PiPO M7 pro User Manual
User Manual
M7 pro
1
２
３
Contents
Welcome ........................................................................................................................................... ５
Important Notices ......................................................................................................................... ５
Keys and Functions....................................................................................................................... ６
I. Getting Started ........................................................................................................................... ７
1.1 Turn on/off ............................................................................................................................... ７
1.1.1 Turn on ................................................................................................................................... ７
1.1.2 Turn off ................................................................................................................................... ８
1.2 Lock/unlock the screen (sleep mode) .......................................................................... ８
1.3 Connect to computer........................................................................................................... ８
II. Your Home Screen ................................................................................................................... ９
2.1 Change wallpaper: ............................................................................................................ １０
2.2 Add/delete applications on home screen: ............................................................ １１
2.3 Add widgets to home screen: ..................................................................................... １１
III. Network Connection ........................................................................................................ １１
3.1 Wi-Fi ....................................................................................................................................... １１
3.1.1 Turn on Wi-Fi .................................................................................................................. １２
3.1.2 Turn off Wi-Fi .................................................................................................................. １２
3.1.3 Add a Wi-Fi network .................................................................................................... １２
3.2 Bluetooth .............................................................................................................................. １３
3.2.1 Make device discoverable ......................................................................................... １３
3.2.2 Scan for devices ............................................................................................................. １３
3.2.3 Pair with the Bluetooth device ................................................................................ １３
４
3.3 3G Network ......................................................................................................................... １４
3.3.1 External 3G Network .................................................................................................... １４
3.3.2 Internal 3G support (optional) ................................................................................ １４
IV. Internet Browsing .............................................................................................................. １５
4.1 Internet Browsing ............................................................................................................. １５
V. Install and Manage Apps................................................................................................. １６
5.1 Install Apps .......................................................................................................................... １６
5.2 Manage Apps ..................................................................................................................... １６
VI. Multi-media Functions .................................................................................................... １７
6.1 Music ...................................................................................................................................... １７
6.2 Video ...................................................................................................................................... １８
6.2.1 HDMI output ................................................................................................................... １９
6.3 Gallery .................................................................................................................................... ２０
6.4 Camera .................................................................................................................................. ２０
6.5 E-book reader..................................................................................................................... ２１
6.6 Sign function....................................................................................................................... ２２
VII. Settings ................................................................................................................................. ２３
VIII. Battery .................................................................................................................................. ２９
IX .Firmware Upgrading Procedures ................................................................................ ３０
Troubleshooting ....................................................................................................................... ３６
５
Welcome
Thank you for purchasing this tablet.
It brings you much convenience for your business (supports Word, Excel, send
& receive e-mails...) and entertainment (supports 3D game, chatting, movie
playback, eBooks.....).
Running on Android 4.2, with a 1.6GHz processor and highly responsive
capacitive touch screen, it brings you wonderful user experience.
Before beginning, please refer to this user manual carefully.
Important Notices
⊙ While using the earphone, if the volume is excessively high it may cause
hearing damage. So please adjust the volume of the player to a moderate
level and balance the time of using.
⊙ Do not disconnect the tablet suddenly when formatting or uploading and
downloading, which can lead to program errors.
⊙ Do not dismantle the tablet by yourself, and do not use alcohol, thinner or
benzene to clean its surface.
⊙ The tablet dose not support USB charge. If you want to charge the tablet,
please use the AC adaptor supplied. Please use the original accessories.
６
⊙ Read this User Manual carefully, Make sure you know how to upgrade the
1. SIM card slot
To insert your SIM card (Data only, only 3G version is
with this card slot)
2. TF card slot
To insert your card
3. Earphone jack
To connect your earphone
tablet, other wise do not upgrade it by yourself.
Keys and Functions
７
4. HOST port
USB OTG, supports mouse, keyboard, USB flash disk,
etc, with a converting cable
5. USB port
Connect to a computer to transfer data
(e.g., music, videos, photos, files).
6. HDMI
Connect to TV output via a HDMI cable
7. MIC
Microphone for recording voice
8. Power jack
(DC input)
Connect to a 5V 2.5Aoutput adaptor as included in the
accessories
9. ESC Key
Tap to return to the previous screen/ page.
