tap “OK” to power

it off.

９

1.2 Lock/unlock the screen (sleep mode)

To save battery, you should put your tablet in sleep mode by turning

off the LCD display. To do this, shortly press the power key. Press it

again to wake up the screen.

1.3 Connect to computer

You can connect your tablet to your computer with the supplied USB

cable so you can transfer media files.

II. Your Home Screen

１０

a. Google search

Tap to enter Google search page

b. Voice search

c. ESC key

d. Home

e. Recent

operations

f. Volume -

g. Volume +

h. WIFI Signal

i. Battery

Tap to open voice search

Tap to return to the previous screen/ page.

Tap to return to your home page

Tap to show your recent operations

Tap to lower the volume

Tap to upper the volume

There will be WIFI signal when WIFI connected

Show battery status

status

Tap (All Apps launcher) on the upper right corner to enter into

all apps panel:

１１

2.1 Change wallpaper:

Tap the “Settings” icon on the all apps panel, you will see a pop-up

options; Enter into “Display” interface, you can choose wallpaper

from Gallery, live Wallpapers or Wallpapers.

2.2 Add/delete applications on home screen:

There are several apps in the home screen, you can also add more

frequently-used app icons in this home page and delete some less

frequently-used ones.

Tap the app launcher in the top right corner to go to all apps panel,

tap and move the app you want to the home screen.

１２

To delete an app from home screen, tap and hold it, and them movie

it to the remove icon

2.3 Add widgets to home screen:

Tap all Apps launcher→Tap WIDGETS. There are Analog clock,

bookmarks, calendar, Email, and lots of other widgets. Drag the

widget you want to the home screen.

Tips: Besides your home screen, you can access to other four panels by

sliding left or right in your home screen. You can also customize these

panels.

III. Network Connection

3.1 Wi-Fi

Wi-Fi can only be used when it connects with home Wi-Fi Access Point

(AP) or a free unsecured Wi-Fi hotpot. Under “Wireless & networks”,

tap “Wi-Fi” to turn it on. After a moment, your Wi-Fi networks list

should populate. If you need to rescan for available networks, tap

"scan"

3.1.1 Turn on Wi-Fi

Within the App Panel, tap “Settings”” → “Wi-Fi” to turn on wifi.