10. Front Camera
2M pixels camera
11. Light Sensor
Improve your photo quality
12. Rear Camera
5M pixels auto focus
13. Reset hole
Press to reset the tablet if it freezes or behaves
abnormal
13. Speaker
AAC speaker
14. Speaker
AAC speaker
I. Getting Started
1.1 Turn on/off
1.1.1 Turn on
To start your tablet, press and hold the power key at the right side of your
tablet for a while. Tap and drag the lock out of the circle to unlock.
８
→
Tap and drag the lock out of the circle to unlock.
Drag the lock to right: you will go to the home screen.
Drag the lock to left: you will go to camera directly.
1.1.2 Turn off
To power off your tablet, press and hold the power button until the ―Would
you like to shut down?‖ dialog appears and tap ―OK‖ to power it off.
1.2 Lock/unlock the screen (sleep mode)
To save battery, you should put your tablet in sleep mode by turning off the
LCD display. To do this, shortly press the power key. Press it again to wake up
the screen.
1.3 Connect to computer
You can connect your tablet to your computer with the supplied USB cable so
you can transfer media files.
９
If your computer is XP system, please install a Windows Media Player 11 for
a. Google search
Tap to enter Google search page
b. Voice search
Tap to open voice search
c. ESC key
Tap to return to the previous screen/ page.
d. Home
Tap to return to your home page
e. Recent
Tap to show your recent operations
your computer before transfer media files as android 4.2 system needs
Windows Media Player 11 support.
II. Your Home Screen
１０
operations
f. Volume -
Tap to lower the volume
g. Volume +
Tap to upper the volume
h. WIFI Signal
There will be WIFI signal when WIFI connected
i. Battery status
Show battery status
Tap (All Apps launcher) on the upper right corner to enter into all apps
panel:
2.1 Change wallpaper:
Tap the ―Settings‖ icon on the all apps panel, you will see a pop-up options;
Enter into ―Display‖ interface, you can choose wallpaper from Gallery, live
Wallpapers or Wallpapers.
１１
2.2 Add/delete applications on home screen:
There are several apps in the home screen, you can also add more
frequently-used app icons in this home page and delete some less
frequently-used ones.
Tap the app launcher in the top right corner to go to all apps panel, tap and
move the app you want to the home screen.
To delete an app from home screen, tap and hold it, and them movie it to the
remove icon
2.3 Add widgets to home screen:
Tap all Apps launcher→Tap WIDGETS. There are Analog clock, bookmarks,
calendar, Email, and lots of other widgets. Drag the widget you want to the
home screen.
Tips: Besides your home screen, you can access to other four panels by sliding
left or right in your home screen. You can also customize these panels.
III. Network Connection
3.1 Wi-Fi
Wi-Fi can only be used when it connects with home Wi-Fi Access Point (AP) or
a free unsecured Wi-Fi hotpot. Under ―Wireless & networks‖, tap ―Wi-Fi‖ to
１２
turn it on. After a moment, your Wi-Fi networks list should populate. If you
need to rescan for available networks, tap "scan"
3.1.1 Turn on Wi-Fi
Within the App Panel, tap ―Settings‖‖ → ―Wi-Fi‖ to turn on wifi.
Your tablet lists the networks it finds within range. Tap a network to connect.
If necessary, enter Network SSID, Security, and Wireless password, and tap
―Connect‖. When your tablet is connected to the network, the wireless
indicator appears in the status bar. Waves indicate connection strength.
3.1.2 Turn off Wi-Fi
Please turn off Wi-Fi if you‘re not using it to save the battery. To turn off Wi-Fi,
Tap it again.
3.1.3 Add a Wi-Fi network
Users may also add a Wi-Fi network under ― settings‖. In ―settings‖, tap ― ‖
on the upper right corner. Enter the SSID (name) of the network. If necessary,
enter security or other network configuration details. Touch Save.
Note: Network status icons turn yellow if you have a Google Account
added to your tablet and the tablet is connected to Google services, for
